Lathe – turning machine
- 1. UNIT - 2 Lathe – The turning Machine
- 2. 1. Block diagram of a Lathe 2. Main parts of a Lathe 3. Turning parameters 4. Lathe specifications
- 3. Lathe – Turning Machine Turning: “It is defined as a manufacturing process where material is removed from a rotating work piece with the help of a tool which moves linearly”.
- 4. Lathe – Turning Machine PICTORIAL VIEW OF A LATHE
- 6. Lathe – Turning Machine PICTORIAL VIEW OF A LATHE (with various parts marked)
- 8. Lathe – Turning Machine BLOCK DIAGRAM OF A LATHE
- 9. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage Live Center Dead Center
- 10. Lathe – Turning Machine LATHE BED
- 11. Lathe – Turning Machine LATHE BED Guide ways
- 12. Lathe – Turning Machine LATHE BED Head Stock Guide ways
- 13. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock
- 14. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Live Center
- 15. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Live Center Lathe Axis
- 16. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Live Center Dead Center
- 17. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Carriage Live Center Dead Center
- 18. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage Live Center Dead Center
- 19. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage Live Center Dead Center
- 20. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage Live Center Dead Center
- 21. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage Live Center Dead Center
- 23. Main Parts of a LATHE Lathe – Turning Machine
- 24. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage Live Center Dead Center
- 25. Main Parts of a LATHE 1. Lathe Bed & Guide ways 2. Head Stock 3. Tail Stock 4. Carriage & Tool Post 5. Feed Mechanism 6. Thread Cutting Mechanism Lathe – Turning Machine
- 27. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage Live Center Dead Center
- 28. Lathe – Turning Machine LATHE BED Guide ways
- 29. Lathe Bed & Guide Ways
- 30. Lathe – Turning Machine LATHE BED Head Stock Guide ways
- 31. Head Stock
- 32. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock
- 33. Tail Stock
- 34. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage
- 35. Carriage & Tool post
- 36. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Tool Post Carriage Live Center Dead Center
- 37. Main Parts of a LATHE 1. Lathe Bed & Guide ways 2. Head Stock 3. Tail Stock 4. Carriage & Tool Post 5. Feed Mechanism 6. Thread Cutting Mechanism Lathe – Turning Machine
- 39. Turning Parameters Lathe – Turning Machine
- 40. Turning Parameters 1. Speed 2. Feed 3. Depth of Cut Lathe – Turning Machine
- 41. Lathe – Turning Machine Lathe Spindle Lathe Tool
- 42. Lathe – Turning Machine Lathe Spindle Lathe Tool
- 43. Lathe – Turning Machine Lathe Spindle Lathe Tool
- 44. Lathe – Turning Machine Lathe Tool
- 45. Lathe – Turning Machine Lathe Spindle Lathe Tool
- 46. Lathe – Turning Machine Lathe Spindle Lathe Tool
- 47. Lathe – Turning Machine Lathe Spindle Lathe Tool
- 48. Lathe – Turning Machine Lathe Spindle Lathe Tool
- 49. Turning Parameters 1. Speed 2. Feed 3. Depth of Cut Lathe – Turning Machine Longitudinal Feed Cross Feed
- 50. Lathe – Turning Machine Turning Parameters: LATHE Head Stock Spindle Lathe Tool Speed Feed Depth of Cut TOP VIEW Lathe Axis
- 52. Lathe Specifications Main Specifications of a LATHE
- 53. 1. Height of the centers 2. Swing diameter over the bed 3. Swing over the carriage 4. Length between the centers 5. Maximum bar diameter Lathe Specifications Main Specifications of a LATHE
- 54. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Carriage Length b/n centers Tool Post
- 55. 1. Length between the centers “It is the measure of the maximum length of the work piece that can be fixed between the lathe centers”. Lathe Specifications Main Specifications of a LATHE
- 56. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Carriage Height of the centers Tool Post
- 57. 2. Height of the centers “It is the distance between the lathe axis and the lathe bed”. Lathe Specifications Main Specifications of a LATHE
- 58. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Carriage Swing diameter over the bed Tool Post
- 59. 3. Swing diameter over the bed “It is the maximum diameter of the work piece that can be turned on a lathe without hitting the lathe bed”. Lathe Specifications Main Specifications of a LATHE
- 60. Lathe – Turning Machine LATHE BED Head Stock Guide ways Tail Stock Carriage Swing diameter over the carriage Tool Post
- 61. 4. Swing diameter over the carriage “It is the maximum diameter of the work piece that can be turned on a lathe without hitting the carriage”. Lathe Specifications Main Specifications of a LATHE
- 62. 5. Maximum bar diameter “It is the maximum diameter of the work piece that can be passed through the hole in the head stock”. Lathe Specifications Main Specifications of a LATHE
- 63. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post
- 64. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post Work piece passing through the hole of the HEAD STOCK
- 65. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post Work piece passing through the hole of the HEAD STOCK
- 66. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post Work piece passing through the hole of the HEAD STOCK
- 67. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post Work piece passing through the hole of the HEAD STOCK
- 68. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post Work piece passing through the hole of the HEAD STOCK
- 69. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post Work piece passing through the hole of the HEAD STOCK
- 70. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post Work piece passing through the hole of the HEAD STOCK
- 71. Lathe – Turning Machine LATHE BED Guide ways Tail Stock Carriage Head Stock Tool Post Maximum diameter of the Work piece that can be passed through the hole of the HEAD STOCK
- 72. 1. Block diagram of a Lathe 2. Main parts of a Lathe 3. Turning parameters 4. Lathe specifications
