Lecture 11 (Digital Image Processing)
•
0 likes•83 views
This document discusses modifications to B-spline interpolation formulations. It begins by describing B-splines and their use in interpolation. It notes that constant, linear, quadratic, and cubic interpolation correspond to B-spline orders of 1, 2, 3, and 4, respectively. It then presents a modified relation where a shifted B-spline is used, with the shift determined by the interpolation order. For example, with linear interpolation the shift is 1. Graphs demonstrate how this modified relation gives nearer points higher weight. The document concludes by discussing constant interpolation in 2D images.
