This document compares different architectures for delay line based time-to-digital converters (TDCs) that can be implemented using field programmable gate arrays (FPGAs). It discusses several TDC architectures including single delay line, array of delay lines, tapped delay line, vernier delay line, gated ring oscillator delay line, pulse shrinking delay line, and vernier ring oscillator delay line. It analyzes the resolution, advantages, and disadvantages of each approach. The goal is to study architectures that can measure smaller time intervals with less clock frequency requirements to improve measurement performance.
