Codes
1.
2.
3.
4. Digital system codes are
› BCD code
› Excess-3 code
› EBCDIC code
› Error detection code
› UNI CODE
› ASCII code
› Extended ASCII code
› Gray code
5. It should have some desirable properties
Ease of coding
To increase efficiency of transmission
Ease in arithmetic operations
Minimum use of hardware
Error detection property
Ability to prevent wrong output during
transitions
6. BCD – Binary Coded Decimal
BCD is a convention for mapping binary
numbers to decimal numbers & for Decimal
to binary numbers.
When the decimal numbers are represented
in BCD, each decimal digit is represented by
the equivalent BCD code.
Example :BCD Representation of Decimal
6349
6 3 4 9
0110 0011 0100 1001
6
7. 0-9 decimal digits need to be
represented in a binary code which must
contain at least four bits.
› Four bits can make upto 16 different
combinations.
› Only first 10 combinations are used. (0-9)
BCD is different from binary representation.
› 15 in binary is 1111
8. Note: the Digit Bit pattern
following bit 0 0000
patterns are not 1 0001
used: 2 0010
3 0011
1010 4 0100
1011 5 0101
1100 6 0110
1101 7 0111
1110 8 1000
1111 9 1001
12. Extended BCD Interchange Code
8-bit code
It contains the numbers from 0 to 28-1
Developed by IBM
Rarely used today
IBM mainframes only
13. We need a mechanism of correcting the
errors that occur
It is not always possible or may prove to be
expensive
It is necessary to know if an error occurred
If an occurrence of error is known, data
may be retransmitted
Data integrity is improved by encoding
Encoding may be done for error correction.
14. Error detection code detect errors during
transmission of data from one location to
another.
Error rate cannot be reduced to zero
To achieve error-detection we use a
parity bit.
15. A parity bit is an extra bit included with a
message to the total number of 1’s
transmitted either odd or even.
Parity bit allows us only to detect the
presence of one bit error in a group of bits.
It does not enable us to exactly locate the
bit that changed.
Parity bit scheme can be extended to
locate the faulty bit In a block of
information.
16.
17. Odd parity bit generator can be formed
by inverting the output of the Even parity
bit generator.
18.
19.
20. Gray coding is an important code and is
used for its speed, it is also relatively free
from errors.
Gray coding avoids this since only one bit
changes between subsequent numbers.
In pure binary coding then counting from 7
(0111) to 8 (1000) requires 4 bits to be
changed simultaneously.
Gray code is used to represent the digital data
when it is converted from analog data.
22. Scan the Gray code word from left to right
All the bits of the binary code are the same
as those of the Gray code until the first 1 is
encountered, including the first 1
1’s are written until the next 1 is
encountered, in which case a 0 is written.
0’s are written until the next 1 is
encountered, in which case a 1 is written.
Examples
Gray code : 1 1 0 1 1 0
Binary code: 1 0 0 1 0 0
23. UNICODE is a 16-bit code for
representing alphanumeric data.
Developed by a consortia(An association or a
combination, as of businesses, financial institutions, or investors, for
the purpose of engaging in a joint venture.)
With 16 bits, can represent 216 or 65536
different symbols.
16 bits = 2 Bytes per character.
UNICODE used by Web browsers and
Java these days.
24. ASCII Code
• The standard binary code for representation of
alphanumeric characters is ASCII
•ASCII (American Standard for Information
Interchange)
•It hands not only numbers but letters and
special characters
• Uses 7 bits to code 128 characters
•In ASCII, every letter, number, and
punctuation symbol has a corresponding
number, or ASCII code 24
25. This code is a popular code used to
represent information sent as character-
based data. It uses 7-bits to represent:
› 94 Graphic printing characters.
› 34 Non-printing characters
Some non-printing characters are used for
text format (e.g. BS = Backspace, CR =
carriage return)
Other non-printing characters are used for
record marking and flow control (e.g. STX
and ETX start and end text areas).
26. 95 Graphic codes
000 001 010 011 100 101 110 111
0000 NULL DLE 0 @ P ` p
0001 SOH DC1 ! 1 A Q a q
0010 STX DC2 " 2 B R b r
0011 ETX DC3 # 3 C S c s
0100 EDT DC4 $ 4 D T d t
0101 ENQ NAK % 5 E U e u
0110 ACK SYN & 6 F V f v
0111 BEL ETB ' 7 G W g w
1000 BS CAN ( 8 H X h x
1001 HT EM ) 9 I Y i y
1010 LF SUB * : J Z j z
1011 VT ESC + ; K [ k {
1100 FF FS , < L l |
1101 CR GS - = M ] m }
1110 SO RS . > N ^ n ~
1111 SI US / ? O _ o DEL
27. 33 Control codes
000 001 010 011 100 101 110 111
0000 NULL DLE 0 @ P ` p
0001 SOH DC1 ! 1 A Q a q
0010 STX DC2 " 2 B R b r
0011 ETX DC3 # 3 C S c s
0100 EDT DC4 $ 4 D T d t
0101 ENQ NAK % 5 E U e u
0110 ACK SYN & 6 F V f v
0111 BEL ETB ' 7 G W g w
1000 BS CAN ( 8 H X h x
1001 HT EM ) 9 I Y i y
1010 LF SUB * : J Z j z
1011 VT ESC + ; K [ k {
1100 FF FS , < L l |
1101 CR GS - = M ] m }
1110 SO RS . > N ^ n ~
1111 SI US / ? O _ o DEL
28. Alphabetic codes
000 001 010 011 100 101 110 111
0000 NULL DLE 0 @ P ` p
0001 SOH DC1 ! 1 A Q a q
0010 STX DC2 " 2 B R b r
0011 ETX DC3 # 3 C S c s
0100 EDT DC4 $ 4 D T d t
0101 ENQ NAK % 5 E U e u
0110 ACK SYN & 6 F V f v
0111 BEL ETB ' 7 G W g w
1000 BS CAN ( 8 H X h x
1001 HT EM ) 9 I Y i y
1010 LF SUB * : J Z j z
1011 VT ESC + ; K [ k {
1100 FF FS , < L l |
1101 CR GS - = M ] m }
1110 SO RS . > N ^ n ~
1111 SI US / ? O _ o DEL
29. Numeric codes
000 001 010 011 100 101 110 111
0000 NULL DLE 0 @ P ` p
0001 SOH DC1 ! 1 A Q a q
0010 STX DC2 " 2 B R b r
0011 ETX DC3 # 3 C S c s
0100 EDT DC4 $ 4 D T d t
0101 ENQ NAK % 5 E U e u
0110 ACK SYN & 6 F V f v
0111 BEL ETB ' 7 G W g w
1000 BS CAN ( 8 H X h x
1001 HT EM ) 9 I Y i y
1010 LF SUB * : J Z j z
1011 VT ESC + ; K [ k {
1100 FF FS , < L l |
1101 CR GS - = M ] m }
1110 SO RS . > N ^ n ~
1111 SI US / ? O _ o DEL
30. Punctuation, etc.
000 001 010 011 100 101 110 111
0000 NULL DLE 0 @ P ` p
0001 SOH DC1 ! 1 A Q a q
0010 STX DC2 " 2 B R b r
0011 ETX DC3 # 3 C S c s
0100 EDT DC4 $ 4 D T d t
0101 ENQ NAK % 5 E U e u
0110 ACK SYN & 6 F V f v
0111 BEL ETB ' 7 G W g w
1000 BS CAN ( 8 H X h x
1001 HT EM ) 9 I Y i y
1010 LF SUB * : J Z j z
1011 VT ESC + ; K [ k {
1100 FF FS , < L l |
1101 CR GS - = M ] m }
1110 SO RS . > N ^ n ~
1111 SI US / ? O _ o DEL
31. Let us convert You & I, to decimal, hex and
binary using the ASCII code table :
› Y: 8910 5916 10110012
› o: 11110 6F16 11011112
› u: 11710 7516 11101012
› Space: 3210 2016 01000002
› &: 3810 2616 01001102
› Space: 3210 2016 01000002
› I: 7310 4916 10010012
› ,: 4410 2C16 01011002
32. The term extended ASCII (or high ASCII)
describes eight-bit or larger character
encodings that include the standard
seven-bit ASCII characters as well as
others.
