This document provides an overview of 12-lead electrocardiogram (ECG) interpretation for myocardial infarction (MI). Key points covered include: the phases of the cardiac action potential; principles of Einthoven's triangle and augmented lead interpretation; proper 12-lead placement; identifying ST segment elevation/depression; differentiating STEMI from NSTEMI; reciprocal changes; locations of artery involvement based on lead findings; and treatment considerations for STEMI. Common STEMI mimics and the importance of differentiating MI from conditions like left ventricular hypertrophy are also discussed.
The document provides an overview of electrocardiography (ECG) interpretation. It discusses the heart's electrical conduction system and action potential, as well as the basics of reading an ECG including assessing rhythm, rate, axis, P waves, QRS complex, ST segment, and T waves. It outlines common abnormalities and provides examples of ECG interpretations for case scenarios involving myocardial infarction, left ventricular hypertrophy, sinus arrhythmia, and atrial fibrillation. The goal is to teach readers how to systematically evaluate an ECG tracing and identify potential cardiac issues.
- An ECG records the electrical activity of the heart over time using electrodes placed on the skin. It detects tiny electrical changes arising from the heart muscle contracting during each heartbeat.
- The cardiac impulse originates in the sinoatrial node and travels through the atria and ventricles via specialized conduction pathways before the ventricles contract.
- A standard 12-lead ECG provides multiple views of the heart to analyze the rate and rhythm of the heart as well as measure key intervals like the PR interval, QRS duration, and QT interval to identify any abnormalities.
The document provides an overview of electrocardiography (ECG), describing what a 12-lead ECG is and why it is performed. It explains ECG components like the P wave, QRS complex, and T wave, and how they relate to electrical conduction through the heart. Common arrhythmias, blocks, abnormalities and their ECG presentations are outlined to aid in ECG interpretation.
The document provides information about ECG basics and how to interpret an ECG. It discusses the placement of limb and chest leads and the standard positions on the ECG paper. It describes the normal P wave, PR interval, QRS complex, and identifies some abnormal findings. It discusses criteria for identifying left ventricular hypertrophy and right ventricular hypertrophy. The overall aim is to help understand how to read an ECG and identify normal and abnormal findings.
This document discusses abnormalities of the T wave seen on electrocardiograms. It describes normal T waves, inverted T waves, and tall T waves. Normal T waves are upright in most leads and taller in certain precordial leads. Inverted T waves can be caused by ischemia, infarction, ventricular hypertrophy, bundle branch blocks, and other conditions. Tall T waves are considered abnormal if they exceed certain voltage thresholds and can be caused by hyperkalemia or ischemia. The document also lists which coronary arteries supply certain leads to help localize ischemia.
This document provides an overview of ECG interpretation including:
- The anatomy of the heart's conduction system and how ECG leads are attached
- How to read an ECG strip and calculate heart rate
- Normal P, QRS, and T waves along with intervals like PR and QT
- Abnormalities that can indicate conditions like blocks, arrhythmias, and hypertrophy
- Electrolyte imbalances that can affect the ECG tracing
It concludes with examples of ECG strips and questions to test the reader's understanding.
1. The document discusses ECG patterns in acute myocardial infarction, describing ST segment elevations, depressions, and T wave changes associated with occlusions of the left anterior descending, left circumflex, and right coronary arteries.
2. Mechanisms of ECG changes during acute MI including systolic and diastolic currents of injury are explained.
3. Criteria for diagnosing acute MI based on ECG findings are provided.
1) The QRS axis during ventricular tachycardia (VT) depends on the site of origin of the arrhythmia within the ventricles.
2) A change in axis of more than 40 degrees left or right from the normal range of -30 to 90 degrees is suggestive of VT.
3) The axis can help identify the site of origin, with apical VT showing a left axis and basal VT showing a right axis.
The document provides an overview of electrocardiography (ECG) interpretation. It discusses the heart's electrical conduction system and action potential, as well as the basics of reading an ECG including assessing rhythm, rate, axis, P waves, QRS complex, ST segment, and T waves. It outlines common abnormalities and provides examples of ECG interpretations for case scenarios involving myocardial infarction, left ventricular hypertrophy, sinus arrhythmia, and atrial fibrillation. The goal is to teach readers how to systematically evaluate an ECG tracing and identify potential cardiac issues.
- An ECG records the electrical activity of the heart over time using electrodes placed on the skin. It detects tiny electrical changes arising from the heart muscle contracting during each heartbeat.
- The cardiac impulse originates in the sinoatrial node and travels through the atria and ventricles via specialized conduction pathways before the ventricles contract.
- A standard 12-lead ECG provides multiple views of the heart to analyze the rate and rhythm of the heart as well as measure key intervals like the PR interval, QRS duration, and QT interval to identify any abnormalities.
The document provides an overview of electrocardiography (ECG), describing what a 12-lead ECG is and why it is performed. It explains ECG components like the P wave, QRS complex, and T wave, and how they relate to electrical conduction through the heart. Common arrhythmias, blocks, abnormalities and their ECG presentations are outlined to aid in ECG interpretation.
The document provides information about ECG basics and how to interpret an ECG. It discusses the placement of limb and chest leads and the standard positions on the ECG paper. It describes the normal P wave, PR interval, QRS complex, and identifies some abnormal findings. It discusses criteria for identifying left ventricular hypertrophy and right ventricular hypertrophy. The overall aim is to help understand how to read an ECG and identify normal and abnormal findings.
This document discusses abnormalities of the T wave seen on electrocardiograms. It describes normal T waves, inverted T waves, and tall T waves. Normal T waves are upright in most leads and taller in certain precordial leads. Inverted T waves can be caused by ischemia, infarction, ventricular hypertrophy, bundle branch blocks, and other conditions. Tall T waves are considered abnormal if they exceed certain voltage thresholds and can be caused by hyperkalemia or ischemia. The document also lists which coronary arteries supply certain leads to help localize ischemia.
This document provides an overview of ECG interpretation including:
- The anatomy of the heart's conduction system and how ECG leads are attached
- How to read an ECG strip and calculate heart rate
- Normal P, QRS, and T waves along with intervals like PR and QT
- Abnormalities that can indicate conditions like blocks, arrhythmias, and hypertrophy
- Electrolyte imbalances that can affect the ECG tracing
It concludes with examples of ECG strips and questions to test the reader's understanding.
1. The document discusses ECG patterns in acute myocardial infarction, describing ST segment elevations, depressions, and T wave changes associated with occlusions of the left anterior descending, left circumflex, and right coronary arteries.
2. Mechanisms of ECG changes during acute MI including systolic and diastolic currents of injury are explained.
3. Criteria for diagnosing acute MI based on ECG findings are provided.
1) The QRS axis during ventricular tachycardia (VT) depends on the site of origin of the arrhythmia within the ventricles.
2) A change in axis of more than 40 degrees left or right from the normal range of -30 to 90 degrees is suggestive of VT.
3) The axis can help identify the site of origin, with apical VT showing a left axis and basal VT showing a right axis.
The document provides an outline for a lecture on basic electrocardiograms (ECGs). It discusses the history of ECGs, outlines the standardization of ECGs, and explains the reasons for performing ECGs. It also describes the 12-lead ECG system and proper electrode placement. Key aspects of ECG waves and rhythms are defined. Ten assessment points for ECGs are identified. Finally, the document categorizes cardiac rhythms according to the required intervention hierarchy.
This document discusses the echocardiographic assessment of diastolic dysfunction. It outlines key parameters used to evaluate diastolic function including mitral inflow patterns, tissue Doppler imaging of mitral annular velocities, and pulmonary venous flow. Normal values for these parameters are provided. Guidelines for grading diastolic dysfunction according to the 2016 ASE/EACVI guidelines are presented. Special considerations for evaluating diastolic function in conditions like HCM, mitral stenosis, mitral regurgitation, and atrial fibrillation are also reviewed. Novel indices using speckle tracking echocardiography to assess diastolic function are mentioned.
- LVH is characterized by tall QRS complexes on ECG due to increased electrical forces moving through the thickened myocardium.
- Criteria exists to diagnose LVH using a 12-lead ECG, such as the R wave in V5 or V6 plus the S wave in V1 or V2 exceeding 35 mm.
- The document compares a normal ECG to one with LVH and explains how echocardiogram can also detect LVH by showing increased ventricular wall thickness.
This document provides an overview of electrocardiogram (ECG) interpretation. It begins by outlining the learning objectives, which are to recognize normal sinus rhythm, common rhythm disturbances on a 3-lead ECG, and how to interpret a myocardial infarction on a 12-lead ECG. The document then reviews ECG basics, how to analyze rhythms, defines normal sinus rhythm, and discusses common cardiac dysrhythmias and how to diagnose a myocardial infarction. It provides examples of various normal and abnormal rhythms.
A great tutorial from Dr Alistair Jones NHS medical educator (http://www.yorkshiremedicaleducation.co.uk/about-us) on ECG syndromes. Beyond the basics (but essential knowledge for training emergency physicians)
This document discusses myocardial infarction (MI) and myocardial ischemia. It begins by defining MIs that result from total coronary occlusion (Q-wave MI) versus subtotal occlusion (non-Q-wave MI). It then describes the blood supply territories of the main coronary arteries and shows examples of ECG patterns for different types of MIs, including anterior, inferior, and lateral MIs. It also discusses non-ST elevation acute coronary syndrome (NSTEACS), describing the ECG patterns of ST depression and T-wave changes seen in myocardial ischemia, including Wellens' syndrome. Throughout, it localizes arterial territories and compares ECG findings to understand the likely location and extent of ischemia/infarction.
This document provides an overview of ECG basics, including the cardiac conduction system, components of the cardiac cycle, a systematic approach to rhythm interpretation, and descriptions of common arrhythmias. It discusses the normal P-QRS-T waveform, conduction velocities, factors used to analyze rhythms like regularity and rate, and examples of arrhythmias including sinus arrhythmia, sinus block, WAP, MAT, A-fib, flutter, blocks, and SVTs. It also reviews lead placement, electrical axis, vector concepts, and a systematic approach to 12-lead ECG interpretation.
The 12-lead ECG provides views of the heart from both a horizontal and vertical plane using 12 different leads. The leads are divided into limb leads, which measure electrical activity from the arms and legs, and precordial or chest leads, which measure activity from the chest. Each lead is generated using a positive and negative electrode in different positions to capture the heart's electrical activity from different angles.
The 12-lead ECG is a diagnostic test that helps identify conditions like acute coronary syndrome and myocardial infarction. Obtaining a 12-lead ECG in the field is important to identify ST elevations that could indicate a heart attack and speed up treatment times. The placement of the ECG leads and the patterns in the complexes can provide clues to determine the type and location of any heart issues. It is important for paramedics to become proficient in performing and interpreting 12-lead ECGs to help ensure the best outcomes for patients experiencing potential cardiac events.
The document provides an overview of electrocardiography (ECG), including its history, importance, physiology, leads, waves, intervals, and abnormalities. Key points covered include the names and functions of the P, QRS, and T waves, as well as common abnormalities like ST segment elevation/depression, T wave inversion, and arrhythmias. The summary analyzes ECGs to recognize conditions like myocardial infarction and ventricular hypertrophy.
This document provides an overview of EKG interpretation. It discusses the normal conduction system, EKG leads, waveforms and intervals. It covers determining heart rate, axis, and common rhythms such as sinus, atrial, junctional and ventricular. It also summarizes chamber enlargements, bundle branch blocks, ischemia, infarction patterns and other EKG abnormalities. The goal is to equip the reader with the basics needed for a systematic approach to EKG interpretation.
This document discusses ST-elevation myocardial infarction (STEMI) equivalents that can be identified on electrocardiograms (ECGs). It describes atypical ECG patterns including ST depression or T-wave changes in leads indicating posterior or lateral wall ischemia. Other STEMI equivalents include isolated ST depression in lead AVL, hyperacute T-waves, Wellens' syndrome, ST elevation in lead AVR, and presumed new left bundle branch block with Sgarbossa criteria. The document stresses the importance of recognizing these STEMI-equivalent patterns to identify patients who could benefit from primary percutaneous coronary intervention.
This document provides an overview of electrocardiography (ECG) basics including:
1. It describes what an ECG is and what conditions it can be useful for diagnosing.
2. It outlines the different ECG leads including the standard and precordial leads used to measure electrical activity from different angles.
3. It explains the typical ECG waveforms including the P, QRS, T, and U waves as well as intervals like the PR and QT, and how to interpret abnormalities.
4. It provides guidance on interpreting an ECG including assessing lead position, rhythm, rate, axis, and looking for signs of conditions like bundle branch blocks or chamber enlargement.
The document discusses electrocardiogram (ECG) patterns associated with cardiac chamber enlargement, specifically right atrial enlargement (RAE) and left atrial enlargement (LAE). RAE is suggested by a tall, peaked P wave in leads II, III, AVF and a positive P wave in V1. LAE results in prolongation of the left atrial component of the P wave, increased posterior deviation of the left atrial vector, and left axis deviation of the P wave. The diagnostic accuracy of ECG findings for chamber enlargement is limited but can provide clues when correlated with imaging studies.
This document provides a history of the electrocardiogram (EKG/ECG) and describes how it is used to evaluate cardiac electrical activity and identify various cardiac conditions. Some key points:
- The EKG was developed in the late 19th/early 20th century, with scientists like Matteucci, Marey, and Einthoven contributing to its invention and clinical use.
- An EKG records the heart's electrical activity through electrodes on the skin and can be used to detect arrhythmias, ischemia, infarction, and other conditions.
- It analyzes the P wave, QRS complex, ST segment, and T wave to evaluate conduction and identify abnormalities.
The document provides an overview of echocardiography techniques for assessing various adult heart diseases. It discusses how to evaluate left and right ventricular function, aortic and mitral valve diseases, pericardial diseases, and cardiomyopathies. Evaluation of ventricular size and function involves 2D and Doppler echocardiography to measure dimensions, estimate ejection fraction, and calculate indices like fractional shortening. Valvular lesions are assessed using 2D to visualize anatomy and Doppler to measure velocities and gradients. Right heart function and pressures are evaluated using measurements of the IVC, RV size, TAPSE, and TR jet velocity.
Approach to Wide complex tachycardia /cardiology Cardiology
1) Wide complex tachycardia can be caused by ventricular tachycardia, supraventricular tachycardia with abnormal conduction, or ventricular pacing. The document discusses approaches to distinguishing these based on history, examination, and electrocardiogram findings.
2) Ventricular tachycardia is characterized by a wide QRS complex greater than or equal to 120ms and can be monomorphic, polymorphic, or bidirectional. Features on electrocardiogram can provide clues about site of origin in the ventricles.
3) Sustained ventricular tachycardia can cause hemodynamic instability while non-sustained ventricular tachycardia typically does not. Distinguishing ventricular
- Left bundle branch block (LBBB) is caused by conditions that damage the left bundle branch, such as hypertension, dilated cardiomyopathy, and ischemic heart disease.
- LBBB is diagnosed based on criteria including a QRS duration of over 120ms and abnormal ST segment and T wave patterns.
- The prognosis of LBBB depends on any underlying heart conditions, with LBBB increasing the risk of mortality. LBBB may resolve temporarily following a premature ventricular contraction due to resetting of the conduction system.
This document provides guidance on electrocardiogram (ECG) interpretation for primary care physicians. It outlines the 6 key steps to analyze an ECG: rate, rhythm, axis, intervals, hypertrophy, and infarction/ischemia. Specific abnormalities that may indicate conditions like sinus tachycardia, atrial fibrillation, left ventricular hypertrophy, myocardial infarction, and heart block are described. Diagnosis of cardiac issues is aided by identifying changes in various leads that correspond to specific areas of the heart.
This document discusses the echocardiographic assessment of aortic valve stenosis. It begins by describing the normal aortic valve anatomy. It then discusses various 2D and Doppler echocardiographic views used to evaluate the aortic valve. The main causes of aortic stenosis and their anatomical presentations are described. The key Doppler parameters used to assess stenosis severity are peak aortic jet velocity, mean pressure gradient, and aortic valve area calculated using the continuity equation. Stress echocardiography with dobutamine is discussed for assessing patients with low-flow, low-gradient aortic stenosis. The limitations of echocardiography in evaluating aortic stenosis are also reviewed.
The document discusses cardiovascular emergencies like chest pain and acute coronary syndrome, outlining their epidemiology, pathophysiology, assessment, and management for EMTs. It covers topics like atherosclerosis, angina, myocardial infarction, and provides a case study example to demonstrate assessment and treatment of a patient experiencing chest pain. The goal is to educate EMTs on properly evaluating and stabilizing patients experiencing potential cardiac events before transporting them to the hospital for further care.
(1) The ECG shows normal sinus rhythm with a heart rate of 75 beats per minute and a slightly prolonged QT interval.
(2) There are abnormal Q waves in leads II, III, and aVF along with ST segment elevations and T wave inversions, consistent with an inferolateral myocardial infarction.
(3) The findings also include an early precordial transition with a relatively tall R wave in lead V2, which could reflect posterior wall involvement.
The document provides an outline for a lecture on basic electrocardiograms (ECGs). It discusses the history of ECGs, outlines the standardization of ECGs, and explains the reasons for performing ECGs. It also describes the 12-lead ECG system and proper electrode placement. Key aspects of ECG waves and rhythms are defined. Ten assessment points for ECGs are identified. Finally, the document categorizes cardiac rhythms according to the required intervention hierarchy.
This document discusses the echocardiographic assessment of diastolic dysfunction. It outlines key parameters used to evaluate diastolic function including mitral inflow patterns, tissue Doppler imaging of mitral annular velocities, and pulmonary venous flow. Normal values for these parameters are provided. Guidelines for grading diastolic dysfunction according to the 2016 ASE/EACVI guidelines are presented. Special considerations for evaluating diastolic function in conditions like HCM, mitral stenosis, mitral regurgitation, and atrial fibrillation are also reviewed. Novel indices using speckle tracking echocardiography to assess diastolic function are mentioned.
- LVH is characterized by tall QRS complexes on ECG due to increased electrical forces moving through the thickened myocardium.
- Criteria exists to diagnose LVH using a 12-lead ECG, such as the R wave in V5 or V6 plus the S wave in V1 or V2 exceeding 35 mm.
- The document compares a normal ECG to one with LVH and explains how echocardiogram can also detect LVH by showing increased ventricular wall thickness.
This document provides an overview of electrocardiogram (ECG) interpretation. It begins by outlining the learning objectives, which are to recognize normal sinus rhythm, common rhythm disturbances on a 3-lead ECG, and how to interpret a myocardial infarction on a 12-lead ECG. The document then reviews ECG basics, how to analyze rhythms, defines normal sinus rhythm, and discusses common cardiac dysrhythmias and how to diagnose a myocardial infarction. It provides examples of various normal and abnormal rhythms.
A great tutorial from Dr Alistair Jones NHS medical educator (http://www.yorkshiremedicaleducation.co.uk/about-us) on ECG syndromes. Beyond the basics (but essential knowledge for training emergency physicians)
This document discusses myocardial infarction (MI) and myocardial ischemia. It begins by defining MIs that result from total coronary occlusion (Q-wave MI) versus subtotal occlusion (non-Q-wave MI). It then describes the blood supply territories of the main coronary arteries and shows examples of ECG patterns for different types of MIs, including anterior, inferior, and lateral MIs. It also discusses non-ST elevation acute coronary syndrome (NSTEACS), describing the ECG patterns of ST depression and T-wave changes seen in myocardial ischemia, including Wellens' syndrome. Throughout, it localizes arterial territories and compares ECG findings to understand the likely location and extent of ischemia/infarction.
This document provides an overview of ECG basics, including the cardiac conduction system, components of the cardiac cycle, a systematic approach to rhythm interpretation, and descriptions of common arrhythmias. It discusses the normal P-QRS-T waveform, conduction velocities, factors used to analyze rhythms like regularity and rate, and examples of arrhythmias including sinus arrhythmia, sinus block, WAP, MAT, A-fib, flutter, blocks, and SVTs. It also reviews lead placement, electrical axis, vector concepts, and a systematic approach to 12-lead ECG interpretation.
The 12-lead ECG provides views of the heart from both a horizontal and vertical plane using 12 different leads. The leads are divided into limb leads, which measure electrical activity from the arms and legs, and precordial or chest leads, which measure activity from the chest. Each lead is generated using a positive and negative electrode in different positions to capture the heart's electrical activity from different angles.
The 12-lead ECG is a diagnostic test that helps identify conditions like acute coronary syndrome and myocardial infarction. Obtaining a 12-lead ECG in the field is important to identify ST elevations that could indicate a heart attack and speed up treatment times. The placement of the ECG leads and the patterns in the complexes can provide clues to determine the type and location of any heart issues. It is important for paramedics to become proficient in performing and interpreting 12-lead ECGs to help ensure the best outcomes for patients experiencing potential cardiac events.
The document provides an overview of electrocardiography (ECG), including its history, importance, physiology, leads, waves, intervals, and abnormalities. Key points covered include the names and functions of the P, QRS, and T waves, as well as common abnormalities like ST segment elevation/depression, T wave inversion, and arrhythmias. The summary analyzes ECGs to recognize conditions like myocardial infarction and ventricular hypertrophy.
This document provides an overview of EKG interpretation. It discusses the normal conduction system, EKG leads, waveforms and intervals. It covers determining heart rate, axis, and common rhythms such as sinus, atrial, junctional and ventricular. It also summarizes chamber enlargements, bundle branch blocks, ischemia, infarction patterns and other EKG abnormalities. The goal is to equip the reader with the basics needed for a systematic approach to EKG interpretation.
This document discusses ST-elevation myocardial infarction (STEMI) equivalents that can be identified on electrocardiograms (ECGs). It describes atypical ECG patterns including ST depression or T-wave changes in leads indicating posterior or lateral wall ischemia. Other STEMI equivalents include isolated ST depression in lead AVL, hyperacute T-waves, Wellens' syndrome, ST elevation in lead AVR, and presumed new left bundle branch block with Sgarbossa criteria. The document stresses the importance of recognizing these STEMI-equivalent patterns to identify patients who could benefit from primary percutaneous coronary intervention.
This document provides an overview of electrocardiography (ECG) basics including:
1. It describes what an ECG is and what conditions it can be useful for diagnosing.
2. It outlines the different ECG leads including the standard and precordial leads used to measure electrical activity from different angles.
3. It explains the typical ECG waveforms including the P, QRS, T, and U waves as well as intervals like the PR and QT, and how to interpret abnormalities.
4. It provides guidance on interpreting an ECG including assessing lead position, rhythm, rate, axis, and looking for signs of conditions like bundle branch blocks or chamber enlargement.
The document discusses electrocardiogram (ECG) patterns associated with cardiac chamber enlargement, specifically right atrial enlargement (RAE) and left atrial enlargement (LAE). RAE is suggested by a tall, peaked P wave in leads II, III, AVF and a positive P wave in V1. LAE results in prolongation of the left atrial component of the P wave, increased posterior deviation of the left atrial vector, and left axis deviation of the P wave. The diagnostic accuracy of ECG findings for chamber enlargement is limited but can provide clues when correlated with imaging studies.
This document provides a history of the electrocardiogram (EKG/ECG) and describes how it is used to evaluate cardiac electrical activity and identify various cardiac conditions. Some key points:
- The EKG was developed in the late 19th/early 20th century, with scientists like Matteucci, Marey, and Einthoven contributing to its invention and clinical use.
- An EKG records the heart's electrical activity through electrodes on the skin and can be used to detect arrhythmias, ischemia, infarction, and other conditions.
- It analyzes the P wave, QRS complex, ST segment, and T wave to evaluate conduction and identify abnormalities.
The document provides an overview of echocardiography techniques for assessing various adult heart diseases. It discusses how to evaluate left and right ventricular function, aortic and mitral valve diseases, pericardial diseases, and cardiomyopathies. Evaluation of ventricular size and function involves 2D and Doppler echocardiography to measure dimensions, estimate ejection fraction, and calculate indices like fractional shortening. Valvular lesions are assessed using 2D to visualize anatomy and Doppler to measure velocities and gradients. Right heart function and pressures are evaluated using measurements of the IVC, RV size, TAPSE, and TR jet velocity.
Approach to Wide complex tachycardia /cardiology Cardiology
1) Wide complex tachycardia can be caused by ventricular tachycardia, supraventricular tachycardia with abnormal conduction, or ventricular pacing. The document discusses approaches to distinguishing these based on history, examination, and electrocardiogram findings.
2) Ventricular tachycardia is characterized by a wide QRS complex greater than or equal to 120ms and can be monomorphic, polymorphic, or bidirectional. Features on electrocardiogram can provide clues about site of origin in the ventricles.
3) Sustained ventricular tachycardia can cause hemodynamic instability while non-sustained ventricular tachycardia typically does not. Distinguishing ventricular
- Left bundle branch block (LBBB) is caused by conditions that damage the left bundle branch, such as hypertension, dilated cardiomyopathy, and ischemic heart disease.
- LBBB is diagnosed based on criteria including a QRS duration of over 120ms and abnormal ST segment and T wave patterns.
- The prognosis of LBBB depends on any underlying heart conditions, with LBBB increasing the risk of mortality. LBBB may resolve temporarily following a premature ventricular contraction due to resetting of the conduction system.
This document provides guidance on electrocardiogram (ECG) interpretation for primary care physicians. It outlines the 6 key steps to analyze an ECG: rate, rhythm, axis, intervals, hypertrophy, and infarction/ischemia. Specific abnormalities that may indicate conditions like sinus tachycardia, atrial fibrillation, left ventricular hypertrophy, myocardial infarction, and heart block are described. Diagnosis of cardiac issues is aided by identifying changes in various leads that correspond to specific areas of the heart.
This document discusses the echocardiographic assessment of aortic valve stenosis. It begins by describing the normal aortic valve anatomy. It then discusses various 2D and Doppler echocardiographic views used to evaluate the aortic valve. The main causes of aortic stenosis and their anatomical presentations are described. The key Doppler parameters used to assess stenosis severity are peak aortic jet velocity, mean pressure gradient, and aortic valve area calculated using the continuity equation. Stress echocardiography with dobutamine is discussed for assessing patients with low-flow, low-gradient aortic stenosis. The limitations of echocardiography in evaluating aortic stenosis are also reviewed.
The document discusses cardiovascular emergencies like chest pain and acute coronary syndrome, outlining their epidemiology, pathophysiology, assessment, and management for EMTs. It covers topics like atherosclerosis, angina, myocardial infarction, and provides a case study example to demonstrate assessment and treatment of a patient experiencing chest pain. The goal is to educate EMTs on properly evaluating and stabilizing patients experiencing potential cardiac events before transporting them to the hospital for further care.
(1) The ECG shows normal sinus rhythm with a heart rate of 75 beats per minute and a slightly prolonged QT interval.
(2) There are abnormal Q waves in leads II, III, and aVF along with ST segment elevations and T wave inversions, consistent with an inferolateral myocardial infarction.
(3) The findings also include an early precordial transition with a relatively tall R wave in lead V2, which could reflect posterior wall involvement.
This document provides instructions on obtaining a 12-lead electrocardiogram (ECG or EKG). It covers electrode placement, identifying the correct intercostal spaces for chest leads, demonstrating techniques, reducing artifact, and tips. Key points include using gel to improve skin contact and signal strength, cleaning skin first, and troubleshooting to get clear readings, as accurate ECG interpretation requires a high-quality tracing. With practice, paramedics can learn to rapidly obtain 12-lead ECGs even in challenging patients or situations.
GEMC- EKG and Rhythm Interpretation 101-for ResidentsOpen.Michigan
This is a lecture by Emily Sagalyn from the Ghana Emergency Medicine Collaborative. To download the editable version (in PPT), to access additional learning modules, or to learn more about the project, see http://openmi.ch/em-gemc. Unless otherwise noted, this material is made available under the terms of the Creative Commons Attribution Share Alike-3.0 License: http://creativecommons.org/licenses/by-sa/3.0/.
Chapter 10 - 12 lead Interpretation - Part 2ryanhall911
This document provides a 3-sentence summary of a chapter on 12-lead ECG interpretation from an Ontario Base Hospital Group training manual:
The chapter reviews key concepts for interpreting 12-lead ECGs in acute coronary syndrome patients, including ST segment depression, T-wave inversion, Q-waves, reciprocal changes, and the evolution of ECG patterns over time during a myocardial infarction. It emphasizes that while ST elevation has high specificity for STEMI, a normal ECG does not rule out AMI since not all AMIs exhibit STE and early AMIs may not show changes yet. The document aims to help emergency responders properly recognize and interpret 12-lead ECG findings for acute myocardial infarction.
The 12-lead ECG provides important information about the heart's electrical activity. It begins with atrial depolarization seen as the P wave, followed by ventricular depolarization in the QRS complex. The ST segment and T wave represent ventricular repolarization. Each of the 12 leads views the heart from a different angle, with the standard limb leads in the frontal plane and the chest leads in the horizontal plane. Together they allow clinicians to determine the heart's rate, rhythm, and axis.
Here are the key steps to determine the cardiac axis on a 12-lead ECG:
1. Identify the positive deflection of the QRS complex in leads I, II, III. This will help determine the quadrant of the axis.
2. Use lead aVR to help further refine the axis. A positive aVR narrows it to the left lateral or left posterior quadrant.
3. The axis is the point where an imaginary line drawn through the heart would intersect the ECG if extended to the peripheral leads.
Determining the cardiac axis provides important information to identify conduction abnormalities like hemiblocks. It's an essential part of accurately interpreting and diagnosing from a 12-lead ECG.
This document provides an overview of 12-lead ECG interpretation for EMS professionals. It reviews cardiac anatomy and the relationship between anatomical structures and the 12 leads. It describes the components of the 12-lead ECG device and format. Key waveform components like the QRS complex, ST segment, and T wave are defined. The document explains how the 12 leads are grouped and relate to different views and walls of the heart, such as the inferior, lateral, anterior, and septal walls. Interpretation of ST segment elevation is discussed as it relates to recognizing acute myocardial infarction.
This document is a chapter from the Ontario Base Hospital Group on putting together a systematic approach to 12-lead ECG interpretation for paramedics. It outlines the objectives of using a systematic approach and simple algorithm to read ECGs quickly. The chapter then provides examples of various ECG strips with descriptions of abnormalities like ST elevation, ischemia, blocks, and prior infarcts. It concludes by emphasizing the goal of prehospital 12-lead ECG is rapid identification of STEMI patients for fast reperfusion treatments.
The document provides information on how to read and interpret an electrocardiogram (ECG). It discusses the components of an ECG including the leads, waves, intervals and segments. It describes how to analyze key aspects such as heart rate, rhythm, axes, hypertrophy, blocks, and abnormalities. The systematic 14-point approach involves analyzing standardization, rate, rhythm, P waves, intervals, voltages, axes, and segments to interpret the ECG and identify any pathological conditions.
This document provides an overview of the various causes of ST elevation on electrocardiograms (ECGs). It discusses electrolyte abnormalities, left bundle branch block, early repolarization, ventricular hypertrophy, aneurysms, infections or injuries, Osborne waves, non-occlusive vasospasm, and Brugada syndrome. Specific ECG patterns are presented for each cause. Key factors to evaluate for each condition include the shape, amplitude, and distribution of ST segments and T waves. Scoring systems like Sgarbossa criteria are also described which can help determine if ST elevation in the setting of left bundle branch block is likely due to acute myocardial infarction.
The document discusses differentiating ST elevation myocardial infarction (STEMI) from other causes of ST elevation on an electrocardiogram (ECG). It provides examples of three sample ECGs, describing ECG 1 as showing typical inferior STEMI patterns, ECG 2 as most consistent with pericarditis given its global and concave ST elevation, and ECG 3 showing minimal changes consistent with benign early repolarization. Key factors for differentiation include the magnitude, morphology, distribution of ST elevation, and comparison to previous ECGs. The document emphasizes analyzing ST elevation in the full clinical context and pursuing safe care when in doubt.
The document provides an overview of 12 lead EKG interpretation in 17 steps. It discusses evaluating the rate, rhythm, axis deviation, and signs of hypertrophy or infarction. Common rhythms reviewed include normal sinus rhythm, various arrhythmias, conduction blocks, and tachycardias. The document emphasizes interpreting location of infarction and enlargement based on EKG findings and provides examples of practice EKG interpretations.
An electrocardiogram (ECG or EKG) records the electrical activity of the heart. A 12-lead ECG uses electrodes placed on the wrists, ankles, and chest to assess the heart from 12 different views. It is a valuable diagnostic tool that displays the heart's electrical activity as waveforms. The procedure involves preparing the ECG machine, attaching electrodes to the patient's limbs and chest in specific positions, recording the 12 leads automatically, and removing the electrodes after.
Cardiovascular disease is the leading cause of death in the United States, responsible for over 1 million deaths in 2004. Sudden cardiac death accounts for over 40% of cardiovascular deaths. The patient is a 67-year-old male experiencing crushing chest pressure radiating to his jaw, accompanied by shortness of breath and nausea, with no previous cardiac history. Based on the patient's symptoms and risk factors, the emergency responder suspects the patient may be experiencing an acute myocardial infarction.
This document outlines a STEMI recognition class consisting of 6 modules: 1) Introduction to 12-lead EKGs, 2) Identifying the J point, 3) Identifying ST elevation and depression, 4) Lead views and what areas of the heart each lead represents, 5) Practice exercises, and 6) Putting it all together to recognize STEMIs by identifying ST elevation in two or more contiguous leads. The class teaches students to systematically analyze each lead one by one to check for ST elevation compared to the TP segment baseline in order to diagnose STEMIs.
Myocardial infarction, commonly known as a heart attack, occurs when blood flow to the heart is blocked, preventing oxygen and nutrients from reaching heart muscle tissue. Over time, plaque can build up in the coronary arteries and restrict blood flow, potentially causing a heart attack. Symptoms of a heart attack include chest pain, shortness of breath, nausea and more. Treatment focuses on restoring blood flow through clot-busting drugs or angioplasty to limit heart muscle damage. Lifestyle changes like quitting smoking, eating healthy, and exercise can help prevent heart attacks.
ST segment elevations can be seen in acute myocardial infarction (AMI) but also have other causes. Non-AMI causes of ST elevation include left bundle branch block, left ventricular hypertrophy, pericarditis, Brugada syndrome, and early repolarization. The morphology, distribution, and magnitude of ST elevations, as well as other ECG features, can help differentiate AMI from other causes of ST elevation. It can be challenging to diagnose AMI using ECG criteria alone, as around half of AMI cases present without typical ST elevation patterns.
This document discusses cardiac emergencies including angina pectoris, myocardial infarction, and congestive cardiac failure. It defines each condition, lists causes and risk factors, describes signs and symptoms, outlines diagnostic tests and treatment options, discusses complications, and provides nursing management guidelines. Angina is chest pain due to decreased blood flow to the heart while myocardial infarction and congestive cardiac failure involve the heart's inability to pump sufficiently due to disease or damage. Prompt recognition and treatment are important to save lives during these deadly emergencies.
Salient features of the book are -
- The book provides a shortcut to understand and remember certain specific formulae and points you require to interpret the 12-lead ECG.
- Treatment protocols (in green boxes) for most of the important conditions are also included.
- View sample ECGs as you read along the topics.
- The content is explained in a very simple language to provide good conceptions, written from a student’s point of view.
- People can gain their belief in the book after going through sample ECGs which would be available at www.themedicalpost.net/ecg
- The book competes with the other books available in the market in simplicity, summaries, treatment protocols, live diagrams and regularly updated sample ECGs on the website.
This document reviews STEMI (ST elevation myocardial infarction) recognition and treatment. It defines a STEMI as elevated ST segments on an ECG due to blocked coronary arteries. Imposters like left bundle branch block can mimic STEMIs. The anatomy, ECG interpretation rules, and signs of STEMI versus no STEMI are described. Treatment includes aspirin, nitroglycerin, oxygen, and morphine or dilaudid for pain management in the pre-hospital setting. Recognizing true STEMIs amid imposters like left bundle branch block is a critical skill for emergency responders.
This document discusses the analysis of a 12-lead EKG. It begins by describing the components that should be assessed, including rhythm, rate, axis, and grouped lead analysis. Specific abnormalities are then discussed in detail such as ST segment changes, bundle branch blocks, Q waves, and more. The overall goal is to systematically analyze all aspects of the 12-lead EKG to evaluate for any cardiac abnormalities.
- The document discusses electrocardiography (ECG), including what an ECG is, how to perform one, and how to interpret the results. Key aspects include placing 10 electrodes on the patient and using them to form 12 leads that examine the heart from different angles. The ECG traces the heart's electrical activity through waves like the P, QRS, and T waves. Interpreting the ECG involves checking various parameters like rate, rhythm, intervals, and amplitudes to identify any abnormalities.
This document provides an overview of how to interpret an electrocardiogram (ECG). It describes the basic components of an ECG including patient data, paper speed, calibration, lead placement, and waveform intervals. It then examines each waveform in more detail, covering the P wave, QRS complex, T wave, ST segment, and cardiac rhythm and axis. Key signs and abnormalities are outlined for each component to guide ECG interpretation.
ECGs produce a graph of the heart's electrical activity by detecting the potential differences between electrodes placed on the skin. The electrodes pick up the electrical impulse conducted through the heart muscle and body. The ECG machine reads and records the differences in potential to draw a graph over time. The graph consists of waves, segments, and intervals that provide information about atrial and ventricular depolarization and repolarization during each heartbeat cycle.
ECG- ELECTROCARDIOGRAM basics and interpretationDISHANTVADDORIYA
The document provides an overview of the standard 12-lead electrocardiogram (ECG). It describes the placement of the 12 leads, including 6 limb leads and 6 precordial leads. It then defines the normal components of an ECG trace including waves, intervals, segments and complexes. It proceeds to describe each component in detail including the P wave, QRS complex, T wave, and other intervals. Common abnormalities are also summarized such as atrial fibrillation, left ventricular hypertrophy, myocardial infarction, supraventricular tachycardia, and right/left bundle branch blocks.
1. The document discusses features of the QRS complex that should be considered when analyzing an ECG, including pathological Q waves, large R or S waves, dominant R waves in certain leads, poor R wave progression, and QRS width and morphology.
2. Abnormally large R or S waves can indicate conditions like left ventricular hypertrophy, right ventricular hypertrophy, or myocardial infarction.
3. A dominant R wave in lead aVR can suggest conditions like sodium channel blocker poisoning, dextrocardia, or ventricular tachycardia.
4. A broad QRS complex over 100ms suggests conditions that cause aberrant conduction, like bundle branch blocks, while a narrow QRS
12 Lead EKG Interpretation ( PDFDrive ).pdfzeezoomor
The document discusses a presentation on interpreting 12-lead electrocardiograms (EKGs). It covers proper lead placement, identifying normal EKG intervals and rhythms, recognizing conduction blocks and bundle branch blocks, determining heart axis, and interpreting signs of ischemia including ST elevation myocardial infarctions (STEMIs). The objectives are to learn EKG interpretation skills like identifying arrhythmias, conduction abnormalities, axis deviations, and using ST segment changes to localize infarct location.
The document discusses cardiac axis and mean QRS axis, which represents the direction of electrical spread during ventricular depolarization. It is measured in the frontal plane based on the limb leads. The lead with the tallest R wave is closest to the axis. The normal range is -30 to +120 degrees with right and left axis deviations indicating abnormalities. Common causes of axis changes are also listed.
1. The document discusses ECG interpretation and analysis. It covers ECG basics, normal sinus rhythm, arrhythmias, and diagnosing myocardial infarction.
2. A key point is that diagnosing a myocardial infarction requires analyzing a 12-lead ECG, not just a rhythm strip, as the 12-lead ECG provides multiple views of the heart.
3. ST elevation in certain leads can help locate the site of a myocardial infarction, with the anterior wall seen in leads V1-V4, the lateral wall in leads I, aVL, V5-V6, and the inferior wall in leads II, III, and aVF.
This document provides an overview of interpreting 12-lead electrocardiograms (ECGs) for myocardial infarction (MI). It reviews ECG waves, intervals, and segments. It defines ischemia, injury, and infarction and describes associated ECG changes. It identifies the five major infarct areas and corresponding lead changes. Color coding is used to indicate changes for anterior, inferior, lateral, posterior, and subendocardial MIs. Examples of ECG strips demonstrate single and combined infarct patterns. Cardiac enzymes that indicate infarction and their time courses are also reviewed.
The document discusses how to obtain and interpret a 12-lead electrocardiogram (ECG) to diagnose acute myocardial infarction (AMI), explaining the anatomy, waveform components, localization of ST elevations, and reciprocal changes seen with different types of AMI such as inferior, anterior, lateral, and posterior infarcts. It emphasizes that ST elevation is the most important indicator of AMI and timely treatment is critical, as AMI appears within 1-2 hours on ECG and delays increase damage. Bundle branch blocks and other conditions can obscure ECG findings, so new or presumed new bundle branch blocks are treated as potential AMI.
This document provides information about cardiovascular emergencies and electrocardiograms (ECGs). It discusses how ECG monitors can be used to monitor heart rhythms during transport and obtain prints for interpretation. It also describes how 12-lead ECGs provide detailed information about the heart's conduction system. The document outlines the principles and proper techniques for applying ECG electrodes and identifies potential artifacts. It explains the different types of ECG leads and how they are positioned. Finally, it discusses how to interpret ECG rhythms by identifying the waves, measuring intervals, and classifying dysrhythmias.
The document provides an overview of electrocardiography (ECG) fundamentals. It defines what an ECG is and discusses the cardiac cycle and interpretation of different ECG components such as waves, intervals, complexes, and segments. Key points covered include the components of the ECG, abnormalities that can be identified from the ECG, cardiac electrical conduction pathways, lead placements, and common causes of ECG abnormalities.
This document provides information on electrocardiograms (ECGs), including ECG paper layout, lead placement, interpretation steps, and how to locate infarcts based on ECG findings. Common arrhythmias are summarized, including definitions and treatments for sinus bradycardia, atrial fibrillation, heart blocks, premature ventricular contractions, ventricular tachycardia, and more. Overall health impacts and treatments are discussed for various rhythms.
This document provides an overview of electrocardiography (ECG) basics. It defines ECG as a graphical representation of the heart's electrical activity used to assess cardiovascular diseases. It discusses the conduction system of the heart and the 12 standard chest leads used in ECG. It outlines the key steps in ECG interpretation including analyzing rate, rhythm, intervals, chambers, and waveform durations. It describes how to calculate heart rate from the ECG and defines the normal P wave, PR interval, QRS complex, ST segment, QT interval, and ECG axis.
The document provides an overview of ECG interpretation including components to evaluate such as rate, rhythm, axis, wave morphology, intervals, and segments. It emphasizes considering the patient's clinical condition, obtaining prior ECGs for comparison, and getting a second opinion when needed. The normal ECG is reviewed along with abnormalities including arrhythmias, conduction defects, myocardial infarction, hypertrophy, and other cardiac and non-cardiac conditions.
This document defines and discusses human trafficking. It begins by defining human trafficking and sex trafficking. It then discusses how President Obama has referred to human trafficking as "modern slavery." It provides statistics on human trafficking victims globally and in the US. It discusses how traffickers prey on vulnerable populations and lure victims. It also outlines current laws against trafficking and resources for reporting trafficking and helping victims.
The document discusses disorders of the pancreas and diabetes. It notes that the pancreas produces insulin and glucagon to regulate blood glucose levels. Type 1 diabetes occurs when the pancreas stops producing insulin, while type 2 diabetes involves inadequate or ineffective insulin production. Hypoglycemia, or low blood glucose, is the most common diabetic emergency seen by EMS and results from an imbalance in the endocrine system where insulin overcorrects high blood glucose. Frequent blood glucose monitoring is important for diabetes management.
This document discusses methods of hemorrhage control in the pre-hospital setting. Hemorrhage is the leading cause of preventable death in trauma. The document outlines signs of blood loss and sources of external and internal bleeding. It describes techniques for hemorrhage control including applying direct pressure, pressure dressings, and tourniquets. The goals of pre-hospital care are continuing hemorrhage control and rapid transport to a surgical facility to prevent patients from bleeding to death.
Stacey Wright provides information on infection control, safety, and exposure control for Pender EMS and Fire. She outlines guidelines for accountability, safety forms, personal protective equipment, isolation precautions including MRSA, the respirator program, airborne pathogens like tuberculosis, regulated medical waste disposal, and general infection control measures. The goal is to ensure the safety of all emergency personnel through proper safety protocols and use of protective equipment.
This document discusses P-wave morphology and its relationship to various cardiac rhythms. It begins by defining the P-wave and establishing criteria for normal P-wave characteristics. It then explores how deviations from these criteria can indicate conditions like atrial enlargement or ectopic rhythms. Specific arrhythmias like atrial fibrillation, flutter, sinus arrest and junctional rhythms are examined in terms of their P-wave patterns. The document emphasizes analyzing P-waves to help identify the origin of the cardiac rhythm and any underlying conduction abnormalities.
Stacey Wright provides information on infection control, safety, and exposure management for Pender EMS and Fire. Key points include proper use of personal protective equipment, cleaning and sanitizing procedures, regulated medical waste disposal, tuberculosis precautions including annual respirator training, and immediate reporting of any exposures. The document emphasizes the importance of safety, cleanliness, and confidentiality.
The document provides instructions for using a Combat Application Tourniquet (C-AT). It states that tourniquets should be used for major hemorrhaging that cannot be controlled through other means. The tourniquet must be placed above the injury site and, once applied, should not be removed. The C-AT has a self-adhering band that is wrapped around the limb and a windlass rod that is twisted to tighten the band until bleeding stops. A windlass strap is then used to lock the rod in place.
Pender ems fire manual powerpoint traininggpeditsEMSMedic79
This document summarizes the employee manual for Pender EMS & Fire. It outlines the agenda which includes policies on employee conduct, progressive discipline, time off, and benefits. It provides details on policies regarding harassment, computer use, social media, and attendance. It also describes the recruitment process and guidelines for internal transfers and promotions.
The document provides information about ventricular assist devices (VADs) including:
- VADs are mechanical pumps that are surgically implanted to assist one or both ventricles. They are powered externally and help pump blood continuously.
- They are used as a bridge to transplant, destination therapy, or temporarily to allow heart recovery. Common complications include bleeding, thrombosis, infection, and device malfunctions.
- Key parameters monitored include flow, speed, power, and pulsatility index. Alarms indicate issues that require attention. Proper management focuses on maintaining preload through IV fluids while avoiding risks like bleeding or reducing preload. Transporting VAD patients requires bringing all equipment and contacting the implanting
A ventricular assist device (VAD) is a mechanical pump that is surgically implanted to assist one or both failing ventricles of the heart. It helps pump blood to the body when the heart is too weak. Complications can include bleeding, infection, device malfunction. Proper management focuses on maintaining adequate blood volume and flow through the device. Transporting VAD patients requires bringing all equipment and contacting the implanting center for guidance.
TEST BANK For Community Health Nursing A Canadian Perspective, 5th Edition by...Donc Test
TEST BANK For Community Health Nursing A Canadian Perspective, 5th Edition by Stamler, Verified Chapters 1 - 33, Complete Newest Version Community Health Nursing A Canadian Perspective, 5th Edition by Stamler, Verified Chapters 1 - 33, Complete Newest Version Community Health Nursing A Canadian Perspective, 5th Edition by Stamler Community Health Nursing A Canadian Perspective, 5th Edition TEST BANK by Stamler Test Bank For Community Health Nursing A Canadian Perspective, 5th Edition Pdf Chapters Download Test Bank For Community Health Nursing A Canadian Perspective, 5th Edition Pdf Download Stuvia Test Bank For Community Health Nursing A Canadian Perspective, 5th Edition Study Guide Test Bank For Community Health Nursing A Canadian Perspective, 5th Edition Ebook Download Stuvia Test Bank For Community Health Nursing A Canadian Perspective, 5th Edition Questions and Answers Quizlet Test Bank For Community Health Nursing A Canadian Perspective, 5th Edition Studocu Test Bank For Community Health Nursing A Canadian Perspective, 5th Edition Quizlet Test Bank For Community Health Nursing A Canadian Perspective, 5th Edition Stuvia Community Health Nursing A Canadian Perspective, 5th Edition Pdf Chapters Download Community Health Nursing A Canadian Perspective, 5th Edition Pdf Download Course Hero Community Health Nursing A Canadian Perspective, 5th Edition Answers Quizlet Community Health Nursing A Canadian Perspective, 5th Edition Ebook Download Course hero Community Health Nursing A Canadian Perspective, 5th Edition Questions and Answers Community Health Nursing A Canadian Perspective, 5th Edition Studocu Community Health Nursing A Canadian Perspective, 5th Edition Quizlet Community Health Nursing A Canadian Perspective, 5th Edition Stuvia Community Health Nursing A Canadian Perspective, 5th Edition Test Bank Pdf Chapters Download Community Health Nursing A Canadian Perspective, 5th Edition Test Bank Pdf Download Stuvia Community Health Nursing A Canadian Perspective, 5th Edition Test Bank Study Guide Questions and Answers Community Health Nursing A Canadian Perspective, 5th Edition Test Bank Ebook Download Stuvia Community Health Nursing A Canadian Perspective, 5th Edition Test Bank Questions Quizlet Community Health Nursing A Canadian Perspective, 5th Edition Test Bank Studocu Community Health Nursing A Canadian Perspective, 5th Edition Test Bank Quizlet Community Health Nursing A Canadian Perspective, 5th Edition Test Bank Stuvia
These lecture slides, by Dr Sidra Arshad, offer a quick overview of the physiological basis of a normal electrocardiogram.
Learning objectives:
1. Define an electrocardiogram (ECG) and electrocardiography
2. Describe how dipoles generated by the heart produce the waveforms of the ECG
3. Describe the components of a normal electrocardiogram of a typical bipolar lead (limb II)
4. Differentiate between intervals and segments
5. Enlist some common indications for obtaining an ECG
6. Describe the flow of current around the heart during the cardiac cycle
7. Discuss the placement and polarity of the leads of electrocardiograph
8. Describe the normal electrocardiograms recorded from the limb leads and explain the physiological basis of the different records that are obtained
9. Define mean electrical vector (axis) of the heart and give the normal range
10. Define the mean QRS vector
11. Describe the axes of leads (hexagonal reference system)
12. Comprehend the vectorial analysis of the normal ECG
13. Determine the mean electrical axis of the ventricular QRS and appreciate the mean axis deviation
14. Explain the concepts of current of injury, J point, and their significance
Study Resources:
1. Chapter 11, Guyton and Hall Textbook of Medical Physiology, 14th edition
2. Chapter 9, Human Physiology - From Cells to Systems, Lauralee Sherwood, 9th edition
3. Chapter 29, Ganong’s Review of Medical Physiology, 26th edition
4. Electrocardiogram, StatPearls - https://www.ncbi.nlm.nih.gov/books/NBK549803/
5. ECG in Medical Practice by ABM Abdullah, 4th edition
6. Chapter 3, Cardiology Explained, https://www.ncbi.nlm.nih.gov/books/NBK2214/
7. ECG Basics, http://www.nataliescasebook.com/tag/e-c-g-basics
Muktapishti is a traditional Ayurvedic preparation made from Shoditha Mukta (Purified Pearl), is believed to help regulate thyroid function and reduce symptoms of hyperthyroidism due to its cooling and balancing properties. Clinical evidence on its efficacy remains limited, necessitating further research to validate its therapeutic benefits.
- Video recording of this lecture in English language: https://youtu.be/kqbnxVAZs-0
- Video recording of this lecture in Arabic language: https://youtu.be/SINlygW1Mpc
- Link to download the book free: https://nephrotube.blogspot.com/p/nephrotube-nephrology-books.html
- Link to NephroTube website: www.NephroTube.com
- Link to NephroTube social media accounts: https://nephrotube.blogspot.com/p/join-nephrotube-on-social-media.html
TEST BANK For Basic and Clinical Pharmacology, 14th Edition by Bertram G. Kat...rightmanforbloodline
TEST BANK For Basic and Clinical Pharmacology, 14th Edition by Bertram G. Katzung, Verified Chapters 1 - 66, Complete Newest Version.
TEST BANK For Basic and Clinical Pharmacology, 14th Edition by Bertram G. Katzung, Verified Chapters 1 - 66, Complete Newest Version.
TEST BANK For Basic and Clinical Pharmacology, 14th Edition by Bertram G. Katzung, Verified Chapters 1 - 66, Complete Newest Version.
TEST BANK For Basic and Clinical Pharmacology, 14th Edition by Bertram G. Katzung, Verified Chapters 1 - 66, Complete Newest Version.
Histololgy of Female Reproductive System.pptxAyeshaZaid1
Dive into an in-depth exploration of the histological structure of female reproductive system with this comprehensive lecture. Presented by Dr. Ayesha Irfan, Assistant Professor of Anatomy, this presentation covers the Gross anatomy and functional histology of the female reproductive organs. Ideal for students, educators, and anyone interested in medical science, this lecture provides clear explanations, detailed diagrams, and valuable insights into female reproductive system. Enhance your knowledge and understanding of this essential aspect of human biology.
share - Lions, tigers, AI and health misinformation, oh my!.pptxTina Purnat
• Pitfalls and pivots needed to use AI effectively in public health
• Evidence-based strategies to address health misinformation effectively
• Building trust with communities online and offline
• Equipping health professionals to address questions, concerns and health misinformation
• Assessing risk and mitigating harm from adverse health narratives in communities, health workforce and health system
2. • Action potential of myocardial tissue and areas of ischemia/ infarction
• Proper 12 lead placement and augmented leads
• Wave formation and pathology
• Recognize and diagnose ectopic and idiopathic segments
• Recognize st-segment elevation and depression
• Differentiate between STEMI and Non-STEMI
• Learn areas of ischemia/ infarction and reciprocal changes
• 6 most common STEMI mimickers
• Learn diagnose ectopic rhythms using axis and axis deviation
• Sgarbossa Criteria
• 15 lead and right side 12 lead placement
• Uncommon 12 lead presentation
• Medications and arrhythmias
Introduction
3. • Occurs in 4 phases (some interpret 3 or 5)
• Sodium (Na+)- influx creates depolarization
• Calcium (Ca2+)- Controls the STRENGTH of depolarization
• Potassium (K+)- influx repolarizes (resets) the action potential
• Resting state average -90mV, then depolarization lifts to approx. +40mV
• During resting state, the outside of the cell is MORE positive than the
inside of the cell meaning by default, the inside of the cell is negative
• During depolarization, the inside of the cell becomes MORE positive than
the outside resulting in contraction
Action Potential
4. • Na+ begins to slowly enter the cell until around -70mV, then it enters the
cell rapidly increasing voltage to approx. +40 (phase 0)
• This influx causes K+ to rapidly leave the cell which is where the voltage
decreases (phase 1)
• As this occurs, Ca2+ begin to enter the cell resulting in NO difference in
voltage (plateau phase, Also Phase 2)
• Once depolarization occurs, the cell begins to switch again, causing Na+
and K+ to leave and Ca2+ to be reabsorbed out of the cell back to resting
state (phase 3 and 4)
Action Potential
6. Einthovens Triangle
• “White on right, smoke over fire”
• Negative to positive
• Flow of conduction towards a positive lead
• Augmented leads AVR, AVL, AVF
• Augmentation refers to voltage change
• Voltage change through leads allows
additional segments to be captured on 12
lead
7. Augmented Leads
• Lead voltage changes to reflect positive lead
• Augmentation results in variable deflection
• When voltage moves TOWARDS a positive lead, always a POSITIVE deflection
• When voltage moves AWAY from a positive lead, shows a NEGATIVE deflection
• AVR is NOT a useless lead
8. Lead Placement
• V1: 4th intercostal space right of sternum
• V2: 4th intercostal space left of sternum
• V3: Midway between v2 and V4
• V4: Midclavicular line left side
• V5: Anterior Axillary line same level of V4
• V6: Midaxllary line same level of V5
9. • Measured in milliseconds and millimeters/ millivolts
Time and Size
10. Time and Size
• 0.1 mV = 1 mm (height)
• 1 small box= 0.04 seconds
(width)
• 1 highlighted box= 0.2 seconds
• 5 highlighted boxes =1 second
• 0.5 mV = 5 mm
• Height and width used to
determine additional ectopy
during cardiac rhythm
• Based on location of isoelectric
line
11. Isoelectric line
• Base electrical line on ECG
• Used to determine elevation or
• Depression
• Dependent on upward and
• Downward deflection of QRS
• Registered in time and mV
12. Isoelectric Line
• Elevation determined by positive deviation from isoelectric line
• Depression determined by negative deviation from isoelectric line
• ST-Segment can be above or below but the J-point must be determined to
diagnose elevation or depression
13. The “Quick 6”
• Half of a 12 lead
• Shows a reflection of basic leads and
augmented leads
• May show possible areas of infarction/
ischemia
• Will not show PRI/ QRS/ QT segment
timing
• 12 lead is still the standard for diagnosis
15. •Shows time and elevation in exact sequence
•Considered always reliable
•Do NOT go by the computer interpretation of the rhythm, that’s why you
were trained to manually interpret
Normal range
•PRI- 0.12-0.20 seconds
•QRS- 0.04-0.12 seconds
•QT- Females- 340-400 MS
Males- 330-390 MS
• Prolonged QT segment begins over the limit of gender
Numbers?
18. •Can be typical or atypical
•Caused by CAD
•Can also be caused by coronary artery spasms
•Angina is brought on by stress, vigorous activity or by nothing at all
•Typical presents with frequency and is predictable
•Atypical presents with no rhyme or reason and is often not relieved by nitro
or positioning
•Regardless of the cause, all angina patients need a 12 lead to rule out STEMI
•CAD is the leading cause of STEMI in the WORLD
Angina
21. • Lie Lie Say All
• Alternative to diagnosis of 12 lead
• Not often used but other providers will use this method alone, or in
conjunction with ISAL to determine proper diagnosis
• Follows the appropriate pattern of 12 lead without skipping over additional
leads for completion
• For remainder of the slides, we will be looking at BOTH methods for
determination using ISAL as primary
“LII-LI-SSA-ALL”
22. Arteries of Viewing
• The "LCX", or left circumflex artery is an artery of the heart. It follows the left part of the coronary sulcus,
running first to the left and then to the right, reaching nearly as far as the posterior longitudinal sulcus. Can also
include the low lateral leads V5-V6
• The right coronary artery originates above the right cusp of the aortic valve, travels down the right atrioventricular
groove, and branches into the posterior descending artery and the right marginal artery.
• The left coronary artery arises from the aorta above the left cusp of the aortic valve and feeds blood to the left side
of the heart. It is also known as the left main coronary artery and the left main stem coronary artery. An occlusion
to this artery is often called “the widowmaker”.
24. Inferior Leads
• Leads II, III, and AVF
• Reflect the circuit flow of the inferior/
partial posterior of the heart
• Main focus on RCA and additional
arterial flow from the same
25. Septal Leads
• Leads V1 and V2
• Views the junction/bifercation
of the LAD and Circumflex
artery
• Most proximal portion of the
left and right coronary arteries
26. Anterior Leads
• V3 and V4
• Most anterior portion of the
LAD
• Often defined as the
“widowmaker”
• 27% mortality rate
• Supplies the greatest amount
of blood to the largest muscle
portion of the heart
27. Lateral Leads
• V5 and V6
• Most distal portion of the
LAD and attached arterial
flow
28. Reciprocal Leads
• Any lead or group of leads that oppose primary lead viewed
• Not needed or necessary to presume infarction or diagnose a STEMI
• Strong confirmation of STEMI when present
• Can NOT be used as a “rule out” option
31. J-Point
• Determined by the Joining of
the QRS and ST segment
• Can be elevated or depressed
• Sometimes is hard to
determine location
• Follow the standard rules of
interpretation to find the J-
Point
32. J-Point
• With all 12 lead interpretation of suspected ischemia or infarction, first
find the J-Point on the most Isoelectric lead
• Remember that the J-Point is the connection of the S wave and the T
wave.
33. J-Point
• Once you find the J-Point, simply draw a line through the 12 all
leads and connect the J-Points
34. • Technically defined as any negative deflection that precedes an R wave
• It does not have to be a negative deflection to be present however.
• The Q-wave can be isoelectric
• Q-wave represent normal left to right depolarization of the interventricular
septum
• Most commonly seen in lateral leads (I, AVL, V5, V6)
• Not normal variant if seen in anterior septal leads (V1-V4)
• Most common cause of q-wave pathology and presence in anterior septal
leads is incorrect limb lead placement
Q-wave pathology
35. • Presence of pathological q-waves usually indicate current or prior
myocardial infarction
• Q-wave is considered pathological if:
> 40ms wide
> 2mm deep
> 25 % of the QRS complex
Seen in the anterior septal leads
• If any of these are seen and there is no ST elevation or depression, a high
probability of prior MI is present.
• Can be seen in hypertrophic cardiomyopathy and myocardial rotation as
well
Pathological Q-Wave
36. Pathological Q-Wave
> 40ms wide
> 2mm deep
> 25 % of the QRS complex
Seen in the anterior-septal
leads
The pathological Q-Wave
will NOT form until 1-2
hours into a STEMI. If it’s
presence is there, you now
know how much time the
muscle has been infarcting.
38. Ischemia VS. Infarction
• Ischemia is noted by ST-Depression
• Infarction is noted by ST-Elevation
• The higher the ST-Elevation, the worse
the infarction is
• Reciprocal change is known as the area
of ischemia opposite area of infarction
• As shown in the figure, infarction has
an evolution from start to finish of the
area
• Once the evolution is finished, the
cardiac muscle is PERMANENTLY
damaged
• Best pre-hospital treatment is MONA
• Morphine
• Oxygen
• Nitro
• Aspirin
39. • ST-elevated myocardial infarction
• Must be at least 1 mm elevation in 2 CONTIGUOUS leads
• Contiguous leads are any set of leads the reflect the same area, or are next
to the same area
STEMI
• *V6 and Lead I are contiguous*
• V2 and V3
• V4 and V5
41. ST Elevation Patterns
ST elevation in stemi can be reflected either concave,
convex, or obliquely straight
42. • *Smile for me*- The smile of the st-segment means NO STEMI
• *Frown means down*- The frown is in indication or st-segment elevation
STEMI
43. • Area of infarction is reflected by the area of ST-Elevation
• Reciprocal changes are NOT needed to diagnose a STEMI in the field
• Be careful of the STEMI mimickers
• As long as you have 1 mm elevation in 2 or more CONTIGUOUS leads, a
STEMI can be diagnosed
STEMI-Location
44. Inferior MI
• ST-Elevation in leads II,III, and AVF
• Reciprocal changes in leads I and AVL
KEY NOTE!!!
Inferior AMI have shown an 88% probability to lead with either an
Inverted or depressed AVL PRIOR to the infarct presenting.
•If AVL is inverted or depressed, an AMI may be on the way
45. Septal MI
• Elevation in leads V1 and V2
• Note elevation in anterior leads as well
• Septal most often present in anterior MI as well
• Reciprocal changes noted?
46. Anterior MI
• ST-Elevation noted in leads V3 and V4
• Note the elevation in leads V1 and V2
• Anterior and Septal mi often correlate with each other
• Reciprocal changes?
48. • Universal in nature
• Deep, depressive, substernal chest pain/
pressure not relieved or reproducible
• Levine sign
• Pain in left or right arm, shoulders,
neck, jaw
• Weakness upon exertion
• Nausea
• Diaphoresis
• Ashen grey skin
• Rule of thumb, if pain above the naval,
do a 12 lead
Classic Presentation
49. Inferior Presentation
• In majority of population, 90% SA and AV node blood flow comes from the
RCA
• Conduction deficits/ delays
• Brady-arrhythmias
• Sinus Bradycardia
• Sinus Exit Block
• 1st degree heart block
• Hypotension
• Treat hypotension with fluid but DO NOT OVERTREAT
• May result in pulmonary edema
• Morphine and Nitro combined will drop pressure, both vasodilate
• Treat but keep pressure sustainable for cognition
50. • Most often the LCA occluded partially or fully
• Dull pressure that turns to crushing chest pain
• Pain radiates into the left arm
• Numbness or tingling sensation in fingers
• Pt may appear ashen grey or diaphoretic
Septal Presentation
51. • LCA / Circumflex occlusion, may be both
• Crushing, substernal chest pain
• Pain radiating into the left arm, right arm, or both
• Pain may appear in the shoulders and jaw
• Nausea
• Vomiting
• Diaphoresis
• Tingling or complete numbness in the fingers
• Shortness of breath
• Weakness upon exertion of any kind
• Near syncopal or positive syncopal episodes
• “Feeling of impending doom”
Anterior Presentation
52. • May have a combined presentation of both Anterior and Inferior wall MI
• Weakness upon exertion
• Pain radiating to one or both arms
• Syncope or near syncopal episodes
• Hypotension
• Brady-arrhythmias
• New heart blocks
• Most common presentation of new Bundle Branch Blocks
Lateral Presentation
53. Combination STEMI
• STEMI can occur in more than 1 area
• A “combination STEMI” is a STEMI that has ST-elevation in more than the
traditional leads yet are still contiguous
• Anterioseptal STEMI- Anterior and septal lead have ST-Elevation
• Anteriolateral STEMI- Anterior and lateral leads have ST-Elevation
• Inferiolateral STEMI- Inferior and lateral leads have ST-Elevation
• Global AMI- ALL leads have ST-Elevation other than AVR which will be
depressed
• Some STEMIs will have more than one area with additional involvement
• Eg- “Anterioseptal with lateral involvement”
• This indicates that the elevation is continuing through more than 1 area or
view of the 12 lead
57. • Continue to monitor ABC
• Initiate IV if available
• Continue with serial 12 leads
• ASA is a NESSICITY
• O2 via cannula (wave form capnography if indicated)
• IV fluid to maintain adequate blood pressure
• Nitro PRN
• Morphine is indicated for pain management
• Rapid transport to PCI facility
Treatment
58. • Obtain SAMPLE and OPQRST
• Be prepared for the worst
• AMI is the most common cause of acute Congestive Heart Failure
• Treat with CPAP if indicated (bp, hr, waveform capnography)
• Be cautious with Morphine and Nitro especially in Inferior AMI due to
rapid decrease in blood pressure
• Be cautious with patient allergic to aspirin
• Notify the receiving hospital early of STEMI activation and expected
arrival time
• Note area of infarct and ischemia/ reciprocal changes if available
• Remember you DO NOT have to have reciprocal changes to diagnose a
stemi
Considerations
59. • STEMI MIMICKERS!!
• TOP 6
LVH
LBBB
Hyperkalemia
Early Repolarization
Pericarditis
PACED
Could it be?
60. • Left Ventricular Hypertrophy
• Left ventricle is larger requiring more electrical conduction to depolarize
• This results in a longer QRS complex than normal
• Seen in the precordial leads
• Determination is selective
• Find largest QRS complex in either lead V1 or V2
• Add to the largest complex in lead V5 or V6
• If the number is greater than 30 mm, LVH is present
• If the largest QRS complex in V1 or V2 is greater than 30, LVH is present
LVH
61. •Most often referred to as athletic heart syndrome
•Often caused by aerobic exercise and strength training
•Is not a disease
•Is usually a marker for disease
•Any disease that causes an increase in afterload over time that causes the
heart to increase contractility strength, therefore increasing the myocardium
•Causes are referred to as hypertrophic cardiomyopathies
Aortic stenosis
Aortic insufficiency
Chronic hypertension
LVH
63. • Left Bundle Branch Block
• Left main conduction path is injured or blocked
• This results in a “lightning” effect
• The current must come back and re-route itself down the left ventricle to
complete conduction in the myocardium
• QRS must be negative deflection in lead V1 and greater than 0.12 ms
(3 small boxes)
• Was considered impossible to diagnose a STEMI in the presence of a
LBBB
• Sgarbossa criteria now used to diagnose STEMI when LBBB is present
LBBB
66. • LBBB
• Can NOT call STEMI w/o
sgarbossa
• Negative deflection in V1
• QRS greater than 0.12
• May or may not present with R
prime wave
LBBB vs RBBB
• RBBB
• CAN call a STEMI
• Positive deflection in V1
• QRS greater than 0.12 ms
• Typically presents with R prime
wave (RsR)
67. • Clinical presentation
• Nausea
• Dyspnea
• Fatigue and weakness
• Chest pain
• Muscle paralysis
• Parasthesias
• Palpitations
• Absent DTR
• New LBBB
• Late signs include- bradycardia, lethargy/ unconsciousness, bradypnea, flat
t-waves, death
Hyperkalemia
69. • Increased serum potassium levels in the blood
• Often found in renal impaired/ failure patients
• ECG reflects peaked T waves
• Pay close attention to the QRS segment as it will begin to get wider
• Do NOT confuse this with hypernatremia where the QRS remains the same
or gets more NARROW as the T waves begin to peak
Hyperkalemia
71. • Goal is to displace potassium and sodium in the blood
• REMEMBER THE SODIUM POTASSIUM PUMP
• Influx of sodium will offset the higher potassium load to be reabsorbed into the
kidneys for excretion
• IV access (bilaterally if available)
• CBIGKD
• Calcium gluconate
• Bicarbonate
• Insulin
• G (glucose) D50
• Kayexalate- Sodium polystyrene sulfonate. If total body potassium is an issue
• Dialysis
Hyperkalemia Treatment
72. • Typically seen in adolescent males who lead a physically active life
• May present in any male under 50
• Also called “high J-point” or “early take off”
• Etiology is still not completely understood but was once believed to be
benign in possibility of cardiac disease. This is no longer the case.
• More recent reports have suggested an association between ER and an
increased risk for arrhythmic death and idiopathic ventricular fibrillation
• Some level of increased risk of sudden cardiac death has been reported in
persons with ER.
Early Repole (not so benign)
73. • The relatively high prevalence of the ER pattern in the general population
(5 to 13 percent) in comparison to the incidence of idiopathic VF
(approximately 10 cases per 100,000 population) means that the ER pattern
will nearly always be an incidental ECG finding with no clinical
implications.
• A primary arrhythmic disorder such as idiopathic VF due to ER is far more
likely when associated with syncope or resuscitated sudden cardiac death
in the absence of other etiologies
• If seen in males 50-70, consider acute infarct
• Rarely seen in patients over 70
Early Repole (not so benign)
74. • Presentation
• PR depression
• St depression in AVR with T wave inversion
• Barbed “fish hook” appearance as a J-point with ST elevation in all leads
Early Repole cont.
75. Early Repole
•“Barbed fish hook” appearance on the ST segment
•Will almost always have ST depression and inverted T wave in AVR
76. • Clinical presentation
• Chest pain radiating to the back that is typically relieved by sitting forward
(to relieve pressure on the myocardium)
• Dry cough
• Fever
• Fatigue
• History of infection
• SHARP chest pain
• Often clinically misdiagnosed as STEMI
• Diffuse ST-elevation
• Often with Pr-depression
• Most commonly presents with t-wave inversion or ST depression in AVR
Pericarditis
78. •Very common STEMI mimicker
•Additional voltage used to supercharge the muscles externally for cardiac
contraction
•Often results in elevation and depression
Paced Rhythm
79. • A numerical representation of the MAJOR direction of electrical flow
through myocardium
• Ranges from 0 to -180 degrees
• Proper range is from -30 to +90
• Referred to as “normal axis”
• Deviation from the normal axis is referred to as “axis deviation” (go figure
right?)
• Deviation can be physiological, pathological or extreme
• Extreme is a significant sign of life threatening cardiac abnormality or
rhythm
The Axis
81. • Several methods are in use today, we will focus on these 3
• Quadrant method
Utilizes lead I and AVF
• Lead method
Utilizes Lead I and II
Tri-lead method
• Utilizes leads I, II, and III
Determining Axis
82. • LEAD I LEAD AVF QUADRANT AXIS
• Positive Positive Left Lower Quadrant Normal
• Positive Negative Left Upper Quadrant Possible LAD
• Negative Positive Right Lower Quadrant RAD
• Negative Negative Right Upper Quadrant ERAD
Quadrant Method
83. Quadrant Method
• Lead I- Positive
• Lead AVF- Positive
• Quadrant- Lower Left
• Axis- Normal
84. Quadrant Method
• Lead I- Positive
• Lead AVF- Negative
• Quadrant- Left Upper
• Axis- LAD
85. Quadrant Method
• Lead I- Negative
• Lead AVF- Positive
• Quadrant- Right Lower
• Axis- RAD
86. Quadrant Method
• Lead I- Negative
• Lead AVF- Negative
• Quadrant- Right Upper
• Axis- ERAD
87. • Determined by looking at leads I and II
• If the QRS is positive in lead I, it is roughly in the same direction as lead I
• If the QRS is in the same direction as lead II, it puts the axis in roughly the
same direction of lead II
• If leads I and II are BOTH positive, it places the axis in the area of -30 and
+ 90, meaning normal axis variant
Lead Method
88. •Also referred to as the “rapid-axis” method
•Utilizes the lead method with addition of lead III for better determination
TRI-Lead Method
89. • Left or Right
• Can be physiological or pathological
• Caused by a number of factors
Deviation
90. • May be a normal variant
• Conduction issues
Left anterior block
LVH
LBBB
Prior mechanical shift (surgery, lung disease, etc)
Inferior AMI
WPW
Idioventricular rhythms ie. V-tach or accelerated idioventricular
Atrial septal defects
LAD
91. • Causes
Left posterior fascicular block
RVH
Lung disease (acute or chronic)
Ventricular ectopy
Hyperkalemia
Sodium-channel blocker toxicity
WPW
May also be a normal variant for children or adults with mechanical
shifting of the heart
RAD
95. •ERAD- Extreme right axis deviation
•Physiological vs pathological LAD
•Physiological left axis deviation- typically between 0 and -30
•Pathological left axis deviation- -30 to -90
•Axis deviation can be skewed due to left or right bundle branch blocks
•Be careful when using axis for complete diagnosis as the number do not lie,
however they can confuse
Extreme Axis
96. •Often seen in wide complex tachycardias (V-tach)
•Is possible to have a wide complex tachycardia that mimics v-tach but
brought on by “F” waves (flutter waves)
Extreme Axis
99. •FINALLY!!
•Used to diagnose a STEMI in the presence of a LEFT bundle branch block
AND a paced rhythm
•Criteria simple to follow
•We as a prehospital provider in our local area can NOT utilize this tool as of
yet (2016)
•The criteria has increased in usage and accuracy for the past few years and is
being taught to medical providers globally
•The rules are continuing to be modified every year by new clinical evidence
and presentations
•What you learn today may NOT be in effect tomorrow
Sgarbossa Criteria
100. Sgarbossa Criteria:
• ST Elevation ≥ 1 mm and concordant with QRS complex
• ST segment depression ≥ 1 mm in lead V1, V2, V3
• ST elevation ≥ 5mm and discordant with QRS complex
•IF #1 and #2 are present, 98% probability of STEMI
•NEW rules has been added to update the parameters of Sgarbossa
•If positive concordance in ANY lead with the presence of a LBBB, Sgarbossa
criteria has been met
• ≥ 1 lead anywhere with ≥ 1 mm STE and proportionally excessive
discordant STE, as defined by ≥ 25% of the depth of the preceding S-wave
Sgarbossa
105. • Some common medications and drugs can cause cardiac arrhythmias
• Most over the counter medications are relatively harmless
• Stimulant drugs and medications are the most common type to cause an
arrhythmia (usually sinus tach)
• Illicit drug use can either speed up or slow down the heart
• Common household items can also cause an arrhythmia (fertilizer, cleaning
materials)
• Most drugs that stimulate the sympathetic nervous system can cause a short
lived arrhythmia, but will usually subside due to a relatively short half-life
Medication Problem?
106. • Caffeine
• Tobacco
• Alcohol
• Cold and cough medications
• Appetite suppressors (stimulants)
• ADHD medications
• Antiarrhythmic medications (paradoxical arrhythmias from medications)
• Tricyclic antidepressants
• Beta Blockers (primarily for blood pressure)
• Cocaine, marijuana, methamphetamines
Common medications and drugs
107. • Most stimulant drugs are dopaminergic (releasing or involving dopamine
as a neurotransmitter)
• These drugs will stimulate the release and inhibit the reuptake of
dopamine, leaving it at the synaptic cleft
• This leads to an increase in energy and a feeling of alertness and
concentration
• Norepinephrine is released as an additional catecholamine along with
dopamine which leads to the increase in heart rate and contractility
• If these drugs are taken too much or abused, the heart rate can increase to a
dangerous level
• The overstimulation of the sympathetic nervous system cause a fluctuation
and lowers parasympathetic response, this leads to an additional side effect
of not wanting to eat
Stimulants
111. • Increase levels of norepinephrine and serotonin
• Block the action of acetylcholine
• Can cause sedation and block histamines as well
• TCA have sodium-channel blocking properties which increase quickly in high
doses
• This causes a prolongation of the Q-T segment on an ECG
• Using the ECG and tracing the Q-T Segment can give you a better time frame
on potential cardiac arrhythmias
• Most common late stage arrhythmias are V-Fib and Torsades De Pointes
• Best initial treatment via IV is sodium bicarb, NOT for the sodium channel
issue alone but to alkalize the blood stream for protein synthesis and reduced
bioavailability of the drug
• This increases elimination of the drug
• Calcium Can be given as well (through a different, or well flushed line) to open
calcium channels and promote sodium availability
Tricyclics Cont
112. • A separate reason they are called “TCA’S”
• Mnemonic
• T-Thrombocytopenia- decrease in platelet count, increase in platelet
deficiency
• C-Cardiac- AMI, arrhythmia, stroke
• A-Anticholinergic effects- Exact opposite of SLUDGE, everything hot
• S-Seizures
• All signs and symptoms of TCA overdose
• Pay attention to the ECG changes during a suspected TCA overdose
Tricyclics Cont.
113. • Toxicity usually is apparent within the first hour after ingestion
• New onset of all complexes widening
• Prolonged PRI, QRS and QT segments
• Prolonged PRI is usually the latest sign and high indication of inevitable V-
Fib
• Prolonged QT is usually the first ECG change in an overdose
TCA ECG Changes
114. • These rules apply inconsideration of Sodium Channel Blocker overdose
• QRS > 100ms (0.10s) in lead II
• Terminal R wave in AVR > 3mm
• R-S ratio > 0.7s AVR
• Patients will often be Tachycardic however, the P waves will be hidden in
the prior T wave due to elongation of the PRI
TCA ECG Rules
116. •Gives additional views of the heart anterior and posterior
•Leads V7, V8, V9, V4R, V5R, V6R
•V7- between V6 and V8
•V8- Midscapular on the same line as V7 and V6
•V9- Between the spine and V8
•V4R- Midclavicular in opposite intercostal space as V4
•V5R- Between V4R and V6R on same plane
•V6R- Midaxillary right side
15 Lead / Right Sided Lead Placement
122. •12leads are not just for diagnostic properties of a STEMI
•Additional ectopy can be viewed and assist in a diagnosis for life threatening
ailments either acute or chronic
•Brugadas syndrome
•Acute pulmonary embolism
•Hypernatremia
•Right Ventricular Hypertrophy
•Dewinters STEMI
What is That?
123. •An aberrant conduction abnormality that causes sudden cardiac death
•Leading cause in SUDS (sudden unexplained death syndrome)
•Genetic abnormality of the sodium ion pump channels
•SCN5A- influx flow sodium ion channel that fails which results in prolonged,
untreatable V-fib
•Can be viewed on a 12 lead in the V-Leads
Brugadas Syndrome
124. •3 different types of ECG patterns
•Type 1 has a coved type ST elevation with at least 2 mm (0.2 mV) J-point
elevation a gradually descending ST segment followed by a negative T-wave
•Type 2 has a saddle back pattern with a least 2 mm J-point elevation and at
least 1 mm ST elevation with a positive or biphasic T-wave. Type 2 pattern
can occasionally be seen in healthy subjects
•Type 3 has either a coved (type 1 like) or a saddle back (type 2 like) pattern
with less than 2 mm J-point elevation and less than 1 mm ST elevation. Type 3
pattern is not rare in healthy subjects
Brugadas Syndrome
126. Brugadas Syndrome 1
Coved type ST elevation with at least
2 mm (0.2 mV) J-point elevation a
gradually descending ST segment
followed by a negative T-wave
127. Brugadas Syndrome 2
Saddle back pattern with a least
2 mm J-point elevation and at least
1 mm ST elevation with a positive
or biphasic T-wave. Type 2 pattern
can occasionally be seen in healthy
subjects
128. Brugadas Syndrome 3
Either a coved (type 1 like) or a
saddle back (type 2 like) pattern
with less than 2 mm J-point
elevation and less than 1 mm ST
elevation. Type 3 pattern is not rare
in healthy subjects
129. •The clot that won’t break
•Usually acute in nature with severe difficulty breathing though lungs are
clear
•Often misdiagnosed and treated due to its acute nature and inability of the
prehospital provider to administer fibrinolytics or perform surgery to remove
the clot
•If suspected, look at the 12 lead
•Deemed “S1, Q3, T3”
•Also known as McGinn-White sign
Acute PE
130. Acute PE
•Large deflection of the S wave in lead I
•Presence of a Q wave in lead III
•Inverted T wave in lead III
•Signals the presence of right heart strain
due to overuse/ occlusion of Pulmonary
Artery
131. •Often seen in the elderly
•Hypokalemia can mimic hypernatremia and vise versa
•Serum potassium levels may be normal in comparison to the sodium levels
•Initially present the same way in a 12 lead but subtle differences can be
examined
•Always obtain a SAMPLE from EVERY patient to determine the nature of
the 12 lead
•Hypernatremia begins to present with prolonged QT segments due to the
delay in repolarization from the potassium influx
•This is the PRIMARY difference between Hypokalemia and Hypernatremia
Hypernatremia
134. •Right ventricular hypertrophy
•Increase in myocardium of the right ventricle
•Often caused by
Pulmonary hypertension
Tetrology of the fallot
Pulmonary valve stenosis
Pulmonic regurgitation
VSD
High altitude
Cardiac fibrosis
COPD
Athletic heart syndrome
RVH
135. •Peaked P wave in lead II
•Right axis deviation in the presence of disease that causes RVH
•R wave in AVR > 5mm OR
•R wave in AVR > Q in AVR
•ST segment depression AND T wave inversion in right precordial leads
•Any one of the following in V1
R/S ratio > 1 and negative T wave
qR pattern
R > 6mm, or S < 2mm, or rSR` with R` > 10mm
RVH
137. •The de Winter ECG pattern is an anterior STEMI equivalent that presents
without obvious ST segment elevation.
•Key diagnostic features include ST depression and peaked T waves in the
precordial leads.
•The de Winter pattern is seen in ~2% of acute LAD occlusions and is under-
recognised by clinicians.
•Unfamiliarity with this high-risk ECG pattern may lead to under-treatment
(e.g. failure of cath lab activation), with attendant negative effects on
morbidity and mortality.
DeWinters STEMI
138. •Tall, prominent, symmetric T waves in the precordial leads
•Upsloping ST segment depression >1mm at the J-point in the precordial leads
•Absence of ST elevation in the precordial leads
•ST segment elevation (0.5mm-1mm) in aVR (told yeah it wasn’t useless)
•“Normal” STEMI morphology may precede or follow the deWinter pattern
DeWinters Criteria
139. •MAY present atypically with no symptoms of cardiac issues
•Most common complication of Diabetes is CAD
•Many patients with Diabetes present with no angina or “silent” AMI
•This is primarily found in patients with persistent higher than normal levels
of serum glucose
•Most often these patients with have “diabetic nerve pain” and will not be able
to feel the consistent pressure from angina due to either the medications they
take, the exact location of nerve damage, the bodies pH, the particular tissue
involved and ability to function homeostatically, or prior injury resulting in
dead or weakened nerve supply to the area.
Diabetes
141. •Remember to always do a SAMPLE/ OPQRST on your patients
•Make sure the leads go on the appropriated areas for the best picture possible
•Remember the difference between benign elevation and malignant elevation
•A smile is what we want, frowns are bad
•Each lead reflects a particular section of the heart, if you need other angles
the 15 lead can very useful
•Not every STEMI will show up, but it may be calculated with the numbers
provided by the machine
•Some STEMIs are NOT STEMIs, at least 6 you know can be false
•Sgarbossa may change criteria, but the single concordant lead will remain
•12 leads can help you determine a course of action for treatment if all else
gives no answers
Summary
