CT detectors
•Download as PPTX, PDF•
17 likes•6,038 views
The document discusses the key components of a CT scanner, including the gantry, data acquisition system (DAS), computer, and storage. It describes the detectors and data conversion process in the DAS, including scintillation and gas-filled detectors. Scintillation detectors were improved by replacing photomultiplier tubes with photo cathode assemblies, allowing for smaller size, lower cost, and not requiring separate power supplies. Common scintillation crystals mentioned include sodium iodide, bismuth germinate, cesium iodide, and cadmium tungstate. Gas-filled detectors provide similar efficiency and are constructed with large metallic chambers separated by approximately 1mm baffles. Examples of gases used include xenon
