2. Learning Objectives
Define layout planning and its importance
Identify and describe different types of layouts
Compare process layouts & product layouts
Describe the steps involved in designing both
process and product layouts
Explain the advantages of hybrid layouts
Define the meaning of group technology & its
importance to cellular layouts
3. What Is Layout Planning
Layout planning is determining the best
physical arrangement of resources
within a facility
Two broad categories of operations:
Intermittent processing systems
Continuous processing systems
4. Types of Layouts
Process layouts:
Group similar resources together
Product layouts:
Designed to produce a specific product efficiently
Hybrid layouts:
Combine aspects of both process and product layouts
Fixed-Position layouts:
Product is two large to move; e.g. a building
5. Process Layouts
General purpose & flexible resources
Lower capital intensity & automation
Higher labor intensity
Resources have greater flexibility
Processing rates are slower
Material handling costs are higher
Scheduling resources & work flow is more
complex
Space requirements are higher
6. Product Layouts
Specialized equipment
High capital intensity & wide use of
automation
Processing rates are faster
Material handling costs are lower
Less space required for inventories
Less volume or design flexibility
7. Hybrid Layouts
Combine elements of both product &
process layouts
Maintain some of the efficiencies of product
layouts
Maintain some of the flexibility of process
layouts
Examples:
Group technology & manufacturing cells
Grocery stores
8. Comparison of Product vs. Product Layouts
Process Layouts Product Layouts
Products: large #, different small # efficiently
Resources: general purpose specialized
Facilities: more labor intensive more capital intensive
Flexibility: greater relative to market lower relative to market
Processing slower faster
Rates:
Handling costs: high low
Space requirements: higher lower
9. Designing Process Layouts
Step 1: Gather information:
Space needed, space available, importance of
proximity between various units
Step 2: Develop alternative block plans:
Using trial-and-error or decision support tools
Step 3: Develop a detailed layout
Consider exact sizes and shapes of departments
and work centers including aisles and stairways
Tools like drawings, 3-D models, and CAD
software are available to facilitate this process
10. Process Layout Steps
Step 1: Gather information like space needed, from-to matrix,
and REL Chart for Recovery First Sports Medicine Clinic (total
space 3750 sq. ft.)
A B C
Radiology Laboratory Lobby &
Waiting
400 sq. ft. 300 sq. ft. 300 sq. ft.
D E F
Examining Surgery & Physical
Rooms Recovery Therapy
800 sq. ft. 900 sq. ft. 1050 sq. ft.
12. Step 2: Develop a New Block Layout
Use trial and error with
from-to and REL Charts as a guide
Use computer software like ALDEP
or CRAFT
13. Warehouse Layouts
Warehouse Layout Considerations:
Primary decision is where to locate each department
relative to the dock
Departments can be organized to minimize “ld”
totals
Departments of unequal size require modification of
the typical ld calculations to include a calculation
of the “ratio of trips to area needed”
The usage of “Crossdocking” (see Ch.4) modifies
the traditional warehouse layouts; more docks, less
storage space, and less order picking
14. Office Layouts
Office Layout Considerations:
Almost half of US workforce works in an office
environment
Human interaction and communication are the primary
factors in designing office layouts
Layouts need to account for physical environment and
psychological needs of the organization
One key layout trade-off is between proximity and
privacy
Open concept offices promote understanding & trust
Flexible layouts incorporating “office landscaping” help
to solve the privacy issue in open office environments
15. Designing Product Layouts
Step 1:
Identify tasks & immediate predecessors
Step 2:
Determine the desired output rate
Step 3:
Calculate the cycle time
Step 4:
Compute the theoretical minimum number
of workstations
Step 5: Assign tasks to workstations (balance the
line)
Step 6: Compute efficiency, idle time & balance
delay
16. Step 1: Identify Tasks &
Immediate Predecessors
Example 10.4 Vicki's Pizzeria and the Precedence Diagram
Immediate Task Time
Work Element Task Description Predecessor (seconds
A Roll dough None 50
B Place on cardboard backing A 5
C Sprinkle cheese B 25
D Spread Sauce C 15
E Add pepperoni D 12
F Add sausage D 10
G Add mushrooms D 15
H Shrinkwrap pizza E,F,G 18
I Pack in box H 15
Total task time 165
17. Layout Calculations
Step 2: Determine output rate
Vicki needs to produce 60 pizzas per hour
Step 3: Determine cycle time
The amount of time each workstation is allowed to
complete its tasks
available time ( sec./day ) 60 min/hr x 60 sec/min
Cycle time (sec./unit) = = = 60 sec./unit
desired output ( units/hr ) 60 units/hr
Limited by the bottleneck task (the longest task in a
process):
available time 3600 sec./hr.
Maximum output = = = 72 units/hr, or pizzas per hour
bottleneck task time 50 sec./unit
18. Layout Calculations (continued)
Step 4: Compute the theoretical minimum
number of stations
TM = number of stations needed to
achieve 100% efficiency (every second is
used)
TM =
∑ ( task times ) = 165 seconds
= 2.75, or 3 stations
cycle time 60 sec/station
Always round up (no partial workstations)
Serves as a lower bound for our analysis
19. Layout Calculations (continued)
Step 5: Assign tasks to workstations
Start at the first station & choose the longest eligible task following
precedence relationships
Continue adding the longest eligible task that fits without going over the
desired cycle time
When no additional tasks can be added within the desired cycle time, begin
assigning tasks to the next workstation until finished
Workstation Eligible task Task Selected Task time Idle time
A A 50 10
1
B B 5 5
C C 25 35
2 D D 15 20
E, F, G G 15 5
E, F E 12 48
F F 10 38
3
H H 18 20
I I 15 5
20. Last Layout Calculation
Step 6: Compute efficiency and balance delay
Efficiency (%) is the ratio of total productive
time divided by total time
Efficiency (%) =
∑t = 165 sec.
( 100) = 91.7%
NC 3 stations x 60 sec.
Balance delay (%) is the amount by which the
line falls short of 100%
Balance delay = 100% − 91.7% = 8.3%
21. Other Product Layout Considerations
Shape of the line (S, U, O, L):
Share resources, enhance communication &
visibility, impact location of loading &
unloading
Paced versus un-paced lines
Paced lines use an automatically enforced
cycle time
Single or mixed-model lines
22. Designing Hybrid Layouts
One of the most popular hybrid layouts uses Group
Technology (GT) and a cellular layout
GT has the advantage of bringing the efficiencies of a
product layout to a process layout environment
25. Chapter 10 Highlights
Layout planning is deciding on the best physical
arrangement of resources.
There are four basic types of layouts: process,
product, hybrid, and fixed position.
Process layouts provide flexibility to make a
variety of different products. Product layouts
provide greater efficiency for one product.
The steps for designing process layouts are:
gather space and closeness information, develop a
block plan, and develop a detailed layout.
26. Chapter 10 Highlights (continued)
The steps for designing an product layout are:
identify tasks and predecessors, determine output
rate, determine cycle time, computing the
theoretical minimum number of work stations,
assigning tasks to workstations, and computing
efficiency and balance delay.
Hybrids layouts combine elements from both types
of layouts to increase efficiency.
Hybrid layouts combine GT analysis with cellular
layout concepts .
