1. LECTURE - 8
BOOLEAN FUNCTIONS
&
ALGEBRAIC MANIPULATIONS

2. BOOLEAN FUNCTIONS
■ EXPRESSIONS that contain:
– Binary Variables
■ Values = 0,1
– Binary Operators
■ OR, AND, NOT
– Parenthesis * Optional
– Equal Sign
F = xy’ + x’z

3. F = xy’ + x’y
x y x’ y’ x.y’ x’.y F
0 0 1 1 0 0 0
0 1 1 0 0 1 1
1 0 0 1 1 0 1
1 1 0 0 0 0 0

4. SIMPLIFICATION USING BOOLEAN
ALGEBRA
■ Simplification of Boolean Expressions may be done using:
– Laws / Postulates
– Rules
– Theorems

5. Advantage of Simplification
■ Fewer Variables
■ Simpler Circuit

6. EXAMPLE
F = A.B + A.(B+C) + B.(B+C)
Total No. of Gates = 5
A
B
C
A.B
A.(B+C)
B.(B+C)
F

7. Simplification of
F = A.B + A.(B+C) + B.(B+C)
F = A.B + A.(B+C) + B.(B+C)
= AB + AB + AC + BB + BC
= AB + AC + B + BC
= AB + AC + B (1 + C)
= AB + AC + B (1)
= AB + AC + B
= AB + B + AC
= B (A + 1) + AC
= B (1) + AC
= B + AC

8. SIMPLIFIED OUTPUT:
F = B + AC
Circuit Diagram
A
B
C
A.C
B
F = B + AC
Total No. of Gates = 2

9. MORE EXAMPLES
1. x + x’y
2. x (x’+y)
3. x’y’z + x’yz + xy’
4. xy + x’z + yz
5. (x+y).(x’+z).(y+z)
6. y (wz’ +wz) + xy

10. SOLUTIONS TO EXAMPLES
1. x+y
2. xy
3. x’z+xy’
4. xy+x’z
5. x’y+xz
6. y (x+w)

11. CIRCUIT DIAGRAMS
HOMEWORK:
Draw the Circuit Diagrams of the
examples
