It is a mathematical modelling of computation that is extensively used for designing both computer programs as well as sequential logic circuits and can be perceived as an intellectual machine in one of a finite number of states. Copy the link given below and paste it in new browser window to get more information on Finite State Machine:- http://www.transtutors.com/homework-help/computer-science/finite-state-machines.aspx

1. Finite string matching consists of states, inputs and
outputs.

2. In a Finite State Machine diagram:
1. States are represented by circle.
2. Transitions are represented by an arrow and are labeled with an input causing
the transition.
3. An accepted state is represented by a double circle.
TRANSITION 1
TRANSITION 2
TRANSITION 3
TRANSITION 4

3. Finite State Machine Diagram:

4. In the above diagram it starts in state S1, an input of A will keep it in state S1 and an input of
B will move it to state S2.
Once it is in S2 an input of A will keep it there, and an input of B will switch it back to S1.
This means that the following inputs are valid:
AABBAABBA
BBAAABBAA

5. Example of Finite State Machine
Turnstile is an example of a mechanism modeled on finite state machine used to control
the access at the entrance gate of an amusement park or museum with three arms that
rotates at waist height.

6. Finite State Machine state transition table representing state of Turnstile
Current State Input Next State Output
Locked Token Unlocked Turnstile unlocked for entry
Push Locked None
Unlocked Token Unlocked None
Push Locked After one entry Turnstile locked again.

7. Hey Friends,
This was just a summary on Finite State Machine. For more detailed
information on this topic, please type the link given below or copy it from the
description of this PPT and open it in a new browser window.
http://www.transtutors.com/homework-help/computer-science/finite-state-
machines.aspx
