1. Evolution of Apache Spark
Journey of Spark in 1.x series

2. ● Madhukara Phatak
● Technical Lead at Tellius
● Consultant and Trainer at
datamantra.io
● Consult in Hadoop, Spark
and Scala
● www.madhukaraphatak.com

3. Agenda
● Spark 1.0
● State of Big data
● Change in ecosystem
● Dawn of structured data
● Working with structured sources
● Dawn of custom memory management
● Evolution of Libraries

4. Spark 1.0
● Release on May 2014 [1]
● First production ready, backward compatible release
● Contains
○ Spark batch
○ Spark streaming
○ Shark
○ MLLib and Graphx
● Developed over 4 years
● Better hadoop

5. State of Big data Industry
● Map/Reduce was the way to do big data processing
● HDFS was primary source of the data
● Tools like Sqoop developed for moving data to hdfs and
hdfs acted like single point of source
● Every data by default assumed to be unstructured and
structure was laid on top of it
● Hive and Pig were popular ways to do structured and
semi structured data processing on top of Map/Reduce

6. Spark 1.0 Ideas
● RDD abstraction was supported to do Map/Reduce style
programming
● Primary source supported was HDFS and memory as
the speedup layer
● Spark-streaming viewed as faster batch processing
rather than as streaming
● To support Hive, Shark was created to generate RDD
code rather than Map/Reduce

7. Changes from 2014
● Big data industry has gone through many radical
changes in thinking in last two years
● Some of those changes started in spark and some other
are influenced by other frameworks
● These changes are important to understand why Spark
2.0 abstractions are radically different than Spark 1.0
● Many of these are already discussed in earlier meetups,
links to the videos are in reference

8. Dawn of Structured Data

9. Usage of Big data in 2014.
● Most of the people were using higher level tools like
Hive and Pig to process data rather using Map/Reduce
● Most of the data was residing in the RDBMS databases
and user ETL data from mysql to hive to query
● So lot of use cases were analysing structured data
rather than basic assumption of unstructured in big data
world
● Huge time is consumed for ETL and non optimized
workflows from Hive

10. Spark with Structured Data in 1.2
● Spark recognised need of structured data in the market
and started to evolve the platform to support that use
case
● First attempt was to have a specialised RDD called
SchemaRDD in Spark 1.2 which represented that
schema
● But this approach was not clean
● Also even though there was InputFormat to read from
structured data, there was no direct API to read from
Spark

11. DataSource API in Spark 1.3
● First API to provide an unified API to read from
structured and semi structured sources
● Can read from RDBMS, NoSql databases like
Mongodb,Cassandra etc
● Advanced API like InputFormat which gives lot of
control to source to optimize locality of data
● So in Spark 1.3, spark addressed the need of structured
data being first class in Big data ecosystem
● For more info refer to, Anatomy of DataSource API talk[2]

12. DataFrame abstraction in Spark
● Spark understood modifying the RDD abstraction is not
good enough
● Many frameworks like Hive, Pig tried and failed mapping
querying efficiently on Map/Reduce
● So Spark came up with Dataframe abstraction which
goes through a complete different pipeline that of RDD
which is highly optimized
● For more info refer to, Anatomy of DataFrame API talk [3]

13. Evolution of InMemory processing

14. In memory in Spark 1.0
● Spark was the first open source big data framework to
embrace in memory computing
● With cheaper hardware and abstractions like RDD
allowed spark to exploit memory in efficient way than all
other hadoop ecosystem projects
● The first implementation of in memory computing
followed typical cache approach of keeping serialized
java bytes
● This proved to be challenging in future

15. Challenges of in memory in Java
● As more and more big data frameworks started to
exploit memory, soon they realised few limitation of
Java memory model
● Java memory is tuned for short lived objects and
complete control of memory is given to JVM
● But big data system started using JVM for long term
storage, JVM memory model started feel inadequate
● Also as java heap grew, to cache more data, GC
pauses started to kill performance

16. Custom memory management
● Apache Flink is first big data system to implement
custom memory management in java
● Flink follows Dataframe like API with custom memory
model
● The custom memory model with non GC based
approach proved to be highly successful
● By observing trends in community, optly Spark also
adopted same in Spark 1.4

17. Tungsten in Spark 1.4
● Spark release first version of custom memory
management in 1.4 version
● It was only supported DF as they need custom memory
model
● Custom memory management greatly improved use of
spark in higher vm size and fewer GC paused
● Solved OOM issues which plagued earlier versions of
spark
● For more info refer to, Anatomy of In memory
management in Spark talk [4]

18. DSL’s for data processing

19. RDD and Map/Reduce API API
● RDD API of spark follows functional programming
paradigm which is similar to Map/Reduce
● RDD API passes around opaque function objects which
is great for programming but bad for system based
optimization
● Map/Reduce API of Java also follows same patterns but
less elegant than scala ones
● Hard to optimise compared to Pig/Hive
● So we saw a steady increase in custom DSL’s in
hadoop world

20. Need of DSL’s in Hadoop
● DSL’s like Pig or Hive are much more easier to
understand compare to Java API
● Less error prone and helps to be very specific
● Can be easily optimised, as DSL only focuses on what
to do not how to do
● As Java Map/Reduce mixes what with how, it’s hard to
optimize compare to Hive and Pig
● So more and more people prefered these DSL over
platform level API’s

21. Challenges of DSL in Hadoop
● Hive and Pig DSL do not integrate well with
Map/Reduce API’s
● DSL often lack the flexibility of complete programming
language
● Hive/Pig DSL don’t define single abstraction to share so
you will be not able mix
● DSL are powerful for optimization but soon become
limited in terms of functionality

22. Scala as language to host DSL
● Scala is one of the first language to embrace DSL as
the first class citizens
● Scala features like implicits, higher order functions,
structured types etc allow easily build DSL’s and
integrate with language
● This allows any library on scala to integrate DSL and
harness full power of language
● Many libraries define their own DSL outside big data. Ex
: Slick, Akka-http, Sbt

23. DF DSL and Spark SQL DSL
● To harness power of custom memory management and
hive like optimizes spark encourages to write DF and
spark sql DSL over spark RDD code
● Whenever we write this DSL, all the features of scala
language and its libraries are available,which makes it
more powerful that Pig/ Hive
● Other frameworks like Flink, Beam follow same ideas on
scala, Java 8 etc
● You can easily mix and match DSL with RDD API

24. Dataset DSL in Spark 1.6
● Dataframe DSL introduced in 1.4 and stabilised in 1.5
● As spark observed the user and performance benefits of
DSL based programming, it wanted to make as import
pillar of Spark
● So in Spark 1.6, Spark released Dataset DSL which is
poised to complete RDD API from user land
● This indicates a big shift in thinking as we are more and
more moving away from 1.0 Map/Reduce and
unstructured mindset.

25. Evolution of Libraries

26. Evolution of libraries vs frameworks
● Spark is one of the first big data framework to build
platform rather than collection of frameworks
● Single abstraction results in multiple libraries not
multiple frameworks
● All these libraries get benefits from the improvements in
run time
● This made spark to build lot of ecosystem in very less
time
● To understand the meaning of platform, refer to
Introduction to Flink talk [5]

27. Data exchange between Libraries
● As more and more libraries are added to spark, having
common way to exchange data became important
● Initially libraries started using RDD as data exchange
format, but soon discovered some limitations
● Limitations of RDD as data exchange format is
○ No defined schema. Need to come up with domain
object for each library
○ Too low level
○ Custom serialization is hard to integrate

28. DataFrame as data exchange format
● From last few release, spark is making Dataframe as
new data exchange format of Spark
● Dataframe has schema and can be easily passed
around between libraries
● Dataframe is higher level abstraction compared RDD
● As Dataframe are serialized using platform specific
code generation, all libraries will be following same
serialization
● Dataset will follow the same advantages

29. Learnings from Spark 1.x
● Structured/Semi structured data is the first class of Big
data processing system
● Custom memory management and code generated
serialization gives best performance on JVM
● DataFrame/ Dataset are the new abstraction layers to
build next generation big data processing system
● DSL is the way forward over Map/Reduce like API’s
● Having high level structured abstractions make libraries
coexist happily on a platform

30. References
1. http://spark.apache.org/news/spark-1-0-0-released.html
2. https://www.youtube.com/watch?v=ckX6fT3kYG0
3. https://www.youtube.com/watch?v=iKOGBr-kOks
4. https://www.youtube.com/watch?v=7nIMpD5TyNs
5. https://www.youtube.com/watch?v=jErEhxP8LYQ
