Chapter 26
The
Urinary System
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Urinary System
The urinary systems consists of the kidneys, ureters,
bladder, and urethra, along with its associated nerves and
blood vessels.
The system maintains homeostasis by:
 Regulating blood volume, pressure, pH, and
concentration (osmolarity) of electrolytes (Na+
, K+
,
Ca 2+
, Cl-
, HPO4
-3
, Mg2+
, HCO3
-
)
 Reabsorbing glucose and excreting wastes
 Releasing certain hormones like renin and EPO
Copyright © John Wiley & Sons, Inc. All rights reserved.
The kidneys are bean-shaped organs located just above the
waist between the peritoneum and the posterior wall of
the abdomen (in the retroperitoneal space).
 They are partially protected
by the eleventh and
twelfth pairs of ribs.
 Because of the position
of the liver, the right
kidney is slightly
lower than the left.
Renal Anatomy
Copyright © John Wiley & Sons, Inc. All rights reserved.
A ureter (approximately 25 cm long)
originates near an indented area of each
kidney called the hilum and travels to
the base of the bladder.
 From the bladder, the
urethra (4 cm in length in
women and 24 cm in length
in men) allows urine to
be excreted.
Renal Anatomy
Copyright © John Wiley & Sons, Inc. All rights reserved.
Renal Anatomy
A frontal section through the kidney reveals two distinct
regions of internal anatomy, the cortex and medulla.
 The main function of the cortex
is filtration to form urine.
 The main function of
the medulla is to
collect and
excrete urine.
Copyright © John Wiley & Sons, Inc. All rights reserved.
The renal pyramids consists of 8 to 18 conical subdivisions
within the medulla that contain the kidney’s
secreting apparatus and tubules.
Renal columns are
composed of lines of
blood vessels and
fibrous material
which allows the
cortex to be better anchored.
Renal Anatomy
Copyright © John Wiley & Sons, Inc. All rights reserved.
The renal papilla is the location where the medullary
pyramids empty urine into cuplike structures called minor
and major calyces.
 8-18 minor calyces and
2-3 major calyces receive
urine from the papilla of
one renal pyramid.
Renal Anatomy
Copyright © John Wiley & Sons, Inc. All rights reserved.
From the major calyces, urine drains into a single large
cavity called the renal pelvis and then out through
the ureter.
The hilum expands into
a cavity within the
kidney called the renal
sinus, which contains part
of the renal pelvis, the calyces,
and branches of the renal blood
vessels and nerves.
Renal Anatomy
Copyright © John Wiley & Sons, Inc. All rights reserved.
The ureters transport urine from the renal pelvis of the
kidneys to the bladder using peristaltic waves,
hydrostatic pressure and gravity to move the urine.
There is no anatomical
valve at the
opening of the
ureter into
the bladder.
Renal Anatomy
Copyright © John Wiley & Sons, Inc. All rights reserved.
The urethra is a small tube leading from the internal
urethral orifice in the bladder floor to the exterior.
 In males, it
is also used
to discharge
semen.
Renal Anatomy
Copyright © John Wiley & Sons, Inc. All rights reserved.
Renal Blood Flow
The renal artery and renal vein pass into the substance of
the kidney (the parenchyma) at the hilum.
 Arterial blood enters via the renal artery and exits the
renal vein.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Blood follows the path depicted in the
graphic to the right:
Renal Blood Flow
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
The nephron is the functional unit of the kidney.
 It is a microscopic
structure composed
of blood vessels and
tubules that collect
the filtrate which
will ultimately
become urine.
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
Each nephron receives one afferent arteriole, which
divides into a tangled, ball-shaped capillary network
called the glomerulus.
 The glomerular
capillaries then
reunite to form an
efferent arteriole that
carries blood out of
the glomerulus.
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
Glomerular capillaries are unique among capillaries in
the body because they are positioned between two
arterioles, rather than between an arteriole and a venule.
 There are venules in the kidney, but they come later.
The Renal Corpuscle consists of two structures:
 The glomerular capillaries
 The glomerular capsule (Bowman’s capsule) – a double-
walled epithelial cup that surrounds the glomerular
capillaries.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Bowman’s capsule consists of visceral and parietal layers.
 The visceral layer is made of modified simple squamous
epithelial cells called podocytes. The many foot-like
projections of these cells (pedicels) wrap around the
single layer of endothelial cells of the glomerular
capillaries and form the inner wall of the capsule.
 The parietal layer of the glomerular capsule is a simple
squamous epithelium and forms the outer wall of the
capsule.
The Nephron
Copyright © John Wiley & Sons, Inc. All rights reserved.
The epithelium of the visceral
and parietal layers of the
renal corpuscle form
festrations (pores)
which act as a
filtration (dialysis)
membrane.
The Nephron
Copyright © John Wiley & Sons, Inc. All rights reserved.
Fluid filtered from the glomerular capillaries enters
Bowman’s space, (the space between the two layers of the
glomerular capsule), which is the lumen of the urinary
tube.
The Nephron
Copyright © John Wiley & Sons, Inc. All rights reserved.
Blood plasma is filtered through the glomerular capillaries
into the glomerular capsule.
 Filtered fluid passes into
the renal tubule, which
has three main sections:
◦the proximal convoluted
tubule (PCT)
◦the loop of Henle
◦the distal convoluted
tubule (DCT)
The Nephron
Copyright © John Wiley & Sons, Inc. All rights reserved.
The distal convoluted tubules of several nephrons empty
into a single collecting duct.
 Collecting ducts
unite and converge
into several hundred
large papillary ducts
which drain into the
minor calyces, major calyces,
renal pelvis, and ureters.
The Nephron
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
The first part of the loop of Henle (the descending limb)
dips into the renal medulla. It then makes a hairpin turn
and returns to the renal cortex as the ascending limb.
 The descending limb of the loop of Henle is composed of
a simple squamous epithelium.
 The ascending limb of the loop may be either “thin”
(composed of a simple squamous epithelium) or “thick”
(composed of simple cuboidal to low columnar cells).
◦ Some nephrons contain both thick and thin ascending
limbs.
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
Based on the length of the loop of Henle and the presence
of thin segments in the ascending limb, nephrons can be
sorted into two populations:
cortical and juxtamedullary.
Nephrons with long loops of
Henle enable the kidneys to
create a concentration gradient
in the renal medulla and to
excrete very dilute or very
concentrated urine.
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
Cortical nephrons make up about 80–85% of the 1 million
microscopic nephrons that comprise each kidney.
 Their renal corpuscles are located in the outer portion of
the cortex, with short loops of Henle that penetrate only
a small way into the medulla.
 The ascending limbs of their loops of Henle consist of
only a thick segment, lacking any thin portions.
 Nephrons with short loops receive their blood supply
from peritubular capillaries that arise from efferent
arterioles.
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
The other 15–20% of the nephrons are juxtamedullary
nephrons .
 Their renal corpuscles lie deep in the cortex, close to
the medulla, and they have long loops of Henle that
extend into the deepest region of the medulla.
 The ascending limbs of their loops of Henle consist of
both thin and thick segments.
 Nephrons with long loops receive their blood supply
from the vasa recta that arise from peritubular
capillaries before becoming peritubular venules.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Juxtamedullary Nephron
Copyright © John Wiley & Sons, Inc. All rights reserved.
In each nephron, the final part of the ascending limb of
the loop of Henle makes contact with the afferent
arteriole serving that renal corpuscle. Because the
columnar tubule cells in this region are crowded together,
they are known as the macula densa.
 Alongside the macula densa, the wall of the afferent
arteriole contains modified smooth muscle fibers called
juxtaglomerular (JG) cells.
◦ Together with the macula densa, they constitute the
juxtaglomerular apparatus (JGA).
The Nephron
Copyright © John Wiley & Sons, Inc. All rights reserved.
The Nephron
As we will shortly see, the JGA helps regulate blood
pressure within the kidneys.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Renal Physiology
The 3 basic functions performed by nephrons and
collecting ducts are:
 Glomerular filtration - pressure forces filtration of
waste-laden blood in the glomerulus. The glomerular
filtration rate (GFR) is the amount of filtrate formed in
all the renal corpuscles of both kidneys each minute.
 Tubular reabsorption – the process of returning
important substances from the filtrate back to the body.
 Tubular secretion – the movement of waste materials
from the body to the filtrate.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Glomerular Filtration
Glomerular filtration is the formation of a protein-free
filtrate (ultrafiltrate) of plasma across the glomerular
membrane.
 Only a portion of the blood plasma delivered to the
kidney via the renal artery is filtered.
 Plasma which escapes filtration, along with its protein
and cellular elements, exits the renal corpuscle via the
efferent arteriole, perfuses the tubular capillary beds,
and is eventually collected in the renal venous system.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Glomerular Filtration
In the average adult, the body’s entire extracellular fluid
volume is filtered about 12 times per day.
 Since we cannot afford to lose that amount of fluid, the
vast majority must be reclaimed, with just a small
portion being excreted in the urine.
Copyright © John Wiley & Sons, Inc. All rights reserved.
The daily composition of plasma, filtrate, and urine are compared.
Glomerular Filtration
Total
Amount in
Plasma
Amount in 180 L
of filtrate (/day)
Amount
returned to
blood/d
(Reabsorbed)
Amount in
Urine (/day)
Water (passive) 3 L 180 L 178-179 L 1-2 L
Protein (active) 200 g 2 g 1.9 g 0.1 g
Glucose (active) 3 g 162 g 162 g 0 g
Urea (passive) 1 g 54 g
24 g
(about 1/2)
30 g
(about 1/2)
Creatinine 0.03 g 1.6 g
0 g
(all filtered)
1.6 g
(none reabsorbed)
Copyright © John Wiley & Sons, Inc. All rights reserved.
Glomerular Filtration
Filtration is controlled by 2 opposing hydrostatic forces
and 2 opposing osmotic forces at the glomerular
membrane called Starling forces.
 Blood hydrostatic pressure (55mmHg) is the main force
that “pushes” water and solutes through the filtration
membrane (promotes filtration).
 Capsular hydrostatic pressure (15 mmHg) is exerted
against the filtration membrane by fluid in the capsular
space (opposes filtration).
Copyright © John Wiley & Sons, Inc. All rights reserved.
Glomerular Filtration
Starling forces continued
 Blood osmotic (oncotic) pressure (30 mmHg) is the
pressure of plasma proteins “pulling” on water (opposes
filtration).
 Normally very little protein escapes through the
filtration membrane making capsular oncotic pressure a
negligible force except in certain disease states.
Net Filtration = Blood Hydrostatic Pressure – Blood
Osmotic Pressure – Capsular Hydrostatic Pressure
 Net Filtration = 55-30-15 = 10 mmHg
Copyright © John Wiley & Sons, Inc. All rights reserved.
Glomerular Filtration
Normally, 3 Starling forces are at work in glomerular filtration
Copyright © John Wiley & Sons, Inc. All rights reserved.
Regulation of the GFR is critical to maintaining
homeostasis and is regulated by an assortment of local and
systemic mechanisms:
 Renal autoregulation occurs when the kidneys
themselves regulate GFR.
 Neural regulation occurs when the ANS regulates renal
blood flow and GFR.
 Hormonal regulation involves angiotensin II and atrial
natriuretic peptide (ANP).
Glomerular Filtration
Copyright © John Wiley & Sons, Inc. All rights reserved.
Renal autoregulation of GFR occurs by two means:
 Stretching in the glomerular capillaries triggers
myogenic contraction of smooth muscle
cells in afferent arterioles (reduces GFR).
 Pressure and flow monitored in the
macula densa provides tubuloglomerular
feedback to the glomerulus, causing the
afferent arterioles to constrict (decreasing
blood flow and GFR) or dilate (increasing
blood flow and GFR) appropriately.
Glomerular Filtration
Copyright © John Wiley & Sons, Inc. All rights reserved.
Neural regulation of GFR is possible because the renal
blood vessels are supplied by sympathetic ANS fibers that
release norepinephrine causing vasoconstriction.
 Sympathetic input to
the kidneys is most
important with extreme
drops of B.P. (as occurs
with hemorrhage).
Glomerular Filtration
Copyright © John Wiley & Sons, Inc. All rights reserved.
Two hormones contribute to regulation of GFR
 Angiotensin II is a potent vasoconstrictor of both
afferent and efferent arterioles (reduces GFR).
 A sudden large increase in BP stretches the cardiac atria
and releases atrial
natriuretic peptide (ANP).
◦ ANP causes the
glomerulus to relax,
increasing the surface
area for filtration.
Glomerular Filtration
Copyright © John Wiley & Sons, Inc. All rights reserved.
Filtration slitPedicel of podocyte
Fenestration (pore) of
glomerular endothelial cell
Basal lamina
Lumen of glomerulus
(b) Filtration membrane
TEM 78,000x
(a) Details of filtration membrane
Filtration slit
Pedicel
Fenestration (pore) of glomerular
endothelial cell: prevents filtration of
blood cells but allows all components
of blood plasma to pass through
Podocyte of visceral
layer of glomerular
(Bowman’s) capsule
1
Filtration slitPedicel of podocyte
Fenestration (pore) of
glomerular endothelial cell
Basal lamina
Lumen of glomerulus
(b) Filtration membrane
TEM 78,000x
(a) Details of filtration membrane
Filtration slit
Pedicel
Fenestration (pore) of glomerular
endothelial cell: prevents filtration of
blood cells but allows all components
of blood plasma to pass through
Basal lamina of glomerulus:
prevents filtration of larger proteins
Podocyte of visceral
layer of glomerular
(Bowman’s) capsule
1
2
Filtration slitPedicel of podocyte
Fenestration (pore) of
glomerular endothelial cell
Basal lamina
Lumen of glomerulus
(b) Filtration membrane
TEM 78,000x
(a) Details of filtration membrane
Filtration slit
Pedicel
Fenestration (pore) of glomerular
endothelial cell: prevents filtration of
blood cells but allows all components
of blood plasma to pass through
Basal lamina of glomerulus:
prevents filtration of larger proteins
Slit membrane between pedicels:
prevents filtration of medium-sized
proteins
Podocyte of visceral
layer of glomerular
(Bowman’s) capsule
1
2
3
The Filtration Membrane
Copyright © John Wiley & Sons, Inc. All rights reserved.
Glomerular Filtration
(Interactions Animation)
Renal Filtration
You must be connected to the internet to run this animation
Copyright © John Wiley & Sons, Inc. All rights reserved.
NET FILTRATION PRESSURE (NFP)
=GBHP – CHP – BCOP
= 55 mmHg 15 mmHg 30 mmHg
= 10 mmHg
GLOMERULAR BLOOD
HYDROSTATIC PRESSURE
(GBHP) = 55 mmHg
Capsular
space
Glomerular
(Bowman's)
capsule
Efferent
arteriole
Afferent arteriole
1
Proximal convoluted tubule
NET FILTRATION PRESSURE (NFP)
=GBHP – CHP – BCOP
= 55 mmHg 15 mmHg 30 mmHg
= 10 mmHg
CAPSULAR HYDROSTATIC
PRESSURE (CHP) = 15 mmHg
GLOMERULAR BLOOD
HYDROSTATIC PRESSURE
(GBHP) = 55 mmHg
Capsular
space
Glomerular
(Bowman's)
capsule
Efferent
arteriole
Afferent arteriole
1
2
Proximal convoluted tubule
NET FILTRATION PRESSURE (NFP)
=GBHP – CHP – BCOP
= 55 mmHg 15 mmHg 30 mmHg
= 10 mmHg
BLOOD COLLOID
OSMOTIC PRESSURE
(BCOP) = 30 mmHg
CAPSULAR HYDROSTATIC
PRESSURE (CHP) = 15 mmHg
GLOMERULAR BLOOD
HYDROSTATIC PRESSURE
(GBHP) = 55 mmHg
Capsular
space
Glomerular
(Bowman's)
capsule
Efferent
arteriole
Afferent arteriole
1
2
3
Proximal convoluted tubule
Pressures That Drive Glomerular Filtration
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Reabsorption
Tubular reabsorption is the process of returning important
substances (“good stuff”) from the filtrate back into the
renal interstitium, then into the renal blood vessels... and
ultimately back into the body.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Reabsorption
The “good stuff” is glucose, electrolytes, vitamins, water,
amino acids, and any small proteins that might have
inadvertently escaped from the blood into the filtrate.
Ninety nine percent of the glomerular filtrate is
reabsorbed (most of it before the end of the PCT)!
 To appreciate the magnitude of tubular reabsorption,
look once again at the table in the next slide and
compare the amounts of substances that are filtered,
reabsorbed, and excreted in urine.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Reabsorption
Total
Amount in
Plasma
Amount in 180 L
of filtrate (/day)
Amount
returned to
blood/d
(Reabsorbed)
Amount in
Urine (/day)
Water (passive) 3 L 180 L 178-179 L 1-2 L
Protein (active) 200 g 2 g 1.9 g 0.1 g
Glucose (active) 3 g 162 g 162 g 0 g
Urea (passive) 1 g 54 g
24 g
(about 1/2)
30 g
(about 1/2)
Creatinine 0.03 g 1.6 g
0 g
(all filtered)
1.6 g
(none reabsorbed)
Copyright © John Wiley & Sons, Inc. All rights reserved.
Reabsorption into the interstitium has two routes:
 Paracellular reabsorption is a passive process that occurs
between adjacent tubule
cells (tight junctions do
not completely seal off
interstitial fluid from
tubule fluid.)
 Transcellular reabsorption
is movement through an
individual cell.
Tubular Reabsorption
Copyright © John Wiley & Sons, Inc. All rights reserved.
It is a tremendous feat to reabsorb all of the nutrients and
fluid we must to survive, while still filtering out,
concentrating and excreting toxic substance.
 To accomplish this, the kidney establishes a
countercurrent flow between the filtrate in the limbs of
the Loops of Henle and the blood in the peritubular
capillaries and Vasa Recta.
◦ Two types of countercurrent mechanisms exist in the
kidneys: countercurrent multiplication and
countercurrent exchange.
Tubular Reabsorption
Copyright © John Wiley & Sons, Inc. All rights reserved.
Countercurrent multiplication is the process by which a
progressively increasing osmotic gradient is formed in the
interstitial fluid of the renal medulla as a result of
countercurrent flow.
Countercurrent exchange is the process by which solutes
and water are passively exchanged between the blood of
the vasa recta and interstitial fluid of the renal medulla as
a result of countercurrent flow.
 This provides oxygen and nutrients to the renal medulla
without washing out or diminishing the gradient.
Tubular Reabsorption
Copyright © John Wiley & Sons, Inc. All rights reserved.
Both mechanisms contribute to reabsorption of fluid and
electrolytes and the formation of concentrated urine.
Tubular Reabsorption
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Reabsorption
Reabsorption of fluids, ions, and other substances occurs
by active and passive means.
 A variety of symporters and antiporters actively
transport Na+ , Cl– , Ca2+, H+, HCO3
– , glucose, HPO4
2– ,
SO4
2– , NH4
+, urea, all amino acids, and lactic acid.
 Reabsorption of water can be obligatory or facultative,
but it always moves by osmosis down its concentration
gradient depending on the permeability of the tubule
cells (which varies between the PCT, the different
portions of the loop of Henle, DCT, and collecting ducts).
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Reabsorption
Obligatory reabsorption of water occurs when it is
obliged to follow the solutes as they are reabsorbed (to
maintain the osmotic gradient).
Facultative reabsorption describes variable water
reabsorption, adapted to specific needs.
 It is regulated by the effects
of ADH and aldosterone on
the principal cells of the renal
tubules and collecting ducts.
Copyright © John Wiley & Sons, Inc. All rights reserved.
This graphic depicts the formation of a dilute urine, mostly
through obligatory
reabsorption of water.
Compare this process to
the one depicted on the
next slide where urine is
concentrated by the action
of ADH on the DCT and
collecting ducts of
juxtamedullary nephrons.
Tubular Reabsorption
Copyright © John Wiley & Sons, Inc. All rights reserved.
Urine can be
up to 4 times
more
concentrated
than blood
plasma.
Tubular Reabsorption
Copyright © John Wiley & Sons, Inc. All rights reserved.(b) Recycling of salts and urea in the vasa recta(a) Reabsorption of Na+CI– and water in a long-loop juxtamedullary nephron
Glomerular (Bowman’s) capsule
Afferent
arteriole
Efferent
arteriole
Glomerulus
Distal convoluted tubule
Proximal
convoluted
tubule
Symporters in thick
ascending limb cause
buildup of Na+ and Cl–
Interstitial fluid
in renal medulla
300
1200
1000
800
Osmotic
gradient
600
400
H2O
H2O
H2O
200
1200
980
600780
400580
200380
300
100
Loop of Henle
1200 Concentrated urine
300
300
320
400
600
800
1000
1200
800
H2O
Urea
Papillary
duct
Collecting
duct
300
500
700
900
1100
1200
400
800
1000
600
Na+CI–
Blood flow
Flow of tubular fluid
Presense of Na+-K+-2CI–
symporters
Interstitial
fluid in
renal cortex
320
Juxtamedullary nephron
and its blood supply
together
Vasa
recta
Loop of
Henle
H2O
H2O
H2O
H2O
H2O
H2O
H2O
1
H2O
H2O
Na+CI–
Na+CI–
H2O
Na+CI–
H2O
Na+CI–
(b) Recycling of salts and urea in the vasa recta(a) Reabsorption of Na+CI– and water in a long-loop juxtamedullary nephron
Glomerular (Bowman’s) capsule
Afferent
arteriole
Efferent
arteriole
Glomerulus
Distal convoluted tubule
Proximal
convoluted
tubule
Symporters in thick
ascending limb cause
buildup of Na+ and Cl–
Interstitial fluid
in renal medulla
300
1200
1000
800
Osmotic
gradient
600
400
H2O
H2O
H2O
200
1200
980
600780
400580
200380
300
100
Loop of Henle
1200 Concentrated urine
300
300
320
400
600
800
1000
1200
800
H2O
Urea
Papillary
duct
Collecting
duct
Countercurrent flow
through loop of Henle
establishes an osmotic
gradient
300
500
700
900
1100
1200
400
800
1000
600
Na+CI–
Blood flow
Flow of tubular fluid
Presense of Na+-K+-2CI–
symporters
Interstitial
fluid in
renal cortex
320
Juxtamedullary nephron
and its blood supply
together
Vasa
recta
Loop of
Henle
H2O
H2O
H2O
H2O
H2O
H2O
H2O
1
2
H2O
H2O
Na+CI–
Na+CI–
H2O
Na+CI–
H2O
Na+CI–
(b) Recycling of salts and urea in the vasa recta(a) Reabsorption of Na+CI– and water in a long-loop juxtamedullary nephron
Glomerular (Bowman’s) capsule
Afferent
arteriole
Efferent
arteriole
Glomerulus
Distal convoluted tubule
Proximal
convoluted
tubule
Symporters in thick
ascending limb cause
buildup of Na+ and Cl–
Interstitial fluid
in renal medulla
300
1200
1000
800
Osmotic
gradient
600
400
H2O
H2O
H2O
200
1200
980
600780
400580
200380
300
100
Loop of Henle
1200 Concentrated urine
300
300
320
400
600
800
1000
1200
800
H2O
Urea
Papillary
duct
Collecting
duct
Countercurrent flow
through loop of Henle
establishes an osmotic
gradient
Principal cells in
collecting duct
reabsorb more
water when ADH
is present
300
500
700
900
1100
1200
400
800
1000
600
Na+CI–
Blood flow
Flow of tubular fluid
Presense of Na+-K+-2CI–
symporters
Interstitial
fluid in
renal cortex
320
Juxtamedullary nephron
and its blood supply
together
Vasa
recta
Loop of
Henle
H2O
H2O
H2O
H2O
H2O
H2O
H2O
1
2
3
H2O
H2O
Na+CI–
Na+CI–
H2O
Na+CI–
H2O
Na+CI–
(b) Recycling of salts and urea in the vasa recta(a) Reabsorption of Na+CI– and water in a long-loop juxtamedullary nephron
Glomerular (Bowman’s) capsule
Afferent
arteriole
Efferent
arteriole
Glomerulus
Distal convoluted tubule
Proximal
convoluted
tubule
Symporters in thick
ascending limb cause
buildup of Na+ and Cl–
Interstitial fluid
in renal medulla
300
1200
1000
800
Osmotic
gradient
600
400
H2O
H2O
H2O
200
1200
980
600780
400580
200380
300
100
Loop of Henle
1200 Concentrated urine
300
300
320
400
600
800
1000
1200
800
H2O
Urea
Papillary
duct
Urea recycling
causes buildup
of urea in the
renal medulla
Collecting
duct
Countercurrent flow
through loop of Henle
establishes an osmotic
gradient
Principal cells in
collecting duct
reabsorb more
water when ADH
is present
300
500
700
900
1100
1200
400
800
1000
600
Na+CI–
Blood flow
Flow of tubular fluid
Presense of Na+-K+-2CI–
symporters
Interstitial
fluid in
renal cortex
320
Juxtamedullary nephron
and its blood supply
together
Vasa
recta
Loop of
Henle
H2O
H2O
H2O
H2O
H2O
H2O
H2O
1
2
3
4
H2O
H2O
Na+CI–
Na+CI–
H2O
Na+CI–
H2O
Na+CI–
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Reabsorption
(Interactions Animation)
Water Homeostasis
You must be connected to the internet to run this animation
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Reabsorption
If higher than normal amounts of a substance are present
in the filtrate, then the renal threshold for reabsorption of
that substance may be surpassed.
 When that happens, the substance cannot be reabsorbed
fast enough, and it will be excreted in the urine.
 For example, the renal [reabsorption] threshold of
glucose is 180-200mg/dl. When this level is exceeded (as
in diabetes mellitus), the glucose is said to “spill” into
the urine (meaning a substance which is not normally
present in urine begins to appear).
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Secretion
Tubular secretion is the movement of substances from the
capillaries which surround the nephron into the filtrate.
 It occurs at a site other than the filtration membrane (in
the proximal convoluted tubule, distal convoluted
tubule and collecting ducts) by active transport.
The process of tubular secretion controls pH.
 Hydrogen and ammonium ions are secreted to decrease
the acidity in the body, and bicarbonate is conserved.
◦ Secreted substances include H+
, K+
, NH4
+
, and some
drugs; the amount often depends on body needs.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Tubular Secretion
Maintaining the body’s proper pH requires cooperation
mainly between the lungs and the kidneys.
 The lungs eliminate CO2.
◦ Provides a rapid response (minutes)
 The kidneys eliminate H+
and NH4
+
ions and conserve
bicarbonate.
◦ This is a slower response (hours-days).
 The alimentary canal (digestive), and integumentary
system (skin) provide minor contributions.
Copyright © John Wiley & Sons, Inc. All rights reserved.
Five hormones affect the extent of Na+, Cl–, Ca2+, and
water reabsorption as well as K+ secretion by the renal
tubules. These hormones, all of which are key to
maintaining homeostasis of not only renal blood flow
and B.P., but systemic blood flow and B.P., are:
 angiotensin II
 antidiuretic hormone (ADH)
 aldosterone
 atrial natriuretic peptide (ANP)
 parathyroid hormone (PTH)
Hormones and Homeostasis
Copyright © John Wiley & Sons, Inc. All rights reserved.
We have already mentioned the effect of ANP on GFR.
ADH is released by the posterior pituitary in response to
low blood flow in this part of the brain.
 ADH affects facultative water reabsorption by
increasing the water permeability of principal cells in
the last part of the distal convoluted tubule and
throughout the collecting duct.
◦ In the absence of ADH, the apical
membranes of principal cells
are almost impermeable to water.
Hormones and Homeostasis
Copyright © John Wiley & Sons, Inc. All rights reserved.
Secretion of the hormones angiotensin II and aldosterone
are tied to one another: When blood volume and blood
pressure decrease or the sympathetic NS is stimulated, the
walls of the
afferent arterioles
are stretched
less, and the
cells of the JGA
secrete renin.
Hormones and Homeostasis
Copyright © John Wiley & Sons, Inc. All rights reserved.
Renin clips off a 10-amino-acid peptide called
angiotensin I from angiotensinogen, which is synthesized
by hepatocytes. By clipping off two more amino acids,
angiotensin converting enzyme (ACE) converts
angiotensin I to angiotensin II, which is the active form
of the hormone. Angiotensin II has 3 main effects:
1. Vasoconstriction decreases GFR.
2. It increases blood volume by increasing reabsorption
of water and electrolytes in the PCT.
3. It stimulates the adrenal cortex to release aldosterone.
Hormones and Homeostasis
Copyright © John Wiley & Sons, Inc. All rights reserved.
Aldosterone stimulates the principal cells in the
collecting ducts to reabsorb more Na+ and Cl– and secrete
more K+. The osmotic consequence of reabsorbing more
Na+ and Cl– is that more
water is reabsorbed,
which increases blood
volume and blood
pressure.
Hormones and Homeostasis
Copyright © John Wiley & Sons, Inc. All rights reserved.
The events of
filtration,
absorption, and
secretion are
summarized in
this graphic.
Summary of Renal Function
Copyright © John Wiley & Sons, Inc. All rights reserved.
Increases in GFR usually result in an increase in urine
production. However, as we have seen, the mechanisms
which control electrolyte and
water reabsorption in the
various parts of the nephron
and collecting ducts are subject
to many complex controls.
 Normal urine output (UOP)
is 1-2 L/d.
Urine
Copyright © John Wiley & Sons, Inc. All rights reserved.
A urinalysis analyzes the physical, chemical and
microscopic properties of urine.
 Water accounts for 95% of total urine volume.
 The solutes normally present in urine are filtered and
secreted substances that are not reabsorbed.
 If disease alters metabolism or kidney function, traces of
substances normally not present or normal constituents
in abnormal amounts may appear (bacteria, albumin
protein, glucose, white blood cells, red blood cells to
name a few).
Urine
Copyright © John Wiley & Sons, Inc. All rights reserved.
In addition to a urinalysis, two blood tests are commonly
done clinically to assess the adequacy of renal function.
 Blood urea nitrogen (BUN) measures nitrogen wastes in
blood from catabolism and deamination of amino acids.
 Creatinine levels appear in the blood as a result of
catabolism of creatine phosphate in skeletal muscle.
◦ The serum creatinine test measures the amount of
creatinine in the blood, which increases in states of
renal dysfunction.
Urine

More Related Content

What's hot

Lymphatic system
Lymphatic systemLymphatic system
Lymphatic system
MuNevveR SERDAROGULLARI

Renal physiology-1
Renal physiology-1Renal physiology-1
Renal physiology-1
FarragBahbah

Urinary System
Urinary SystemUrinary System
Urinary Systemraj kumar

Histology of kidney.pptx
Histology of kidney.pptxHistology of kidney.pptx
Histology of kidney.pptx
UTTARAN MODHUKALYA

Urinary System
Urinary SystemUrinary System
Urinary System
Eneutron

The urinary system
The urinary systemThe urinary system
The urinary system
Sohel Daria

Introduction of gastrointestinal tract
Introduction of gastrointestinal tractIntroduction of gastrointestinal tract
Introduction of gastrointestinal tractRajesh Goit

Histology of Kidney
Histology of KidneyHistology of Kidney
Histology of Kidney
DiniSyazwaniLotfi

Anatomy of urinary system
Anatomy of urinary systemAnatomy of urinary system
Anatomy of urinary system
SELINA SRAVANTHI

Cell physiology
Cell physiologyCell physiology
Cell physiology
vmailj

Introduction to Digestive System
Introduction to Digestive System Introduction to Digestive System
Introduction to Digestive System
Pharmacy Universe

Kidney
KidneyKidney
Histology & Function of The Pancreas
Histology & Function of The Pancreas Histology & Function of The Pancreas
Histology & Function of The Pancreas
FatmaGhoneim3

Structure and functions of nephron assignment
Structure and functions of nephron assignmentStructure and functions of nephron assignment
Structure and functions of nephron assignment
aquib59

Anatomy of kidney By M.Adil
Anatomy of kidney By M.AdilAnatomy of kidney By M.Adil
Anatomy of kidney By M.Adil
Adil Subhani

histology of Digestive system 3
 histology of Digestive system 3 histology of Digestive system 3
histology of Digestive system 3
Muhammad Amir Sohail

the urinary system
the urinary systemthe urinary system
the urinary systemDeb Smu

Small intestine by Pandian M
Small intestine by Pandian MSmall intestine by Pandian M
Small intestine by Pandian M
Pandian M

Human Human Anatomy Urinary System
Human Human Anatomy Urinary SystemHuman Human Anatomy Urinary System
Human Human Anatomy Urinary Systemkangaro10a


What's hot (20)

Lymphatic system
Lymphatic systemLymphatic system
Lymphatic system

Renal physiology-1
Renal physiology-1Renal physiology-1
Renal physiology-1

Urinary System
Urinary SystemUrinary System
Urinary System

Histology of kidney.pptx
Histology of kidney.pptxHistology of kidney.pptx
Histology of kidney.pptx

Urinary System
Urinary SystemUrinary System
Urinary System

The urinary system
The urinary systemThe urinary system
The urinary system

Introduction of gastrointestinal tract
Introduction of gastrointestinal tractIntroduction of gastrointestinal tract
Introduction of gastrointestinal tract

Histology of Kidney
Histology of KidneyHistology of Kidney
Histology of Kidney

Anatomy of urinary system
Anatomy of urinary systemAnatomy of urinary system
Anatomy of urinary system

Digestive system
Digestive systemDigestive system
Digestive system

Cell physiology
Cell physiologyCell physiology
Cell physiology

Introduction to Digestive System
Introduction to Digestive System Introduction to Digestive System
Introduction to Digestive System

Kidney
KidneyKidney
Kidney

Histology & Function of The Pancreas
Histology & Function of The Pancreas Histology & Function of The Pancreas
Histology & Function of The Pancreas

Structure and functions of nephron assignment
Structure and functions of nephron assignmentStructure and functions of nephron assignment
Structure and functions of nephron assignment

Anatomy of kidney By M.Adil
Anatomy of kidney By M.AdilAnatomy of kidney By M.Adil
Anatomy of kidney By M.Adil

histology of Digestive system 3
 histology of Digestive system 3 histology of Digestive system 3
histology of Digestive system 3

the urinary system
the urinary systemthe urinary system
the urinary system

Small intestine by Pandian M
Small intestine by Pandian MSmall intestine by Pandian M
Small intestine by Pandian M

Human Human Anatomy Urinary System
Human Human Anatomy Urinary SystemHuman Human Anatomy Urinary System
Human Human Anatomy Urinary System


Viewers also liked

Renal physiology introduction.
Renal physiology introduction.Renal physiology introduction.
Renal physiology introduction.
Shaikhani.

Renal physiology 3
Renal physiology 3Renal physiology 3
Renal physiology 3
manoj000049

Anatomy and physiology of urinary system
Anatomy and physiology of urinary systemAnatomy and physiology of urinary system
Anatomy and physiology of urinary system
Michael John Pendon

Renal Physiology
Renal PhysiologyRenal Physiology
Renal PhysiologyKern Rocke

Urinary system
Urinary  systemUrinary  system
Urinary system
Sudarshana Elapatha

Chapter 2
Chapter 2Chapter 2
Chapter 2
Yukti Sharma

Chapter 25
Chapter 25Chapter 25
Chapter 25
Yukti Sharma

Professor Peivand Pirouzi: Pathophysiology of the urinary system 2016
Professor Peivand Pirouzi: Pathophysiology of the urinary system 2016Professor Peivand Pirouzi: Pathophysiology of the urinary system 2016
Professor Peivand Pirouzi: Pathophysiology of the urinary system 2016
Pharmaceutical Compliance Inspection unit, Crown College of Canada

Chapter 3
Chapter 3Chapter 3
Chapter 3
Yukti Sharma

Kidney anat online
Kidney anat onlineKidney anat online
Kidney anat onlinekmilaniBCC

Life Science 3.2 : The Urinary System
Life Science 3.2 : The Urinary SystemLife Science 3.2 : The Urinary System
Life Science 3.2 : The Urinary SystemChris Foltz

Chapter 19
Chapter 19Chapter 19
Chapter 19
Yukti Sharma

Osmoregulation and-excretion
Osmoregulation and-excretionOsmoregulation and-excretion
Osmoregulation and-excretionroshanchristo

Autoregulation of glomerular filtration rate and renal blood
Autoregulation of glomerular filtration rate and renal bloodAutoregulation of glomerular filtration rate and renal blood
Autoregulation of glomerular filtration rate and renal blood
Deepa Devkota

Chapter 21&22
Chapter 21&22Chapter 21&22
Chapter 21&22
Yukti Sharma

Chapter 4
Chapter 4Chapter 4
Chapter 4
Yukti Sharma


Viewers also liked (20)

Renal physiology introduction.
Renal physiology introduction.Renal physiology introduction.
Renal physiology introduction.

Renal physiology 3
Renal physiology 3Renal physiology 3
Renal physiology 3

Anatomy and physiology of urinary system
Anatomy and physiology of urinary systemAnatomy and physiology of urinary system
Anatomy and physiology of urinary system

Renal Physiology
Renal PhysiologyRenal Physiology
Renal Physiology

Urinary system
Urinary  systemUrinary  system
Urinary system

Chapter 2
Chapter 2Chapter 2
Chapter 2

Chapter 25
Chapter 25Chapter 25
Chapter 25

Professor Peivand Pirouzi: Pathophysiology of the urinary system 2016
Professor Peivand Pirouzi: Pathophysiology of the urinary system 2016Professor Peivand Pirouzi: Pathophysiology of the urinary system 2016
Professor Peivand Pirouzi: Pathophysiology of the urinary system 2016

Chapter 3
Chapter 3Chapter 3
Chapter 3

Kidney anat online
Kidney anat onlineKidney anat online
Kidney anat online

Life Science 3.2 : The Urinary System
Life Science 3.2 : The Urinary SystemLife Science 3.2 : The Urinary System
Life Science 3.2 : The Urinary System

Chapter 18
Chapter 18Chapter 18
Chapter 18

Chapter 19
Chapter 19Chapter 19
Chapter 19

Renal handling of water
Renal handling of waterRenal handling of water
Renal handling of water

702 kidney
702 kidney702 kidney
702 kidney

Urinary System Notes
Urinary System NotesUrinary System Notes
Urinary System Notes

Osmoregulation and-excretion
Osmoregulation and-excretionOsmoregulation and-excretion
Osmoregulation and-excretion

Autoregulation of glomerular filtration rate and renal blood
Autoregulation of glomerular filtration rate and renal bloodAutoregulation of glomerular filtration rate and renal blood
Autoregulation of glomerular filtration rate and renal blood

Chapter 21&22
Chapter 21&22Chapter 21&22
Chapter 21&22

Chapter 4
Chapter 4Chapter 4
Chapter 4


Similar to Chapter 26

Excretory system.ppt
Excretory system.pptExcretory system.ppt
Excretory system.ppt
noman khan

Excretory products n their elimination by BNP.pdf
Excretory products n their elimination by BNP.pdfExcretory products n their elimination by BNP.pdf
Excretory products n their elimination by BNP.pdf
College of pharmaceutical sciences

Urinary System.pdf
Urinary System.pdfUrinary System.pdf
Urinary System.pdf
Dr Musadiq

Physiology
PhysiologyPhysiology
Physiology
MBBS IMS MSU

Physiology
PhysiologyPhysiology
Physiology
MBBS IMS MSU

Urinary system
Urinary systemUrinary system
Urinary system
Kevin Balda

URINARY SYSTEM.pptx
URINARY SYSTEM.pptxURINARY SYSTEM.pptx
URINARY SYSTEM.pptx
RameeThj

urinary system (1).pptx
urinary system (1).pptxurinary system (1).pptx
urinary system (1).pptx
AbidaLaghari2

Urinary System By Dr. Bhagat Singh Jaiswal (1).pdf
Urinary System By Dr.  Bhagat Singh Jaiswal (1).pdfUrinary System By Dr.  Bhagat Singh Jaiswal (1).pdf
Urinary System By Dr. Bhagat Singh Jaiswal (1).pdf
AmitDubey431477

Urinary system.pptx
Urinary system.pptxUrinary system.pptx
Urinary system.pptx
CLASH CATALYSTS

Anatomy Urinary System 2022-2023(01).pdf
Anatomy Urinary System 2022-2023(01).pdfAnatomy Urinary System 2022-2023(01).pdf
Anatomy Urinary System 2022-2023(01).pdf
M SHAKEEL

Urinary system
Urinary systemUrinary system
Urinary system
Chanukya Vanam . Dr

35. kidney 1-07-08
35. kidney 1-07-0835. kidney 1-07-08
35. kidney 1-07-08Nasir Koko

URINARY-SYSTEM.pptx
URINARY-SYSTEM.pptxURINARY-SYSTEM.pptx
URINARY-SYSTEM.pptx
MylaOrlanda

Anatomy of urinary system
Anatomy of urinary systemAnatomy of urinary system
Anatomy of urinary system
jafarqamar

Anatomy of urinary system
Anatomy of urinary systemAnatomy of urinary system
Anatomy of urinary system
Johny Wilbert

Excretory+System.pptx
Excretory+System.pptxExcretory+System.pptx
Excretory+System.pptx
Christopher Singh


Similar to Chapter 26 (20)

Urinary system
Urinary systemUrinary system
Urinary system

Excretory system.ppt
Excretory system.pptExcretory system.ppt
Excretory system.ppt

Excretory products n their elimination by BNP.pdf
Excretory products n their elimination by BNP.pdfExcretory products n their elimination by BNP.pdf
Excretory products n their elimination by BNP.pdf

Urinary System.pdf
Urinary System.pdfUrinary System.pdf
Urinary System.pdf

Physiology
PhysiologyPhysiology
Physiology

Physiology
PhysiologyPhysiology
Physiology

Urinary system
Urinary systemUrinary system
Urinary system

URINARY SYSTEM.pptx
URINARY SYSTEM.pptxURINARY SYSTEM.pptx
URINARY SYSTEM.pptx

urinary system (1).pptx
urinary system (1).pptxurinary system (1).pptx
urinary system (1).pptx

Urinary System By Dr. Bhagat Singh Jaiswal (1).pdf
Urinary System By Dr.  Bhagat Singh Jaiswal (1).pdfUrinary System By Dr.  Bhagat Singh Jaiswal (1).pdf
Urinary System By Dr. Bhagat Singh Jaiswal (1).pdf

Urinary system.pptx
Urinary system.pptxUrinary system.pptx
Urinary system.pptx

Anatomy Urinary System 2022-2023(01).pdf
Anatomy Urinary System 2022-2023(01).pdfAnatomy Urinary System 2022-2023(01).pdf
Anatomy Urinary System 2022-2023(01).pdf

Urinary system
Urinary systemUrinary system
Urinary system

35. kidney 1-07-08
35. kidney 1-07-0835. kidney 1-07-08
35. kidney 1-07-08

URINARY-SYSTEM.pptx
URINARY-SYSTEM.pptxURINARY-SYSTEM.pptx
URINARY-SYSTEM.pptx

Renal system
Renal systemRenal system
Renal system

Anatomy of urinary system
Anatomy of urinary systemAnatomy of urinary system
Anatomy of urinary system

Anatomy of urinary system
Anatomy of urinary systemAnatomy of urinary system
Anatomy of urinary system

Urinary System
Urinary SystemUrinary System
Urinary System

Excretory+System.pptx
Excretory+System.pptxExcretory+System.pptx
Excretory+System.pptx


More from Yukti Sharma

Chapter 1
Chapter 1Chapter 1
Chapter 1
Yukti Sharma

Muscle funccellularlevel animal systems
Muscle funccellularlevel animal systemsMuscle funccellularlevel animal systems
Muscle funccellularlevel animal systems
Yukti Sharma

Chapter 25
Chapter 25Chapter 25
Chapter 25
Yukti Sharma

Chapter 24
Chapter 24Chapter 24
Chapter 24
Yukti Sharma

Sensory receptors animal systems
Sensory receptors animal systemsSensory receptors animal systems
Sensory receptors animal systems
Yukti Sharma

Action potentials animal systems
Action potentials  animal systemsAction potentials  animal systems
Action potentials animal systems
Yukti Sharma

Chapter 25
Chapter 25Chapter 25
Chapter 25
Yukti Sharma

Chapter 24
Chapter 24Chapter 24
Chapter 24
Yukti Sharma

Chapter 20
Chapter 20Chapter 20
Chapter 20
Yukti Sharma

Lecture 23
Lecture 23 Lecture 23
Lecture 23
Yukti Sharma

Chapter 10&11
Chapter 10&11Chapter 10&11
Chapter 10&11
Yukti Sharma

Chapter 9
Chapter 9Chapter 9
Chapter 9
Yukti Sharma

Chapter 7&8
Chapter 7&8Chapter 7&8
Chapter 7&8
Yukti Sharma


More from Yukti Sharma (20)

Chapter 1
Chapter 1Chapter 1
Chapter 1

Muscle funccellularlevel animal systems
Muscle funccellularlevel animal systemsMuscle funccellularlevel animal systems
Muscle funccellularlevel animal systems

Chapter 25
Chapter 25Chapter 25
Chapter 25

Chapter 24
Chapter 24Chapter 24
Chapter 24

Sensory receptors animal systems
Sensory receptors animal systemsSensory receptors animal systems
Sensory receptors animal systems

Action potentials animal systems
Action potentials  animal systemsAction potentials  animal systems
Action potentials animal systems

Chapter 27
Chapter 27Chapter 27
Chapter 27

Chapter 17
Chapter 17Chapter 17
Chapter 17

Chapter 16
Chapter 16Chapter 16
Chapter 16

Chapter 14
Chapter 14Chapter 14
Chapter 14

Chapter 13
Chapter 13Chapter 13
Chapter 13

Chapter 12
Chapter 12Chapter 12
Chapter 12

Chapter 28
Chapter 28Chapter 28
Chapter 28

Chapter 25
Chapter 25Chapter 25
Chapter 25

Chapter 24
Chapter 24Chapter 24
Chapter 24

Chapter 20
Chapter 20Chapter 20
Chapter 20

Lecture 23
Lecture 23 Lecture 23
Lecture 23

Chapter 10&11
Chapter 10&11Chapter 10&11
Chapter 10&11

Chapter 9
Chapter 9Chapter 9
Chapter 9

Chapter 7&8
Chapter 7&8Chapter 7&8
Chapter 7&8


Chapter 26

  • 2. Copyright © John Wiley & Sons, Inc. All rights reserved. The Urinary System The urinary systems consists of the kidneys, ureters, bladder, and urethra, along with its associated nerves and blood vessels. The system maintains homeostasis by:  Regulating blood volume, pressure, pH, and concentration (osmolarity) of electrolytes (Na+ , K+ , Ca 2+ , Cl- , HPO4 -3 , Mg2+ , HCO3 - )  Reabsorbing glucose and excreting wastes  Releasing certain hormones like renin and EPO
  • 3. Copyright © John Wiley & Sons, Inc. All rights reserved. The kidneys are bean-shaped organs located just above the waist between the peritoneum and the posterior wall of the abdomen (in the retroperitoneal space).  They are partially protected by the eleventh and twelfth pairs of ribs.  Because of the position of the liver, the right kidney is slightly lower than the left. Renal Anatomy
  • 4. Copyright © John Wiley & Sons, Inc. All rights reserved. A ureter (approximately 25 cm long) originates near an indented area of each kidney called the hilum and travels to the base of the bladder.  From the bladder, the urethra (4 cm in length in women and 24 cm in length in men) allows urine to be excreted. Renal Anatomy
  • 5. Copyright © John Wiley & Sons, Inc. All rights reserved. Renal Anatomy A frontal section through the kidney reveals two distinct regions of internal anatomy, the cortex and medulla.  The main function of the cortex is filtration to form urine.  The main function of the medulla is to collect and excrete urine.
  • 6. Copyright © John Wiley & Sons, Inc. All rights reserved. The renal pyramids consists of 8 to 18 conical subdivisions within the medulla that contain the kidney’s secreting apparatus and tubules. Renal columns are composed of lines of blood vessels and fibrous material which allows the cortex to be better anchored. Renal Anatomy
  • 7. Copyright © John Wiley & Sons, Inc. All rights reserved. The renal papilla is the location where the medullary pyramids empty urine into cuplike structures called minor and major calyces.  8-18 minor calyces and 2-3 major calyces receive urine from the papilla of one renal pyramid. Renal Anatomy
  • 8. Copyright © John Wiley & Sons, Inc. All rights reserved. From the major calyces, urine drains into a single large cavity called the renal pelvis and then out through the ureter. The hilum expands into a cavity within the kidney called the renal sinus, which contains part of the renal pelvis, the calyces, and branches of the renal blood vessels and nerves. Renal Anatomy
  • 9. Copyright © John Wiley & Sons, Inc. All rights reserved. The ureters transport urine from the renal pelvis of the kidneys to the bladder using peristaltic waves, hydrostatic pressure and gravity to move the urine. There is no anatomical valve at the opening of the ureter into the bladder. Renal Anatomy
  • 10. Copyright © John Wiley & Sons, Inc. All rights reserved. The urethra is a small tube leading from the internal urethral orifice in the bladder floor to the exterior.  In males, it is also used to discharge semen. Renal Anatomy
  • 11. Copyright © John Wiley & Sons, Inc. All rights reserved. Renal Blood Flow The renal artery and renal vein pass into the substance of the kidney (the parenchyma) at the hilum.  Arterial blood enters via the renal artery and exits the renal vein.
  • 12. Copyright © John Wiley & Sons, Inc. All rights reserved. Blood follows the path depicted in the graphic to the right: Renal Blood Flow
  • 13. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron The nephron is the functional unit of the kidney.  It is a microscopic structure composed of blood vessels and tubules that collect the filtrate which will ultimately become urine.
  • 14. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron Each nephron receives one afferent arteriole, which divides into a tangled, ball-shaped capillary network called the glomerulus.  The glomerular capillaries then reunite to form an efferent arteriole that carries blood out of the glomerulus.
  • 15. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron Glomerular capillaries are unique among capillaries in the body because they are positioned between two arterioles, rather than between an arteriole and a venule.  There are venules in the kidney, but they come later. The Renal Corpuscle consists of two structures:  The glomerular capillaries  The glomerular capsule (Bowman’s capsule) – a double- walled epithelial cup that surrounds the glomerular capillaries.
  • 16. Copyright © John Wiley & Sons, Inc. All rights reserved. Bowman’s capsule consists of visceral and parietal layers.  The visceral layer is made of modified simple squamous epithelial cells called podocytes. The many foot-like projections of these cells (pedicels) wrap around the single layer of endothelial cells of the glomerular capillaries and form the inner wall of the capsule.  The parietal layer of the glomerular capsule is a simple squamous epithelium and forms the outer wall of the capsule. The Nephron
  • 17. Copyright © John Wiley & Sons, Inc. All rights reserved. The epithelium of the visceral and parietal layers of the renal corpuscle form festrations (pores) which act as a filtration (dialysis) membrane. The Nephron
  • 18. Copyright © John Wiley & Sons, Inc. All rights reserved. Fluid filtered from the glomerular capillaries enters Bowman’s space, (the space between the two layers of the glomerular capsule), which is the lumen of the urinary tube. The Nephron
  • 19. Copyright © John Wiley & Sons, Inc. All rights reserved. Blood plasma is filtered through the glomerular capillaries into the glomerular capsule.  Filtered fluid passes into the renal tubule, which has three main sections: ◦the proximal convoluted tubule (PCT) ◦the loop of Henle ◦the distal convoluted tubule (DCT) The Nephron
  • 20. Copyright © John Wiley & Sons, Inc. All rights reserved. The distal convoluted tubules of several nephrons empty into a single collecting duct.  Collecting ducts unite and converge into several hundred large papillary ducts which drain into the minor calyces, major calyces, renal pelvis, and ureters. The Nephron
  • 21. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron The first part of the loop of Henle (the descending limb) dips into the renal medulla. It then makes a hairpin turn and returns to the renal cortex as the ascending limb.  The descending limb of the loop of Henle is composed of a simple squamous epithelium.  The ascending limb of the loop may be either “thin” (composed of a simple squamous epithelium) or “thick” (composed of simple cuboidal to low columnar cells). ◦ Some nephrons contain both thick and thin ascending limbs.
  • 22. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron Based on the length of the loop of Henle and the presence of thin segments in the ascending limb, nephrons can be sorted into two populations: cortical and juxtamedullary. Nephrons with long loops of Henle enable the kidneys to create a concentration gradient in the renal medulla and to excrete very dilute or very concentrated urine.
  • 23. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron Cortical nephrons make up about 80–85% of the 1 million microscopic nephrons that comprise each kidney.  Their renal corpuscles are located in the outer portion of the cortex, with short loops of Henle that penetrate only a small way into the medulla.  The ascending limbs of their loops of Henle consist of only a thick segment, lacking any thin portions.  Nephrons with short loops receive their blood supply from peritubular capillaries that arise from efferent arterioles.
  • 24. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron
  • 25. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron The other 15–20% of the nephrons are juxtamedullary nephrons .  Their renal corpuscles lie deep in the cortex, close to the medulla, and they have long loops of Henle that extend into the deepest region of the medulla.  The ascending limbs of their loops of Henle consist of both thin and thick segments.  Nephrons with long loops receive their blood supply from the vasa recta that arise from peritubular capillaries before becoming peritubular venules.
  • 26. Copyright © John Wiley & Sons, Inc. All rights reserved. Juxtamedullary Nephron
  • 27. Copyright © John Wiley & Sons, Inc. All rights reserved. In each nephron, the final part of the ascending limb of the loop of Henle makes contact with the afferent arteriole serving that renal corpuscle. Because the columnar tubule cells in this region are crowded together, they are known as the macula densa.  Alongside the macula densa, the wall of the afferent arteriole contains modified smooth muscle fibers called juxtaglomerular (JG) cells. ◦ Together with the macula densa, they constitute the juxtaglomerular apparatus (JGA). The Nephron
  • 28. Copyright © John Wiley & Sons, Inc. All rights reserved. The Nephron As we will shortly see, the JGA helps regulate blood pressure within the kidneys.
  • 29. Copyright © John Wiley & Sons, Inc. All rights reserved. Renal Physiology The 3 basic functions performed by nephrons and collecting ducts are:  Glomerular filtration - pressure forces filtration of waste-laden blood in the glomerulus. The glomerular filtration rate (GFR) is the amount of filtrate formed in all the renal corpuscles of both kidneys each minute.  Tubular reabsorption – the process of returning important substances from the filtrate back to the body.  Tubular secretion – the movement of waste materials from the body to the filtrate.
  • 30. Copyright © John Wiley & Sons, Inc. All rights reserved. Glomerular Filtration Glomerular filtration is the formation of a protein-free filtrate (ultrafiltrate) of plasma across the glomerular membrane.  Only a portion of the blood plasma delivered to the kidney via the renal artery is filtered.  Plasma which escapes filtration, along with its protein and cellular elements, exits the renal corpuscle via the efferent arteriole, perfuses the tubular capillary beds, and is eventually collected in the renal venous system.
  • 31. Copyright © John Wiley & Sons, Inc. All rights reserved. Glomerular Filtration In the average adult, the body’s entire extracellular fluid volume is filtered about 12 times per day.  Since we cannot afford to lose that amount of fluid, the vast majority must be reclaimed, with just a small portion being excreted in the urine.
  • 32. Copyright © John Wiley & Sons, Inc. All rights reserved. The daily composition of plasma, filtrate, and urine are compared. Glomerular Filtration Total Amount in Plasma Amount in 180 L of filtrate (/day) Amount returned to blood/d (Reabsorbed) Amount in Urine (/day) Water (passive) 3 L 180 L 178-179 L 1-2 L Protein (active) 200 g 2 g 1.9 g 0.1 g Glucose (active) 3 g 162 g 162 g 0 g Urea (passive) 1 g 54 g 24 g (about 1/2) 30 g (about 1/2) Creatinine 0.03 g 1.6 g 0 g (all filtered) 1.6 g (none reabsorbed)
  • 33. Copyright © John Wiley & Sons, Inc. All rights reserved. Glomerular Filtration Filtration is controlled by 2 opposing hydrostatic forces and 2 opposing osmotic forces at the glomerular membrane called Starling forces.  Blood hydrostatic pressure (55mmHg) is the main force that “pushes” water and solutes through the filtration membrane (promotes filtration).  Capsular hydrostatic pressure (15 mmHg) is exerted against the filtration membrane by fluid in the capsular space (opposes filtration).
  • 34. Copyright © John Wiley & Sons, Inc. All rights reserved. Glomerular Filtration Starling forces continued  Blood osmotic (oncotic) pressure (30 mmHg) is the pressure of plasma proteins “pulling” on water (opposes filtration).  Normally very little protein escapes through the filtration membrane making capsular oncotic pressure a negligible force except in certain disease states. Net Filtration = Blood Hydrostatic Pressure – Blood Osmotic Pressure – Capsular Hydrostatic Pressure  Net Filtration = 55-30-15 = 10 mmHg
  • 35. Copyright © John Wiley & Sons, Inc. All rights reserved. Glomerular Filtration Normally, 3 Starling forces are at work in glomerular filtration
  • 36. Copyright © John Wiley & Sons, Inc. All rights reserved. Regulation of the GFR is critical to maintaining homeostasis and is regulated by an assortment of local and systemic mechanisms:  Renal autoregulation occurs when the kidneys themselves regulate GFR.  Neural regulation occurs when the ANS regulates renal blood flow and GFR.  Hormonal regulation involves angiotensin II and atrial natriuretic peptide (ANP). Glomerular Filtration
  • 37. Copyright © John Wiley & Sons, Inc. All rights reserved. Renal autoregulation of GFR occurs by two means:  Stretching in the glomerular capillaries triggers myogenic contraction of smooth muscle cells in afferent arterioles (reduces GFR).  Pressure and flow monitored in the macula densa provides tubuloglomerular feedback to the glomerulus, causing the afferent arterioles to constrict (decreasing blood flow and GFR) or dilate (increasing blood flow and GFR) appropriately. Glomerular Filtration
  • 38. Copyright © John Wiley & Sons, Inc. All rights reserved. Neural regulation of GFR is possible because the renal blood vessels are supplied by sympathetic ANS fibers that release norepinephrine causing vasoconstriction.  Sympathetic input to the kidneys is most important with extreme drops of B.P. (as occurs with hemorrhage). Glomerular Filtration
  • 39. Copyright © John Wiley & Sons, Inc. All rights reserved. Two hormones contribute to regulation of GFR  Angiotensin II is a potent vasoconstrictor of both afferent and efferent arterioles (reduces GFR).  A sudden large increase in BP stretches the cardiac atria and releases atrial natriuretic peptide (ANP). ◦ ANP causes the glomerulus to relax, increasing the surface area for filtration. Glomerular Filtration
  • 40. Copyright © John Wiley & Sons, Inc. All rights reserved. Filtration slitPedicel of podocyte Fenestration (pore) of glomerular endothelial cell Basal lamina Lumen of glomerulus (b) Filtration membrane TEM 78,000x (a) Details of filtration membrane Filtration slit Pedicel Fenestration (pore) of glomerular endothelial cell: prevents filtration of blood cells but allows all components of blood plasma to pass through Podocyte of visceral layer of glomerular (Bowman’s) capsule 1 Filtration slitPedicel of podocyte Fenestration (pore) of glomerular endothelial cell Basal lamina Lumen of glomerulus (b) Filtration membrane TEM 78,000x (a) Details of filtration membrane Filtration slit Pedicel Fenestration (pore) of glomerular endothelial cell: prevents filtration of blood cells but allows all components of blood plasma to pass through Basal lamina of glomerulus: prevents filtration of larger proteins Podocyte of visceral layer of glomerular (Bowman’s) capsule 1 2 Filtration slitPedicel of podocyte Fenestration (pore) of glomerular endothelial cell Basal lamina Lumen of glomerulus (b) Filtration membrane TEM 78,000x (a) Details of filtration membrane Filtration slit Pedicel Fenestration (pore) of glomerular endothelial cell: prevents filtration of blood cells but allows all components of blood plasma to pass through Basal lamina of glomerulus: prevents filtration of larger proteins Slit membrane between pedicels: prevents filtration of medium-sized proteins Podocyte of visceral layer of glomerular (Bowman’s) capsule 1 2 3 The Filtration Membrane
  • 41. Copyright © John Wiley & Sons, Inc. All rights reserved. Glomerular Filtration (Interactions Animation) Renal Filtration You must be connected to the internet to run this animation
  • 42. Copyright © John Wiley & Sons, Inc. All rights reserved. NET FILTRATION PRESSURE (NFP) =GBHP – CHP – BCOP = 55 mmHg 15 mmHg 30 mmHg = 10 mmHg GLOMERULAR BLOOD HYDROSTATIC PRESSURE (GBHP) = 55 mmHg Capsular space Glomerular (Bowman's) capsule Efferent arteriole Afferent arteriole 1 Proximal convoluted tubule NET FILTRATION PRESSURE (NFP) =GBHP – CHP – BCOP = 55 mmHg 15 mmHg 30 mmHg = 10 mmHg CAPSULAR HYDROSTATIC PRESSURE (CHP) = 15 mmHg GLOMERULAR BLOOD HYDROSTATIC PRESSURE (GBHP) = 55 mmHg Capsular space Glomerular (Bowman's) capsule Efferent arteriole Afferent arteriole 1 2 Proximal convoluted tubule NET FILTRATION PRESSURE (NFP) =GBHP – CHP – BCOP = 55 mmHg 15 mmHg 30 mmHg = 10 mmHg BLOOD COLLOID OSMOTIC PRESSURE (BCOP) = 30 mmHg CAPSULAR HYDROSTATIC PRESSURE (CHP) = 15 mmHg GLOMERULAR BLOOD HYDROSTATIC PRESSURE (GBHP) = 55 mmHg Capsular space Glomerular (Bowman's) capsule Efferent arteriole Afferent arteriole 1 2 3 Proximal convoluted tubule Pressures That Drive Glomerular Filtration
  • 43. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Reabsorption Tubular reabsorption is the process of returning important substances (“good stuff”) from the filtrate back into the renal interstitium, then into the renal blood vessels... and ultimately back into the body.
  • 44. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Reabsorption The “good stuff” is glucose, electrolytes, vitamins, water, amino acids, and any small proteins that might have inadvertently escaped from the blood into the filtrate. Ninety nine percent of the glomerular filtrate is reabsorbed (most of it before the end of the PCT)!  To appreciate the magnitude of tubular reabsorption, look once again at the table in the next slide and compare the amounts of substances that are filtered, reabsorbed, and excreted in urine.
  • 45. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Reabsorption Total Amount in Plasma Amount in 180 L of filtrate (/day) Amount returned to blood/d (Reabsorbed) Amount in Urine (/day) Water (passive) 3 L 180 L 178-179 L 1-2 L Protein (active) 200 g 2 g 1.9 g 0.1 g Glucose (active) 3 g 162 g 162 g 0 g Urea (passive) 1 g 54 g 24 g (about 1/2) 30 g (about 1/2) Creatinine 0.03 g 1.6 g 0 g (all filtered) 1.6 g (none reabsorbed)
  • 46. Copyright © John Wiley & Sons, Inc. All rights reserved. Reabsorption into the interstitium has two routes:  Paracellular reabsorption is a passive process that occurs between adjacent tubule cells (tight junctions do not completely seal off interstitial fluid from tubule fluid.)  Transcellular reabsorption is movement through an individual cell. Tubular Reabsorption
  • 47. Copyright © John Wiley & Sons, Inc. All rights reserved. It is a tremendous feat to reabsorb all of the nutrients and fluid we must to survive, while still filtering out, concentrating and excreting toxic substance.  To accomplish this, the kidney establishes a countercurrent flow between the filtrate in the limbs of the Loops of Henle and the blood in the peritubular capillaries and Vasa Recta. ◦ Two types of countercurrent mechanisms exist in the kidneys: countercurrent multiplication and countercurrent exchange. Tubular Reabsorption
  • 48. Copyright © John Wiley & Sons, Inc. All rights reserved. Countercurrent multiplication is the process by which a progressively increasing osmotic gradient is formed in the interstitial fluid of the renal medulla as a result of countercurrent flow. Countercurrent exchange is the process by which solutes and water are passively exchanged between the blood of the vasa recta and interstitial fluid of the renal medulla as a result of countercurrent flow.  This provides oxygen and nutrients to the renal medulla without washing out or diminishing the gradient. Tubular Reabsorption
  • 49. Copyright © John Wiley & Sons, Inc. All rights reserved. Both mechanisms contribute to reabsorption of fluid and electrolytes and the formation of concentrated urine. Tubular Reabsorption
  • 50. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Reabsorption Reabsorption of fluids, ions, and other substances occurs by active and passive means.  A variety of symporters and antiporters actively transport Na+ , Cl– , Ca2+, H+, HCO3 – , glucose, HPO4 2– , SO4 2– , NH4 +, urea, all amino acids, and lactic acid.  Reabsorption of water can be obligatory or facultative, but it always moves by osmosis down its concentration gradient depending on the permeability of the tubule cells (which varies between the PCT, the different portions of the loop of Henle, DCT, and collecting ducts).
  • 51. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Reabsorption Obligatory reabsorption of water occurs when it is obliged to follow the solutes as they are reabsorbed (to maintain the osmotic gradient). Facultative reabsorption describes variable water reabsorption, adapted to specific needs.  It is regulated by the effects of ADH and aldosterone on the principal cells of the renal tubules and collecting ducts.
  • 52. Copyright © John Wiley & Sons, Inc. All rights reserved. This graphic depicts the formation of a dilute urine, mostly through obligatory reabsorption of water. Compare this process to the one depicted on the next slide where urine is concentrated by the action of ADH on the DCT and collecting ducts of juxtamedullary nephrons. Tubular Reabsorption
  • 53. Copyright © John Wiley & Sons, Inc. All rights reserved. Urine can be up to 4 times more concentrated than blood plasma. Tubular Reabsorption
  • 54. Copyright © John Wiley & Sons, Inc. All rights reserved.(b) Recycling of salts and urea in the vasa recta(a) Reabsorption of Na+CI– and water in a long-loop juxtamedullary nephron Glomerular (Bowman’s) capsule Afferent arteriole Efferent arteriole Glomerulus Distal convoluted tubule Proximal convoluted tubule Symporters in thick ascending limb cause buildup of Na+ and Cl– Interstitial fluid in renal medulla 300 1200 1000 800 Osmotic gradient 600 400 H2O H2O H2O 200 1200 980 600780 400580 200380 300 100 Loop of Henle 1200 Concentrated urine 300 300 320 400 600 800 1000 1200 800 H2O Urea Papillary duct Collecting duct 300 500 700 900 1100 1200 400 800 1000 600 Na+CI– Blood flow Flow of tubular fluid Presense of Na+-K+-2CI– symporters Interstitial fluid in renal cortex 320 Juxtamedullary nephron and its blood supply together Vasa recta Loop of Henle H2O H2O H2O H2O H2O H2O H2O 1 H2O H2O Na+CI– Na+CI– H2O Na+CI– H2O Na+CI– (b) Recycling of salts and urea in the vasa recta(a) Reabsorption of Na+CI– and water in a long-loop juxtamedullary nephron Glomerular (Bowman’s) capsule Afferent arteriole Efferent arteriole Glomerulus Distal convoluted tubule Proximal convoluted tubule Symporters in thick ascending limb cause buildup of Na+ and Cl– Interstitial fluid in renal medulla 300 1200 1000 800 Osmotic gradient 600 400 H2O H2O H2O 200 1200 980 600780 400580 200380 300 100 Loop of Henle 1200 Concentrated urine 300 300 320 400 600 800 1000 1200 800 H2O Urea Papillary duct Collecting duct Countercurrent flow through loop of Henle establishes an osmotic gradient 300 500 700 900 1100 1200 400 800 1000 600 Na+CI– Blood flow Flow of tubular fluid Presense of Na+-K+-2CI– symporters Interstitial fluid in renal cortex 320 Juxtamedullary nephron and its blood supply together Vasa recta Loop of Henle H2O H2O H2O H2O H2O H2O H2O 1 2 H2O H2O Na+CI– Na+CI– H2O Na+CI– H2O Na+CI– (b) Recycling of salts and urea in the vasa recta(a) Reabsorption of Na+CI– and water in a long-loop juxtamedullary nephron Glomerular (Bowman’s) capsule Afferent arteriole Efferent arteriole Glomerulus Distal convoluted tubule Proximal convoluted tubule Symporters in thick ascending limb cause buildup of Na+ and Cl– Interstitial fluid in renal medulla 300 1200 1000 800 Osmotic gradient 600 400 H2O H2O H2O 200 1200 980 600780 400580 200380 300 100 Loop of Henle 1200 Concentrated urine 300 300 320 400 600 800 1000 1200 800 H2O Urea Papillary duct Collecting duct Countercurrent flow through loop of Henle establishes an osmotic gradient Principal cells in collecting duct reabsorb more water when ADH is present 300 500 700 900 1100 1200 400 800 1000 600 Na+CI– Blood flow Flow of tubular fluid Presense of Na+-K+-2CI– symporters Interstitial fluid in renal cortex 320 Juxtamedullary nephron and its blood supply together Vasa recta Loop of Henle H2O H2O H2O H2O H2O H2O H2O 1 2 3 H2O H2O Na+CI– Na+CI– H2O Na+CI– H2O Na+CI– (b) Recycling of salts and urea in the vasa recta(a) Reabsorption of Na+CI– and water in a long-loop juxtamedullary nephron Glomerular (Bowman’s) capsule Afferent arteriole Efferent arteriole Glomerulus Distal convoluted tubule Proximal convoluted tubule Symporters in thick ascending limb cause buildup of Na+ and Cl– Interstitial fluid in renal medulla 300 1200 1000 800 Osmotic gradient 600 400 H2O H2O H2O 200 1200 980 600780 400580 200380 300 100 Loop of Henle 1200 Concentrated urine 300 300 320 400 600 800 1000 1200 800 H2O Urea Papillary duct Urea recycling causes buildup of urea in the renal medulla Collecting duct Countercurrent flow through loop of Henle establishes an osmotic gradient Principal cells in collecting duct reabsorb more water when ADH is present 300 500 700 900 1100 1200 400 800 1000 600 Na+CI– Blood flow Flow of tubular fluid Presense of Na+-K+-2CI– symporters Interstitial fluid in renal cortex 320 Juxtamedullary nephron and its blood supply together Vasa recta Loop of Henle H2O H2O H2O H2O H2O H2O H2O 1 2 3 4 H2O H2O Na+CI– Na+CI– H2O Na+CI– H2O Na+CI–
  • 55. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Reabsorption (Interactions Animation) Water Homeostasis You must be connected to the internet to run this animation
  • 56. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Reabsorption If higher than normal amounts of a substance are present in the filtrate, then the renal threshold for reabsorption of that substance may be surpassed.  When that happens, the substance cannot be reabsorbed fast enough, and it will be excreted in the urine.  For example, the renal [reabsorption] threshold of glucose is 180-200mg/dl. When this level is exceeded (as in diabetes mellitus), the glucose is said to “spill” into the urine (meaning a substance which is not normally present in urine begins to appear).
  • 57. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Secretion Tubular secretion is the movement of substances from the capillaries which surround the nephron into the filtrate.  It occurs at a site other than the filtration membrane (in the proximal convoluted tubule, distal convoluted tubule and collecting ducts) by active transport. The process of tubular secretion controls pH.  Hydrogen and ammonium ions are secreted to decrease the acidity in the body, and bicarbonate is conserved. ◦ Secreted substances include H+ , K+ , NH4 + , and some drugs; the amount often depends on body needs.
  • 58. Copyright © John Wiley & Sons, Inc. All rights reserved. Tubular Secretion Maintaining the body’s proper pH requires cooperation mainly between the lungs and the kidneys.  The lungs eliminate CO2. ◦ Provides a rapid response (minutes)  The kidneys eliminate H+ and NH4 + ions and conserve bicarbonate. ◦ This is a slower response (hours-days).  The alimentary canal (digestive), and integumentary system (skin) provide minor contributions.
  • 59. Copyright © John Wiley & Sons, Inc. All rights reserved. Five hormones affect the extent of Na+, Cl–, Ca2+, and water reabsorption as well as K+ secretion by the renal tubules. These hormones, all of which are key to maintaining homeostasis of not only renal blood flow and B.P., but systemic blood flow and B.P., are:  angiotensin II  antidiuretic hormone (ADH)  aldosterone  atrial natriuretic peptide (ANP)  parathyroid hormone (PTH) Hormones and Homeostasis
  • 60. Copyright © John Wiley & Sons, Inc. All rights reserved. We have already mentioned the effect of ANP on GFR. ADH is released by the posterior pituitary in response to low blood flow in this part of the brain.  ADH affects facultative water reabsorption by increasing the water permeability of principal cells in the last part of the distal convoluted tubule and throughout the collecting duct. ◦ In the absence of ADH, the apical membranes of principal cells are almost impermeable to water. Hormones and Homeostasis
  • 61. Copyright © John Wiley & Sons, Inc. All rights reserved. Secretion of the hormones angiotensin II and aldosterone are tied to one another: When blood volume and blood pressure decrease or the sympathetic NS is stimulated, the walls of the afferent arterioles are stretched less, and the cells of the JGA secrete renin. Hormones and Homeostasis
  • 62. Copyright © John Wiley & Sons, Inc. All rights reserved. Renin clips off a 10-amino-acid peptide called angiotensin I from angiotensinogen, which is synthesized by hepatocytes. By clipping off two more amino acids, angiotensin converting enzyme (ACE) converts angiotensin I to angiotensin II, which is the active form of the hormone. Angiotensin II has 3 main effects: 1. Vasoconstriction decreases GFR. 2. It increases blood volume by increasing reabsorption of water and electrolytes in the PCT. 3. It stimulates the adrenal cortex to release aldosterone. Hormones and Homeostasis
  • 63. Copyright © John Wiley & Sons, Inc. All rights reserved. Aldosterone stimulates the principal cells in the collecting ducts to reabsorb more Na+ and Cl– and secrete more K+. The osmotic consequence of reabsorbing more Na+ and Cl– is that more water is reabsorbed, which increases blood volume and blood pressure. Hormones and Homeostasis
  • 64. Copyright © John Wiley & Sons, Inc. All rights reserved. The events of filtration, absorption, and secretion are summarized in this graphic. Summary of Renal Function
  • 65. Copyright © John Wiley & Sons, Inc. All rights reserved. Increases in GFR usually result in an increase in urine production. However, as we have seen, the mechanisms which control electrolyte and water reabsorption in the various parts of the nephron and collecting ducts are subject to many complex controls.  Normal urine output (UOP) is 1-2 L/d. Urine
  • 66. Copyright © John Wiley & Sons, Inc. All rights reserved. A urinalysis analyzes the physical, chemical and microscopic properties of urine.  Water accounts for 95% of total urine volume.  The solutes normally present in urine are filtered and secreted substances that are not reabsorbed.  If disease alters metabolism or kidney function, traces of substances normally not present or normal constituents in abnormal amounts may appear (bacteria, albumin protein, glucose, white blood cells, red blood cells to name a few). Urine
  • 67. Copyright © John Wiley & Sons, Inc. All rights reserved. In addition to a urinalysis, two blood tests are commonly done clinically to assess the adequacy of renal function.  Blood urea nitrogen (BUN) measures nitrogen wastes in blood from catabolism and deamination of amino acids.  Creatinine levels appear in the blood as a result of catabolism of creatine phosphate in skeletal muscle. ◦ The serum creatinine test measures the amount of creatinine in the blood, which increases in states of renal dysfunction. Urine
