1. Chapter 04
Basic Communication Operation

2. Processes need to exchange data with
other processes
This exchange of data can significantly impact the efficiency of parallel programs by
introducing interaction delays during their execution

3. ts + mtw
simple exchange of an m-word message between two processes running on different
nodes of an interconnection network with cut-through routing.
ts: latency or the startup time for the data transfer
tw: per word transfer time
ts & tw inversely proportional to the available bandwidthbetween the nodes

4. Many interactions in practical parallel programs occur in well-defined patterns
involving more than two processes. Often either all processes
participate together in a single global interaction operation, or
subsets of processes participate in interactions local to each
subset.

5. Let's Digon Different kind of interations.

6. Chapter 4.1
One-to-All Broadcast
&
All-to-One Reduction

7. One-to-All Broadcast
Parallel algorithms often
require a single process to
send identical data to all
other processes or to a
subset of them
Initially, only the source process has the data of size m that needs to be broadcast.
At the termination of the procedure, there are p copies of the initial data – one
belonging to each process.

8. All-to-One Reduction
Each of the pparticipating processes starts
with a buffer M containing m words. The
data from all processes are combined
through an associative operator and
accumulated at a single destination process
into one buffer of size m

9. One-to-all broadcast and all-to-one reduction
usage
matrix-vector multiplication
Gaussian elimination
shortest paths
vector inner product

10. Chapter 4.1.1
Ring or Linear Array

11. Chapter 4.1.1
Ring or Linear Array

12. Chapter 4.1.1
A naive way to perform one-to-all broadcast is to sequentially
send p - 1 messages from the source to the other
p - 1 processes.

13. Chapter 4.1.1
A naive way to perform one-to-all broadcast is to sequentially
send p - 1 messages from the source to the other p -
1 processes.
This is inefficientbecause the source process becomes
a bottleneck
only the connection between a single pair of nodes is used at a time

14. Chapter 4.1.1
How to solve this bottleneck issue !

15. Chapter 4.1.1
The Solution is recursive doubling

16. Chapter 4.1.1
The Solution is recursive doubling
The source process first sends the message to another
process. Now both these processes can simultaneously send
the message to two other processes that are still waiting for the
message. By continuing this procedure until all the processes have
received the data, the message can be broadcast in log p steps.

17. Chapter 4.1.1

18. Chapter 4.1.1
Reductionon a linear array can be performed by simply
reversing the direction and the sequence of communication

19. Chapter 4.1.1
Reductionon a linear array can be performed by simply
reversing the direction and the sequence of communication

20. Chapter 4.1.1
Consider the problem of multiplying a
matrixwith a vector.
● The n x n matrix is assigned to an n x n (virtual)
processor grid. The vector is assumed to be on the
first row of processors.
● The first step of the product requires a one-to-all
broadcast of the vector element along the
corresponding column of processors. This can be
done concurrently for all n columns.
● The processors compute local product of the vector
element and the local matrix entry.
● In the final step, the results of these products are
accumulated to the first row using n concurrent all-to-
one reduction operations along the columns (using the
sum operation).

21. Chapter 4.1.2
Mesh

22. Chapter 4.1.2
Each row and column of a
square mesh of p nodes as
a linear array of √p nodes

23. Chapter 4.1.2
The linear array communication operation can be made in 2 phases
In the first phase, the operation is
performed along one or all rows by
treating the rows as linear arrays.
1

24. Chapter 4.1.2
The linear array communication operation can be made in 2 phases
In the second phase, the columns are
treated similarly.
2

25. Chapter 4.1.2
Consider a one-to-all
broadcast in 2D mesh

26. Chapter 4.1.2
All the data first going to
√(p-1) nodes in the same
raw

27. Chapter 4.1.2
Once all the nodes in a
row of the mesh have
acquired the data, they
initiate a one-to-all
broadcast in their
respective columns.

28. Chapter 4.1.2
At the end of the second
phase, every node in the
mesh has a copy of the
initial message.

29. Chapter 4.1.3
Hypercube

30. Chapter 4.1.3
Rows of p1/3
nodes in each
of the 3D mesh would be
treated as linear arrays

31. Chapter 4.1.3
Likethe mesh
The process is carried out by three phases
If D dimensional mesh we need d steps

32. Chapter 4.1.4
source processor is the root of
this tree
In the first step, the source sends the data to the right child
(assuming the source is also the left child). The problem has now
been decomposed into two problems with half the number of
processors.

33. Chapter 4.1.5
Algorithm

34. Chapter 4.1.5
One-to-all Broadcast
● All of the algorithms described above are adaptations of the same
algorithmic template.
● We illustrate the algorithm for a hypercube, but the algorithm, as has
been seen, can be adapted to other architectures.
●
The hypercube has 2d
nodes and my_id is the label for a node.
● X is the message to be broadcast, which initially resides
at the source node 0 means 000.
● initially resides at the source node 0
● The variable mask helps determine which nodes communicate in a
particular iteration of the loop

35. s
Algorithm 4.1
works only if node 0 is the source of the broadcast. For an arbitrary source, we must relabel the
nodes of the hypothetical hypercube by XORing the label of each node with the label of the source
node before we apply this procedure.

36. General Algorithm – whatever source can be...

37. Cost Analysis
T = (ts + mtw)logp

38. 4.2 All-to-All Broadcast
and Reduction

39. Generalization of One-to-All-Broadcast
A process sends the same m-word
message to every other process, but
different processes may broadcast
different messages.

40. Usage of All-to-All-Broadcast
It's used on matrix operations like
matrix multiplications and matrix-vector
multiplication

41. Dual is All-to-All-reduction

42. Figure illustration

43. All-to-All-Broadcast in Linear Array and Ring
While performing all-to-all broadcast on a linear array or a ring, all
communication links can be kept busy
simultaneously until the operation is complete because
each node always has some information that it can pass along to
its neighbor.

44. ● Simplest approach: perform p one-to-all
broadcasts. This is not the most efficient
way, though.
● Each node first sends to one of its neighbors
the data it needs to broadcast.
● In subsequent steps, it forwards the data
received from one of its neighbors to its other
neighbor.
● The algorithm terminates in p-1 steps.

45. All-to-All Broadcast and Reduction

46. Algorithm for All-to-All-Broadcast in Ring

47. In all-to-all reduction, the dual of all-to-all broadcast
All-to-all reduction can be performed by reversing the direction and
sequence of the messages
< Example />
First communication step in all-to-all broadcast would be the last step
of all-to-all reduction.
0 sending msg[1] to 7 instead of receiving it. The only additional step required is that upon receiving a
message, a node must combine it with the local copy of the message that has the same destination as
the received message before forwarding the combined message to the next neighbor.

49. All-to-All-Broadcast in Mesh
Performed in two phases -
In the first phase :- each row of the mesh performs an all-to-all broadcast using
the procedure for the linear array.
In this phase, all nodes collect √p messages corresponding to the √p
nodes of their respective rows. Each node consolidates this information into a
single message of size m√p.
In second communication phase :- a columnwise all-to-all broadcast of the
consolidated messages.

50. Algorithm for All-to-All-Broadcast in Mesh

51. ● Generalization of the mesh algorithm to log p dimensions.
● Message size doubles at each of the log p steps.
All-to-All-Broadcast in Hypercube

53. Cost Analysis
For linear array
T = (ts + mtw)(p-1)

54. For Mesh
Tfirst = (ts + mtw)(√p-1)
Tsecond = (ts + m√ptw)(√p-1)
Ttotal = (2ts)(√p-1) + twm(p-1)
Cost Analysis

55. Chapter 4.3
All-Reduce and Prefix Sum Operation

56. All-Reduce
Each node starts with a buffer of size m
and
The final results of the operation are identical buffers of size
m on each node that are formed by combining the original p
buffers using an associative operator

57. There is 2 ways to perform all-reduce
A simple method to perform all-reduce is to
perform an all-to-one reduction followed by a one-
to-all broadcast

58. There is 2 ways to perform all-reduce
There is a faster way to perform all-reduce by
using the communication pattern of all-to-all
broadcast
The Specialty is the message size is not increased here.
That is message size is m (m√p)

59. ……...

60. Chapter 4.4
Scatter and Gather

61. Scatter and Gather
●
In the scatter operation, a single node sends a unique
message of size m to every other node (also called a
one-to-all personalized communication).
●
In the gather operation, a single node collects a unique
message from each node.
● While the scatter operation is fundamentally different from
broadcast, the algorithmic structure is similar, except for
differences in message sizes (messages get smaller in
scatter and stay constant in broadcast).
● The gather operation is exactly the inverse of the scatter
operation.

63. Example of Scatter on Hypercube
In the first communication step, the source transfers half of the messages to
one of its neighbors. In subsequent steps, each node that has some data transfers half
of it to a neighbor that has yet to receive any data. There is a total of log p
communication steps corresponding to the log p dimensions of the hypercube.

64. The gather operation is simply the reverse of
scatter.
