1. Analysis of Algorithms
Multi-threaded Algorithms
Andres Mendez-Vazquez
April 15, 2016
1 / 94

2. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
2 / 94

3. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
3 / 94

4. Multi-Threaded Algorithms
Motivation
Until now, our serial algorithms are quite suitable for running on a
single processor system.
However, multiprocessor algorithms are ubiquitous:
Therefore, extending our serial models to a parallel computation model
is a must.
Computational Model
There exist many competing models of parallel computation that are
essentially different:
Shared Memory
Message Passing
Etc.
4 / 94

5. Multi-Threaded Algorithms
Motivation
Until now, our serial algorithms are quite suitable for running on a
single processor system.
However, multiprocessor algorithms are ubiquitous:
Therefore, extending our serial models to a parallel computation model
is a must.
Computational Model
There exist many competing models of parallel computation that are
essentially different:
Shared Memory
Message Passing
Etc.
4 / 94

6. Multi-Threaded Algorithms
Motivation
Until now, our serial algorithms are quite suitable for running on a
single processor system.
However, multiprocessor algorithms are ubiquitous:
Therefore, extending our serial models to a parallel computation model
is a must.
Computational Model
There exist many competing models of parallel computation that are
essentially different:
Shared Memory
Message Passing
Etc.
4 / 94

7. Multi-Threaded Algorithms
Motivation
Until now, our serial algorithms are quite suitable for running on a
single processor system.
However, multiprocessor algorithms are ubiquitous:
Therefore, extending our serial models to a parallel computation model
is a must.
Computational Model
There exist many competing models of parallel computation that are
essentially different:
Shared Memory
Message Passing
Etc.
4 / 94

8. Multi-Threaded Algorithms
Motivation
Until now, our serial algorithms are quite suitable for running on a
single processor system.
However, multiprocessor algorithms are ubiquitous:
Therefore, extending our serial models to a parallel computation model
is a must.
Computational Model
There exist many competing models of parallel computation that are
essentially different:
Shared Memory
Message Passing
Etc.
4 / 94

9. Multi-Threaded Algorithms
Motivation
Until now, our serial algorithms are quite suitable for running on a
single processor system.
However, multiprocessor algorithms are ubiquitous:
Therefore, extending our serial models to a parallel computation model
is a must.
Computational Model
There exist many competing models of parallel computation that are
essentially different:
Shared Memory
Message Passing
Etc.
4 / 94

10. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
5 / 94

11. The Model to Be Used
Symmetric Multiprocessor
The model that we will use is the Symmetric Multiprocessor (SMP) where
a shared memory exists.
L3 Cache
L2 Cache L1i Cache
L1d Cache CPU Core 1
CPU Core 3 CPU Core 4
CPU Core 2
L1d Cache
L1d Cache
L1d Cache
L1i Cache
L1i Cache
L1i Cache
L2 Cache
L2 CacheL2 Cache
P-to-P
L3 Cache
L2 Cache L1i Cache
L1d Cache CPU Core 1
CPU Core 3 CPU Core 4
CPU Core 2
L1d Cache
L1d Cache
L1d Cache
L1i Cache
L1i Cache
L1i Cache
L2 Cache
L2 CacheL2 Cache
P-to-P
L3 Cache
L2 Cache L1i Cache
L1d Cache CPU Core 1
CPU Core 3 CPU Core 4
CPU Core 2
L1d Cache
L1d Cache
L1d Cache
L1i Cache
L1i Cache
L1i Cache
L2 Cache
L2 CacheL2 Cache
P-to-P
L3 Cache
L2 Cache L1i Cache
L1d Cache CPU Core 1
CPU Core 3 CPU Core 4
CPU Core 2
L1d Cache
L1d Cache
L1d Cache
L1i Cache
L1i Cache
L1i Cache
L2 Cache
L2 CacheL2 Cache
P-to-P
MAIN SHARED MEMORY
Processor 1 Processor 2 Processor 3 Processor 4
BUS
6 / 94

12. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

13. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

14. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

15. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

16. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

17. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

18. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

19. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

20. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

21. Dynamic Multi-Threading
Dynamic Multi-Threading
In reality it can be difficult to handle multi-threaded programs in a
SMP.
Thus, we will assume a simple concurrency platform that handles all
the resources:
Schedules
Memory
Etc
It is Called Dynamic Multi-threading.
Dynamic Multi-Threading Computing Operations
Spawn
Sync
Parallel
7 / 94

22. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
8 / 94

23. SPAWN
SPAWN
When called before a procedure, the parent procedure may continue to
execute in parallel.
Note
The keyword spawn does not say anything about concurrent
execution, but it can happen.
The Scheduler decide which computations should run concurrently.
9 / 94

24. SPAWN
SPAWN
When called before a procedure, the parent procedure may continue to
execute in parallel.
Note
The keyword spawn does not say anything about concurrent
execution, but it can happen.
The Scheduler decide which computations should run concurrently.
9 / 94

25. SPAWN
SPAWN
When called before a procedure, the parent procedure may continue to
execute in parallel.
Note
The keyword spawn does not say anything about concurrent
execution, but it can happen.
The Scheduler decide which computations should run concurrently.
9 / 94

26. SYNC AND PARALLEL
SYNC
The keyword sync indicates that the procedure must wait for all its
spawned children to complete.
PARALLEL
This operation applies to loops, which make possible to execute the body
of the loop in parallel.
10 / 94

27. SYNC AND PARALLEL
SYNC
The keyword sync indicates that the procedure must wait for all its
spawned children to complete.
PARALLEL
This operation applies to loops, which make possible to execute the body
of the loop in parallel.
10 / 94

28. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
11 / 94

29. A Classic Parallel Piece of Code: Fibonacci Numbers
Fibonacci’s Definition
F0 = 0
F1 = 1
Fi = Fi−1 + Fi−2 for i > 1.
Naive Algorithm
Fibonacci(n)
1 if n ≤ 1 then
2 return n
3 else x = Fibonacci(n − 1)
4 y = Fibonacci(n − 2)
5 return x + y
12 / 94

30. A Classic Parallel Piece of Code: Fibonacci Numbers
Fibonacci’s Definition
F0 = 0
F1 = 1
Fi = Fi−1 + Fi−2 for i > 1.
Naive Algorithm
Fibonacci(n)
1 if n ≤ 1 then
2 return n
3 else x = Fibonacci(n − 1)
4 y = Fibonacci(n − 2)
5 return x + y
12 / 94

31. Time Complexity
Recursion and Complexity
Recursion T (n) =T (n − 1) + T (n − 2) + Θ (1).
Complexity T(n) = Θ (Fn) = Θ (φn), φ = 1+
√
5
2 .
13 / 94

32. Time Complexity
Recursion and Complexity
Recursion T (n) =T (n − 1) + T (n − 2) + Θ (1).
Complexity T(n) = Θ (Fn) = Θ (φn), φ = 1+
√
5
2 .
13 / 94

33. There is a Better Way
We can order the first tree numbers in the sequence as
F2 F1
F1 F0
=
1 1
1 0
Then
F2 F1
F1 F0
F2 F1
F1 F0
=
1 1
1 0
1 1
1 0
=
2 1
1 1
=
F3 F2
F2 F1
14 / 94

34. There is a Better Way
We can order the first tree numbers in the sequence as
F2 F1
F1 F0
=
1 1
1 0
Then
F2 F1
F1 F0
F2 F1
F1 F0
=
1 1
1 0
1 1
1 0
=
2 1
1 1
=
F3 F2
F2 F1
14 / 94

35. There is a Better Way
Calculating in O(log n) when n is a power of 2
1 1
1 0
n
=
F (n + 1) F (n)
F (n) F (n − 1)
Thus
1 1
1 0
n
2
1 1
1 0
n
2
=
F n
2
+ 1 F n
2
F n
2
F n
2
− 1
F n
2
+ 1 F n
2
F n
2
F n
2
− 1
However...
We will use the naive version to illustrate the principles of parallel
programming.
15 / 94

36. There is a Better Way
Calculating in O(log n) when n is a power of 2
1 1
1 0
n
=
F (n + 1) F (n)
F (n) F (n − 1)
Thus
1 1
1 0
n
2
1 1
1 0
n
2
=
F n
2
+ 1 F n
2
F n
2
F n
2
− 1
F n
2
+ 1 F n
2
F n
2
F n
2
− 1
However...
We will use the naive version to illustrate the principles of parallel
programming.
15 / 94

37. The Concurrent Code
Parallel Algorithm
PFibonacci(n)
1 if n ≤ 1 then
2 return n
3 else x = spawn Fibonacci(n − 1)
4 y = Fibonacci(n − 2)
5 sync
6 return x + y
16 / 94

38. The Concurrent Code
Parallel Algorithm
PFibonacci(n)
1 if n ≤ 1 then
2 return n
3 else x = spawn Fibonacci(n − 1)
4 y = Fibonacci(n − 2)
5 sync
6 return x + y
16 / 94

39. The Concurrent Code
Parallel Algorithm
PFibonacci(n)
1 if n ≤ 1 then
2 return n
3 else x = spawn Fibonacci(n − 1)
4 y = Fibonacci(n − 2)
5 sync
6 return x + y
16 / 94

40. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
17 / 94

41. How do we compute a complexity? Computation DAG
Definition
A directed acyclic G = (V , E) graph where
The vertices V are sets of instructions.
The edges E represent dependencies between sets of instructions i.e.
(u, v) instruction u before v.
Notes
A set of instructions without any parallel control are grouped in a
strand.
Thus, V represents a set of strands and E represents dependencies
between strands induced by parallel control.
A strand of maximal length will be called a thread.
18 / 94

42. How do we compute a complexity? Computation DAG
Definition
A directed acyclic G = (V , E) graph where
The vertices V are sets of instructions.
The edges E represent dependencies between sets of instructions i.e.
(u, v) instruction u before v.
Notes
A set of instructions without any parallel control are grouped in a
strand.
Thus, V represents a set of strands and E represents dependencies
between strands induced by parallel control.
A strand of maximal length will be called a thread.
18 / 94

43. How do we compute a complexity? Computation DAG
Definition
A directed acyclic G = (V , E) graph where
The vertices V are sets of instructions.
The edges E represent dependencies between sets of instructions i.e.
(u, v) instruction u before v.
Notes
A set of instructions without any parallel control are grouped in a
strand.
Thus, V represents a set of strands and E represents dependencies
between strands induced by parallel control.
A strand of maximal length will be called a thread.
18 / 94

44. How do we compute a complexity? Computation DAG
Definition
A directed acyclic G = (V , E) graph where
The vertices V are sets of instructions.
The edges E represent dependencies between sets of instructions i.e.
(u, v) instruction u before v.
Notes
A set of instructions without any parallel control are grouped in a
strand.
Thus, V represents a set of strands and E represents dependencies
between strands induced by parallel control.
A strand of maximal length will be called a thread.
18 / 94

45. How do we compute a complexity? Computation DAG
Definition
A directed acyclic G = (V , E) graph where
The vertices V are sets of instructions.
The edges E represent dependencies between sets of instructions i.e.
(u, v) instruction u before v.
Notes
A set of instructions without any parallel control are grouped in a
strand.
Thus, V represents a set of strands and E represents dependencies
between strands induced by parallel control.
A strand of maximal length will be called a thread.
18 / 94

46. How do we compute a complexity? Computation DAG
Definition
A directed acyclic G = (V , E) graph where
The vertices V are sets of instructions.
The edges E represent dependencies between sets of instructions i.e.
(u, v) instruction u before v.
Notes
A set of instructions without any parallel control are grouped in a
strand.
Thus, V represents a set of strands and E represents dependencies
between strands induced by parallel control.
A strand of maximal length will be called a thread.
18 / 94

47. How do we compute a complexity? Computation DAG
Thus
If there is an edge between thread u and v, then they are said to be
(logically) in series.
If there is no edge, then they are said to be (logically) in parallel.
19 / 94

48. How do we compute a complexity? Computation DAG
Thus
If there is an edge between thread u and v, then they are said to be
(logically) in series.
If there is no edge, then they are said to be (logically) in parallel.
19 / 94

49. Example: PFibonacci(4)
Example
PFibonacci(4)
PFibonacci(3) PFibonacci(2)
PFibonacci(2)
PFibonacci(1) PFibonacci(1)
PFibonacci(1) PFibonacci(0)
PFibonacci(0)
20 / 94

50. Edge Classification
Continuation Edge
A continuation edge (u, v) connects a thread u to its successor v within
the same procedure instance.
Spawned Edge
When a thread u spawns a new thread v, then (u, v) is called a spawned
edge.
Call Edges
Call edges represent normal procedure call.
Return Edge
Return edge signals when a thread v returns to its calling procedure.
21 / 94

51. Edge Classification
Continuation Edge
A continuation edge (u, v) connects a thread u to its successor v within
the same procedure instance.
Spawned Edge
When a thread u spawns a new thread v, then (u, v) is called a spawned
edge.
Call Edges
Call edges represent normal procedure call.
Return Edge
Return edge signals when a thread v returns to its calling procedure.
21 / 94

52. Edge Classification
Continuation Edge
A continuation edge (u, v) connects a thread u to its successor v within
the same procedure instance.
Spawned Edge
When a thread u spawns a new thread v, then (u, v) is called a spawned
edge.
Call Edges
Call edges represent normal procedure call.
Return Edge
Return edge signals when a thread v returns to its calling procedure.
21 / 94

53. Edge Classification
Continuation Edge
A continuation edge (u, v) connects a thread u to its successor v within
the same procedure instance.
Spawned Edge
When a thread u spawns a new thread v, then (u, v) is called a spawned
edge.
Call Edges
Call edges represent normal procedure call.
Return Edge
Return edge signals when a thread v returns to its calling procedure.
21 / 94

54. Example: PFibonacci(4)
The Different Edges
PFibonacci(4)
PFibonacci(3) PFibonacci(2)
PFibonacci(2)
PFibonacci(1) PFibonacci(1)
PFibonacci(1) PFibonacci(0)
PFibonacci(0)
Init Thread
Spawn Edge
Continuation Edge
Return Edge
Final Thread
Call Edge
22 / 94

55. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
23 / 94

56. Performance Measures
WORK
The work of a multi-threaded computation is the total time to execute the
entire computation on one processor.
Work =
i∈I
Time (Threadi)
SPAN
The span is the longest time to execute the strands along any path of the
DAG.
In a DAG which each strand takes unit time, the span equals the
number of vertices on a longest or critical path in the DAG.
24 / 94

57. Performance Measures
WORK
The work of a multi-threaded computation is the total time to execute the
entire computation on one processor.
Work =
i∈I
Time (Threadi)
SPAN
The span is the longest time to execute the strands along any path of the
DAG.
In a DAG which each strand takes unit time, the span equals the
number of vertices on a longest or critical path in the DAG.
24 / 94

58. Example: PFibonacci(4)
Example
Critical Path
PFibonacci(4)
PFibonacci(3) PFibonacci(2)
PFibonacci(2)
PFibonacci(1) PFibonacci(1)
PFibonacci(1) PFibonacci(0)
PFibonacci(0)
25 / 94

59. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

60. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

61. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

62. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

63. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

64. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

65. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

66. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

67. Example
Example
In Fibonacci(4), we have
17 threads.
8 vertices in the longest path
We have that
Assuming unit time
WORK=17 time units
SPAN=8 time units
Note
Running time not only depends on work and span but
Available Cores
Scheduler Policies
26 / 94

68. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
27 / 94

69. Running Time Classification
Single Processor
T1 running time on a single processor.
Multiple Processors
Tp running time on P processors.
Unlimited Processors
T∞ running time on unlimited processors, also called the span, if we
run each strand on its own processor.
28 / 94

70. Running Time Classification
Single Processor
T1 running time on a single processor.
Multiple Processors
Tp running time on P processors.
Unlimited Processors
T∞ running time on unlimited processors, also called the span, if we
run each strand on its own processor.
28 / 94

71. Running Time Classification
Single Processor
T1 running time on a single processor.
Multiple Processors
Tp running time on P processors.
Unlimited Processors
T∞ running time on unlimited processors, also called the span, if we
run each strand on its own processor.
28 / 94

72. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
29 / 94

73. Work Law
Definition
In one step, an ideal parallel computer with P processors can do:
At most P units of work.
Thus in TP time, it can perform at most PTP work.
PTP ≥ T1 =⇒ Tp ≥
T1
P
30 / 94

74. Work Law
Definition
In one step, an ideal parallel computer with P processors can do:
At most P units of work.
Thus in TP time, it can perform at most PTP work.
PTP ≥ T1 =⇒ Tp ≥
T1
P
30 / 94

75. Work Law
Definition
In one step, an ideal parallel computer with P processors can do:
At most P units of work.
Thus in TP time, it can perform at most PTP work.
PTP ≥ T1 =⇒ Tp ≥
T1
P
30 / 94

76. Work Law
Definition
In one step, an ideal parallel computer with P processors can do:
At most P units of work.
Thus in TP time, it can perform at most PTP work.
PTP ≥ T1 =⇒ Tp ≥
T1
P
30 / 94

77. Span Law
Definition
A P-processor ideal parallel computer cannot run faster than a
machine with unlimited number of processors.
However, a computer with unlimited number of processors can
emulate a P-processor machine by using simply P of its processors.
Therefore,
TP ≥ T∞
31 / 94

78. Span Law
Definition
A P-processor ideal parallel computer cannot run faster than a
machine with unlimited number of processors.
However, a computer with unlimited number of processors can
emulate a P-processor machine by using simply P of its processors.
Therefore,
TP ≥ T∞
31 / 94

79. Work Calculations: Serial
Serial Computations
A B
Note
Work: T1 (A ∪ B) = T1 (A) + T1 (B).
Span: T∞ (A ∪ B) = T∞ (A) + T∞ (B).
32 / 94

80. Work Calculations: Serial
Serial Computations
A B
Note
Work: T1 (A ∪ B) = T1 (A) + T1 (B).
Span: T∞ (A ∪ B) = T∞ (A) + T∞ (B).
32 / 94

81. Work Calculations: Serial
Serial Computations
A B
Note
Work: T1 (A ∪ B) = T1 (A) + T1 (B).
Span: T∞ (A ∪ B) = T∞ (A) + T∞ (B).
32 / 94

82. Work Calculations: Parallel
Parallel Computations
A
B
Note
Work: T1 (A ∪ B) = T1 (A) + T1 (B).
Span: T∞ (A ∪ B) = max {T∞ (A) , T∞ (B)}.
33 / 94

83. Work Calculations: Parallel
Parallel Computations
A
B
Note
Work: T1 (A ∪ B) = T1 (A) + T1 (B).
Span: T∞ (A ∪ B) = max {T∞ (A) , T∞ (B)}.
33 / 94

84. Work Calculations: Parallel
Parallel Computations
A
B
Note
Work: T1 (A ∪ B) = T1 (A) + T1 (B).
Span: T∞ (A ∪ B) = max {T∞ (A) , T∞ (B)}.
33 / 94

85. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
34 / 94

86. Speedup and Parallelism
Speed up
The speed up of a computation on P processors is defined as T1
TP
.
Then, by work law T1
TP
≤ P. Thus, the speedup on P processors can
be at most P.
Notes
Linear Speedup when T1
TP
= Θ (P).
Perfect Linear Speedup when T1
TP
= P.
Parallelism
The parallelism of a computation on P processors is defined as T1
T∞
.
In specific, we are looking to have a lot of parallelism.
This changes from Algorithm to Algorithm.
35 / 94

87. Speedup and Parallelism
Speed up
The speed up of a computation on P processors is defined as T1
TP
.
Then, by work law T1
TP
≤ P. Thus, the speedup on P processors can
be at most P.
Notes
Linear Speedup when T1
TP
= Θ (P).
Perfect Linear Speedup when T1
TP
= P.
Parallelism
The parallelism of a computation on P processors is defined as T1
T∞
.
In specific, we are looking to have a lot of parallelism.
This changes from Algorithm to Algorithm.
35 / 94

88. Speedup and Parallelism
Speed up
The speed up of a computation on P processors is defined as T1
TP
.
Then, by work law T1
TP
≤ P. Thus, the speedup on P processors can
be at most P.
Notes
Linear Speedup when T1
TP
= Θ (P).
Perfect Linear Speedup when T1
TP
= P.
Parallelism
The parallelism of a computation on P processors is defined as T1
T∞
.
In specific, we are looking to have a lot of parallelism.
This changes from Algorithm to Algorithm.
35 / 94

89. Speedup and Parallelism
Speed up
The speed up of a computation on P processors is defined as T1
TP
.
Then, by work law T1
TP
≤ P. Thus, the speedup on P processors can
be at most P.
Notes
Linear Speedup when T1
TP
= Θ (P).
Perfect Linear Speedup when T1
TP
= P.
Parallelism
The parallelism of a computation on P processors is defined as T1
T∞
.
In specific, we are looking to have a lot of parallelism.
This changes from Algorithm to Algorithm.
35 / 94

90. Speedup and Parallelism
Speed up
The speed up of a computation on P processors is defined as T1
TP
.
Then, by work law T1
TP
≤ P. Thus, the speedup on P processors can
be at most P.
Notes
Linear Speedup when T1
TP
= Θ (P).
Perfect Linear Speedup when T1
TP
= P.
Parallelism
The parallelism of a computation on P processors is defined as T1
T∞
.
In specific, we are looking to have a lot of parallelism.
This changes from Algorithm to Algorithm.
35 / 94

91. Speedup and Parallelism
Speed up
The speed up of a computation on P processors is defined as T1
TP
.
Then, by work law T1
TP
≤ P. Thus, the speedup on P processors can
be at most P.
Notes
Linear Speedup when T1
TP
= Θ (P).
Perfect Linear Speedup when T1
TP
= P.
Parallelism
The parallelism of a computation on P processors is defined as T1
T∞
.
In specific, we are looking to have a lot of parallelism.
This changes from Algorithm to Algorithm.
35 / 94

92. Speedup and Parallelism
Speed up
The speed up of a computation on P processors is defined as T1
TP
.
Then, by work law T1
TP
≤ P. Thus, the speedup on P processors can
be at most P.
Notes
Linear Speedup when T1
TP
= Θ (P).
Perfect Linear Speedup when T1
TP
= P.
Parallelism
The parallelism of a computation on P processors is defined as T1
T∞
.
In specific, we are looking to have a lot of parallelism.
This changes from Algorithm to Algorithm.
35 / 94

93. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
36 / 94

94. Greedy Scheduler
Definition
A greedy scheduler assigns as many strands to processors as
possible in each time step.
Note
On P processors, if at least P strands are ready to execute during a
time step, then we say that the step is a complete step.
Otherwise we say that it is an incomplete step.
This changes from Algorithm to Algorithm.
37 / 94

95. Greedy Scheduler
Definition
A greedy scheduler assigns as many strands to processors as
possible in each time step.
Note
On P processors, if at least P strands are ready to execute during a
time step, then we say that the step is a complete step.
Otherwise we say that it is an incomplete step.
This changes from Algorithm to Algorithm.
37 / 94

96. Greedy Scheduler
Definition
A greedy scheduler assigns as many strands to processors as
possible in each time step.
Note
On P processors, if at least P strands are ready to execute during a
time step, then we say that the step is a complete step.
Otherwise we say that it is an incomplete step.
This changes from Algorithm to Algorithm.
37 / 94

97. Greedy Scheduler
Definition
A greedy scheduler assigns as many strands to processors as
possible in each time step.
Note
On P processors, if at least P strands are ready to execute during a
time step, then we say that the step is a complete step.
Otherwise we say that it is an incomplete step.
This changes from Algorithm to Algorithm.
37 / 94

98. Greedy Scheduler Theorem and Corollaries
Theorem 27.1
On an ideal parallel computer with P processors, a greedy scheduler
executes a multi-threaded computation with work T1 and span T∞ in time
TP ≤ T1
P + T∞.
Corollary 27.2
The running time TP of any multi-threaded computation scheduled by a
greedy scheduler on an ideal parallel computer with P processors is within
a factor of 2 of optimal.
Corollary 27.3
Let TP be the running time of a multi-threaded computation produced by
a greedy scheduler on an ideal parallel computer with P processors, and let
T1 and T∞ be the work and span of the computation, respectively. Then,
if P T1
T∞
(Much Less), we have TP ≈ T1
P , or equivalently, a speedup of
approximately P .
38 / 94

99. Greedy Scheduler Theorem and Corollaries
Theorem 27.1
On an ideal parallel computer with P processors, a greedy scheduler
executes a multi-threaded computation with work T1 and span T∞ in time
TP ≤ T1
P + T∞.
Corollary 27.2
The running time TP of any multi-threaded computation scheduled by a
greedy scheduler on an ideal parallel computer with P processors is within
a factor of 2 of optimal.
Corollary 27.3
Let TP be the running time of a multi-threaded computation produced by
a greedy scheduler on an ideal parallel computer with P processors, and let
T1 and T∞ be the work and span of the computation, respectively. Then,
if P T1
T∞
(Much Less), we have TP ≈ T1
P , or equivalently, a speedup of
approximately P .
38 / 94

100. Greedy Scheduler Theorem and Corollaries
Theorem 27.1
On an ideal parallel computer with P processors, a greedy scheduler
executes a multi-threaded computation with work T1 and span T∞ in time
TP ≤ T1
P + T∞.
Corollary 27.2
The running time TP of any multi-threaded computation scheduled by a
greedy scheduler on an ideal parallel computer with P processors is within
a factor of 2 of optimal.
Corollary 27.3
Let TP be the running time of a multi-threaded computation produced by
a greedy scheduler on an ideal parallel computer with P processors, and let
T1 and T∞ be the work and span of the computation, respectively. Then,
if P T1
T∞
(Much Less), we have TP ≈ T1
P , or equivalently, a speedup of
approximately P .
38 / 94

101. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
39 / 94

102. Race Conditions
Determinacy Race
A determinacy race occurs when two logically parallel instructions access
the same memory location and at least one of the instructions performs a
write.
Example
Race-Example()
1 x = 0
2 parallel for i = 1 to 3 do
3 x = x + 1
4 print x
40 / 94

103. Race Conditions
Determinacy Race
A determinacy race occurs when two logically parallel instructions access
the same memory location and at least one of the instructions performs a
write.
Example
Race-Example()
1 x = 0
2 parallel for i = 1 to 3 do
3 x = x + 1
4 print x
40 / 94

104. Example
Determinacy Race Example
1
2
3
4 5
67
8 910
11
step x r1 r2 r3
1 0
2 0 0
3 0 1
4 0 1 0
5 0 1 0 0
6 0 1 0 1
7 0 1 1 1
8 1 1 1 1
9 1 1 1 1
10 1 1 1 1
41 / 94

105. Example
NOTE
Although, this is of great importance is beyond the scope of this class:
For More about this topic, we have:
Maurice Herlihy and Nir Shavit, “The Art of Multiprocessor
Programming,” Morgan Kaufmann Publishers Inc., San Francisco, CA,
USA, 2008.
Andrew S. Tanenbaum, “Modern Operating Systems” (3rd ed.).
Prentice Hall Press, Upper Saddle River, NJ, USA, 2007.
42 / 94

106. Example
NOTE
Although, this is of great importance is beyond the scope of this class:
For More about this topic, we have:
Maurice Herlihy and Nir Shavit, “The Art of Multiprocessor
Programming,” Morgan Kaufmann Publishers Inc., San Francisco, CA,
USA, 2008.
Andrew S. Tanenbaum, “Modern Operating Systems” (3rd ed.).
Prentice Hall Press, Upper Saddle River, NJ, USA, 2007.
42 / 94

107. Example
NOTE
Although, this is of great importance is beyond the scope of this class:
For More about this topic, we have:
Maurice Herlihy and Nir Shavit, “The Art of Multiprocessor
Programming,” Morgan Kaufmann Publishers Inc., San Francisco, CA,
USA, 2008.
Andrew S. Tanenbaum, “Modern Operating Systems” (3rd ed.).
Prentice Hall Press, Upper Saddle River, NJ, USA, 2007.
42 / 94

108. Example
NOTE
Although, this is of great importance is beyond the scope of this class:
For More about this topic, we have:
Maurice Herlihy and Nir Shavit, “The Art of Multiprocessor
Programming,” Morgan Kaufmann Publishers Inc., San Francisco, CA,
USA, 2008.
Andrew S. Tanenbaum, “Modern Operating Systems” (3rd ed.).
Prentice Hall Press, Upper Saddle River, NJ, USA, 2007.
42 / 94

109. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
43 / 94

110. Example of Complexity: PFibonacci
Complexity
T∞ (n) = max {T∞ (n − 1) , T∞ (n − 2)} + Θ (1)
Finally
T∞ (n) = T∞ (n − 1) + Θ (1) = Θ (n)
Parallelism
T1 (n)
T∞ (n)
= Θ
φn
n
44 / 94

111. Example of Complexity: PFibonacci
Complexity
T∞ (n) = max {T∞ (n − 1) , T∞ (n − 2)} + Θ (1)
Finally
T∞ (n) = T∞ (n − 1) + Θ (1) = Θ (n)
Parallelism
T1 (n)
T∞ (n)
= Θ
φn
n
44 / 94

112. Example of Complexity: PFibonacci
Complexity
T∞ (n) = max {T∞ (n − 1) , T∞ (n − 2)} + Θ (1)
Finally
T∞ (n) = T∞ (n − 1) + Θ (1) = Θ (n)
Parallelism
T1 (n)
T∞ (n)
= Θ
φn
n
44 / 94

113. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
45 / 94

114. Matrix Multiplication
Trick
To multiply two n × n matrices, we perform 8 matrix multiplications of
n
2 × n
2 matrices and one addition n × n of matrices.
Idea
A=
A11 A12
A21 A22
,B =
B11 B12
B21 B22
, C =
C11 C12
C21 C22
C =
C11 C12
C21 C22
=
A11 A12
A21 A22
B11 B12
B21 B22
= ...
A11B11 A11B12
A21B11 A21B12
+
A12B21 A12B22
A22B21 A22B22
46 / 94

115. Matrix Multiplication
Trick
To multiply two n × n matrices, we perform 8 matrix multiplications of
n
2 × n
2 matrices and one addition n × n of matrices.
Idea
A=
A11 A12
A21 A22
,B =
B11 B12
B21 B22
, C =
C11 C12
C21 C22
C =
C11 C12
C21 C22
=
A11 A12
A21 A22
B11 B12
B21 B22
= ...
A11B11 A11B12
A21B11 A21B12
+
A12B21 A12B22
A22B21 A22B22
46 / 94

116. Any Idea to Parallelize the Code?
What do you think?
Did you notice the multiplications of sub-matrices?
Then What?
We have for example A11B11 and A12B21!!!
We can do the following
A11B11 + A12B21
47 / 94

117. Any Idea to Parallelize the Code?
What do you think?
Did you notice the multiplications of sub-matrices?
Then What?
We have for example A11B11 and A12B21!!!
We can do the following
A11B11 + A12B21
47 / 94

118. Any Idea to Parallelize the Code?
What do you think?
Did you notice the multiplications of sub-matrices?
Then What?
We have for example A11B11 and A12B21!!!
We can do the following
A11B11 + A12B21
47 / 94

119. The use of the recursion!!!
As always our friend!!!
48 / 94

120. Pseudo-code of Matrix-Multiply
Matrix − Multiply(C, A, B, n) // The result of A × B in C with n a power of 2 for simplicity
1 if (n == 1)
2 C [1, 1] = A [1, 1] + B [1, 1]
3 else
4 allocate a temporary matrix T [1...n, 1...n]
5 partition A, B, C, T into n
2
× n
2
sub-matrices
6 spawn Matrix − Multiply (C11, A11, B11, n/2)
7 spawn Matrix − Multiply (C12, A11, B12, n/2)
8 spawn Matrix − Multiply (C21, A21, B11, n/2)
9 spawn Matrix − Multiply (C22, A21, B12, n/2)
10 spawn Matrix − Multiply (T11, A12, B21, n/2)
11 spawn Matrix − Multiply (T12, A12, B21, n/2)
12 spawn Matrix − Multiply (T21, A22, B21, n/2)
13 Matrix − Multiply (T22, A22, B22, n/2)
14 sync
15 Matrix − Add(C, T, n)
49 / 94

121. Pseudo-code of Matrix-Multiply
Matrix − Multiply(C, A, B, n) // The result of A × B in C with n a power of 2 for simplicity
1 if (n == 1)
2 C [1, 1] = A [1, 1] + B [1, 1]
3 else
4 allocate a temporary matrix T [1...n, 1...n]
5 partition A, B, C, T into n
2
× n
2
sub-matrices
6 spawn Matrix − Multiply (C11, A11, B11, n/2)
7 spawn Matrix − Multiply (C12, A11, B12, n/2)
8 spawn Matrix − Multiply (C21, A21, B11, n/2)
9 spawn Matrix − Multiply (C22, A21, B12, n/2)
10 spawn Matrix − Multiply (T11, A12, B21, n/2)
11 spawn Matrix − Multiply (T12, A12, B21, n/2)
12 spawn Matrix − Multiply (T21, A22, B21, n/2)
13 Matrix − Multiply (T22, A22, B22, n/2)
14 sync
15 Matrix − Add(C, T, n)
49 / 94

122. Pseudo-code of Matrix-Multiply
Matrix − Multiply(C, A, B, n) // The result of A × B in C with n a power of 2 for simplicity
1 if (n == 1)
2 C [1, 1] = A [1, 1] + B [1, 1]
3 else
4 allocate a temporary matrix T [1...n, 1...n]
5 partition A, B, C, T into n
2
× n
2
sub-matrices
6 spawn Matrix − Multiply (C11, A11, B11, n/2)
7 spawn Matrix − Multiply (C12, A11, B12, n/2)
8 spawn Matrix − Multiply (C21, A21, B11, n/2)
9 spawn Matrix − Multiply (C22, A21, B12, n/2)
10 spawn Matrix − Multiply (T11, A12, B21, n/2)
11 spawn Matrix − Multiply (T12, A12, B21, n/2)
12 spawn Matrix − Multiply (T21, A22, B21, n/2)
13 Matrix − Multiply (T22, A22, B22, n/2)
14 sync
15 Matrix − Add(C, T, n)
49 / 94

123. Pseudo-code of Matrix-Multiply
Matrix − Multiply(C, A, B, n) // The result of A × B in C with n a power of 2 for simplicity
1 if (n == 1)
2 C [1, 1] = A [1, 1] + B [1, 1]
3 else
4 allocate a temporary matrix T [1...n, 1...n]
5 partition A, B, C, T into n
2
× n
2
sub-matrices
6 spawn Matrix − Multiply (C11, A11, B11, n/2)
7 spawn Matrix − Multiply (C12, A11, B12, n/2)
8 spawn Matrix − Multiply (C21, A21, B11, n/2)
9 spawn Matrix − Multiply (C22, A21, B12, n/2)
10 spawn Matrix − Multiply (T11, A12, B21, n/2)
11 spawn Matrix − Multiply (T12, A12, B21, n/2)
12 spawn Matrix − Multiply (T21, A22, B21, n/2)
13 Matrix − Multiply (T22, A22, B22, n/2)
14 sync
15 Matrix − Add(C, T, n)
49 / 94

124. Pseudo-code of Matrix-Multiply
Matrix − Multiply(C, A, B, n) // The result of A × B in C with n a power of 2 for simplicity
1 if (n == 1)
2 C [1, 1] = A [1, 1] + B [1, 1]
3 else
4 allocate a temporary matrix T [1...n, 1...n]
5 partition A, B, C, T into n
2
× n
2
sub-matrices
6 spawn Matrix − Multiply (C11, A11, B11, n/2)
7 spawn Matrix − Multiply (C12, A11, B12, n/2)
8 spawn Matrix − Multiply (C21, A21, B11, n/2)
9 spawn Matrix − Multiply (C22, A21, B12, n/2)
10 spawn Matrix − Multiply (T11, A12, B21, n/2)
11 spawn Matrix − Multiply (T12, A12, B21, n/2)
12 spawn Matrix − Multiply (T21, A22, B21, n/2)
13 Matrix − Multiply (T22, A22, B22, n/2)
14 sync
15 Matrix − Add(C, T, n)
49 / 94

125. Explanation
Lines 1 - 2
Stops the recursion once you have only two numbers to multiply
Line 4
Extra matrix for storing the second matrix in
A11B11 A11B12
A21B11 A21B12
+
A12B21 A12B22
A22B21 A22B22
T
Line 5
Do the desired partition!!!
50 / 94

126. Explanation
Lines 1 - 2
Stops the recursion once you have only two numbers to multiply
Line 4
Extra matrix for storing the second matrix in
A11B11 A11B12
A21B11 A21B12
+
A12B21 A12B22
A22B21 A22B22
T
Line 5
Do the desired partition!!!
50 / 94

127. Explanation
Lines 1 - 2
Stops the recursion once you have only two numbers to multiply
Line 4
Extra matrix for storing the second matrix in
A11B11 A11B12
A21B11 A21B12
+
A12B21 A12B22
A22B21 A22B22
T
Line 5
Do the desired partition!!!
50 / 94

128. Explanation
Lines 6 to 13
Calculating the products in
A11B11 A11B12
A21B11 A21B12
+
A12B21 A12B22
A22B21 A22B22
Using Recursion and Parallel Computations
Line 14
A barrier to wait until all the parallel computations are done!!!
Line 15
Call Matrix − Add to add C and T.
51 / 94

129. Explanation
Lines 6 to 13
Calculating the products in
A11B11 A11B12
A21B11 A21B12
+
A12B21 A12B22
A22B21 A22B22
Using Recursion and Parallel Computations
Line 14
A barrier to wait until all the parallel computations are done!!!
Line 15
Call Matrix − Add to add C and T.
51 / 94

130. Explanation
Lines 6 to 13
Calculating the products in
A11B11 A11B12
A21B11 A21B12
+
A12B21 A12B22
A22B21 A22B22
Using Recursion and Parallel Computations
Line 14
A barrier to wait until all the parallel computations are done!!!
Line 15
Call Matrix − Add to add C and T.
51 / 94

131. Matrix ADD
Matrix Add Code
Matrix − Add(C, T, n)
// Add matrices C and T in-place to produce C = C + T
1 if (n == 1)
2 C [1, 1] = C [1, 1] + T [1, 1]
3 else
4 Partition C and T into n
2 × n
2 sub-matrices
5 spawn Matrix − Add (C11, T11, n/2)
6 spawn Matrix − Add (C12, T12, n/2)
7 spawn Matrix − Add (C21, T21, n/2)
8 Matrix − Add (C22, T22, n/2)
9 sync
52 / 94

132. Matrix ADD
Matrix Add Code
Matrix − Add(C, T, n)
// Add matrices C and T in-place to produce C = C + T
1 if (n == 1)
2 C [1, 1] = C [1, 1] + T [1, 1]
3 else
4 Partition C and T into n
2 × n
2 sub-matrices
5 spawn Matrix − Add (C11, T11, n/2)
6 spawn Matrix − Add (C12, T12, n/2)
7 spawn Matrix − Add (C21, T21, n/2)
8 Matrix − Add (C22, T22, n/2)
9 sync
52 / 94

133. Matrix ADD
Matrix Add Code
Matrix − Add(C, T, n)
// Add matrices C and T in-place to produce C = C + T
1 if (n == 1)
2 C [1, 1] = C [1, 1] + T [1, 1]
3 else
4 Partition C and T into n
2 × n
2 sub-matrices
5 spawn Matrix − Add (C11, T11, n/2)
6 spawn Matrix − Add (C12, T12, n/2)
7 spawn Matrix − Add (C21, T21, n/2)
8 Matrix − Add (C22, T22, n/2)
9 sync
52 / 94

134. Matrix ADD
Matrix Add Code
Matrix − Add(C, T, n)
// Add matrices C and T in-place to produce C = C + T
1 if (n == 1)
2 C [1, 1] = C [1, 1] + T [1, 1]
3 else
4 Partition C and T into n
2 × n
2 sub-matrices
5 spawn Matrix − Add (C11, T11, n/2)
6 spawn Matrix − Add (C12, T12, n/2)
7 spawn Matrix − Add (C21, T21, n/2)
8 Matrix − Add (C22, T22, n/2)
9 sync
52 / 94

135. Explanation
Line 1 - 2
Stops the recursion once you have only two numbers to multiply
Line 4
To Partition
C =
A11B11 A11B12
A21B11 A21B12
T =
A12B21 A12B22
A22B21 A22B22
In lines 5 to 8
We do the following sum in parallel!!!
A11B11 A11B12
A21B11 A21B12
C
+
A12B21 A12B22
A22B21 A22B22
T
53 / 94

136. Explanation
Line 1 - 2
Stops the recursion once you have only two numbers to multiply
Line 4
To Partition
C =
A11B11 A11B12
A21B11 A21B12
T =
A12B21 A12B22
A22B21 A22B22
In lines 5 to 8
We do the following sum in parallel!!!
A11B11 A11B12
A21B11 A21B12
C
+
A12B21 A12B22
A22B21 A22B22
T
53 / 94

137. Explanation
Line 1 - 2
Stops the recursion once you have only two numbers to multiply
Line 4
To Partition
C =
A11B11 A11B12
A21B11 A21B12
T =
A12B21 A12B22
A22B21 A22B22
In lines 5 to 8
We do the following sum in parallel!!!
A11B11 A11B12
A21B11 A21B12
C
+
A12B21 A12B22
A22B21 A22B22
T
53 / 94

138. Explanation
Line 1 - 2
Stops the recursion once you have only two numbers to multiply
Line 4
To Partition
C =
A11B11 A11B12
A21B11 A21B12
T =
A12B21 A12B22
A22B21 A22B22
In lines 5 to 8
We do the following sum in parallel!!!
A11B11 A11B12
A21B11 A21B12
C
+
A12B21 A12B22
A22B21 A22B22
T
53 / 94

139. Calculating Complexity of Matrix Multiplication
Work of Matrix Multiplication
The work of T1 (n) of matrix multiplication satisfies the recurrence:
T1 (n) = 8T1
n
2
The sequential product
+ Θ n2
The sequential sum
= Θ n3
.
54 / 94

140. Calculating Complexity of Matrix Multiplication
Span of Matrix Multiplication
T∞ (n) = T∞
n
2
The parallel product
+ Θ (log n)
The parallel sum
= Θ log2
n
This is because:
T∞
n
2 Matrix Multiplication is taking n
2 × n
2 matrices at the same
time because parallelism.
Θ (log n) is the span of the addition of the matrices (Remember, we
are using unlimited processors) which has a critical path of length
log n.
55 / 94

141. Calculating Complexity of Matrix Multiplication
Span of Matrix Multiplication
T∞ (n) = T∞
n
2
The parallel product
+ Θ (log n)
The parallel sum
= Θ log2
n
This is because:
T∞
n
2 Matrix Multiplication is taking n
2 × n
2 matrices at the same
time because parallelism.
Θ (log n) is the span of the addition of the matrices (Remember, we
are using unlimited processors) which has a critical path of length
log n.
55 / 94

142. Calculating Complexity of Matrix Multiplication
Span of Matrix Multiplication
T∞ (n) = T∞
n
2
The parallel product
+ Θ (log n)
The parallel sum
= Θ log2
n
This is because:
T∞
n
2 Matrix Multiplication is taking n
2 × n
2 matrices at the same
time because parallelism.
Θ (log n) is the span of the addition of the matrices (Remember, we
are using unlimited processors) which has a critical path of length
log n.
55 / 94

143. Collapsing the sum
Parallel Sum
+ +
56 / 94

144. How much Parallelism?
The Final Parallelism in this Algorithm is
T1 (n)
T∞ (n)
= Θ
n3
log2
n
Quite A Lot!!!
57 / 94

145. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
58 / 94

146. Merge-Sort : The Serial Version
We have
Merge − Sort (A, p, r)
Observation: Sort elements in A [p...r]
1 if (p < r) then
2 q = (p+r)/2
3 Merge − Sort (A, p, q)
4 Merge − Sort (A, q + 1, r)
5 Merge (A, p, q, r)
59 / 94

147. Merge-Sort : The Parallel Version
We have
Merge − Sort (A, p, r)
Observation: Sort elements in A [p...r]
1 if (p < r) then
2 q = (p+r)/2
3 spawn Merge − Sort (A, p, q)
4 Merge − Sort (A, q + 1, r) // Not necessary to spawn this
5 sync
6 Merge (A, p, q, r)
60 / 94

148. Calculating Complexity of This simple Parallel Merge-Sort
Work of Merge-Sort
The work of T1 (n) of this Parallel Merge-Sort satisfies the recurrence:
T1 (n) =
Θ (1) if n = 1
2T1
n
2 + Θ (n) otherwise
= Θ (n log n)
Because the Master Theorem Case 2.
Span
T∞ (n) =
Θ (1) if n = 1
T∞
n
2 + Θ (n) otherwise
We have then
T∞
n
2 sort is taking two sorts at the same time because parallelism.
Then, T∞ (n) = Θ (n) because the Master Theorem Case 3.
61 / 94

149. Calculating Complexity of This simple Parallel Merge-Sort
Work of Merge-Sort
The work of T1 (n) of this Parallel Merge-Sort satisfies the recurrence:
T1 (n) =
Θ (1) if n = 1
2T1
n
2 + Θ (n) otherwise
= Θ (n log n)
Because the Master Theorem Case 2.
Span
T∞ (n) =
Θ (1) if n = 1
T∞
n
2 + Θ (n) otherwise
We have then
T∞
n
2 sort is taking two sorts at the same time because parallelism.
Then, T∞ (n) = Θ (n) because the Master Theorem Case 3.
61 / 94

150. Calculating Complexity of This simple Parallel Merge-Sort
Work of Merge-Sort
The work of T1 (n) of this Parallel Merge-Sort satisfies the recurrence:
T1 (n) =
Θ (1) if n = 1
2T1
n
2 + Θ (n) otherwise
= Θ (n log n)
Because the Master Theorem Case 2.
Span
T∞ (n) =
Θ (1) if n = 1
T∞
n
2 + Θ (n) otherwise
We have then
T∞
n
2 sort is taking two sorts at the same time because parallelism.
Then, T∞ (n) = Θ (n) because the Master Theorem Case 3.
61 / 94

151. Calculating Complexity of This simple Parallel Merge-Sort
Work of Merge-Sort
The work of T1 (n) of this Parallel Merge-Sort satisfies the recurrence:
T1 (n) =
Θ (1) if n = 1
2T1
n
2 + Θ (n) otherwise
= Θ (n log n)
Because the Master Theorem Case 2.
Span
T∞ (n) =
Θ (1) if n = 1
T∞
n
2 + Θ (n) otherwise
We have then
T∞
n
2 sort is taking two sorts at the same time because parallelism.
Then, T∞ (n) = Θ (n) because the Master Theorem Case 3.
61 / 94

152. How much Parallelism?
The Final Parallelism in this Algorithm is
T1 (n)
T∞ (n)
= Θ (log n)
NOT NOT A Lot!!!
62 / 94

153. Can we improve this?
We have a problem
We have a bottleneck!!! Where?
Yes in the Merge part!!!
We need to improve that bottleneck!!!
63 / 94

154. Can we improve this?
We have a problem
We have a bottleneck!!! Where?
Yes in the Merge part!!!
We need to improve that bottleneck!!!
63 / 94

155. Parallel Merge
Example: Here, we use and intermediate array T
64 / 94

156. Parallel Merge
Step 1. Find x = T [q1] where q1 = (p1+r1)/2 or the midpoint in
T [p1..r1]
65 / 94

157. Parallel Merge
Step 2. Use Binary Search in T [p1..r1] to find q2
66 / 94

158. Then
So that if we insert x between T [q2 − 1] and T [q2]
T p1 · · · q2 − 1 x q2 · · · r1 is sorted
67 / 94

159. Binary Search
It takes a key x and a sub-array T [p..r] and it does
1 If T [p..r] is empty r < p, then it returns the index p.
2 if x ≤ T [p], then it returns p.
3 if x > T [p], then it returns the largest index q in the range
p < q ≤ r + 1 such that T [q − 1] < x.
68 / 94

160. Binary Search
It takes a key x and a sub-array T [p..r] and it does
1 If T [p..r] is empty r < p, then it returns the index p.
2 if x ≤ T [p], then it returns p.
3 if x > T [p], then it returns the largest index q in the range
p < q ≤ r + 1 such that T [q − 1] < x.
68 / 94

161. Binary Search
It takes a key x and a sub-array T [p..r] and it does
1 If T [p..r] is empty r < p, then it returns the index p.
2 if x ≤ T [p], then it returns p.
3 if x > T [p], then it returns the largest index q in the range
p < q ≤ r + 1 such that T [q − 1] < x.
68 / 94

162. Binary Search Code
BINARY-SEARCH(x, T, p, r)
1 low = p
2 high = max {p, r + 1}
3 while low < high
4 mid = log+high
2
5 if x ≤ T [mid]
6 high = mid
7 else low = mid + 1
8 return high
69 / 94

163. Binary Search Code
BINARY-SEARCH(x, T, p, r)
1 low = p
2 high = max {p, r + 1}
3 while low < high
4 mid = log+high
2
5 if x ≤ T [mid]
6 high = mid
7 else low = mid + 1
8 return high
69 / 94

164. Binary Search Code
BINARY-SEARCH(x, T, p, r)
1 low = p
2 high = max {p, r + 1}
3 while low < high
4 mid = log+high
2
5 if x ≤ T [mid]
6 high = mid
7 else low = mid + 1
8 return high
69 / 94

165. Binary Search Code
BINARY-SEARCH(x, T, p, r)
1 low = p
2 high = max {p, r + 1}
3 while low < high
4 mid = log+high
2
5 if x ≤ T [mid]
6 high = mid
7 else low = mid + 1
8 return high
69 / 94

166. Binary Search Code
BINARY-SEARCH(x, T, p, r)
1 low = p
2 high = max {p, r + 1}
3 while low < high
4 mid = log+high
2
5 if x ≤ T [mid]
6 high = mid
7 else low = mid + 1
8 return high
69 / 94

167. Parallel Merge
Step 3. Copy x in A [q3] where q3 = p3 + (q1 − p1) + (q2 − p2)
70 / 94

168. Parallel Merge
Step 4. Recursively merge T [p1..q1 − 1] and T [p2..q2 − 1] and place
result into A [p3..q3 − 1]
71 / 94

169. Parallel Merge
Step 5. Recursively merge T [q1 + 1..r1] and T [q2..r2] and place
result into A [q3 + 1..r3]
72 / 94

170. The Final Code for Parallel Merge
Par − Merge (T, p1, r1, p2, r2, A, p3)
1 n1 = r1 − p1 + 1, n2 = r2 − p2 + 1
2 if n1 < n2
3 Exchange p1 ↔ p2, r1 ↔ r2, n1 ↔ n2
4 if (n1 == 0)
5 return
6 else
7 q1 = (p1+r1)/2
8 q2 = BinarySearch (T [q1] , T, p2, r2)
9 q3 = p3 + (q1 − p1) + (q2 − p2)
10 A [q3] = T [q1]
11 spawn Par − Merge (T, p1, q1 − 1, p2, q2 − 1, A, p3)
12 Par − Merge (T, q1 + 1, r1, q2 + 1, r2, A, q3 + 1)
13 sync
73 / 94

171. The Final Code for Parallel Merge
Par − Merge (T, p1, r1, p2, r2, A, p3)
1 n1 = r1 − p1 + 1, n2 = r2 − p2 + 1
2 if n1 < n2
3 Exchange p1 ↔ p2, r1 ↔ r2, n1 ↔ n2
4 if (n1 == 0)
5 return
6 else
7 q1 = (p1+r1)/2
8 q2 = BinarySearch (T [q1] , T, p2, r2)
9 q3 = p3 + (q1 − p1) + (q2 − p2)
10 A [q3] = T [q1]
11 spawn Par − Merge (T, p1, q1 − 1, p2, q2 − 1, A, p3)
12 Par − Merge (T, q1 + 1, r1, q2 + 1, r2, A, q3 + 1)
13 sync
73 / 94

172. The Final Code for Parallel Merge
Par − Merge (T, p1, r1, p2, r2, A, p3)
1 n1 = r1 − p1 + 1, n2 = r2 − p2 + 1
2 if n1 < n2
3 Exchange p1 ↔ p2, r1 ↔ r2, n1 ↔ n2
4 if (n1 == 0)
5 return
6 else
7 q1 = (p1+r1)/2
8 q2 = BinarySearch (T [q1] , T, p2, r2)
9 q3 = p3 + (q1 − p1) + (q2 − p2)
10 A [q3] = T [q1]
11 spawn Par − Merge (T, p1, q1 − 1, p2, q2 − 1, A, p3)
12 Par − Merge (T, q1 + 1, r1, q2 + 1, r2, A, q3 + 1)
13 sync
73 / 94

173. The Final Code for Parallel Merge
Par − Merge (T, p1, r1, p2, r2, A, p3)
1 n1 = r1 − p1 + 1, n2 = r2 − p2 + 1
2 if n1 < n2
3 Exchange p1 ↔ p2, r1 ↔ r2, n1 ↔ n2
4 if (n1 == 0)
5 return
6 else
7 q1 = (p1+r1)/2
8 q2 = BinarySearch (T [q1] , T, p2, r2)
9 q3 = p3 + (q1 − p1) + (q2 − p2)
10 A [q3] = T [q1]
11 spawn Par − Merge (T, p1, q1 − 1, p2, q2 − 1, A, p3)
12 Par − Merge (T, q1 + 1, r1, q2 + 1, r2, A, q3 + 1)
13 sync
73 / 94

174. The Final Code for Parallel Merge
Par − Merge (T, p1, r1, p2, r2, A, p3)
1 n1 = r1 − p1 + 1, n2 = r2 − p2 + 1
2 if n1 < n2
3 Exchange p1 ↔ p2, r1 ↔ r2, n1 ↔ n2
4 if (n1 == 0)
5 return
6 else
7 q1 = (p1+r1)/2
8 q2 = BinarySearch (T [q1] , T, p2, r2)
9 q3 = p3 + (q1 − p1) + (q2 − p2)
10 A [q3] = T [q1]
11 spawn Par − Merge (T, p1, q1 − 1, p2, q2 − 1, A, p3)
12 Par − Merge (T, q1 + 1, r1, q2 + 1, r2, A, q3 + 1)
13 sync
73 / 94

175. The Final Code for Parallel Merge
Par − Merge (T, p1, r1, p2, r2, A, p3)
1 n1 = r1 − p1 + 1, n2 = r2 − p2 + 1
2 if n1 < n2
3 Exchange p1 ↔ p2, r1 ↔ r2, n1 ↔ n2
4 if (n1 == 0)
5 return
6 else
7 q1 = (p1+r1)/2
8 q2 = BinarySearch (T [q1] , T, p2, r2)
9 q3 = p3 + (q1 − p1) + (q2 − p2)
10 A [q3] = T [q1]
11 spawn Par − Merge (T, p1, q1 − 1, p2, q2 − 1, A, p3)
12 Par − Merge (T, q1 + 1, r1, q2 + 1, r2, A, q3 + 1)
13 sync
73 / 94

176. Explanation
Line 1
Obtain the length of the two arrays to be merged
Line 2: If one is larger than the other
We exchange the variables to work the largest element!!! In this case we
make n1 ≥ n2
Line 4
if n1 == 0 return nothing to merge!!!
74 / 94

177. Explanation
Line 1
Obtain the length of the two arrays to be merged
Line 2: If one is larger than the other
We exchange the variables to work the largest element!!! In this case we
make n1 ≥ n2
Line 4
if n1 == 0 return nothing to merge!!!
74 / 94

178. Explanation
Line 1
Obtain the length of the two arrays to be merged
Line 2: If one is larger than the other
We exchange the variables to work the largest element!!! In this case we
make n1 ≥ n2
Line 4
if n1 == 0 return nothing to merge!!!
74 / 94

179. Explanation
Line 10
It copies T [q1] directly into A [q3]
Line 11 and 12
They are used to recurse using nested parallelism to merge the sub-arrays
less and greater than x.
Line 13
The sync is used to ensure that the subproblems have completed before
the procedure returns.
75 / 94

180. Explanation
Line 10
It copies T [q1] directly into A [q3]
Line 11 and 12
They are used to recurse using nested parallelism to merge the sub-arrays
less and greater than x.
Line 13
The sync is used to ensure that the subproblems have completed before
the procedure returns.
75 / 94

181. Explanation
Line 10
It copies T [q1] directly into A [q3]
Line 11 and 12
They are used to recurse using nested parallelism to merge the sub-arrays
less and greater than x.
Line 13
The sync is used to ensure that the subproblems have completed before
the procedure returns.
75 / 94

182. First the Span Complexity of Parallel Merge: T∞ (n)
Suppositions
n = n1 + n2
What case should we study?
Remember T∞ (n) = max {T∞ (n1) + T∞ (n2)}
We notice then that
Because lines 3-6 n2 ≤ n1
76 / 94

183. First the Span Complexity of Parallel Merge: T∞ (n)
Suppositions
n = n1 + n2
What case should we study?
Remember T∞ (n) = max {T∞ (n1) + T∞ (n2)}
We notice then that
Because lines 3-6 n2 ≤ n1
76 / 94

184. First the Span Complexity of Parallel Merge: T∞ (n)
Suppositions
n = n1 + n2
What case should we study?
Remember T∞ (n) = max {T∞ (n1) + T∞ (n2)}
We notice then that
Because lines 3-6 n2 ≤ n1
76 / 94

185. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Then
2n2 ≤ n1 + n2 = n =⇒ n2 ≤ n/2
Thus
In the worst case, a recursive call in lines 11 merges:
n1
2 elements of T [p1...r1] (Remember we are halving the array by
mid-point).
With all n2 elements of T [p2...r2].
77 / 94

186. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Then
2n2 ≤ n1 + n2 = n =⇒ n2 ≤ n/2
Thus
In the worst case, a recursive call in lines 11 merges:
n1
2 elements of T [p1...r1] (Remember we are halving the array by
mid-point).
With all n2 elements of T [p2...r2].
77 / 94

187. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Then
2n2 ≤ n1 + n2 = n =⇒ n2 ≤ n/2
Thus
In the worst case, a recursive call in lines 11 merges:
n1
2 elements of T [p1...r1] (Remember we are halving the array by
mid-point).
With all n2 elements of T [p2...r2].
77 / 94

188. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Then
2n2 ≤ n1 + n2 = n =⇒ n2 ≤ n/2
Thus
In the worst case, a recursive call in lines 11 merges:
n1
2 elements of T [p1...r1] (Remember we are halving the array by
mid-point).
With all n2 elements of T [p2...r2].
77 / 94

189. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Thus, the number of elements involved in such a call is
n1
2
+ n2 ≤
n1
2
+
n2
2
+
n2
2
≤
n1
2
+
n2
2
+
n/2
2
=
n1 + n2
2
+
n
4
≤
n
2
+
n
4
=
3n
4
78 / 94

190. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Thus, the number of elements involved in such a call is
n1
2
+ n2 ≤
n1
2
+
n2
2
+
n2
2
≤
n1
2
+
n2
2
+
n/2
2
=
n1 + n2
2
+
n
4
≤
n
2
+
n
4
=
3n
4
78 / 94

191. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Thus, the number of elements involved in such a call is
n1
2
+ n2 ≤
n1
2
+
n2
2
+
n2
2
≤
n1
2
+
n2
2
+
n/2
2
=
n1 + n2
2
+
n
4
≤
n
2
+
n
4
=
3n
4
78 / 94

192. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Thus, the number of elements involved in such a call is
n1
2
+ n2 ≤
n1
2
+
n2
2
+
n2
2
≤
n1
2
+
n2
2
+
n/2
2
=
n1 + n2
2
+
n
4
≤
n
2
+
n
4
=
3n
4
78 / 94

193. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Knowing that the Binary Search takes
Θ (log n)
We get the span for parallel merge
T∞ (n) = T∞
3n
4
+ Θ (log n)
This can can be solved using the exercise 4.6-2 in the Cormen’s Book
T∞ (n) = Θ log2
n
79 / 94

194. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Knowing that the Binary Search takes
Θ (log n)
We get the span for parallel merge
T∞ (n) = T∞
3n
4
+ Θ (log n)
This can can be solved using the exercise 4.6-2 in the Cormen’s Book
T∞ (n) = Θ log2
n
79 / 94

195. Span Complexity of the Parallel Merge with One
Processor: T1 (n)
Knowing that the Binary Search takes
Θ (log n)
We get the span for parallel merge
T∞ (n) = T∞
3n
4
+ Θ (log n)
This can can be solved using the exercise 4.6-2 in the Cormen’s Book
T∞ (n) = Θ log2
n
79 / 94

196. Calculating Work Complexity of Parallel Merge
Ok!!! We need to calculate the WORK
T1 (n) = Θ (Something)
Thus
We need to calculate the upper and lower bound.
80 / 94

197. Calculating Work Complexity of Parallel Merge
Ok!!! We need to calculate the WORK
T1 (n) = Θ (Something)
Thus
We need to calculate the upper and lower bound.
80 / 94

198. Calculating Work Complexity of Parallel Merge
Work of Parallel Merge
The work of T1 (n) of this Parallel Merge satisfies:
T1 (n) = Ω (n)
Because each of the n elements must be copied from array T to array
A.
What about the Upper Bound O?
First notice that we can have a merge with
n
4 elements when we have we have the worst case of n1
2 + n2 in the
other merge.
And 3n
4 for the worst case.
And the work of the Binary Search of O (log n)
81 / 94

199. Calculating Work Complexity of Parallel Merge
Work of Parallel Merge
The work of T1 (n) of this Parallel Merge satisfies:
T1 (n) = Ω (n)
Because each of the n elements must be copied from array T to array
A.
What about the Upper Bound O?
First notice that we can have a merge with
n
4 elements when we have we have the worst case of n1
2 + n2 in the
other merge.
And 3n
4 for the worst case.
And the work of the Binary Search of O (log n)
81 / 94

200. Calculating Work Complexity of Parallel Merge
Work of Parallel Merge
The work of T1 (n) of this Parallel Merge satisfies:
T1 (n) = Ω (n)
Because each of the n elements must be copied from array T to array
A.
What about the Upper Bound O?
First notice that we can have a merge with
n
4 elements when we have we have the worst case of n1
2 + n2 in the
other merge.
And 3n
4 for the worst case.
And the work of the Binary Search of O (log n)
81 / 94

201. Calculating Work Complexity of Parallel Merge
Work of Parallel Merge
The work of T1 (n) of this Parallel Merge satisfies:
T1 (n) = Ω (n)
Because each of the n elements must be copied from array T to array
A.
What about the Upper Bound O?
First notice that we can have a merge with
n
4 elements when we have we have the worst case of n1
2 + n2 in the
other merge.
And 3n
4 for the worst case.
And the work of the Binary Search of O (log n)
81 / 94

202. Calculating Work Complexity of Parallel Merge
Work of Parallel Merge
The work of T1 (n) of this Parallel Merge satisfies:
T1 (n) = Ω (n)
Because each of the n elements must be copied from array T to array
A.
What about the Upper Bound O?
First notice that we can have a merge with
n
4 elements when we have we have the worst case of n1
2 + n2 in the
other merge.
And 3n
4 for the worst case.
And the work of the Binary Search of O (log n)
81 / 94

203. Calculating Work Complexity of Parallel Merge
Work of Parallel Merge
The work of T1 (n) of this Parallel Merge satisfies:
T1 (n) = Ω (n)
Because each of the n elements must be copied from array T to array
A.
What about the Upper Bound O?
First notice that we can have a merge with
n
4 elements when we have we have the worst case of n1
2 + n2 in the
other merge.
And 3n
4 for the worst case.
And the work of the Binary Search of O (log n)
81 / 94

204. Calculating Work Complexity of Parallel Merge
Work of Parallel Merge
The work of T1 (n) of this Parallel Merge satisfies:
T1 (n) = Ω (n)
Because each of the n elements must be copied from array T to array
A.
What about the Upper Bound O?
First notice that we can have a merge with
n
4 elements when we have we have the worst case of n1
2 + n2 in the
other merge.
And 3n
4 for the worst case.
And the work of the Binary Search of O (log n)
81 / 94

205. Calculating Work Complexity of Parallel Merge
Then
Then, for some α ∈ 1
4, 3
4 , then we have the following recursion for the
Parallel Merge when we have one processor:
T1 (n) = T1 (αn) + T1 ((1 − α) n)
Merge Part
+ Θ (log n)
Binary Search
Remark: α varies at each level of the recursion!!!
82 / 94

206. Calculating Work Complexity of Parallel Merge
Then
Then, for some α ∈ 1
4, 3
4 , then we have the following recursion for the
Parallel Merge when we have one processor:
T1 (n) = T1 (αn) + T1 ((1 − α) n)
Merge Part
+ Θ (log n)
Binary Search
Remark: α varies at each level of the recursion!!!
82 / 94

207. Calculating Work Complexity of Parallel Merge
Then
Then, for some α ∈ 1
4, 3
4 , then we have the following recursion for the
Parallel Merge when we have one processor:
T1 (n) = T1 (αn) + T1 ((1 − α) n)
Merge Part
+ Θ (log n)
Binary Search
Remark: α varies at each level of the recursion!!!
82 / 94

208. Calculating Work Complexity of Parallel Merge
Then
Assume that T1 (n) ≤ c1n − c2 log n for positive constants c1 and c2.
We have then using c3 for Θ (log n)
T1 (n) ≤ T1 (αn) + T1 ((1 − α) n) + c3 log n
≤ c1αn − c2 log (αn) + c1 (1 − α) n − c2 log ((1 − α) n) + c3 log n
= c1n − c2 log (α(1 − α)) − 2c2 log n + c3 log n (splitting elements)
= c1n − c2 (log n + log (α(1 − α))) − (c2 − c3) log n
≤ c1n − (c2 − c3) log n because log n + log (α(1 − α)) > 0
83 / 94

209. Calculating Work Complexity of Parallel Merge
Then
Assume that T1 (n) ≤ c1n − c2 log n for positive constants c1 and c2.
We have then using c3 for Θ (log n)
T1 (n) ≤ T1 (αn) + T1 ((1 − α) n) + c3 log n
≤ c1αn − c2 log (αn) + c1 (1 − α) n − c2 log ((1 − α) n) + c3 log n
= c1n − c2 log (α(1 − α)) − 2c2 log n + c3 log n (splitting elements)
= c1n − c2 (log n + log (α(1 − α))) − (c2 − c3) log n
≤ c1n − (c2 − c3) log n because log n + log (α(1 − α)) > 0
83 / 94

210. Calculating Work Complexity of Parallel Merge
Then
Assume that T1 (n) ≤ c1n − c2 log n for positive constants c1 and c2.
We have then using c3 for Θ (log n)
T1 (n) ≤ T1 (αn) + T1 ((1 − α) n) + c3 log n
≤ c1αn − c2 log (αn) + c1 (1 − α) n − c2 log ((1 − α) n) + c3 log n
= c1n − c2 log (α(1 − α)) − 2c2 log n + c3 log n (splitting elements)
= c1n − c2 (log n + log (α(1 − α))) − (c2 − c3) log n
≤ c1n − (c2 − c3) log n because log n + log (α(1 − α)) > 0
83 / 94

211. Calculating Work Complexity of Parallel Merge
Then
Assume that T1 (n) ≤ c1n − c2 log n for positive constants c1 and c2.
We have then using c3 for Θ (log n)
T1 (n) ≤ T1 (αn) + T1 ((1 − α) n) + c3 log n
≤ c1αn − c2 log (αn) + c1 (1 − α) n − c2 log ((1 − α) n) + c3 log n
= c1n − c2 log (α(1 − α)) − 2c2 log n + c3 log n (splitting elements)
= c1n − c2 (log n + log (α(1 − α))) − (c2 − c3) log n
≤ c1n − (c2 − c3) log n because log n + log (α(1 − α)) > 0
83 / 94

212. Calculating Work Complexity of Parallel Merge
Then
Assume that T1 (n) ≤ c1n − c2 log n for positive constants c1 and c2.
We have then using c3 for Θ (log n)
T1 (n) ≤ T1 (αn) + T1 ((1 − α) n) + c3 log n
≤ c1αn − c2 log (αn) + c1 (1 − α) n − c2 log ((1 − α) n) + c3 log n
= c1n − c2 log (α(1 − α)) − 2c2 log n + c3 log n (splitting elements)
= c1n − c2 (log n + log (α(1 − α))) − (c2 − c3) log n
≤ c1n − (c2 − c3) log n because log n + log (α(1 − α)) > 0
83 / 94

213. Calculating Work Complexity of Parallel Merge
Now, we have that given 0 < α(1 − α) < 1
We have log (α(1 − α)) < 0
Thus, making n large enough
log n + log (α(1 − α)) > 0 (1)
Then
T1 (n) ≤ c1n − (c2 − c3) log n
84 / 94

214. Calculating Work Complexity of Parallel Merge
Now, we have that given 0 < α(1 − α) < 1
We have log (α(1 − α)) < 0
Thus, making n large enough
log n + log (α(1 − α)) > 0 (1)
Then
T1 (n) ≤ c1n − (c2 − c3) log n
84 / 94

215. Calculating Work Complexity of Parallel Merge
Now, we have that given 0 < α(1 − α) < 1
We have log (α(1 − α)) < 0
Thus, making n large enough
log n + log (α(1 − α)) > 0 (1)
Then
T1 (n) ≤ c1n − (c2 − c3) log n
84 / 94

216. Calculating Work Complexity of Parallel Merge
Now, we choose c2 and c3 such that
c2 − c3 ≥ 0
We have that
T1 (n) ≤ c1n = O(n)
85 / 94

217. Calculating Work Complexity of Parallel Merge
Now, we choose c2 and c3 such that
c2 − c3 ≥ 0
We have that
T1 (n) ≤ c1n = O(n)
85 / 94

218. Finally
Then
T1 (n) = Θ (n)
The parallelism of Parallel Merge
T1 (n)
T∞ (n)
= Θ
n
log2
n
86 / 94

219. Finally
Then
T1 (n) = Θ (n)
The parallelism of Parallel Merge
T1 (n)
T∞ (n)
= Θ
n
log2
n
86 / 94

220. Then What is the Complexity of Parallel Merge-sort with
Parallel Merge?
First, the new code - Input A [p..r] - Output B [s..s + r − p]
Par − Merge − Sort (A, p, r, B, s)
1 n = r − p + 1
2 if (n == 1)
3 B [s] = A [p]
4 else let T [1..n] be a new array
5 q = (p+r)/2
6 q = q − p + 1
7 spawn Par − Merge − Sort (A, p, q, T, 1)
8 Par − Merge − Sort (A, q + 1, r, T, q + 1)
9 sync
10 Par − Merge (T, 1, q , q + 1, n, B, s)
87 / 94

221. Then What is the Complexity of Parallel Merge-sort with
Parallel Merge?
First, the new code - Input A [p..r] - Output B [s..s + r − p]
Par − Merge − Sort (A, p, r, B, s)
1 n = r − p + 1
2 if (n == 1)
3 B [s] = A [p]
4 else let T [1..n] be a new array
5 q = (p+r)/2
6 q = q − p + 1
7 spawn Par − Merge − Sort (A, p, q, T, 1)
8 Par − Merge − Sort (A, q + 1, r, T, q + 1)
9 sync
10 Par − Merge (T, 1, q , q + 1, n, B, s)
87 / 94

222. Then What is the Complexity of Parallel Merge-sort with
Parallel Merge?
First, the new code - Input A [p..r] - Output B [s..s + r − p]
Par − Merge − Sort (A, p, r, B, s)
1 n = r − p + 1
2 if (n == 1)
3 B [s] = A [p]
4 else let T [1..n] be a new array
5 q = (p+r)/2
6 q = q − p + 1
7 spawn Par − Merge − Sort (A, p, q, T, 1)
8 Par − Merge − Sort (A, q + 1, r, T, q + 1)
9 sync
10 Par − Merge (T, 1, q , q + 1, n, B, s)
87 / 94

223. Then What is the Complexity of Parallel Merge-sort with
Parallel Merge?
First, the new code - Input A [p..r] - Output B [s..s + r − p]
Par − Merge − Sort (A, p, r, B, s)
1 n = r − p + 1
2 if (n == 1)
3 B [s] = A [p]
4 else let T [1..n] be a new array
5 q = (p+r)/2
6 q = q − p + 1
7 spawn Par − Merge − Sort (A, p, q, T, 1)
8 Par − Merge − Sort (A, q + 1, r, T, q + 1)
9 sync
10 Par − Merge (T, 1, q , q + 1, n, B, s)
87 / 94

224. Then What is the Complexity of Parallel Merge-sort with
Parallel Merge?
First, the new code - Input A [p..r] - Output B [s..s + r − p]
Par − Merge − Sort (A, p, r, B, s)
1 n = r − p + 1
2 if (n == 1)
3 B [s] = A [p]
4 else let T [1..n] be a new array
5 q = (p+r)/2
6 q = q − p + 1
7 spawn Par − Merge − Sort (A, p, q, T, 1)
8 Par − Merge − Sort (A, q + 1, r, T, q + 1)
9 sync
10 Par − Merge (T, 1, q , q + 1, n, B, s)
87 / 94

225. Then What is the Complexity of Parallel Merge-sort with
Parallel Merge?
First, the new code - Input A [p..r] - Output B [s..s + r − p]
Par − Merge − Sort (A, p, r, B, s)
1 n = r − p + 1
2 if (n == 1)
3 B [s] = A [p]
4 else let T [1..n] be a new array
5 q = (p+r)/2
6 q = q − p + 1
7 spawn Par − Merge − Sort (A, p, q, T, 1)
8 Par − Merge − Sort (A, q + 1, r, T, q + 1)
9 sync
10 Par − Merge (T, 1, q , q + 1, n, B, s)
87 / 94

226. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Work
We can use the worst work in the parallel to generate the recursion:
TPMS
1 (n) = 2TPMS
1
n
2
+ TPM
1 (n)
= 2TPMS
1
n
2
+ Θ (n)
= Θ (n log n) Case 2 of the MT
88 / 94

227. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Work
We can use the worst work in the parallel to generate the recursion:
TPMS
1 (n) = 2TPMS
1
n
2
+ TPM
1 (n)
= 2TPMS
1
n
2
+ Θ (n)
= Θ (n log n) Case 2 of the MT
88 / 94

228. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Work
We can use the worst work in the parallel to generate the recursion:
TPMS
1 (n) = 2TPMS
1
n
2
+ TPM
1 (n)
= 2TPMS
1
n
2
+ Θ (n)
= Θ (n log n) Case 2 of the MT
88 / 94

229. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Work
We can use the worst work in the parallel to generate the recursion:
TPMS
1 (n) = 2TPMS
1
n
2
+ TPM
1 (n)
= 2TPMS
1
n
2
+ Θ (n)
= Θ (n log n) Case 2 of the MT
88 / 94

230. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Span
We get the following recursion for the span by taking in account that lines
7 and 8 of parallel merge sort run in parallel:
TPMS
∞ (n) = TPMS
∞
n
2
+ TPM
∞ (n)
= TPMS
∞
n
2
+ Θ log2
n
= Θ log3
n Exercise 4.6-2 in the Cormen’s Book
89 / 94

231. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Span
We get the following recursion for the span by taking in account that lines
7 and 8 of parallel merge sort run in parallel:
TPMS
∞ (n) = TPMS
∞
n
2
+ TPM
∞ (n)
= TPMS
∞
n
2
+ Θ log2
n
= Θ log3
n Exercise 4.6-2 in the Cormen’s Book
89 / 94

232. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Span
We get the following recursion for the span by taking in account that lines
7 and 8 of parallel merge sort run in parallel:
TPMS
∞ (n) = TPMS
∞
n
2
+ TPM
∞ (n)
= TPMS
∞
n
2
+ Θ log2
n
= Θ log3
n Exercise 4.6-2 in the Cormen’s Book
89 / 94

233. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Span
We get the following recursion for the span by taking in account that lines
7 and 8 of parallel merge sort run in parallel:
TPMS
∞ (n) = TPMS
∞
n
2
+ TPM
∞ (n)
= TPMS
∞
n
2
+ Θ log2
n
= Θ log3
n Exercise 4.6-2 in the Cormen’s Book
89 / 94

234. Then, What is the amount of Parallelism of Parallel
Merge-sort with Parallel Merge?
Parallelism
T1 (n)
T∞ (n)
= Θ
n
log2
n
90 / 94

235. Plotting both Parallelisms
We get the incredible difference between both algorithm
91 / 94

236. Plotting the T∞
We get the incredible difference when running both algorithms with
an infinite number of processors!!!
92 / 94

237. Outline
1 Introduction
Why Multi-Threaded Algorithms?
2 Model To Be Used
Symmetric Multiprocessor
Operations
Example
3 Computation DAG
Introduction
4 Performance Measures
Introduction
Running Time Classification
5 Parallel Laws
Work and Span Laws
Speedup and Parallelism
Greedy Scheduler
Scheduling Rises the Following Issue
6 Examples
Parallel Fibonacci
Matrix Multiplication
Parallel Merge-Sort
7 Exercises
Some Exercises you can try!!!
93 / 94

238. Exercises
27.1-1
27.1-2
27.1-4
27.1-6
27.1-7
27.2-1
27.2-3
27.2-4
27.2-5
27.3-1
27.3-2
27.3-3
27.3-4
94 / 94
