System-on-Chip Programmable Retina

•Download as PPTX, PDF•
•
Vanya Valindria
Vanya Valindria

The document discusses a system-on-chip (SoC) and programmable retina that aims to mimic the functions of the human retina in a single integrated circuit. The SoC retina combines image sensing and processing to acquire and analyze images in real-time with low power consumption. It consists of a CMOS sensor, cellular processor, and digital processing units. The SoC retina can perform tasks like target tracking, image recognition and industrial machine vision with applications in areas like retinal prosthesis and autonomous systems.

TechnologyBusiness
1 of 20
SOC (SYSTEM-ON-CHIP) AND PROGRAMMABLE RETINA By: Vanya Vabrina Valindria Vega Valentine Eng Wei Yong -VIBOT-
Outline 1. Human Retina 2. What is SoC and Programmable Retina? 3. SoC and Programmable Retina Architecture 4. SoC and Programmable Retina System 5. Applications 6. Conclusion
Human Retina Photoreceptors: 126 millions Task: Convert light  electrical impulse  optic nerve  brain
Retina Disease What happened when some photoreceptors degraded in the retina?  Unable to perceive the light completely
Retina Prosthesis Other application: Industrial – robotics, vehicle, etc.
How to implement this excellent functions of human retina in a single chip?
SoC and Programmable Retina Task: Image acquisition and low-to-medium-level image processing Main Challenge: Other Integrate Sensor and Processing  Challenges: Real time different from conventional approach  highly parallel processing (separated CCD + Processing Units) Programmable  functional flexibility Fast, low cost and lower power
Image Processing inside the SoC Retina Gray-scale Morphology Target Tracking Binary Morphology
Retina Chip- Basic Architecture 1 PE (Processing Element) + 1 photo-detector= 1 pixel Mimic Human Retina? Photo detector ~ Photo-receptor (in human retina) • Doorway to SoC chip • Large dynamic range CMOS technology ~ Synapses (in human retina) Photo- Block diagram of detecto the retina chip • High connectivity r • Ease integration with PE on the same chip
How does it work?
SoC & Programmable Retina System  The circuit: combining image acquisition and processing function, consists of:  CMOS sensor  Cellular SIMD (Single Instruction Multiple Data) machine  Digital processor (very small)
SoC & Programmable Retina System • Four components of Retina Circuit: – Phototransduction obtain analog value of the image – Analog Processing spatio-temporal filtering – A/D Coding • NISP (Near Image Sensor Processing) • Digitize the analog value through multiple thresholding – Digital Processing • The SIMD machine, made of digital processor meshes • Process Boolean planes (binary image) data
Comparison
SoC & Programmable Retina (specification) Specification 1000 FPS Vision Chip PVLSAR 2.2 SCAMP-3 Technology 0.18 μm 1P6M CMOS 0.8μm digital CMOS 0.35 μm CMOS Std Chip Size 3.5 mm x 1.5 mm 76 mm2 50 mm2 Array Size 64x64 pixels 128x128 pixels 128x128 pixels Pixel Size 9.5 μm × 9.5 μm 60 μm x 60 μm 50 μm x 50 μm Clock 40 MHz 150 KHz 1.25 MHz frequency Power 1.8 V & 3.3V 3.3 V & 2.2V 240mW Supply, 82.5mW (@, 1,000 fps) 1W Consumption
Application  Retinal prosthesis  Intelligent security and surveillance systems (high speed target tracking)  Image recognition  Motion detection  Industrial machine vision (rapid inspection)
Application  Retinal prosthesis  http://www.io.mei.titech.ac.jp/research/retina/index.html
Application  An embedded system for autonomous collision avoidance & objects tracking
Application  Interactive Game
Conclusion  Power Consumption, Size, Cost, Real-time efficiency are main issues in this field  SOC programmable retina integrate parallel processing with sensing  reduce size and cost  Low power dissipation  Autonomous decision making from real-time analysis  Promising application in various areas
References  Paillet, D.Mercier, T.M.Bernard and E. Senn, "Low power issues in a Programmable Artificial Retina", Proc. IEEE Workshop on Low. Power Design, pp.153-161, 1999.  Lin Q, Miau.W,, et al. A 1,000 Frames/s Programmable Vision Chip with Variable Resolution and Row-Pixel-Mixed Parallel Image Processors. 2009. ISSN 1424-8220  Elouardi A, Bouaziz S, Dupret A, Klein J O and Reynaud R. 2004. On chip vision system architecture using a CMOS retina Proceeding.  A. Manzanera. Morpholigical Segmentation on the Programmable Retina: Towards Mixed Synchronous/Asynchrounous Algorithms. in ACM ISMM Conference.  K Kyuma, Y.Nitta, Artifical Retina Chips for Image Processing. 1997. Artif Life Robotis 1: 79 – 87.
