The transmission overhead line is one of the vital elements in the power system for transmitting the electrical energy. In the transmission, the disturbances are often occurred. In the conventional algorithm, alpha and beta (mode) currents generated by Clarke’s transformation are utilized to convert the signal of Discrete Wavelet Transform (DWT) to obtain the Wavelet Transform Coefficient (WTC) and the Wavelet Coefficient Energy (WCE). This study introduces a new algorithm, called Modified Clarke for fault detection and classification using DWT and Back-Propagation Neural Network (BPNN) based on Clarke’s transformation on transmission overhead line by adding gamma current in the system. Daubechies4 (Db4) is used as a mother wavelet to decompose the high frequency components of the signal error. Simulation is performed using PSCAD / EMTDC transmission system modeling and carried out at different locations along the transmission line with different types of fault, fault resistances, fault locations and fault of the initial angle on a given power system model. The simulated fault types are in the study are the Single Line to Ground, the Line To Line, the Double Line to Ground and the Three Phases. There are four statistic methods utilized in the present study to determine the accuracy of detection and classification of faults. The result shows that the best and the worst structures of BPNN occurred on the configuration of 12-24-48-4 and 12-12-6-4, respectively. For instance, the error using Mean Square Error Method. The Error Of Clarke’s, Without Clarke’s and Modified Clarke’s are 0.05862, 0.05513 and 0.03721 which are the best, respectively, whereas, the worst are 0.06387, 0.0753 and 0.052, respectively. This indicates that the Modified Clarke’s result is in the lowest error. The method is successfully implement can be utilized in the detection and classification of fault in transmission line by utilities and power regulation in power system planning and operation.
These slides are all about Phasor Measurement Units (PMUs). An introduction to PMU is presented as a preliminary knowledge for the course 'Distribution Generation and Smart Grid'. Your valuable suggestions are welcome.
Transmission line is one the important compnent in protection of electric power system because the transmission line connects the power station with load centers.
The fault includes storms, lightning, snow, damage to insulation, short circuit fault [1].
Fault needs to be predicted earlier in order to be prevented before it occur
Fault location and correction are important in case of any power systems. This process has to be prompt and accurate so that system reliability can be improved , outage time can be reduced and restoration of system from fault can be accelerated.
Fault location calculation using Magnetoresistance sensor is described here.
Automatic generation control (AGC) is a system for adjusting the power output of multiple generators at different power plants, in response to changes in the load. Since a power grid requires that generation and load closely balance moment by moment, frequent adjustments to the output of generators are necessary. The balance can be judged by measuring the system frequency; if it is increasing, more power is being generated than used, which causes all the machines in the system to accelerate. If the system frequency is decreasing, more load is on the system than the instantaneous generation can provide, which causes all generators to slow down.
High Voltage Direct Current technology has certain characteristics which
make it especially attractive for transmission system applications. HVDC
transmission system is useful for long-distance transmission, bulk power delivery and
long submarine cable crossings and asynchronous interconnections. The study of
faults is essential for reasonable protection design because the faults will induce a
significant influence on operation of HVDC transmission system. This paper provides
the most dominant and frequent faults on the HVDC systems such as DC Line-to-
Ground fault and Line-to-Line fault on DC link and some common types of AC faults
occurs in overhead transmission system such as Line-to-Ground fault, Line-to-Line
fault and L-L-L fault. In HVDC system, faults on rectifier side or inverter side have
major affects on system stability. The various types of faults are considered in the
HVDC system which causes due to malfunctions of valves and controllers, misfire
and short circuit across the inverter station, flashover and three phase short circuit.
The various faults occurs at the converter station of a HVDC system and
Controlling action for those faults. Most of the studies have been conducted on line
faults. But faults on rectifier or inverter side of a HVDC system have great impact on
system stability. Faults considered are fire-through, misfire, and short circuit across
the inverter station, flashover, and a three-phase short circuit in the ac system. These
investigations are studied using matlab simulink models and the result represented in
the form of typical time responses.
