1. Engineering Submittal Essential for a SPV Power Plant
Design & Engineering is an integral part of the implementation of the SPV power plants.
Engineering drawings & documents convey specifications, construction methodology, dimensions,
tolerances etc capturing the scope of works and presenting a first-hand idea on the final by product
that would be constructed.
Typical Master Deliverable list can be divided in two broad categories of Civil & Electrical which would
each entail the following:
S.No. Category Particulars
1 Start offs Land Contour & Topographical Analysis
2 Geo-tech analysis
3 Water test report
4 Module Mounting Structures
5 Evacuation Single line diagram
6
Major Equipment Selection -
Transformer, HT panels and String
Monitoring Boxes
7 Module Mix (wattage & make)
8 Leadoff Plant Layout
9 Switchyard / Sub Station layout
10 Civil - Fence Boundary Fence
11 Transformer Yard Fence
12 Switchyard Fence
13 Civil – Road Periphery
14 Internal
15
Civil - Land
Development &
Cleaning
Land Development, Grading & Filling
16 Civil- Buildings
General Arrangement of Inverter
room
17
General Arrangement of control room
18 Structural of Inverter Room
19 Structural of Control Room
20 Watch Tower
21 Security Cabin

2. S.No. Category Particulars
22 Gates Main + Wicket Gate
23
Plumbing &
Module cleaning
System
Water reservoirs
24 Pipeline layout and P&ID
25 Reverse Osmosis P&ID
26 Drainage Drains cross-section and Layouts
27
Foundation
details , location &
coordinate
markings
Lightning Arrestors
28 Weather Monitoring Station
29 Inverter Transformer
30 Auxiliary Transformer
31 Street Light
32 CCTV
33 Switchyard equipment
34 Electrical – SLD DC SLD
35 SCADA SLD & Architecture
36 Auxiliary SLD
37
Electrical –
Routings
DC Cable trench
38 AC cable Trench
39 Solar cable routing
40 Auxiliary cable routing
41 Inverter Room trenching
42 Control Room trenching
43 Earthing PV array
44 Inverter Room earthing
45 Control Room earthing
46 Switchyard
47
Panels &
Distribution
Boards
AC power distribution board
48 Illuminations Street lights
49 Inverter Room Illuminations
50 Control Room Illuminations
51 Plant Protection Layout of CCTV and cabling
52 Lightning Arrestors
53 Weather Monitoring Station
54 SCADA architecture

3. S.No. Category Particulars
55 Fire Fighting & Protection System
56 PV array String Combiner Box Layout
57 String Distribution & Numbering
58 Cable Schedules SPV module to SCB
59 SCB to inverters
60 LT AC Cable schedule
61 HT AC cable Schedule
62 Communication cable schedule
63 Auxiliary cable schedule
The drawing should be able to serve site related changes, capture details of vast and remote access,
and be clear in nature to aid faster construction.
Apart from the above drawings the developer should also seek out for relevant technical
specifications, quality assurance plans, design basis reports, generation yield assessments,
implementation schedules & bill of material with quantities.
