This document provides information on designing structured cabling systems, including premises and backbone cabling. It discusses network-specific and open cabling systems, as well as centralized and distributed network architectures. Key considerations for cabling system design include applications, hardware, software, physical plant and cost. The document also covers telecommunications outlet placement, telecommunications and equipment room design, horizontal and backbone cabling, media types, and standards bodies. Diagrams illustrate typical topologies, pathways, and closet layouts.
A structured cabling system allows for constant moves and changes to be performed by on-site personnel with growth and flexibility built into the cabling scheme. It supports and outlives most network components while only representing 5% of the total network investment. A structured cabling system allows moves, adds, and changes to occur quickly and cost-effectively, preventing downtime that can cost between $1,000 and $50,000 per hour.
In-building Solution (IBS) / Distributed Antenna System (DAS)
Small Cell Coverage within building premises
Signal is restricted inside the building
Antenna installed inside the building
Low Transmit Power of Antenna
Smaller Antenna size
A structured cabling system integrates data, voice, video and management systems through a standardized infrastructure. It includes 6 sub-systems: building entrance, equipment room, telecommunications room, backbone cabling, horizontal cabling, and work areas. The telecommunications room houses networking equipment and cross-connects between backbone and horizontal cabling. Backbone cabling connects telecommunications rooms to the equipment room. Horizontal cabling extends from telecommunications rooms to work areas. A structured cabling system provides benefits like redundancy, ease of fault location and repair, flexibility, and long-term cost containment.
