Visual Dictionary By: Sp10Downspout

Air Barrier Paper ,[object Object],[object Object],Air barrier paper- AKA Building Wrap

Attic Ventilation ,[object Object],Ridge Vent- allows Roof Turbines Soffit Vent Gable Vent ,[object Object]

Back Hoe ,[object Object],[object Object],[object Object]

Batter Boards ,[object Object]

Brick Arches Segmental Arch Keystone Roman Arch Jack Arch

Brick Arches- Centering ,[object Object],[object Object]

Brick Bonds Common Bond Running Bond

Brick Bonds Header Soldier Sailor Stretcher-Rowlock Rowlock

Brick Sizes ,[object Object],[object Object]

Bulldozer ,[object Object],Blade Bulldozer

Cladding Part 1 ,[object Object],Stone-Random Rubble Brick Wood Shingles

Code Requirements ,[object Object],[object Object],[object Object],[object Object],[object Object],[object Object],Sill height AFF- 22’’ Opening Width- 30’’ Opening Height – 60” Area- 1800 square inches ---Meets Code---

Code Requirements ,[object Object],[object Object],[object Object],The stairs that I measured had 7 ½’’ risers, a 1’’ nosing, and a 10 ½’’ tread, so it met code. Riser Tread Nosing

Concrete Joints ,[object Object],[object Object],Isolation Joint- isolating column from slab on grade below Failed Control Joint

Concrete Masonry Units (CMU) ,[object Object],[object Object],1 Course of CMU=3 Courses of Brick 8’’x8’’x16’’ 12’’x8’’x16’’

Decorative Concrete Masonry Units Ribbed Block Split Block

Doors ,[object Object],[object Object],Sidelight Transom Flush Door

Doors-Panel Door Top Rail Stile Lock Rail Panel Bottom Rail

Electrical Components Part 1 Service Head Meter Transformer Box Transformer Box- Box that converts energy in the form of electricity from one circuit to another. Service Head- Brings electricity from transformer box to meter Meter- reads the number of kilowatts per hour of electricity the structure uses.

Electrical Components Part 2 Service Panel-distributes the electricity brought in to branch circuits Duplex Receptacle- used to allow anything that uses electricity to plug into circuit

Framing Elements 1. Anchor Bolt 2. Sill Plate 3. Floor Joist 4. Subflooring

Framing Elements Part 2 5. Sole Plate 6. Studs 7.Top Plate (Doubled)

Framing Elements Part 3 9. Ceiling Joist 10.Rafter 11. Roof Decking 12. Sheathing

Front End Loader ,[object Object],[object Object],Front End Loader

Gypsum Board ,[object Object],First installed in ceilings, then moved down walls. Joints filled with “mud” a bonding substance similar to mortar.

Heat Pump ,[object Object],[object Object],Air Handling Unit Evaporator/Condenser

Insulation ,[object Object],Loose Fill Insulation Batt/Blanket Insulation Rigid Board Insulation Loose Fill is normally a spray applied insulation often in Attics to not disturb structure, while Batt/Blanket Insulation comes in precut rolls for stud widths or can be cut separately. Foamed is strong in R-value and can fill difficult gaps, while rigid board is strong and can be used as sheathing as well

Lintel ,[object Object],Steel angle Lintel

Mortar Concave Joint Tooled 3/8’’ width Type S mortar on House Flush Joint Troweled 3/8’’ width Type S Mortar on House

Oriented Strand Board ,[object Object],4’x8’ Sheet of OSB

Plumbing Part 1 ,[object Object],[object Object],Lavatory Water Closet

Plumbing Part 2 ,[object Object],Vent Thru Roof (VTR) Drop In Kitchen Sink Prefabricated Tub ,[object Object]

Plywood ,[object Object],[object Object],[object Object],4’ x 8’ sheet of Plywood

Radiant Barrier ,[object Object],[object Object],[object Object]

Rebar ,[object Object],[object Object],#8 Rebar (1 inch diameter)

Steep Roof Drainage ,[object Object],[object Object],[object Object],Downspout Splashblock Gutter

Steep Roof Materials ,[object Object],[object Object],[object Object],[object Object],Clay Tile Roof Black Underlayment Metal Panel Roof

Steep Roof Shapes Part 1 Mansard Roof Gambrel Roof

Steep Roof Shapes Part 2 Hip Roof Gable Roof

Steep Roof Terms Part 1 ,[object Object],[object Object],[object Object],Eave Hip Fascia Soffit ,[object Object]

Steep Roof Terms Part 2 Ridge Valley Rake Ridge-Highest horizontal piece of the roof, topmost part Valley- The slope intersection of two slopes, must be flashed Rake- Sloping edge of a steep roof on end of Gable roof

Steep Roof Terms Part 3 Wood Shingles

Stone- Part 1 Coursed Ashlar Coursed Rubble

Stone- Part 2 Random Rubble Random Ashlar

Vapor Retarder ,[object Object],Kraft Paper Vapor Retarder (R-13)

Waterproofing ,[object Object],Liquid Applied Waterproofing

Weep Hole ,[object Object],Weep Hole

Welded Wire Fabric (WWF) ,[object Object]

Windows Outswinging Casement because hinged on the side and swings outward Fixed windows because panes of glass that does not move Awning Window because hinged at top corners, inward swinging
