The document discusses the composition and functions of the extracellular matrix (ECM) and cell-cell junctions. The ECM provides structural support to cells and regulates cell behavior. It is composed of fibrous proteins like collagen, polysaccharides like glycosaminoglycans, and adhesion proteins like fibronectin and laminin. Cells interact with the ECM through integrin receptors. Cell-cell junctions allow communication between cells and include adherens junctions, desmosomes, tight junctions, and gap junctions. The ECM and cell-cell junctions are essential for tissue structure and function.

1. Extracellular Matrix

2. Readings and Objectives
• Reading
– Cooper: Chapter 14
• Topics
• The Extracellular Matrix
• Composition
• Cell-Matrix Interactions
• Cell-Cell Interactions
2

3. Extracellular Matrix
Introduction
• Cell walls: bacteria, fungi, algae, and higher
plants
• Animal cell in tissues embedded in an
extracellular matrix of proteins and
polysaccharides
Function
• Provides structural support to cells and tissues
• Important role in regulating cell behavior
–Cell to cell interaction, communication 3

4. General Structure of Extracellular Matrix
• Animal cells embedded in an
extracellular matrix
• Basal laminae: thin layer on which
epithelial cells rest. Also surrounds
muscle cells, adipose cells, and
peripheral nerves
• most abundant in connective
tissues
• Connective tissue
– loose connective tissue
– Bone
– tendon
– cartilage 4

5. Composition of Extracellular Matrix
• Fibrous proteins
• Polysaccharides- gel like environment
• Adhesion proteins- link components of the
matrix to one another and to cells
• Different matrices have different amounts of
each component
– Tendons, rich in fibrous proteins
– Cartilage, high in polysaccharides
– Bone, calcium phosphate crystal deposition
5

6. • Collagen- major structural fibrous
protein
• Forms triple helices
• Triple helix domains: repeats of the
amino acid sequence Gly-X-Y
• Glycine in every 3rd position
• X=Pro, packs helices closely
• Y= hydroxyproline,
synthesized in ER
• Pro, Hpro stabilizes
by helping H-bonding
Matrix composition: Collagen
6

7. • Type I collagen- the most abundant
• polypeptide chains have about 330
Gly-X-Y repeats
• Secreted through ER/golgi, form
collagen fibrils
• Triple helical molecules are
associated in regular staggered arrays
• Covalent cross-links: lysine and
hydroxylysine side chains
• strengthen the fibrils
• Fibrils form collagen fibers, several
µm in diameter
Matrix composition: Collagen
7

8. • Some are not fibril forming
• Fibril-associated collagens: bind to
collagen fibrils, link to others or to
other matrix components
• Network-forming collagens: have
non helical interruption, cross-link
to network
• Anchoring fibrils: link basal
laminae to underlying connective
tissues
• Transmembrane collagens:
proteins that participate in cell-
matrix interactions
Types of Collagen
8
Network-forming collagens

9. • Extracellular matrix gels are polysaccharides called
glycosaminoglycans (GAGs).
• GAGs are repeating units of disaccharides: One sugar is
either N-acetylglucosamine or N-acetylgalactosamine, the
second is usually acidic (glucuronic acid or iduronic acid).
Matrix Polysaccharides
9

10. • sulfate groups make GAGs
negatively charged
• bind positively charged ions
and trap water molecules to
form hydrated gel
• GAGs are linked to proteins
to form proteoglycans
Matrix Polysaccharides
10

11. • Link matrix components
– to each other
– to cell surfaces
• Fibronectin : main adhesion protein
of connective tissues
• A homodimeric protein (2500
aa/subunit), binds
– collagen and GAGs
– cells
• Recognized by cell surface receptors
• Attachment of cells to the
extracellular matrix
Matrix Adhesion proteins: Fibronectin
11

12. • Laminin: adehsion protein of basal
laminae
• Heterotrimeric: α, β, and γ-chains
(5, 4, 3 genes, respectively)
• have binding sites for
– cell surface receptors, eg integrins
– type IV collagen
– Proteoglycans
• Assemble to cross-linked network
• Linking cells and matrix
Matrix Adhesion proteins: Laminins
12

13. Cell-Matrix Interactions
• Integrins: major cell surface
receptors, involved in attachment of
cells to the extracellular matrix
• Transmembrane proteins,
heterodimer of α and β subunits
(18α, 8β)
• Bind to short aa in,
– Collagen
– Fibronectin
– laminin
• also anchor the cytoskeleton to the
extracellular matrix
13

14. Cell-Matrix Junctions
Two types of cell-matrix junction
• Focal adhesions: bundles of
actin filaments are anchored
to β subunits of integrins via
– α-actinin
– Vinculin via talin
• Assembly of focal adhesions
• Focal complex: small group of
integrins
• Recruite Talin, Vinculin, α-
actinin and Formin
• Formin initiates actin bundles
14

15. Focal adhesions are reversible
• Integrins can reversibly bind matrix components
• change conformation between active and inactive states
• Inactive state: integrin heads turned close to cell surface
• Cell signaling extends heads to matrix
• Migrating cells: focal adhesions form at the leading edge
15

16. Cell-Matrix Junctions: Hemidesmosomes
• Hemidesmosomes anchor
epithelial cells to the basal
lamina
• α6β4 integrins bind to
lamins
• long cytoplasmic tail of β
subunit binds to
intermediate filaments via
• Plectin and BP230 and
BP180 (similar to
transmembrane collagens)
16

17. Cell-Cell interactions
• Interactions between cells are critical for development
and function of multicellular organisms
• Cell-cell interactions:
– Transient: activation of immune cells; migration to injury site
– Stable: role in the organization of tissues.
• Cell-Cell junctions allow rapid communication between
cells
• During embryo development, cells from one tissue
specifically adhere to cells of the same tissue rather than
cells of a different tissue
17

18. Cell-Cell interactions
• Cell-cell adhesion- mediated by four groups of cell
adhesion molecules
• Selectins, integrins, the immunoglobulin (Ig) superfamily,
and cadherins
• Many adhesions are divalent cation-dependent, requiring
Ca2+, Mg2+ or Mn2+
18

19. Selectins
• Selectins- transient interactions between leukocytes and
endothelial cells
• Leukocytes slow down, flattened, migrate from the
circulation to sites of tissue inflammation
• initial adhesion
• stable adhesions
binding of integrins
to intercellular
adhesion molecules
(ICAMs) on
endothelial cells
19

20. Cell to Cell Junctions
Four types of Cell-Cell connections in
animal cells
• Adherens Junctions
• Desmosomes
• Tight Junctions
• Gap Junctions
20

21. Adherens Junctions
• Cadherin form stable
cell-cell connections
involve actin filaments
• Also include β-catenin,
p120, and α-catenin,
• β-catenin and p120 bind
to cadherin and help
maintain stability
• β-catenin binds α-catenin
that interacts with actin
filament of cytoskeleton
21

22. Desmosomes
• link the intermediate
filament of adjacent cells
• Desmoglein and
desmocollin
(transmembrane cadherins)
bind by heterophilic
interactions across the
junction
• Plakoglobin and plakophilin
bind to the cadherins and
link to the intermediate
filament binding protein,
desmoplakin
22

23. Tight Junctions
• Tight junctions provide
minimal adhesive strength
between the cells, usually
associated with adherens
junctions and desmosomes
in a junctional complex
23

24. Tight Junctions
• Tight junctions in
epithelial cell form a
seal that prevents free
passage of molecules
and ions between
cells
• separate apical and
basolateral domains
of the plasma
membrane
• prevent free diffusion
of lipids and
membrane proteins 24

25. Tight Junctions
• transmembrane proteins, occludin,
claudin, and junctional adhesion molecule
(JAM), anchored on F-actin
• Bind similar proteins on the adjacent cell
• Sealing the space between cells
25

26. Gap Junctions
• open channels through the plasma
membrane
• allowing ions and small molecules to
diffuse freely
• Proteins and nucleic acids can not
pass through
• heart muscle cells, passage of ions
through gap junctions synchronizes
the contractions of neighboring cells
• allow passage of some signaling
molecules, such as cAMP and Ca2+,
coordinating responses of cells in
tissues
26

27. Gap Junctions
• Gap junctions are made of
transmembrane proteins
in the connexin family
• 6 connexins form a
cylinder with an open
aqueous pore in its center,
called a connexon
• Connexons in the plasma
membrane adjacent cells
align
• form open channels
between the two
cytoplasms 27

28. Gap Junctions
• Specialized gap junctions
occur on specific nerve
cells and form an electrical
synapse
• Individual connexons can
be opened or closed
• When open, they allow
rapid passage of ions
between the two nerve
cells
28
