The document provides an overview of basic electrical and electronics concepts and components. It begins with definitions of key terms like electricity, voltage, current and atomic structure. It then explains components like resistors, capacitors, diodes, transistors and how they work. Different circuit applications using these components are discussed, including rectifiers, amplifiers and oscillators. The document serves as training material for an introductory workshop on circuit design and analysis.

1. WELCOME

2. Contents
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 2

3. Introduction
• Concepts of…
• Electricity
• EMF
• Potential difference
• Voltage
• Current
• Atomic structure
• semiconductors
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 3

4. What’s Electricity..?
• Electricity is a form of energy, which can
produce the light, heat, motion and magnetic
effects by the flow of electrons through a
conductor
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 4

5. Electronics Vs Electrical
Electronics
• Current through Semi
conductors, Gas and
Vacuum
• High frequency current
through Conductors
Electrical
• Current through conductors
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 5

6. EMF
• Force, to motive Electron
• Unit Volt
• The Actual voltage of a Cell.
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 6

7. Potential Difference
• Force Due to the difference in Potential
• It’s a kind of potential
• Output voltage of a Battery
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 7

8. Atomic Structure
• Electrons
– Negative Charge
– Moving Around Nucleus
– Have PE and KE
– In Orbits
• Nucleus
• Positive Charge
• Neutrons and protons
• Orbits
• Energy levels
Since electricity is related
to the electrons, the
Electrical behavior of a
material is decided by the
atomic structure of the
material.
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 8

9. Atomic Structure
• Valance Electrons: are the
electrons in the Outer most
Shells.
• Max No of Valance
Electron is 8 and the 8
electron is the stable state.
To attain Stability the
Electron may lose or gain.
• Free Electrons: are valance
electrons having very weak
attachment with the
nucleus(Lose for stability)
Electrons are able to lose or gain
energy and to move (Excite) from one
orbit to another. Electrons have
Potential energy due to the nucleus
and kinetic energy due to the motion.
Electron requires energy to escape
from the atomic nucleus. Number of
outer most electrons is called the
valance of the atom. For a stable
atom, the valance number should be
eight. Atom has a tendency to attain
stability. For this, they lose, gain or
share electrons
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 9

10. Energy Bands: • Valance Band: is the energy
band of outer most orbits.
• Conduction Band: is the energy
band of conduction band (the
minimum energy required to
an electron is free).
• Conductors
• Semi Conductors
• Insulators
Consider a particular orbit of an atom;
each electron in the orbit has different
energy. In a Semiconductor (Crystal), a
number of such atoms are there. So a
particular Shell or Sub shell have a an
energy band (Collection of Energy
levels),instead of a single energy level.
Such bands are called energy bands.
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 10

11. Semi conductors
• Intrinsic
• Extrinsic
• N-type
• P-type
• Conduction in Semi Conductors
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 11

12. Contents
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 12

13. Electronic components
• Resistors
• Capacitors
• Diodes
• Zener diodes
• LEDs
• Transistors
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 13

14. Resistors • Fixed
– Carbon Film
– Metal film
– Carbon Composition
• Variable
– Linear
– Log
• Semi Variable
They are used for offering resistance
for the circuit. They are available as
Fixed, Variable and Semi variable
Resistors A resistor has Following
Specifications.
Resistance: is the Resistance offered
by the Resistor. For Variable and Semi
Variable Resistors, Resistance is the
maximum resistance, that offers.
Tolerance: indicates the deviation of
the resistance from the typical value,
due to other parameters like
temperature variation. Tolerance is
expressed in percentage.
Wattage: of a resistor says about max
current, that a resistor can withstand,
without any damage.
Used for:
Current control
Voltage divider
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 14

15. Capacitors
• Fixed
– Paper
– Mica
– Ceramic
• Variable
• Semi Variable
Capacitors are used to store charges.
Capacitor is made by placing an
insulator (called dielectric) in between
two Metal plates. Capacitance is the
measure of capacitor’s ability to store
electric charge. Its unit is farad. Like
Resistors, they are also available as
Fixed, Variable and Semi Variable.
They are called by the name of the
dielectric used in it.
Capacitance: is the value marked on it.
Micro Farad (μF) is the practical unit.
Tolerance: will also be marked as
percentage.
Voltage rating: of capacitor is the
maximum voltage that can be stored
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 15

16. IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 16

17. Diodes • Forward Voltage drop (VF): is
the voltage drop across the
diode when it’s in conducting
state (forward biased). It will
be slightly greater than the
Knee Voltage.
• Peak Inverse Voltage (PIV):is
the maximum voltage that can
be applied in the reverse bias,
without any damage.
Diodes are P-N junction devices.
An ordinary Diode act as a Valve.
Diodes are known a particular No.
Data Sheet, provided by the
Manufacture says the
Specifications of Diode
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 17

18. P-N junction
P type N-type
-
-
-
-
+
+
+
+
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 18

19. Forward Bias
+
+
+
+
P type N-type
-
-
-
-
P type N-type
+
+
+
+
-
-
-
-
P type N-type
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 19

20. +
+
+
+
P type N-type
-
-
-
-
P type N-type
-
-
-
-
+
+
+
+
+
+
+
+
-
-
-
-
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 20

21. Zener Diodes
• Specifications
– Voltage
– Wattage
• Shunt Regulator
are the diodes which can be used for
the voltage regulation. Zener diodes
work like ordinary diode,; but in
reverse bias, instead of Avalanche
breakdown, they undergo Zener
breakdown. When avalanche break
down reached the diode will be
burned.
Common zener diode voltages are
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 21

22. LEDs
LEDs are the diodes, which emit light.
In diodes the electrons from N-region,
having high energy are recombined
with holes in the P-region as in figure.
So they emit Light. The energy Gap
decides the color of LED, as shown in
the Table. White LED basically emits
ultraviolet light; and is converted to
white by the Phosphorus coating on
the LED.
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 22

23. Transistors
Operating Regions of a Transistor:
• Active region:
• Saturation:
• Cutoff region:
• Inverted region
Basic functions as
1. A switch
2. An amplifier
3. A regulator.
Transistors are three terminals, two
junction devices. Transistors are made
by sandwich of an N-type in between
Two P-type semi conductors
(PNP).NPN Transistors are common in
use. Consider an N type
semiconductor in connection with a
battery as in figure. The electrons Flow
from the –ve terminal to +ve. Now
look in two the Figure B; there is the p-
region blocks the current. This device
is the Transistor. If we apply a biasing
voltage as shown in figure C, the
electrons from emitter will come to
Base because of the forward bias. But
the Base is physically small and the
collector is highly positive. So the
electrons will entre to Collector and
Transistor Conducts.
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 23

24. Contents
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 24

25. Diode Circuits
• Rectifiers
• Clippers
• Clampers
• Voltage Multipliers
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 25

26. Rectifiers
• Half Wave Rectifier
• Full wave Rectifier
• Bridge rectifier
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 26

27. IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 27

28. Clippers
• Positive Clipper
• Negative Clipper
• Biased Clipper
Clippers are wave shaping circuits.
They clips out some portions of in put
signal.
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 28

29. Circuit Equivallent
Input Signal
OUT PUT
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 29

30. Clamper
• Positive
• Negative
• Biased
Clamper circuits Chang the DC
levels of an ac.
Here the Capacitor is charged
through the diode when it’s in
forward bias.
The input is added with the
capacitor voltage and is give to
out put while the diode is in
reverse bias.
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 30

31. Voltage Multipliers
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 31

32. Contents
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 32

33. Transistor circuits
• Biasing Methods
• Transistors as amplifiers
• Feed Back amplifiers
• Switches
• Multivibrators
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 33

34. Transistor Biasing
• Base resistor Biasing
• Feed Back Resistor
• Voltage Divider
We have discussed the operating
regions of transistors. A transistor
works as an amplifier in active region.
To reach this we need some fixed
voltages at each junction. How this
acquires? Separate voltage sources are
not a suitable solution. So we provide
the required voltages by some
additional circuits with transistors,
called biasing circuits. Biasing circuits
are used to…
Fix the operating point
Stabilize collector current against
temperature variations
 Make the operating point,
independent of the transistor
parameters.
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 34

35. Amplifier
• A transistor is a transfer Resistor
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 35

36. Feed Back in Amplifiers
• Positive
• Negative
• Sampling
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 36

37. Oscillators
• Tank circuits
• R-c phase shift Oscillators
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 37

38. Multivibrators
• Transistor as a switch
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 38

39. Multivibrators
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 39

40. Contents
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 40

41. Miscellaneous
• Relays
• Read switches
• LDRs
• Regulator circuits
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 41

42. Relays
• Handle Heavy Loads
• Controlled by a dc supply
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 42

43. Read Switch
• Magnetic power
• High current Application
• Like Relays
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 43

44. Contents
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 44

45. Reference
Basic electronic Circuits : N.N Bhargava
Electronic Devices and Circuits : Jacob milman
www.elexp.com
Electronicslab .com
WEB
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 45

46. Thanks
muhsin@in.com
muhsin.ca@gmail.com
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 46

47. 864329
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 47

48. IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 48

49. IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 49

50. IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 50

51. IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 51

52. Circuit Equivallent
Input Signal
IEEE Circuit Designing
Workshop
by: MUHSIN CA 9961864329 52
