3. • THE MICROPROCESSOR 8086 IS MADE OF HMOS: HIGH
PERFORMANCE METAL OXIDE SEMICONDUCTOR
TECHNOLOGY WITH AN IC CIRCUITRY EQUIVALENT TO
≈ 29000 TRANSISTORS.
• HOUSED IN A 40-PIN DUAL IN-LINE PACKAGE.
• 8086 IS A 16BIT PROCESSOR. IT’S ALU, INTERNAL
REGISTERS WORKS WITH 16BIT BINARY WORD.
• 8086 HAS A 16BIT DATA BUS. IT CAN READ OR WRITE
DATA TO A MEMORY/PORT EITHER 16BITS OR 8 BIT AT
A TIME.
• 8086 HAS A 20 BIT ADDRESS BUS WHICH MEANS, IT
CAN ADDRESS UP TO 220 = 1MB MEMORY LOCATION.
3
INTRODUCTION TO 8086
5. BUS INTERFACE UNIT (BIU)
• THE BIU FETCHES INSTRUCTIONS, READS AND
WRITES DATA, AND COMPUTES THE 20-BIT
ADDRESS.
• BIU HANDLES ALL THE DATA TRANSFERS AND
ADDRESSES ON THE BUSES FOR EU.
• EU EXECUTES INSTRUCTIONS FROM THE
INSTRUCTION SYSTEM BYTE QUEUE.
6. EXECUTION UNIT (EU)
• THE EU CONTAINS CONTROL CIRCUITRY, INSTRUCTION
DECODER, ALU, POINTER AND INDEX REGISTER, FLAG
REGISTER.
• EU TELLS THE BIU WHERE TO FETCH INSTRUCTIONS
AND DATA.
• THE EU DECODES AND EXECUTES THE INSTRUCTIONS
USING THE 16-BIT ALU.
• DECODER TRANSLATES INSTRUCTIONS INTO SERIES OF
ACTIONS WHICH EU CARRIES OUT.
• ALU CAN PERFORM ARITHMETIC AND LOGICAL
OPERATIONS.
8. REGISTERS DESCRIPTION
• Registers
– Data registers
•Hold data for an operation to be performed
•There are 4 data registers (AX, BX, CX, DX)
– Address registers
•Hold the address of an instruction or data element
•Segment registers (CS, DS, ES, SS)
•Pointer registers (SP, BP, IP)
•Index registers (SI, DI)
– Status register (FLAG Register)
•Keeps the current status of the processor
• In total there are fourteen 16-bit registers in an
8086/8088
9. FLAG REGISTER
Carry flag
Parity flag
Auxiliary flag
Zero
Overflow
Direction
Interrupt enable
Trap
Sign
6 are status flags
3 are control flag
10. FLAG REGISTER
DESCRIPTION• SF (sign) Contains the resulting sign of an arithmetic operation
(1=negative)
• ZF (zero) Indicates when the result of arithmetic or a comparison
is zero. (1=yes)
• CF (Carry) Holds the carry out after addition or the borrow after
subtraction.
• AF (auxiliary carry) Contains carry out of bit 3 into bit 4 for
specialized arithmetic.
• PF (parity) Indicates the number of 1 bits that result from an
operation in accumulator.
• OF (overflow) Indicates overflow of the leftmost bit during
arithmetic operation.
• DF (direction) Indicates left or right for moving or comparing
string data if df=0 then then string proceed from lower address
to high otherwise high add. To low add..
.
11. 11
• TF (TRAP) PERMITS OPERATION OF A PROCESSOR IN
SINGLE-STEP MODE. IF SUCH A FLAG IS
AVAILABLE, DEBUGGERS CAN USE IT TO STEP THROUGH
THE EXECUTION OF A COMPUTER PROGRAM.
• IF (INTERRUPT) DETERMINES WHETHER OR NOT
THE CPU WILL HANDLE MASKABLE HARDWARE INTERRUPTS.
12. POINTER AND INDEX
REGISTERS
• IP: INSTRUCTION POINTER
• POINTS TO NEXT INSTRUCTION IN CODE MEMORY.IT
CALCULATE THE 20 BIT PHYSICAL ADDRESS.
• SP: STACK POINTER
• POINTS TO PROGRAM STACK.IT CONTAINS 16 BIT
OFFSET FROM START OF STACK SEGMENT.
• BP: BASE POINTER
• PRIMARILY USED TO ACCESS DATA ON THE STACK
• CAN BE USED TO ACCESS DATA IN OTHER SEGMENTS
12
13. • SI & DI: SOURCE AND DESTINATION INDEX REGISTER
IT IS REQUIRED FOR STRING OPERATIONS. WHEN
STRING OPERATIONS ARE PERFORMED, THE SI & DI
REGISTER POINTS TO MEMORY LOCATIONS IN THE DATA
SEGMENT WHICH IS ADDRESSED BY THE DS REGISTER.
13
14. ALU
ALU STANDS FOR ARITHMETIC AND LOGIC UNIT. IT
PERFORMS,
1. MATH OPERATION LIKE 8 OR 16 BIT ADDITION,
SUBTRACTION, DATA CONVERSION,
2. LOGICAL OPERATION LIKE NOT, OR, XOR, AND,
ETC.
3. INCREMENT ,DECREMENT, AND SHIFT
OPERATIONS.
14
15. INSTRUCTION QUEUE IN
8086
• 8086 PROVIDES QUEUING FACILITY WHERE BIU
FETCHES THE SIX INSTRUCTION BYTE FROM
MEMORY WHILE CURRENT INSTRUCTION IS BEING
EXECUTED. IT SPEED UP THE PROGRAM
EXECUTION.
• IT WORKS ON FIRST IN FIRST OUT (FIFO)
FASHION.
• THE SIZE OF QUEUE FOR 8086 IS 6 BYTES.
• BIU FETCHES THE INSTRUCTION CODE FROM
MEMORY AND STORES IN QUEUE, EU FETCHES
15
