2. Microwave Engineering
1. Smith chart
Photo of Smith chart
Graphical method
Essential diagram for
microwave engineering
P. Smith in 1939
2 EM Wave Lab
3. Microwave Engineering
1. Smith chart
Induction of Smith chart
Γ =| Γ | e jφ where | Γ |< 1
Z − Z0
Γ= L
Z L + Z0
Normalized load impedance :
Z L RL + jX L
z L = r + jx = =
Z0 Z0
zL −1 1+ Γ
Γ=
zL + 1
or z L =
1− Γ
Γ = Γr + jΓi
3 EM Wave Lab
4. Microwave Engineering
1. Smith chart
Induction of Smith chart
1 + Γr + jΓi
z L = r + jx =
1 − Γr − jΓi
1 − Γr2 − Γi2 2Γi
r= x=
(1 − Γr ) 2 + Γi2 (1 − Γr ) 2 + Γi2
Circle equations
2 2 2 2
r 1 1 1
Γr − + Γi =
2
, ( Γr − 1) + Γi − =
2
1+ r 1+ r x x
4 EM Wave Lab
5. Microwave Engineering
1. Smith chart
Constant resistance circles
2 2
r 1
Γr − + Γi =
2
1+ r 1+ r
5 EM Wave Lab
7. Microwave Engineering
1. Smith chart
Input impedance
V0+ − jβz
Vs = Vo+ (e − jβz + Γe jβz ) and I s = (e − Γe jβz )
Z0
Z in Vs e − jβz + Γe jβz
zin = = = − jβz
Z0 Z0 I s e − Γe jβz
At z = −l
1 + Γe − j 2 βl 1+ | Γ | e j (φ − 2 βl )
zin = − j 2 βl
= j (φ − 2 βl )
1 − Γe 1− | Γ | e
7 EM Wave Lab
8. Microwave Engineering
1. Smith chart
Input impedance
Γ ⇒ Γe − j 2 βl
Clockwise angle of 2 βl on the Smith chart.
βl = π
one lap around the chart (l = 0.5λ )
8 EM Wave Lab
10. Microwave Engineering
2. Applications
VNA (Vector Network Analyzer)
Measurement equipment
Reflection coefficients
with frequency sweep
10 EM Wave Lab
11. Microwave Engineering
2. Applications
Representation of Smith chart
Z L = 25 + j 50Ω on a 50 - Ω line
z L = 0.5 + j1
r = 0.5 x = 1 ⇒ Point A
| Γ |≈ 0.62, φ ≈ 83
11 EM Wave Lab
