3. INTRODUCTION
Retinal vascular occlusions are serious
diseases and significant causes of blindness
that include arterial and venous obstructions
The clinical presentation aids in distinguishing
the type of the occlusion, which may be
classified according to the anatomical site of
the occlusion
4. Blood supply of RETINA
Outer 4 layers of RETINA: Choriocapillaries.
Inner 6 layers of RETINA: Central retinal artery
The fovea is avascular and is mainly supplied
by Choriocapillaries.
Cilio retinal artery is present in 20% of eyes
The veins of the RETINA unite to form Central
retinal vein at the disc , which follows the
corresponding artery
7. RETINAL ARTERIAL
OCCLUSIONS
Visual loss from retinal arterial occlusion
(RAO) occurs from the loss of blood supply to
the inner layers of the retina
CAUSES:
ATHEROSCLEROSIS
EMBOLISM
10. CENTRAL RETINAL ARTERY
OCCLUSION
Incidence and demographics:
Frequency -1 per 10,000 outpatients visits
CRAO accounts for (57%), BRAO(38%), CRAO(5%)
Mean age at the time of presentation is in the early 60’s
Men affected more then women
1-2 % of cases have B/L involvement, for which the
DD : should include cardiac valvular disease , GCA and
other vascular inflammations.
11. CLINICAL FEATURES
Sudden and profound LOSS of vision,
painless except in GCA.
VA is severely reduced
RAPD present
RUBEOSIS IRIDIS(1/5 eyes)
12. FUNDUS
Superficial retina
YELLOW WHITE APPEARANCE
CHERRY RED SPOT
Cattle trucking/box caring
Retinal/Disc NV(2%)
LATE signs:
Optic atrophy
Narrowing of vessels
Vessel sheathing
RPE changes
14. INVESTIGATIONS
FA: Delay in retinal arterial filling (highest
SPECIFICITY).
Delay in Retinal A-V transit time (Most common and
highest SENSITIVITY)
15. OCT: shows highly reflective emboli plaque within
superficial nerve head
ERG: Diminution of amplitude of “b” wave,
with normal “a” wave
16. BRANCH RETINAL ARTERIAL
OCCLUSION
BRAO occurs when the embolus lodges in a
more distal branch of the retinal artery.
Typically involves the TEMPORAL retinal
vessels
Clinical features
Sudden and painless SECTORAL visual field loss
VA is variable.
RAPD is often present.
18. INVESTIGATIONS
FA shows delay in arterial filling and hypo
fluorescence of the involved segment due to blockage
of background fluorescence by retinal swelling
19. CILIO RETINAL ARTERIAL
OCCLUSION
Cilioretinal arteries-Temporal aspect of the
optic disc , separate from the CRA
20% of eyes
Provides second arterial supply to the
MACULA from posterior ciliary circulation.
On FFA fill concomitantly with choroidal
circulation 1-2 seconds before retinal arteries
20. THREE VARIANTS
ISOLATED :
• >40%
• Young patients
with systemic
vasculitis
• Good visual
prognosis
• No ocular
treatment required
21. WITH CRVO:
>40%
Reduced pressure in the
CilioRA as compared to CRA
Better visual prognosis
No ocular treatment required
22. WITH AION :
15%
Both appear to be
manifestations of
posterior ciliary
insufficiency
Poor prognosis
GCA as a cause
should be
investigated.
23. TREATMENT OF ACUTE ARTERIAL
OCCLUSION:
OCULAR
Retinal artery occlusion is an emergency
because it causes irreversible visual loss unless
the retinal circulation is re-established prior to
the development of retinal infarction
The following treatments may be tried in
patients with occlusions of less than 24 hours
duration at presentation.
.
24. Adoption of a supine posture
Ocular massage
Anterior chamber paracentesis
Sublingual isosorbide dinitrate to induce vasodilation.
25. ‘Rebreathing’ into a paper bag OR Breathing
‘CARBOGEN’.
Topical apraclonidine 1%, timolol 0.5% and intravenous
acetazolamide 500 mg to achieve sustained lowering
of intraocular pressure
Hyperosmotic agents. Mannitol or glycerol
Transluminal Nd: YAG laser embolysis.
26. SYSTEMIC
General risk factors like smoking to be discontinued.
Anti- Platelet therapy to be started , if not CI.
Oral anticoagulants treatment (e.g.Warfarin) in
patients with AF
Carotid endarterectomy in symptomatic stenosis
greater than 70%
Asymptomatic retinal embolus if identified ,indicates
increased risk of stroke and IHD, evaluation and
treatment of risk factors is required.
27. FOLLOW UP
CRAO: After 3-4 weeks and a minimum of twice
subsequently at monthly intervals to detect
neovascularization of Anterior segment
BRAO: After 3 months
29. RISK FACTORS:
1. AGE: 50% of cases occur in >65 years .
2. HYPERTENSION :73% in >50 years ,25% in younger
patients
3. HYPERLIPIDAEMIA (total cholesterol >6.5 mmol /l) is
present in 35% of patients
4. DIABETES MELLITUS 10% of cases over the age of 50
years
5.OCULAR: OAG, Ischemic optic neuropathy , Optic
nerve head drusen
30. CENTRAL RETINAL VEIN
OCCLUSION
Incidence and demographics :
Prevalence of CVO - 0.1-0.4%.
Age at the time of presentation is above
60’s
Men and women equally affected
U/L ,with 1% risk of development in the
fellow eye by the end of 1 year, 7% risk by
the end of 7 years.
31. NON-ISCHAEMIC CRVO
Non-ischaemic CRVO is the most common
type, accounting for about 75%.
CLINICAL FEATURES:
1.Sudden painless unilateral loss of vision.
2.VA is impaired to a moderate-severe degree.
3.RAPD is absent or mild (in contrast to ischaemic
CRVO)
32. FUNDUS
Tortuosity and dilatation of all the branches
Dot/blot and flame-shaped haemorrhages,
throughout ALL quadrants
Cotton wool spots, Disc and macular oedema
are common.
Most acute signs resolve over 6–12 months.
OPTOCILIARY shunts/RETINOCHOROIDAL
shunts
Conversion to ischaemic CRVO occurs in 15%
33. Investigations
o FA shows delayed A-V transit time, blockage
by haemorrhages, good retinal capillary perfusion(<10 disc
areas of non perfusion) and late leakage.
o OCT is useful in the assessment of CMO(mild
in NI-CRVO)
Follow up:
Initial follow-up should take place after
3months.
Subsequent review is usually at 18-24
36. ISCHAEMIC CRVO
Clinical features:
1. Sudden and severe painless unilateral loss of
vision, occasionally can present with pain,
redness or photophobia
2. VA is CF or worse
3. RAPD is present
4. Anterior segment findings : NVI , ANV,
NVG(100 day glaucoma).CVOS STUDY
38. FUNDUS
Tortuosity of all branches
Extensive deep dot/blot and
flame-shaped
haemorrhages,
Cotton wool spots are
prominent, optic disc
swelling usually present.
Most acute signs resolve
over 9–12 months.
39. INVESTIGATIONS
FA shows delayed arteriovenous transit time,
masking by haemorrhages, extensive areas of
retinal capillary non- perfusion(10 or > disc areas in
diameter)
OCT is useful in quantification of CMO
Electroretinogram (ERG).
42. SYSTEMIC ASSESSMENT
ALL PATIENTS
BP
ESR,CBC
RBS
HDL . Cholesterol
OTHERS:
Urea Creatinine Electrolytes (renal
disease @ with HTN)
Thyroid function tests
ECG(LVH is associated with HTN)
SELECTED
PATIENTS
(<50 yrs, B/L, Common inv-negative, family h/o
thrombophilia)
Chest X ray: TB, Sarcoidosis
CRP: sensitive indicator for
inflammation
Plasma homocysteine level
“Thrombophilia screen”
Plasma Protein electrophoresis
Autoantibodies: RF, ANA, ANCA,
anti-DNA antibody
ACE: Sarcoidosis
Treponemal serology
Carotid duplex imaging
43. Medical therapy
Treatment of MACULAR OEDEMA:
a) VA worse than 6/9 and significant central macular
thickening on OCT
b) Intravitreal anti-VEGF agents: Ranibizumab showed
a significant visual benefit when used for CMO
c) Intravitreal Dexamethasone implant
d) Intravitreal Triamcinolone:
The SCORE study showed an improvement in the vision of 3 or more
lines at one year in over 25% of patients treated with an average of 2
injections of 1 mg triamcinolone versus 7% of controls.
44. e) Laser photocoagulation
CVOS study: Grid pattern argon laser photocoagulation did
reduce macular oedema by 1 year (31%), BUT it did not result
in an improvement in visual acuity.
OTHER treatments include
Chorioretinal anastomosis
Pars plana vitrectomy
Radial optic neurotomy
Recombinant tissue plasminogen
activator(r-tPA)
45. Treatment of NEOVASCULARIZATION
a) PRP in eyes with NVI or NVA:application of
1500–3000 burns (0.5–0.1 second, spaced one burn
width apart).
CVOS study: PRP should be given after the development of INV/ANV
and not prophylactically, to be considered in patients with RF of
developing INV/ANV or follow up not possible
b) Intravitreal anti-VEGF agents
46.
47. BRANCH RETINAL VEIN
OCCLUSION
Macular BRVO involving only a macular branch
Peripheral BRVO not involving the macular circulation
Clinical features:
1. Sudden painless onset of blurred vision
Peripheral occlusion may be asymptomatic
2.VA is variable
3. NVI and NVG are much less common than CRVO
(2-3% at 3 years )
48. FUNDUS
• Tortuosity with dot/blot &
flame-shaped haemorrhages
• Cotton wool spots and
retinal oedema are present
• SUPEROTEMPORAL
quadrant
• Resolution over 6–12
months.
• Retinal neovascularization
8%
50. Residual findings-
Venous sheathing and sclerosis, persistent /recurrent
haemorrhages.
Collaterals may form near areas of limited capillary
perfusion.
FA shows peripheral and macular ischaemia, Venous
filling delayed
OCT is useful in quantification of CMO
51. Management
Systemic assessment
Observation without intervention if VA is 6/9 or
better
NVE/NVD: sector photocoagulation 400-500 µm
diameter for 0.05 sec duration and spaced one burn width
apart are applied to ischaemic area.
NVI : Sector PRP
Intravitreal anti-VEGF agents
Intravitreal Dexamethasone implant
52. Macular laser:
Eligibility criteria
Method
Intravitreal Triamcinolone
Review : After 3months and then 3-6 monthly
intervals for 2 years to detect neovascularization
53. HEMIRETINAL VEIN OCCLUSION
Hemiretinal vein occlusion is generally
regarded as a variant of CRVO and may be
ischaemic or non-ischaemic.
54. DIAGNOSIS
Sudden onset altitudinal visual field defect.
VA reduction is variable.
NVI more common than BRVO , but less than
CRVO
FUNDUS shows the features of BRVO,
involving the superior or inferior hemisphere ,
NVD more common
FA shows masking by haemorrhages , hyper
fluorescence due to leakage and variable
capillary non perfusion
56. TREATMENT
Depends on the severity of retinal ischaemia
Extensive retinal ischaemia carries the risk of
neovascular glaucoma and should be
managed in the same way as ischaemic
CRVO.
Macular oedema usually responds poorly to
grid laser due to extensive foveal capillary
shutdown
57. Systemic treatment in retinal vein
occlusion
Control of systemic risk factors
Antiplatelet therapy with aspirin or an
alternative agent should be considered
61. References
Ryan Retina
American Academy of ophthalmology
Kanski’s clinical ophthalmology
Retinal vein occlusions by royal college of
ophthalmologists
CRA arises from OA near optic foramen ,lies below the ON adherent to dura,at about 10-15 mm pierces dura and arachnoid
In accompany with vein on the temporal side passes anteriorly and pierces the lamina cribrosa to appear inside the eye
In the optic nerve head
Superficially in the nasal part of physiological cup, divides into 2 branches
Cholesterol :minute ,bright , refractile , golden to yellow orange crystals often seen at the bifurcation
Fibrin :dull grey elongated usually multiple
Calcific : single white non scintillating particles
Coagulopathies: antiphospholipid syndrome,protein c and s defici
PAN,TA,SLE
OCULAR :Optic nerve drusen, PRE retinal arterial loops
except when a portion of the papillo macular bundle is supplied by a cilioretinal artery, when central vision may be preserved
Rubeosis iridis 4-5 weeks after obstruction,if present along with obstruction ,concomitant carotid artery obstruction to be considered
YELLOW WHITE APPEARANCE Ischaemic necrosis in the affected inner half of retina corresponds to the whitening seen clinically
Occurs 15min to several hrs ,resolves by 4-6 weeks
CHERRY RED SPOT orange reflex from foveola
(i)intact retinal pigment epithelium and choroid underlying the fovea
(ii) the foveolar retina is nourished by the choriocapillaris, and
(iii) the thinnest NFL at this location.
Narrowing (attenuation) of arteries and veins with sludging and segmentation of the blood column
OCULAR MASSAGE:
In and out movement using goldman contact lens /digital massage apply pressure for 10-15 seconds and sudden release,improves perfusion and dislodge the embolus/thrombus
AC paracentesis:
Sudden decrease in IOP ,retinal artery perfusion pressure behind the obstruction will force an obstructing embolus downstream
In which the occluding embolus is given shots of 0.5-1.0 mJ or higher are applied directly on to the embolus using a fundus contact lens
Complication:VH
NASCET (North American Symptomatic Carotid Endarterectomy Trial)
Mechanical pressure on the optic nerve head and lamina cribrosa causes the occlusion
External compression of the globe and optic nerve from thyroid related ophthalmopathy/mass lesion
Head trauma with orbital fracture
Hyperviscosity syndromes: Dysproteinemia (MM) and blood dyscrasias (PCV)
Meta analysis :INC plasma hoocysteinemia and low serum folate levels r @ RVO
Residual findings include disc collaterals , Epiretinal gliosis and pigmentary changes at the macula.
Disc collaterals are common following CRVO ,called as OPTOCILIARY
Tortuosity and dilatation of all the branches
Dot/blot and flame-shaped haemorrhages, throughout ALL quadrants
NVI typically begins at the pupillary border may extend across the iris surface
ANV fine branching vessels bridging the scleral spur
INC IOP + INV/ANG hallmark of NVG
NVI typically begins at the pupillary border may extend across the iris surface
CVOS study used an index of any 2 clock hrs of NVI/ANV as significant AS neoVAS which was found in 16% eyes with 10 to 29 disc areas of non perfusion
52% of eyes with 75 disc areas of non perfusion
BLOOD THUNDER Appearance
Residual findings include
Epiretinal membrane ,
Chronic CME
Disc collaterals are common
ERG : Reduction in 60% or < of normal mean b wave amplitude and the presence of RAPD (>0.70 log units)differentiate I/NI CVO
Used to treat the squeal of CVO esp NVG
Include:
Topical/systemic anti glaucoma
Topical steroids :decrease ant segment inflammation by stabilising the tight junctions
Cycloplegics:to prevent posterior synechae formation b/w iris and lens
CVOS study :widespread damage to perifoveal capillary network hypothesized to contribute to lack of visual recovery. CHORIORETINAL ANASTOMOSIS:b/w nasal bRV with choroidal circulation,surgicallyby trans retinal venipunture technique /laser energy delivered ,success in 10-54 %of perfused CVO
Complications : Immediate intra retinal/sub/fibrovascular proliferation vitreous haemorrhage
PARS PLANA vitrectomy:non clearing VH from 2 retinal NV
RADIAL OPTIC N:PPV + trans vitral incision of nasal scleral ring to release pressure at the level of scleral outlet,Radial incision given to avoid transecting nerve fibres,IO haemorrhage decreased by increasg IOP(73%improved)
BRVO always occur at AV crossings
CMO is the M/C cause of poor VA after BRVO
1.Flouresceine proven perfused macular edema involving the foveal centre
2.Absorption of IRH from foveal centre
3.Recent BRVO(3-18 months)
4 noDR
5 vision reduced to 20/40 or worse…………20-100 mild burns of 50-100 microns for 0.01 sec,laser absorption at RPE,no closer to fovea than d edge of capillaries freezon and no farther into the periphery than themajor vascular arcade….thinning…choroid supplies……autoregulatory constriction
Blocks a major branch of CRV at/near the optic disc or one trunk of the dual trunked CRV(congenital variant)
It is less common than both BRVO and CRVO and involves occlusion of the superior or inferior branch of the CRV.
SUPERFICAL RETINAL OPACIFICATION WITH CHERRY RED SPOT IN THE POSTERIOR POLE ALONG WITH dilated and tortuous veins ,haemorrhages, swollen optic disc ,thickening of retina in posterior pole
