2. FLUID CATALYTIC CRACKING
Fluid catalytic cracking is a catalytic conversion process for
converting heavy gas oil.
The fluid catalytic cracking is a low pressure, intermediate to high
temperature process.
This process can be achieved by two processing objective.
1 β Maximization of middle distillates.
2 β Maximization of LPG and gasoline.
3. TECHNOLOGICAL ASPECTS
FEEDSTOCK
Vacuum gas oil in the boiling range of 350-550 β°C is used in a FCC.
REACTIONS
Catalytic cracking reaction occurs with the formation of carbonium ion.
Reactivity order of carbonium ion formed β
Tertiary > secondary > primary > ethyl > methyl
Catalyst
Fine powder made up primarily of alumina and silica. The particle of this
powder are in the size range of 10-140 microns.
Currently two types of catalyst are significant β amorphous and zeolite.
4. MODELS USED FOR FCC
1 β ESSO model
2 β Kellog Otrthoflow model
3 β Kellog Orthoflow model F-converter with two-stage regeneration
Fluid Catalytic Cracking Process
Principle of operation
FCC process converts heavy gas oils into light hydrocarbon gases, high octane
gasoline and lower boiling gas oil components. This is accomplished by
cracking the vaporized feed over the catalyst at a temperature between 470 -540
β°C and a pressure between 0.5 β 1.5 kgf/cmΒ²g.
5.
6. PROCESS DISCRIPTION
The fresh feed preheated in a heat exchanger and is then heated up to
about 390 β°C in a fired heater. Hot regenerated catalyst mixes with
combined feed stream at the bottom of the riser.
The hydrocarbon are vapourized and also begin to crack. The catalyst
and vapour rises as dilute phase to reactor.
Catalytic cracking of hydrocarbon produces coke which is deposited
on the catalyst. This spent catalyst flows to the stripper where steam
removes hydrocarbon vapours from interstitial voids and spent
catalyst flows to the regenerator.
The catalyst is continuously regenerated in the regenerator by
combustion of coke with a controlled stream of air. The heat produced
by combustion of coke supply the heat necessary for balancing the
heat required to operate the unit.
7. The hot regenerated catalyst flow downward though the regenerated
catalyst standpipe to the reactor riser to complete the cycle.
Hydrocarbon vapours leaving the reactor at temperature between 470 -
540 β°C are send to the main fractionator.
The function of the fractionator is to cool and condense the incoming
hydrocarbon vapour and to separate the product. The product
withdrawn the main fractionator are: gas and naphtha, light and
heavy cycle oils and clarified oil.
8. TYPICAL OPERATING CONDITION
REACTOR TEMPERATURE 470-540
REGENERATOR TEMPERATURE 590-610
REACTOR PRESSURE(KPa) 232
REGENERATOR PRESSURE(KPa) 274
FRACTIONATOR PRESSURE(KPa) 225
