This document discusses biomimetic robots, which are robots that take inspiration from biological organisms in their structure, function, or mechanisms. It provides an overview of the history and development of biomimetic robots, examples of different types of biomimetic robots modeled after animals such as lobsters, snakes, fish, and insects, and applications of biomimetic robots in areas such as medical, rescue, and space exploration.

1. BIOMIMETIC ROBOTS Luke Chang & Yang Zhang

8. In this case, we can see that the scientist attempts to copy the structure of a worm (caterpillar), using soft materials and incorporating them into a new type of highly flexible robot. These robots will possibly have applications in biomedical diagnosis and surgery, emergency rescue and exploration, and for monitoring or repairing space vehicles.

9. What about more smaller ones? What if we could imitate the body structure and the behavior of small insects like mosquito or bee? We can use such robots in certain circumstance as tiny space where human and traditional robots can not work. Or they can be used in military affairs. They can perfectly finish a investigation task without alarming anyone. Moreover, they can also search for survivors after earthquake.

10. Fishlike Robot Fishlike robot is currently a very popular topic. Simulating the unique model of action of fishes, we can design a robot which can use fin and tail to generate vortex, it can swim like a fish in the water. We then could use these robots to do some special investigations underwater.

16. Control algorithm for the snakelike mechanism Interaction forces along the snakelike mechanisms in simultaneous contact with three push-points Curve fitting with three simultaneous contact points

17. Eight intermediary configurations with initial (1) and final (8) conditions of the mechanism for a given trajectory. Red points indicate the contacted push-points. (For interpretation of the references to color in this figure legend, the reader is referred to the web version of this article.

18. Structure

19. For sliding more smoothly, it has wheels instead of snake’s scales

20. Universal joint

21. Universal joint

22. Urban Search and Rescue With the highly flexible body structure of a snakelike robot, we are able to do some tough search when investigating or finding survivors. Applications

23. Or we can use such feature to inspect special interior structure (e.g. tank)

24. Combinations Add legs to a snakelike robot, then it can move with more flexible ways. Combining with a 4-wheels bracket, a snakelike Robot can do inspection more automatically. In water On ground

26. Any Question? END Thank you!
