1. HERNIAS
Presented by:
Sameh Shehata

2. References
NaJah m. N. RaSIKh

3. Definition
 A hernia is the
protrusion of an
organ through its
containing wall.

4. Composition of a hernia
1. The sac
2. The covering of
the sac
3. The content of the
sac

5. Composition of a hernia
1. The sac :
 It is a diverticulum
of peritoneum and
is made up of
three parts :
 The mouth,
 The neck and
 The body of the
sac.

6. Composition of a hernia
2. The covering:
 Coverings are derived from the layers of abdominal
wall through which the sac pass
3. Contents:
 can be
 Omentum = omentocle
 Intestine = enterocele
 Portion of circumference of intestine = Richter’s
hernia
 Portion of the bladder
 Ovary(with or without oviduct)
 Meckel’s diverteculum =Littre’s hernia

7. Etiology
 Hernias occur at sites of weakness in the wall
 This weakness may be :
 Normal (physiological) weakness, related
to the anatomical causes.
 Congenital abnormality.
 Acquired :
• Traumatic
• Diseases

8. Varieties
A hernia at any site may be:
1. Reducible
This is the one which the contents of the sac reduced
spontaneously or can be pushed back manually. A
reducible hernia imparts an expansile impulse on
coughing.
2. Irreducible
This one whose contents cannot be returned to the
peritoneal cavity either because there are:
 adhesions between the sac and contents, or
 because of the narrow neck of the sac.

9. Varieties
 Irreducible hernia can be :
1. Incarcerated: there are adhesions between the sac and
the contents, but there is no obstruction or interference
with blood supply. the hernia simply will not reduce
2. Obstructed: a hollow viscus is trapped within the sac and
obstruction occurs. The blood supply remains intact.
This is a common cause of small bowel obstruction.
3. Strangulated: the arterial blood supply to the contents of
the sac is compromised, in such a hernia unless surgical
relief is undertaken the contents of the sac will become
gangrenous.

11. Classification
A. External hernia
B. Internal hernia

12. Classification continue…
A. External hernia
Common hernia
 inguinal
 Femoral
 Umbilical
 incisional

13. Classification continue…
A. External hernia
Rare hernia
 Spigelian
 Gluteal
 Obturator
 lumbar

14. Some other hernias
 Spigelian hernia:
 This is a hernia through the linea semilunaris at the lateral
border of the rectus sheath.
 Littre's hernia:
 A hernia that contains a Meckel's diverticulum in the sac.
 Obturator hernia:
 This hernia occurs through the obturator foramen. It is
commoner in elderly females.
 Lumbar herniae:
 These occur in the lumbar region (below the 12th rib & above
the iliac crest).

15. Classification continue…
B. Internal hernia
Diaphragmatic hernia
 Esophogial hernia
 Paraesophogial
hernia

16. Signs and Symptoms
- A lump disappears, reappears, and enlarges on
straining and discomfort.
 Physical Signs:
 Reduced.
 + ve cough impulse.
 Investigation:
Hernia is diagnosed clinically. Investigations are
rarely indicated or valuable.

17. Management
 Treatment:
hernias should be operatively repaired both to relieve
symptoms and to eliminate the complications.
 Surgical techniques:
• Herniotomy: removal of sac and closure of its
neck.
• Herniorrhaphy: involves some sort of
reconstruction to:
• Restore the anatomy if this is disturbed.
• Increase the strength of the abdomenal wall.
• Construct a barrier to recurrence.

18. Inguinal hernia
 Epidemiology:
 Male : Female
• by 9 to 1 ratio
 young adults mostly
have indirect inguinal
hernia.
 As age of patient
increases, the incidence
of direct hernias
increases .

19. Inguinal hernia
 Risk factors:
( increases intra-abdominal pressure )
 Chronic cough.
 Constipation.
 Pregnancy.
 Straining at micturation.
 Severe muscular effort (lifting heavy
objects).
 Ascites - fluid may increase the size of an
existing sac.

20. Myopectineal Orifice of Fruchaud

21. Inguinal hernia
Inguinal Canal Anatomy
 Anterior wall:
 aponeurosis of external oblique
(along entire length),
 internal oblique on lateral one
third
 Posterior:
 fascia transversalis
 conjoint tendonon in medial
one third
 Roof:
 arching fibers of internal
oblique ,and
 transversus abdominis
 Floor (inferior):
 inguinal ligament, and
 lacunar ligamen at the medial
end

22. Inguinal hernia
Inguinal Canal Contents:
 Male:
 Spermatic cord structures:
• vas deferens,
• testicular artery
• testicular veins (pampiniform plexus),
• genital branch of genitofemoral nerve,
• artery of the vas deference,
• lymphatics,
• autonomic nerves,
• processus vaginalis.
• Ilio inguinal nerve
 Female:
 Round ligament of the uterus,
 genital branch of genitofemoral nerve,
 lymphatics,
 sympathetic plexus.

23. Inguinal hernia
Signs & symptoms:
 Bulge that enlarges when stand or strain, but often
asymptomatic.
 In general direct hernias produce fewer symptoms
than indirect hernias and are less likely to
complicate.
 On examination:
 Palpable defect or swelling may be present .
 Indirect Hernia usually bulge at Internal InguinalInternal Inguinal
Ring.Ring.
 Direct Hernia usually bulge at External InguinalExternal Inguinal
Ring.Ring.

24. Inguinal hernia
There are two types
of inguinal hernia:
 Direct inguinal
hernia
 Indirect inguinal
hernia

25. Differences between direct
and indirect hernias
1. Origin and coarse:
• Direct: Develops in the area of Hasselbach's triangle. The
origin is medially to the inferior epigastric vessels.
• Indirect: Develops at the internal ring. The origin is lateral
to the inferior epigastric artery.
1. Content:
1. Direct: Retroperitoneal fat. less commonly, peritoneal sac
containing bowel .
2. Indirect: Sac of peritoneum coming through internal ring,
through which omentum or bowel can enter.
2. Etiology:
• Direct: weakness of the posterior floor of the inguinal
canal (acquired).
• Indirect: patent processus vaginalis (Congenital) .

26. Differences between direct
and indirect hernias
 Boundaries of Hasselbach's
triangle:
 Medially: lateral border of
rectus abdominis.
 Laterally: inferior epigastric
vessels.
 Inferiorly: inguinal ligament.

27. Hesselbach’s Triangle

28. Inguinal hernia
 Both types (direct
and indirect inguinal
hernia) may occur at
the same time and
straddle the inferior
epigastric artery.
 This is called:
Pantaloon hernia

29. Inguinal hernia
Male inguinal hernia Female inguinal hernia

30. Indirect Inguinal hernia
Abdominal contents protrude through internal inguinal
ring

31. 31

32. Direct Inguinal Hernia

33. Inguinal hernia
 Complications:
 Irreducibility, but without signs of
obstruction or strangulation
 Small Bowel Obstruction, Usually
urgent surgical repair
 Strangulation, Surgical emergency
50% indirect, 3-10% direct.

34. Inguinal hernia
Management:
 Inguinal hernias should always be
repaired ( herniotomy, herniorrhaphy )
unless there are specific
contraindications.
 Types of operations:
1. a permanent sutures, as in Shouldice
repair (layered suture).
2. a permanent mesh -greater frequency to
decrease tension.

35. Inguinal hernia management
 Treatment of
aggravating factors
(chronic cough,
prostatic obstruction,
etc).
 Use of truss
(appliance to prevent
hernia from protruding)
when a patient refuses
operative repair or
when there are
absolute
contraindications to
operation

36. 36

37. Father of Modern Inguinal Hernia
Repair
EDUARDO BASSINI

38. 38
Herniotomy
Patent processus vaginalis ligated at
origin at internal ring (high ligation(
Nyhus type I
Children

39. 39
Bassini repair
Transversus abdominis aponeurosis +
transversalis fascia  inguinal ligament
with nonabsorbable interrupted sutures

40. 40
Shouldice repair
4rows of suture

41. 41
McVay repair
Inguinal and femoral hernias,
Transversus abdominis aponeurosis +
transversalis fascia  Cooper’s ligament
+ iliopubic tract

42. 42
Hernioplasty
High ligation, inverted sac + reinforce
defect with synthetic material
Tension-free
Lichtenstein
Recurrent rate 0.1%

43. Techniques
Suturing the mesh to the inguinal
ligament is not important.
Fixing the mesh to the rectus sheath
1-1.5cm medial and superior to the
pubic tubercle is very important.
Should have a surplus of mesh over
inguinal ligament, the medial suture
ensures surplus mesh inferiorly

44. Techniques
Coined by Liechtenstein in 1989
Central feature is polypropylene mesh
over unrepaired floor.
Gilbert repair uses a cone shaped
plug placed thru deep ring.
Slit placed in mesh for cord structures

45. Tension-Free Repair
Same initial approach as anterior
repair
Instead of sewing fascial layers
together to repair defect, a prosthetic
mesh onlay used
Simple to learn, easy to perform,
suited for local anesthesia, excellent
results with recurrence less than 4%.

48. Laparoscopic Procedures
Increasingly popular, controversial
Early in the development, hernias
were repaired by placing very large
mesh over entire inguinal region on
top of the peritoneum. Was
abandoned because of contact with
bowel.
Today, most performed TEP or TAPP

50. Laparoscopic Mesh Repair
Note:
Viewed from inside the
pelvis toward the direct
and indirect sites. A
broad portion of mesh is
stapled to span both
hernia defects. Staples
are not used in
proximity to
neurovascular
structures.

51. Laparoscopic Procedures
The argued advantage of these
procedures was less pain and
disability, faster return to work.
Great for bilateral hernia, with no
increase in morbidity.
For recurrent hernia
Disadvantages are cost, time.

52. Recurrence
Type of repair Recurrence
McVay 9%
Shouldice 7-11%
Liechtenstein 0-4%
Laparoscopic 0-1%

53. Femoral hernia
 The defect is in the
transversalis fascia
overlying the femoral ring at
the entry to the femoral
canal.
 The hernia passes through
the femoral canal and
presents in the groin, below
and lateral to the pubic
tubercle.
 It is more common in
females and carries a higher
risk of strangulation.
 Femoral canal-ant.by
inguinal ligament,post by
fascia over pectineus
muscle,lat. by femoral vein n
medial by lacunar ligament

54. Femoral hernia
Signs & symptoms:
 A lump occurs below and lateral to the
pubic tubercle. It may be reducible.
 It may not be noticed until it becomes
tender and painful.
 This type of hernia should be carefully
sought in the obese patient who
presents with signs of intestinal
obstruction without an obvious cause.
 DD’s-saphena varix,enlarged inguinal
LN,femoral artery aneurysm,rare
femoral abscess.

55. Femoral hernia

56. Femoral hernia
Surgical repair:
 An incision is made directly over the
swelling.
 The sac is opened and the contents
reduced and the sac removed.
 Femoral canal obliterated with 3
interrupted non absorbable suture.
 Treatment of strangulation or
obstruction, if present.
 There is no place for a truss in the
treatment of femoral hernia.

57. Anatomy
Inguinal ligament
(Poupart’s) – inferior edge
of external oblique
Lacunar ligament –
triangular extension of the
inguinal ligament before
its insertion upon the pubic
tubercle
conjoined tendon (5-10%)-
Internal oblique fuses with
transversus abdominis
aponeurosis
Cooper’s Ligament -
formed by the periosteum
and fascia along the
superior ramus of the
pubis.

58. Umbilical hernia
 This occurs in children
because of incomplete
closure of the umbilical
orifice.
 The majority close
spontaneously during
the first year of life.
 Surgical repair should
only be carried out if
the hernia has not
disappeared by the
age of 3 and the
fascial defect is greater
than 1.5cm in
diameter.

59. Para-Umbilical hernia
 It occurs just above or
just below the
umbilicus, and is more
common in obese
females.
 Predisposing factors
 multiple pregnancies
and
 obesity.

60. Para-Umbilical hernia
 The neck of the sac is usually narrow and
therefore there is a high risk of strangulation.
 The most common content is
 omentum ,then
 transverse colon and small intestine.
 Treatment: is by
 Contents of sac freed from it’s wall,excision of
the sac, and fascial defect repaired by
 Upper flap overlapping the lower,a two layer
overlapping repair thereby doubling the
strength of repair (Mayo repair)
 >4 cm,recurrent-polypropylene mesh

62. Epigastric hernia
 This is usually a
small protrusion
through the linea
Alba in the upper
part of the
abdomen.
 It consists of :
 extraperitoneal fat
only, but
 May contain
omentum or small
bowel.

63. Epigastric hernia
 It may be extremely painful,
probably because of trapping and
ischaemia of extraperitoneal fat.
 Treatment
 is by enlaging the defect,excising the
fat, simple suture of the defect with
non-absorbable sutures .
>4 cm propylene mesh placed
retromuscular plane

64. Incisional hernia
 This occurs
through a defect
in the scar of a
previous
abdominal
incision.

65. Incisional hernia
 Etiology :
 Age: Wound healing is poor in the older patient.
 Obesity.
 Postoperative wound infection.
 Postoperative wound haematoma.
 Raised intra-abdominal pressure postoperatively,
e.g. coughing, straining, constipation, ileus.
 Steroid therapy.
 Type of incision: Midline vertical wounds have a
higher incidence than transverse incisions.
 Poor suturing technique: Rarely does a suture break

66. Incisional hernia
 Sign & symptoms :
 A swelling protrudes through the wound.
 It May occur up to 5 years postoperatively.
 Many are large and involve the whole incision and
consequently the neck of the sac is wide and the risk of
strangulation rare.
 If the defect is small there is a greater risk of
strangulation .
 Treatment-palliative-abd.belt
 - preoperative measures-reduce weight,treat
cough,improve nutritional status.stop smoking.
 -surgery:excision of sac,identification n apposition,
 -large hernia-poly propylene mesh,

67. Richter’s hernia
 Part of the wall of
the intestine
becomes trapped
in the defect.
 This is usually the
antimesenteric
border of the small
bowel.
 The lumen is
intact
( no obstruction )

68. Diaphragmatic hernia
 Traumatic:
rare and followed by injuries to chest and
abdomen.
The Lt diaphragm is affected more than Rt
and is accompanied by herniation of
stomach and spleen.
 Hiatus:
1. Sliding.
2. Para-esophegial.

69. Diaphragmatic hernia
 Sliding:
 in which the
gastroesophogeal
junction itself
slides through the
defect into the
chest.

70. Diaphragmatic hernia
 Para-esophageal
 in which the junction
remains fixed while
another portion of the
stomach moves up
through the defect.
 This can be
dangerous as they
may allow the
stomach to rotate and
obstruct.

71. Hiatus hernia
