1. Intro To Basic Anatomy
Kinesiotherapy Clinical Training

2. BASIC ANATOMY
Organization of the Body – Direction & Planes
• Anatomical position - body stands erect with
the arms at the sides, palms facing forward
• All body movements and location of anatomical
structures are referenced from this position
Basic Anatomy 2

3. Basic Anatomical Positions and Directions
• Inferior – toward the bottom
• Superior – toward the top
• Anterior – toward the front
• Posterior – toward the back
• Medial – toward the midline
• Lateral – away from the midline
• Proximal – closest to the trunk
• Distal – positioned away from the trunk
• Prone – lying face downward
• Supine – lying face upward
Basic Anatomy 3

4. • The body is divided into 3 imaginary planes of reference
• Sagittal plane – divides the body into right
and left sides
• Coronal (frontal plane) – divides the body
into front and back sections
• Transverse (horizontal) plane – divides the
body into top and bottom sections
• To determine the plane in which a
movement occurs, follow the bisecting line.
• Movements of flexion and extension
generally occur in the sagittal plane
• Movements of abduction and adduction
generally occur in the coronal plane
• Movement of rotation generally occur in the transverse plane
Basic Anatomy 4

5. Skeletal System
• Composed of bones (206), ligaments, and joints
• Main supportive structure of the body
• Axial Skeleton - skull, vertebral column, ribs, sternum, and hyoid bone
• Appendicular Skeleton – upper extremity (scapula, shoulder, arm and hand);
lower extremity (hip, femur, tibia, fibula, foot)
Articular System
• Articulation – a place of union between two or more bones, regardless of the
degree of movement permitted
• Ligaments – attach one bone to another
• Hyaline Cartilage – flexible connective tissue made up of collagen fibers that
line the bones of most joints, aids in smooth articulation of the joint
• Joints – articulating structures within the skeletal system; most serve the
purpose of bearing weight and providing motion
Basic Anatomy 5

6. Basic Body Joints
• Shoulder girdle – scapula, clavicle
• Shoulder joint – scapula (glenoid fossa), humerus
• Elbow joint – humerus, radius, ulna
• Wrist joint – radius, ulna, carpal bones
• Vertebral column – facet joints of the vertebrae, body-to-body via discs
• Hip joint – pelvis (acetabulum), femur
• Knee joint – femur, tibia, fibula
• Ankle joint – tibia, fibula, talus
Basic Anatomy 6

7. Basic Joint Movements
• Abduction – movement away from the body midline
• Adduction – movement toward the body midline
• Flexion – decreased angle between 2 structures
• Extension – increased angle between 2 structures
• Medial (internal) rotation – rotation of the vertical axis of a bone toward
the body midline
• Lateral (external) rotation – rotation of the vertical axis of a bone away
from the midline
• Circumduction - complete circular movement at the joint
• Pronation – medial rotation of the forearm (palms down position)
• Supination – lateral rotation of the forearm (palms up position)
• Plantar flexion – moving the foot downward , away from the shin
• Dorsiflexion – moving the foot upward, toward the shin
Basic Anatomy 7

8. Basic Joint Movements
• Shoulder horizontal abduction – moving the humerus across the body away
from the midline
• Shoulder horizontal adduction – moving the humerus across the body
toward the midline
• Scapular elevation – upward scapula movement (shrugging)
• Scapular depression – downward scapula movement
• Scapular abduction – scapular movement away from the spine
• Scapular adduction – scapular movement toward the spine
• Trunk flexion – anterior movement of the torso toward the pelvis
• Trunk extension – posterior movement of the torso toward the pelvis
• Foot eversion (pronation)– moving the sole of the foot outward at the ankle
• Foot inversion (supination)– moving the sole of the foot inward at the ankle
Basic Anatomy 8

9. Muscular System
• Muscles:
• compose 40-60% of body weight
• provide an important mechanism for maintaining joint stability
• Body movements occur as a result of muscle contractions pulling one bony
structure toward another
• Skeletal movement occurs at the joint structures within the body
• Three types of muscle tissue:
• Cardiac – involuntary (cannot be influenced at will)
• Smooth – involuntary
• Skeletal/Striated – voluntary
§ made up of long slender cells (fibers), with length greater than width
§ control body movements and maintain posture.
Basic Anatomy 9

10. Muscular System
• Musculoskeletal System – the skeletal and muscular systems working in
concert to provide body stabilization and movement
• Skeletal movement occurs at the joint structures within the body
• Tendon
• Indirect attachment of muscle to bone
• Distal structures of a muscle that transmits the force of the muscle contraction to bone
• Tendon attachments
• Origin – attachment closest to the body midline or axial skeleton
• Generally the fixed portion that provides a stable base during muscle contraction
• Insertion – attachment farthest from the body midline or axial skeleton
• Is drawn toward the origin during muscle contraction
Basic Anatomy 10

11.
Muscular System
• Muscles that control joint movements are aligned as agonists and antagonists
• Agonist – the muscle that causes a movement to occur (ex. biceps brachii
muscle flexes the elbow joint)
• Antagonist – the muscle that directly opposes an agonist muscle action (ex.
triceps brachii extends the elbow joint; must relax for elbow flexion to
occur)
• Reciprocal Inhibition – when an agonist contracts, the antagonist muscle must
relax
• Reciprocal inhibition allows joint movement to occur
• If this does not occur, then tetanus (a state of sustained contraction during
which the muscle does not relax to its initial length or tension) results in no
movement
Basic Anatomy 11

12. Muscular System
• Stabilizers – muscles that contract statically in one joint, so that movement
in an adjacent joint can occur
• Example – During walking or running, the hip abductor muscles of the
weight bearing limb contract to stabilize the pelvis so that it does not
drop to the non-weight bearing side
• Synergists – muscles that contract to eliminate an undesired joint action
in another muscle; can also be called "neutralizers" because they help
cancel out, or neutralize, extra motion from the prime mover
• Example – when the gluteus maximus contracts during hip extension, it
also attempts to externally rotate the hip; gluteus minimus and the
tensor fasciae lata contract to neutralize this movement
Basic Anatomy 12

13. Muscular System
• Strain –an over stretch or tear of a muscle or tendon
• Acute (instant or recent) strain of the musculo-tendinous structure
occurs at the junction where the muscle transitions into a tendon
• Occur when a muscle over-stretches or over-contracts, as with running or
jumping
• Symptoms may include pain, muscle spasm, loss of strength, and limited
range of motion
• Chronic (long-lasting) strains occur over time, from overuse or
repetitive stress, resulting in tendinitis (inflammation of a tendon)
• Example: tendinitis in the shoulder as the result of constant stress from
repeated tennis serves
Basic Anatomy 13

14. Muscular System
• Sprain –the over stretch or tear of a ligament or a joint capsule
• Sprains occur when a joint is forced beyond its normal range of motion,
such as turning or rolling the ankle
• Symptoms may include pain, inflammation, bruising and in some cases,
the inability to move a limb
• Sprains (ligament) and strains (muscle or tendon) are categorized according
to severity
• Grade I (mild) - involves a minor over stretch or minor tear
• Grade II (moderate) - partially torn but still intact
• Grade III (severe) – a complete tear; can result in joint instability
Basic Anatomy 14

15. Muscular System
• Hypertrophy – an increase in the cross-sectional size of a muscle fiber
(cell)
• Atrophy – the wasting or reduction of size of muscle, tissues, organs, etc
• Myalgia – muscle pain
• Myositis – inflammation of a muscle
• Fibrositis – inflammation of connective tissue within a muscle
• Tendonitis –inflammation of the tendon
• Fasciculation(muscle twitch) - small, local, involuntary muscle contraction
and relaxation visible under the skin
• Myoclonus - brief, involuntary twitching of a muscle or a group of muscles
• Spasm - a sudden involuntary contraction of a muscle, or a group of
muscles
Basic Anatomy 15

16. Muscle Contraction
• Muscle contraction – strength of contraction depends on the number of
motor units activated, stimulation frequency of the motor units, muscle
fiber length, and speed of contraction
• Types of Contraction
• Isometric (static)- muscle tension develops with no change in muscle length
and no joint movement; ex. carrying a heavy object
• Isotonic (dynamic) – muscle tension remains constant, muscle length changes
and movement occurs; contraction can be concentric or eccentric
• Concentric - force generated is sufficient to overcome the resistance, and the
muscle shortens as it contracts; this is what most people think of as a muscle
contraction
• Eccentric – the muscle lengthens as it develops tension, and contracts to control
motion against an external resistance; ex. lowering a load gently rather than
letting it drop
Basic Anatomy 16

17. Muscle Fibers
• Skeletal muscle contains a combination of fiber types that are classified as:
• Slow Twitch or Type 1
• Fast Twitch or Type IIa
• Fast Twitch or Type IIx
• Type I (slow twitch) fibers use oxidative metabolism
• Appear red due to the high concentration of myoglobin
• Generate a low level of muscle tension
• Have slow contraction times, are well suited for prolonged, low
intensity work
• Endurance athletes generally have a high quantity of slow-twitch fibers
Basic Anatomy 17

18. Muscle Fibers
• Type IIa (fast twitch) use oxidative and glycolytic metabolism
• Type IIa are also red
• An intermediate fast twitch fiber
• Tend to contract with a burst of force, then fatigue
• Can sustain activity for moderate lengths of time at higher intensities
• Examples - Type IIa fibers would be advantageous in gymnastics and
rowing
• Type IIx (fast twitch) use oxidative and glycolytic metabolism
• Type IIx appear white (absence of myoglobin)
• Provide rapid force production, but then fatigue quickly
• Provides greatest potential for power movements that rely on maximal
efforts
• Examples - sprinters, jumpers, shot putters, and Olympic weight
lifters benefit from Type IIx fibers
Basic Anatomy 18

19. Muscle Fibers
• Each muscle contains a combination of all three fiber types
• Percentage of fiber distribution varies considerably from muscle to muscle,
and person to person
• Distribution/proportion of fiber types in a given muscle determines that
muscle’s performance capabilities
• Fiber distribution influences how the muscle responds to training, and
ultimately how it develops
• The mode of training application will not alter a person’s fiber distribution;
however specific fibers within the distribution are enhanced by the type of
stimulus applied to the muscle
Basic Anatomy 19

20. Muscle Fibers
• When performing a series of repetitions during a resistance exercise
movement (such as a barbell curl) the slow twitch fibers are recruited first
• As the repetitions progress, and the effort becomes more intensive, more
fast twitch fibers are recruited
Basic Anatomy 20

21. Nervous System
• Group of tissue composed of highly specialized cells possessing the
characteristics of excitability and conductivity
• Regulates all functions related to human movement, as well as other bodily
functions
• Two types of cells
• Neuroglia – function in supportive, reparative, and metabolic
capacities
• Neurons – basic unit of the nervous system which conducts an
electrical impulse from one part of the body to another
• Two types of processes on each neuron:
• Axon - carries impulse away from the cell body
• Dendrites - carry impulse toward the cell body
Basic Anatomy 21

22.
Nervous System
• Neurons (cont.)
• Two types of functions:
• Afferent (sensory) – convey impulses from receptor cells in the
skin , tissues, or other organs to the spinal cord and brain
• Efferent (motor) - carry impulses from the spinal cord and
brain to effector cells (muscle fibers)
• Major Branches of the Nervous System
• Central Nervous System (CNS) – brain and spinal cord
• Peripheral Nervous System (PNS) – cranial and spinal nerves
• Autonomic Nervous System (ANS) – portions of the CNS and
peripheral nervous system, regulates organ function, blood flow, and
other involuntary functions
Basic Anatomy 22

23.
Nervous System
Basic Anatomy 23

24.
Central Nervous System
• Brain – largest mass of nervous tissue in the body, located in skull
• Cerebrum - largest portion of the brain which contains nerve centers
governing all sensory and motor activities
• Partially divided by median longitudinal fissure into two
hemispheres
• Each hemisphere divided by fissures into four major lobes: frontal,
parietal, occipital, temporal
• Cerebellum – occupies the posterior cranial fossa and consists of three
lobes
• Anterior: controls posture
• Posterior: controls coordination and movement
• Flocculonodular: controls equilibrium
Basic Anatomy 24

25.
Central Nervous System
• Spinal Cord – contains all ascending (afferent) and descending (efferent)
fiber tracts connecting PNS and ANS, and brain
• Anterior gray matter contains cell bodies from which efferent (motor)
fibers of the spinal nerves arise
• Posterior gray contains cell bodies from which afferent (sensory) fibers
pass toward brain
Basic Anatomy 25

26. Peripheral Nervous System
• Cranial Nerves – 12 pairs of symmetrically arranged nerves attached to the
brain
Basic Anatomy 26

27.
Peripheral Nervous System
• Spinal Nerves – 31 pairs:
• 8 cervical
• 12 thoracic
• 5 lumbar
• 5 sacral
• 1 coccygeal
• Four plexuses:
• cervical (C-1,2,3,4)
• brachial (C5,6,7,8,&T1)
• lumbar (L1,2,3,4)
• sacral (L4,5,S1,2,3)
Basic Anatomy 27

28. Dermatomes
• An area of skin
supplied by one pair
of spinal nerves
Basic Anatomy 28

29. Reflexes
• Reflex – an involuntary and nearly instantaneous movement in response to
a sensory stimulus
• Can be superficial (cutaneous stimulation), deep (tendon or
vascular tissue stimulation), visceral (organs), or pathologic
(abnormal)
• Generally serve to protect the body
• Indirect reflex arc – sensory impulse that is processed by a mediating or
internuncial neuron before being passed on to an anterior motor neuron
• Most reflexes are this type
• Example: receptors detect tension applied to a tendon by muscle
contraction; reflex arc results in inhibition of further contraction
Basic Anatomy 29

30. Reflexes
• Direct Reflex Arc – sensory impulse that passes directly to the anterior
motor neuron
• Monosynaptic (i.e. only one sensory and one motor neuron is
involved)
• Example: stretch or myotatic reflex
• Most important and prominent
• Leads to contraction of the muscle
• Prevents overstretching of the muscle
• Ex. knee jerk (stimulation of patellar tendon)
Basic Anatomy 30

31. Autonomic Nervous System
• Controls the visceral functions of the body
• Generally considered to be involuntary
• Links the control centers of the brain with the effector organs
• Overall function is to maintain homeostasis of the internal environment and
provide the “fight or flight” response
• Divided into the sympathetic and parasympathetic nervous divisions
• Sympathetic – more primitive, constricts blood vessels, involved in
“fight or flight”, stimulates activity
• Parasympathetic – more advanced, acts principally on smooth muscles
and glands in the gut, concerned with restorative processes, inhibits
activity
Basic Anatomy 31

32. BASIC ANATOMY
• Suggested Readings :
• 1. Jacob, SW and Francone, CA, Structure and Function in Man. W.B
Saunders, 5th Ed. 1982
Basic Anatomy 32
