1. MINERAL RESERVES
ESTIMATION BY USING
TRIANGULAR METHOD
BY
MD.NUMAN HOSSAIN
DEPT. OF PME ,SUST.

2. MINERAL RESERVES :
• A Mineral Reserve is the economically mineable part of a Measured and/or
Indicated Mineral Resource.
• It is described as total workable or probable working which depending on
thickness of deposit , it’s depth , quality , geological factors etc.
• In general mining practice , there are two types of mineral reserves .
• These are: (1) probable reserve & (2)proven reserves

3. :Proven Reserves Probable reserves
Proven reserves constitute mining assets with
greater confidence than any other mining assets
In other word , reserves in fully explored deposits
Probable reserves constitute mining assets with
lesser confidence than the proven reserves
In other word , reserves in estimated and fully
explored deposits
Mineral recovery :
 In mining , the process of valuable mineral extraction in known as mineral recovery
 It is the measure of mining or extraction efficiency
 For mineral recovery it is very essential to estimate ore reserves,know the mineable reserves ,
pit limits , cutoff grade etc .
 In this slide we will discuss only about different methods for estimating ore reserves.

4. Methods of ore reserves estimation
Triangular method
Polygonal methods
Method of sections (plans); longitudinal, transverse
Regular grid, random stratified grid
Inverse distance weighting (1/d, 1/d2, 1/d2.7, 1/d3, etc.)
Contouring methods
Here we only discuss about triangular method to estimate ore reserves.

5. Triangular method
By using triangular method, the area of the ore body is calculated
After that , this calculated area is multiplied with average thickness of the ore to
calculate the volume of the ore body
The average thickness can be calculated by
 Using known thickness of the ore body
 Using grade and the length of ore body
 Using weight age average thickness
After calculating volume , multiplying this value with ore density to estimate the
ore reserves.

7. • Here ,the area of the rectangle abcd = ( X3 – X2) (Y3 –Y1)
• Area of triangle A1 = ½ ( X2 - X1)(Y2-Y1)
• Area of triangle A2= ½ (X3 –X2) (Y3 –Y1)
• Area of triangle A3= ½ (X3 –X1)(Y3 –Y2)
• So the area of ore A = area of rectangle abcd – area of triangle (A1+A2+A3)

8. Calculate A for the following
Easting ( x )m northing (y) m
1100 1200
1500 1200
1100 800

9. Triangular method
• Using above equation
• The area of rectangle =(1100-1500)(800-1200)=160000 m2
• The area of triangle A1+A2+A3 = 1/2 (( 1500-1100)(1200-1200)+(1500-1100)(1200-
800)+(1100-1100)(800-1200)) =80000 m2
• The area of ore body ,A=160000-80000=80000 m2

10. Calculation of average thickness of the ore
body:
1. If thickness is givenC1= 3 m, C2=5 m,C3= 4 m , then ave. thickness =(C1+C2+C3)/3
=(3+5+4)/3 =4 m
2. If the length of the ore body (m) and the gradient(%) is given then the ave. thickness
is calculated by t(ave) = ∑tigi / ∑gi , for example we calculate ave thickness for
following case :
ymbol

11. The ave thickness , t(ave) =(0.6*0.59+1.4*0.48+1.4*0.6+1.4*0.56+1.3*0.32)/(0.59+0.48+0.6+0.56+0.32)
=0.503 m
3.calculation of reserves using weight age average thickness . For this case the following equ is used:
weight age ave. thickness, tw =( (t1Ѳ1+t2Ѳ2+t3Ѳ3)/60 )÷3 = (t1Ѳ1+t2Ѳ2+t3Ѳ3)/ 180 .an example
problem related with this is given bellow : where thickness t1=40 m, t2 =60 m ,t3 =50 m.
Length of the ore body (m) grade(%)
0.6 0.59
1.4 0.48
1.4 0.6
1.4 0.56
1.3 0.32

13. Now, ore volume calculation:
• Ore volume = area of the ore body * average thickness
• For , first case, t(ave)=4 m, so, ore volume = 80000*4 =320000 m3
• For , second case , using length of the ore body and grade, ave thickness = 0.503
So, for this ore volume = 80000*.503 =40240 m3
• For third case, weight age ave thickness , tw =50.77 m then ,
ore volume = 80000*50.77 =4061600 m3
N.B.here, I use one example problem for several ave thickness ,so don’t be confused with
evaluated ore volume .This indicates just calculation procedure . Here, the ave thickness
data had not been obtained from same ore reserve but I use here only to show the
evaluation procedure ,and so, ore volume can’t be obtained same for all time.

14. Ore reserve estimation:
• Ore reserve(in tons) =ore volume(m3) * density of ore (tons/m3)
• For example ,if the density of the ore = 1.35 tons/m3.
• Then ,for 1st case, ore reserves =320000*1.35 =432000 tons.
• For 2nd case, ore reserves = 40240*1.35 =54324 tons.
• For 3rd case, ore reserves =4061600*1.35 =5483160 tons.

15. Exercise Problem :
• For 1st fig the following parameters are given for a ore deposit :
• If the thickness for first layer C1=4 m, C2=8m ,C3=3m and for 2nd layer
C1=5m,C2=7m,C3=6m .And the density of the ore is 2.5 tons/m3 .Then estimate the
reserves for this ore deposit.
Easting (x) m Northing (y) m
300 700
600 300
100 0

16. Exercise Problem :
• Estimate the reserves by using triangular method for the following mineral
deposit(having density =1.024 tons/m3:
Length of ore body (m) grade (%)
.9 .62
1.2 .56
1.2 .61
1.8 .49
2.1 .68
2.8 .65
2.8 .61
2.5 .57
2.2 .52
1.9 .48
x (m) y(m)
3500 600
1365 450
350 46
N.B. use fig :1

17. Exercise Problem : Ѳ2
Ѳ1
Ѳ3
t3(800,1000)
t1(200,500)
t2(600,1500)
Calculate the reserve of the ore shown in above fig having density 2.65 tons/m3 by using the weight
average thickness , when t1=80 m, t2 = 125 m, t3 = 98 m.

18. Exercise Problem
• Calculate the reserve of the ore shown in above fig having density 2.65 tons/m3 by
using the weight average thickness where others information has give
