This document provides an overview of topics related to bioelectronic systems and biomedical robotics. It lists 10 promising technologies assisting the future of medicine, including health sensors, artificial intelligence, the end of human experiments, augmented reality, and rehabilitation robots. It then discusses what robotics is, defines a robot, and covers various robot classifications. The document outlines the main problems in robotics like forward and inverse kinematics, velocity kinematics, path planning, vision, dynamics, position control, and force control. It provides references for general robotics, biomedical robotics, textbooks, project guides, conferences, and readings. Finally, it shares the syllabus and coursework details for an introduction biomedical robotics lecture course.
