2. Basic Principles of Control Systems
Basic functions & definitions
On/Off control
Modulation control
Principle of closed loop control
PID control modes
Exercises - #2 & #3
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
3. Definitions
PV (Process Variable) - Variable we want to control.
MV (Manipulated Variable) – Variable to manipulate(to control the PV)
Simple controllers – OP – controller output signal
SP(Set Point Value) – Target / Ideal Process Variable
Disturbances
Other random inputs to the process may be measured and predicted
Hysteresis
Output reaction delays to a stimulus response based on direction of approach
Multivariate
Systems based on more than one PV may also have more than one
MV (OP)
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
4. On/Off Control
Good where fluctuations of PV are acceptable
Wear/tear of controlling element is a problem
Increase band of PV to reduce switching action
Output of controller is a digital signal
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
5. Response of a Two Positional Controller
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
6. Simple on/off Control
Enables a very simple form of temperature control
Common form is a domestic gas-fired heater
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
7. Modulating Control
Output of the controller is an analog value
Not digital value as in on/off control
Can be used in open or closed loop control
Use when more precise control of PV required
Less hysteresis (band) of PV variation
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
8. Open Loop Control
Control action is not a direct function of PV
No self-correction when the PV drifts
Allows pre-emptive reaction to disturbance
Control is based on measured disturbances
(E.g. Feedforward control)
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
9. Simple Process Block
PV changes are a function of the control action
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
10. Open Loop Control
Control Action = Position of Accelerator
Control result = Speed of Car
BUT: Speed could vary with changing load
Identify – Disturbances, PV, MV
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
11. Feedforward Control
Form of Open loop control
Value to be controlled (PV) is not used to calculate the
control action
Basic principle is:
Manipulate a variable of the process block so that it
compensates for impact of any input disturbances.
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
15. Feedforward Control
Objective is to keep level constant
Manipulated variable = inlet valve position
Control strategy: Inlet flow = Outlet flow
If Feedforward control is the only control
PV will drift over time
Because of:
Natural Evaporation
Delay in valve positioning etc.
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
16. Feed Heater Example - Analyze Components
Control object -
constant outlet
temperature
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
17. Closed Loop PID
Closed loop Control strategy
Measure PV
Compare PV with SP (ERR)
Calculate OP
Closed Loop PID has 3 Modes:
Proportional Control
React to the amount of ERR
Integral Control
Eliminate residual ERR
Derivative Control
Correct dynamic stability
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
18. Direct or Reverse Controllers
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
19. Manual Feedback Control
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
20. Closed Loop Block Diagram
PV is now part of the control action
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
21. Feedforward and Feedback Combination
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
22. Process Response Curve
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
23. Sample and Hold Algorithms
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
24. Process Response
Response process gain
ratio of the change in the process variable to the change in the
manipulated variable.
Response dead time
Response process lag
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
25. Process Response
Example: Process response related to a step change of the input value
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
26. DO YOU WANT TO KNOW MORE?
If you are interested in further training or information,
please visit:
http://idc-online.com/slideshare
www.idc-online.com/slideshare Technology TTrraaiinniinngg tthhaatt WWoorrkkss
