The document describes an extension kit called the NM310 that adds nonlinear measurement capabilities to Rohde & Schwarz Vector Network Analyzers (VNAs) like the ZVA and ZVT models. The kit allows characterization of RF/HF components from 20 MHz to 24 GHz by measuring their harmonic behavior and response in both the time and frequency domains. Key benefits include full harmonic characterization, measurement of voltages and currents under realistic non-50 ohm conditions, and improved transistor modeling from small-signal to large-signal operation. The NM310 kit works with ICE software to enable complex nonlinear measurements and characterization of devices like diodes, transistors, and amplifiers.
Differential structures such as backplanes and cables are the primary means for transmitting high speed serial data signals. Signal integrity of these systems is determined by the characteristics of the media such as insertion loss, crosstalk, and differential to common mode conversion.
Complete measurement of the mixed mode s-parameters is often performed by transforming single-ended s-parameters and assuming that the system is linear. In some cases, linearity cannot be assumed such as where active components are used.
This presentation describes how to measure true differential s-parameters which can be measured even in the presence of non-linear elements.
As a communication engineer our princple interest is signal and their measuring instrument; Thus Spectrum Analyzer is an instrument which graphically provides the energy distribution of a signal as a function of the frequency on its CRT.
The spectrum analyzer provides information about all these things, by displaying the signal in the frequency domain.
The measurement of dominant frequencies and their responses.
The component levels and energy strength
Frequency stability
Bandwidth and Spectral purity
Modulation index and attenuation
Harmonic and intermodulation distortion
Various signal generation and so on
Which is not easy to measure at time domain
Differential structures such as backplanes and cables are the primary means for transmitting high speed serial data signals. Signal integrity of these systems is determined by the characteristics of the media such as insertion loss, crosstalk, and differential to common mode conversion.
Complete measurement of the mixed mode s-parameters is often performed by transforming single-ended s-parameters and assuming that the system is linear. In some cases, linearity cannot be assumed such as where active components are used.
This presentation describes how to measure true differential s-parameters which can be measured even in the presence of non-linear elements.
As a communication engineer our princple interest is signal and their measuring instrument; Thus Spectrum Analyzer is an instrument which graphically provides the energy distribution of a signal as a function of the frequency on its CRT.
The spectrum analyzer provides information about all these things, by displaying the signal in the frequency domain.
The measurement of dominant frequencies and their responses.
The component levels and energy strength
Frequency stability
Bandwidth and Spectral purity
Modulation index and attenuation
Harmonic and intermodulation distortion
Various signal generation and so on
Which is not easy to measure at time domain
digital down-converter (DDC) converts a digitized real signal centered at an intermediate frequency (IF) to a basebanded complex signal centered at zero frequency. In addition to downconversion
Access the video from this presentation for free from
http://www.rohde-schwarz-usa.com/DebuggingEMISS_On-Demand.html
Overview:
Electromagnetic interference is increasingly becoming a problem in complex systems that must interoperate in both digital and RF domains. When failures due to EMI occur it is often difficult to track down the sources of such failures using standard test receivers and spectrum analyzers. The unique ability of real-time spectrum analysis and synchronous time domain signal acquisition to capture transient events can quickly reveals details about the sources of EMI.
What You Will Learn:
How to isolate and analyze sources of EMI using an oscilloscope
Measurement considerations for correlating time and frequency domains
Near field probing basics
Presented By:
Dave Rishavy, Product Manager Oscilloscopes, Rohde & Schwarz
Dave Rishavy has a BS in Electrical Engineering from Florida State University and an MBA from the University of Colorado. Prior to joining Rohde and Schwarz, Mr. Rishavy gained over 15 years of experience in the test and measurement field at Agilent Technologies. This included positions in a wide range of technical marketing areas such as application engineering, product marketing, marketing management and strategic product planning. While at Agilent, Dave led the marketing and industry segment teams for the Infiniium line of oscilloscopes as well as high end logic analysis.
Join us for a LIVE WEBINAR on this topic! Wednesday, November 14, 2:00pm ET
http://bit.ly/XPgjO7
Wide bandwidth modulation is becoming more common in communications. The emergence of the 802.11ac wireless Ethernet standard has extended the modulation bandwidth to 160 MHz which requires very wide band measurement equipment to measure. This presentation illustrates the details of a measurement method that uses a real time digital down converter and post processing software that measures the performance of this signal.
(Slides from Live webinar on September 25, 2014, presented by Mike Schnecker. Watch the webinar On-Demand here: http://goo.gl/LkjUUg)
Attendees Will Learn:
An overview of switched mode power supplies
Common measurements (ie, what to measure and why)
Circuit loading and probing considerations
How instrument specifications impact measurement accuracy
Switched mode power supplies have become ubiquitous in electronics as they provide precise voltages including high power with very high efficiency. The efficiency of these power supplies requires low loss power transistors and the design requires measurement of highly dynamic voltages. Voltage levels can vary from millivolts to hundreds of volts in some applications.
In this webinar, the proper use of a digital oscilloscope to accurately measure these voltages will be discussed along with key aspects of instrument performance such as noise and overdrive recovery that affect the accuracy of the measurement.
The USB 2.0 standard is widely deployed in both computer and embedded systems. Compliance testing for this standard includes signal integrity as well as a number of low-level protocol tests.
This presentation provides an overview of the test requirements for USB 2.0 compliance and provide background on each test case. Details of fixtures and signal integrity requirements are highlighted in detail.
For more information visit http://rohde-schwarz-scopes.com or call (888) 837-8772 to speak to a local Rohde & Schwarz expert.
Design of all digital phase locked loop (d pll) with fast acquisition timeeSAT Journals
Abstract
A Digital PLL is designed with improved acquisition time and power efficiency. The implemented D-PLL can operate
from 6.54MHz to 105MHz with a power dissipation of is 7.763μW (at 210MHz) with 1.2V supply voltage. The D-PLL is
synthesized using cadence RTL compiler in 45nm CMOS process technology.
Keywords: Digital PLL, Digital Phase/Frequency detector, NCO, Divide by N counter.
60 GHz mixed signal active load pull for millimeter wave devices characteriza...Luca Galatro
Master thesis presentation held on 16-05-2012. In this work a prototipe for a mm-wave mixed signal active load pull working in the frequency range from 50 to 65 GHz is presented. Further work has been accomplished on the topic, and a final version of the measurement setup has been presented at 81st and 83rd ARFTG conferences.
digital down-converter (DDC) converts a digitized real signal centered at an intermediate frequency (IF) to a basebanded complex signal centered at zero frequency. In addition to downconversion
Access the video from this presentation for free from
http://www.rohde-schwarz-usa.com/DebuggingEMISS_On-Demand.html
Overview:
Electromagnetic interference is increasingly becoming a problem in complex systems that must interoperate in both digital and RF domains. When failures due to EMI occur it is often difficult to track down the sources of such failures using standard test receivers and spectrum analyzers. The unique ability of real-time spectrum analysis and synchronous time domain signal acquisition to capture transient events can quickly reveals details about the sources of EMI.
What You Will Learn:
How to isolate and analyze sources of EMI using an oscilloscope
Measurement considerations for correlating time and frequency domains
Near field probing basics
Presented By:
Dave Rishavy, Product Manager Oscilloscopes, Rohde & Schwarz
Dave Rishavy has a BS in Electrical Engineering from Florida State University and an MBA from the University of Colorado. Prior to joining Rohde and Schwarz, Mr. Rishavy gained over 15 years of experience in the test and measurement field at Agilent Technologies. This included positions in a wide range of technical marketing areas such as application engineering, product marketing, marketing management and strategic product planning. While at Agilent, Dave led the marketing and industry segment teams for the Infiniium line of oscilloscopes as well as high end logic analysis.
Join us for a LIVE WEBINAR on this topic! Wednesday, November 14, 2:00pm ET
http://bit.ly/XPgjO7
Wide bandwidth modulation is becoming more common in communications. The emergence of the 802.11ac wireless Ethernet standard has extended the modulation bandwidth to 160 MHz which requires very wide band measurement equipment to measure. This presentation illustrates the details of a measurement method that uses a real time digital down converter and post processing software that measures the performance of this signal.
(Slides from Live webinar on September 25, 2014, presented by Mike Schnecker. Watch the webinar On-Demand here: http://goo.gl/LkjUUg)
Attendees Will Learn:
An overview of switched mode power supplies
Common measurements (ie, what to measure and why)
Circuit loading and probing considerations
How instrument specifications impact measurement accuracy
Switched mode power supplies have become ubiquitous in electronics as they provide precise voltages including high power with very high efficiency. The efficiency of these power supplies requires low loss power transistors and the design requires measurement of highly dynamic voltages. Voltage levels can vary from millivolts to hundreds of volts in some applications.
In this webinar, the proper use of a digital oscilloscope to accurately measure these voltages will be discussed along with key aspects of instrument performance such as noise and overdrive recovery that affect the accuracy of the measurement.
The USB 2.0 standard is widely deployed in both computer and embedded systems. Compliance testing for this standard includes signal integrity as well as a number of low-level protocol tests.
This presentation provides an overview of the test requirements for USB 2.0 compliance and provide background on each test case. Details of fixtures and signal integrity requirements are highlighted in detail.
For more information visit http://rohde-schwarz-scopes.com or call (888) 837-8772 to speak to a local Rohde & Schwarz expert.
Design of all digital phase locked loop (d pll) with fast acquisition timeeSAT Journals
Abstract
A Digital PLL is designed with improved acquisition time and power efficiency. The implemented D-PLL can operate
from 6.54MHz to 105MHz with a power dissipation of is 7.763μW (at 210MHz) with 1.2V supply voltage. The D-PLL is
synthesized using cadence RTL compiler in 45nm CMOS process technology.
Keywords: Digital PLL, Digital Phase/Frequency detector, NCO, Divide by N counter.
60 GHz mixed signal active load pull for millimeter wave devices characteriza...Luca Galatro
Master thesis presentation held on 16-05-2012. In this work a prototipe for a mm-wave mixed signal active load pull working in the frequency range from 50 to 65 GHz is presented. Further work has been accomplished on the topic, and a final version of the measurement setup has been presented at 81st and 83rd ARFTG conferences.
The 7SR210 series of relays provide overcurrent and earth fault protection. These relays are typically applied to provide the main protection on feeders and interconnectors and the back-up protection on items of plant such as transformers, Relays have four current inputs and are housed in E6 or E8 cases
what is Band pass filter (low and high pass) application, working and output voltages values on CRO with different frequencies as well as Picture of PSpice software (output).
IOSR Journal of Electronics and Communication Engineering(IOSR-JECE) is an open access international journal that provides rapid publication (within a month) of articles in all areas of electronics and communication engineering and its applications. The journal welcomes publications of high quality papers on theoretical developments and practical applications in electronics and communication engineering. Original research papers, state-of-the-art reviews, and high quality technical notes are invited for publications.
7SR220 series relays include for directional control of the overcurrent and earth fault functionality and are typically installed where fault current can flow in either direction i.e. on interconnected systems. Relays have five current and four voltage inputs they are housed in E6 or E8 cases.
Stability under Large-Signal Conditions PresentationNMDG NV
This presentation demonstrates calibrated small-signal S-parameters extraction under large-signal conditions, performed in parallel with the calibrated large-signal measurements provided by the ZVxPlus nonlinear extension kits.
The extracted S-parameters allow calculating the different stability criteria as well as the stability circles over the full frequency bandwidth of the selected network analyser.
Using contactless probing techniques, this feature allows you to perform calibrated in-circuit voltage and current time-domain measurements under large-signal conditions, on printed-circuit boards (PCB) or on wafer, at locations which are normally unreachable using standard VNA techniques.
Using one or more high-impedance voltage probes (HIP), this feature allows you to perform calibrated in-circuit voltage time-domain measurements under large-signal conditions, on printed-circuit boards (PCB) or on wafer, at locations which are normally unreachable using standard VNA techniques.
This presentation demonstrates that the S-functions models can be visualized and used directly in MATLAB R2012A (and LabVIEW 2011) thanks to the support of the .NET framework in both environments.
Furthermore, the response of the component, represented by such a model, is fully accessible from within MATLAB (and LabVIEW) for a given set of large-signal operating points and small-signal excitation tones.
Taking advantage of the new extended multi-port measurement ICE feature, NMDG developed a patent-pending technique to accurately model the behaviour of mixers with access to the local oscillator (LO).
NMDG developed different examples illustrating that it is possible to interact with NMDG ICE software from within LabVIEW 2011 or MATLAB R2012A, thanks to the ICE Remoting library and the .NET Remoting technology.
For a generated or measured modulated signal, the phase relationship between the tones remains constant but the phase of the carrier can be arbitrary. Moreover, when comparing phases of the multi-tone between different measurements, the phase values will change for each measurement. This paper explains how to align several measurements of a modulated signal.
As calibration reference planes are defined at probe tips for on-wafer measurement, one cannot connect the required power sensor and harmonic phase reference at the reference plane. This presentation explains how absolute calibration in an on-wafer setup is possible anyway. This method is supported in ICE and with the ZVxPlus.
