This document discusses using S-functions to model switching amplifiers. S-functions are similar to S-parameters but can model nonlinear behavior by describing the amplifier's response to both fundamental and harmonic frequencies under different operating conditions. The document outlines how to extract S-functions by applying tickling tones at various harmonic frequencies while varying the large-signal operating point, and solving for the S-function coefficients. It also describes setups using tuners to control harmonic impedances during extraction and validation of the S-function model. An example case study of extracting S-functions for a GaN power amplifier is presented.
