Introduction to
EMBEDDED SYSTEM
(2nd Edition)
SHIBU K V
Dr Moe Moe Myint
Department of Computer Engineering & Information Technology
Mandalay Technological University
www.slideshare.net/MoeMoeMyint
moemoemyint@moemyanmar.ml
moe2myint.mdy@gmail.com
drmoemoemyint.blogspot.com
Agenda
2.1 Core of the Embedded System 17
2.2 Memory 28
2.3 Sensors and Actuators 35
2.4 Communication Interface 45
2.5 Embedded Firmware 59
2.6 Other System Components 60
2.7 PCB and Passive Components 64
2
Mandalay Technological University
Department of Computer Engineering and Information Technology
Learning Objectives
 Learn the building blocks of a typical Embedded System
 Learn about General Purpose Processors (GPPs), Application
Specific Instruction Set Processors (ASIPs), Microprocessors,
Microcontrollers, Digital Signal Processors, RISC & CISC
processors, Harvad and Von-Neumann Processor Architecture, Big-
endian v/s Little endian processors, Load Store operation and
Instruction pipelining
 Learn about different PLDs like Complex Programmable Logic
Devices (CPLDs), Field Programmable Gate Arrays (FPGAs), etc.
3
Mandalay Technological University
Department of Computer Engineering and Information Technology
Cont’d
 Learn about the different memory technologies and memory types used in
embedded system development
 Learn about Masked ROM (MROM), PROM, OTP, EPROM, EEPROM, and
FLASH memory for embedded firmware storage
 Learn about Serial Access Memory (SAM), Static Random Access Memory
(SRAM), Dynamic Random Access Memory (DRAM) and Nonvolatile
SRAM (NVRAM)
 Understand the different factors to be considered in the selection of memory
for embedded systems
 Understand the role of sensors, actuators and their interfacing with the I/O
subsystems of an embedded system
4
Mandalay Technological University
Department of Computer Engineering and Information Technology
Cont’d
 Learn about the interfacing of LEDs, 7-segment LED Displays, Piezo Buzzer,
Stepper Motor, Relays, Optocouplers, Matrix keyboard, Push button switches,
Programmable Peripheral Interface Device (e.g. 8255 PPI), etc. with the I/O
subsystem of the embedded system
 Learn about the different communication interfaces of an embedded system
 Understand the various chip level communication interfaces like I2C, SPI,
UART, 1-wire, parallel bus, etc
 Understand the different wired and wireless external communication interfaces
like RS-232C, RS-485, Parallel Port, USB, IEEE1394, Infrared (IrDA),
Bluetooth, Wifi, ZigBee, GPRS, etc.
 Know what embedded firmware is and its role in embedded systems
5
Mandalay Technological University
Department of Computer Engineering and Information Technology
Cont’d
 Understand the different system components like Reset Circuit,
Brown-out protection circuit, Oscillator Unit, Real-Time Clock
(RTC) and Watchdog Timer unit
 Understand the role of PCB in embedded systems
6
Mandalay Technological University
Department of Computer Engineering and Information Technology
2.2 Memory
 Memory is an important part of a processor/controller based embedded
systems.
 Some of the processors/controllers contain built in memory and this
memory is referred as on-chip memory.
 Others do not contain any memory inside the chip and requires external
memory to be connected with the controller/processor to store the
control algorithm. It is called off-chip memory.
7
Mandalay Technological University
Department of Computer Engineering and Information Technology
Cont’d
 There are different types of memory used in embedded system applications:
i. Program Storage Memory (ROM)
 Masked ROM (MROM)
 Programmable Read Only Memory (PROM)/ (OTP)
 Erasable Programmable Read Only Memory (EPROM)
 Electrically Erasable Programmable Read Only Memory (EEPROM)
 FLASH
ii. Read-Write Memory/Random Access Memory (RAM)
 Static RAM (SRAM)
 Dynamic RAM (DRAM)
 NVRAM
8
Mandalay Technological University
Department of Computer Engineering and Information Technology
Program Storage Memory (ROM)
 The program memory or code storage
memory of an embedded system stores
the program instructions and it can be
classified into different types as per the
block diagram representation given in
Figure.
 The code memory retains its contents
even after the power to it is turned
off. It is generally known as non-
volatile storage memory.
 Depending on the fabrication, erasing
and programming techniques they are
classified into the following types.
9
Figure. Classification of Program Memory (ROM)
Mandalay Technological University
Department of Computer Engineering and Information Technology
Non Volatile
Memory
FLASH
Classification of ROM
 Mask ROM : Masked ROM is a static ROM which comes programmed into an integrated
circuit by its manufacturer. Masked ROM makes use of the hardwired technology for
storing data. It is a good candidate for storing the embedded firmware for low cost
embedded devices. The primary advantage of this is low cost for high volume production.
The limitation with MROM based firmware storage is the inability to modify the device
firmware against firmware upgrades. They are used in network operating systems, server
operating systems, storing of fonts for laser printers, sound data in electronic musical
instruments.
 PROM/ OTP : Unlike MROM, One Time Programmable Memory (OTP) or PROM is not
pre-programmed by the manufacturer. The end user is responsible for programming
these devices. They have several different applications, including cell phones, video game
consoles, RFID tags, medical devices, and other electronics.
10
Mandalay Technological University
Department of Computer Engineering and Information Technology
Cont’d
 EPROM : EPROM gives the flexibility to re-program the same chip. EPROM stores the bit
information by charging the floating gate of an FET and contains a quartz crystal window for
erasing the stored information. Even though the EPROM chip is flexible in terms of re-
programmability, it needs to be taken out of the circuit board and put in a UV eraser device for 20 to
30 minutes. So it is a tedious and time-consuming process.
 EEPROM : The information contained in the EEPROM memory can be altered by using electrical
signal at the register/Byte level. They can be erased and reprogrammed in-circuit. These chips
include a chip erase mode and in this mode they can be erased in a few milliseconds. It provides
greater flexibility for system design. The only limitation is their capacity is limited when
compared with the standard ROM (a few kilobytes). It is used for storing the computer system
BIOS.
11
Mandalay Technological University
Department of Computer Engineering and Information Technology
How MOS-FET Transistor works?12
Mandalay Technological University
Department of Computer Engineering and Information Technology
 FLASH : It is an enhanced version of EEPROM. It combines the re-programmability of
EEPROM and the high capacity of standard ROMs. FLASH memory is organized as sectors
(blocks) or pages. FLASH memory stores information in an array of floating gate MOS-FET
transistors. The erasing of memory can be done at sector level or page level without affecting
the other sectors or pages. Each sector/ page should be erased before re-programming. The
typical erasable capacity of FLASH is 1000 cycles. Many modern PCs have their BIOS
stored on a flash memory chip, called as flash BIOS and they are also used in memory
cards, USB flash drives, modems as well.
13
Mandalay Technological University
Department of Computer Engineering and Information Technology
Cont’d
Read-Write Memory/Random Access Memory (RAM)
 The Random Access Memory
(RAM) is the data memory or
working memory of the
controller/processor.
 Controller/processor can read from
it and write to it.
 RAM is volatile, meaning when the
power is turned off, all the contents
are destroyed.
 RAM generally falls into three
categories: Static RAM (SRAM),
dynamic RAM (DRAM) and non-
volatile RAM (NVRAM).
14
Figure. Classification of Working Memory (RAM)
Mandalay Technological University
Department of Computer Engineering and Information Technology
Static RAM (SRAM)
 SRAM : SRAM stores data in the
form of voltage. They are made up
of flip-flops. A flip-flop for a
memory cell takes four or six
transistors (or 6 MOSFETs) along
with some wiring, four of the
transistors are used for building the
latch (flip-flop) part of the memory
cell and two for controlling the
access. SRAM is fast in operation
due to its resistive networking and
switching capabilities. In its simplest
representation an SRAM cell can be
visualized as shown in Figure.
15
Figure. SRAM Cell Implementation
Mandalay Technological University
Department of Computer Engineering and Information Technology
Cont’d
 This implementation in its simpler form can be visualized as two-cross coupled inverters
with read/write control through transistors. The four transistors in the middle form the
cross-coupled inverters. This can be visualized as shown in Figure.
 The major limitations of SRAM are low capacity and high cost.
16
Mandalay Technological University
Department of Computer Engineering and Information Technology
Figure. Visualization of SRAM cell
Dynamic RAM (DRAM)
 DRAM : DRAM stores data in the form of charge. They are made up
of MOS transistor gates.
 The advantages of DRAM are its high density and low cost compared
to SRAM.
 The disadvantage is that since the information is stored as charge it
gets leaked off with time and to prevent this they need to be
refreshed periodically.
 Special circuits called DRAM controllers are used for the refreshing
operation.
 The refresh operation is done periodically in milliseconds interval.
 The MOSFET acts as the gate for the incoming and outgoing data
whereas the capacitor acts as the bit storage unit.
17
Figure. DRAM Cell Implementation
Mandalay Technological University
Department of Computer Engineering and Information Technology
Summary of the relative merits and demerits of
SRAM and DRAM technology
18
SRAM Cell DRAM Cell
Made up of 6 CMOS transistors (MOSFET) Made up of a MOSFET and a capacitor
Doesn’t require refreshing Requires refreshing
Low capacity (Less dense) High capacity (Highly dense)
More expensive Less expensive
Fast in operation.
Typical access time is 10 ns.
Slow in operation due to refresh
requirements.
Typical access time is 60 ns. Write operation
is faster than read operation.
Mandalay Technological University
Department of Computer Engineering and Information Technology
NVRAM
 NVRAM: Non-volatile RAM is a random access memory with battery backup.
 It contains static RAM based memory and a minute battery for providing supply to the
memory in the absence of external power supply.
 The memory and battery are packed together in a single package.
 NVRAM is used for the non-volatile storage of results of operations.
 The life span of NVRAM is expected to be around 10 years.
 DS1744 from Maxim/Dallas is an example for 32 KB NVRAM.
19
Mandalay Technological University
Department of Computer Engineering and Information Technology
Understanding Test Questions III
1. Which of the following is one-time programmable memory?
(a) SRAM (b) PROM (c) FLASH (d) NVRAM
2. Which of the following memory type is best suited for development purpose?
(a) EEPROM (b) FLASH (c) UVEPROM (d) OTP
(e) (a) or (b)
3. EEPROM memory is alterable at byte level. State True or False
(a) True (b) False
4. Non-volatile RAM is a Random Access Memory with battery backup. State True or
False
(a) True (b) False
5. Execution of program from ROM is faster than the execution from RAM. Sate True
or False
(a) True (b) False
6. Dynamic RAM stores data in the form of voltage. State True or False
(a) True (b) False
20
Mandalay Technological University
Department of Computer Engineering and Information Technology
Reviewed Questions III
1. What is the difference between RAM and ROM?
2. What are the different types of RAM used for Embedded System design?
3. What are the different types of memories used for Program storage in
Embedded System Design?
4. What are the advantages of FLASH over other program storage in
Embedded System Design?
5. Explain the operation of Static RAM (SRAM) cell.
6. Explain the merits and limitations of SRAM and DRAM as Random
Access Memory.
21
Mandalay Technological University
Department of Computer Engineering and Information Technology
Assignment III
Write a “C” program to find the endianness of the
processor in which the program is running. If the
processor is big endian, print “The processor architecture
is Big endian”, else print “The processor architecture is
Little endian” on the console window.
Remark: for all groups
Deadline : 2. 1. 18 (Coming Tuesday)
22
Mandalay Technological University
Department of Computer Engineering and Information Technology
 Only Original Owner has full rights reserved for copied images.
 This PPT is only for fair academic use.
 Coming soon for chapter 2 (2nd portion)
23
Mandalay Technological University
Department of Computer Engineering and Information Technology
24

More Related Content

What's hot

Trends in Embedded system Design
Trends in Embedded system DesignTrends in Embedded system Design
Trends in Embedded system Design
Raman Deep

Design of embedded systems
Design of embedded systemsDesign of embedded systems
Design of embedded systems
Pradeep Kumar TS


What's hot (20)

Chapter 3 Charateristics and Quality Attributes of Embedded System
Chapter 3 Charateristics and Quality Attributes of Embedded SystemChapter 3 Charateristics and Quality Attributes of Embedded System
Chapter 3 Charateristics and Quality Attributes of Embedded System

Ppt on embedded systems
Ppt on embedded systemsPpt on embedded systems
Ppt on embedded systems

Chapter 4 Embedded System: Application and Domain Specific
Chapter 4 Embedded System: Application and Domain SpecificChapter 4 Embedded System: Application and Domain Specific
Chapter 4 Embedded System: Application and Domain Specific

SYBSC IT SEM IV EMBEDDED SYSTEMS UNIT I Core of Embedded Systems
SYBSC IT SEM IV EMBEDDED SYSTEMS UNIT I   Core of Embedded SystemsSYBSC IT SEM IV EMBEDDED SYSTEMS UNIT I   Core of Embedded Systems
SYBSC IT SEM IV EMBEDDED SYSTEMS UNIT I Core of Embedded Systems

Classification of embedded systems
Classification of embedded systemsClassification of embedded systems
Classification of embedded systems

Embedded Systems - Training ppt
Embedded Systems - Training pptEmbedded Systems - Training ppt
Embedded Systems - Training ppt

Rtos by shibu
Rtos by shibuRtos by shibu
Rtos by shibu

Introduction to embedded systems
Introduction to embedded systemsIntroduction to embedded systems
Introduction to embedded systems

Semiconductor memories
Semiconductor memoriesSemiconductor memories
Semiconductor memories

Embedded Systems
Embedded SystemsEmbedded Systems
Embedded Systems

Chapter 8 Embedded Hardware Design and Development (second portion)
Chapter 8 Embedded Hardware Design and Development (second portion)Chapter 8 Embedded Hardware Design and Development (second portion)
Chapter 8 Embedded Hardware Design and Development (second portion)

Trends in Embedded system Design
Trends in Embedded system DesignTrends in Embedded system Design
Trends in Embedded system Design

Language for Embedded System
Language for Embedded System Language for Embedded System
Language for Embedded System

Embedded System
Embedded SystemEmbedded System
Embedded System

Embedded systems
Embedded systemsEmbedded systems
Embedded systems

Serial Communication Interfaces
Serial Communication InterfacesSerial Communication Interfaces
Serial Communication Interfaces

Design of embedded systems
Design of embedded systemsDesign of embedded systems
Design of embedded systems

Introduction to embedded systems
Introduction to embedded systemsIntroduction to embedded systems
Introduction to embedded systems

Chapter 8 Embedded Hardware Design and Development (third portion)
Chapter 8 Embedded Hardware Design and Development (third portion)Chapter 8 Embedded Hardware Design and Development (third portion)
Chapter 8 Embedded Hardware Design and Development (third portion)

Typical Embedded System
Typical Embedded SystemTypical Embedded System
Typical Embedded System


Similar to Introduction to Embedded System I : Chapter 2 (2nd portion)

301378156 design-of-sram-in-verilog
301378156 design-of-sram-in-verilog301378156 design-of-sram-in-verilog
301378156 design-of-sram-in-verilog
Srinivas Naidu

11. Computer Systems Hardware 1
11. Computer Systems   Hardware 111. Computer Systems   Hardware 1
11. Computer Systems Hardware 1
New Era University

Project report on embedded system using 8051 microcontroller
Project  report on embedded system using 8051 microcontrollerProject  report on embedded system using 8051 microcontroller
Project report on embedded system using 8051 microcontroller
Vandna Sambyal

2. the memory systems (module2)
2. the memory systems (module2)2. the memory systems (module2)
2. the memory systems (module2)
Ajit Saraf


Similar to Introduction to Embedded System I : Chapter 2 (2nd portion) (20)

301378156 design-of-sram-in-verilog
301378156 design-of-sram-in-verilog301378156 design-of-sram-in-verilog
301378156 design-of-sram-in-verilog

Microcomputer & RAM Model
Microcomputer & RAM ModelMicrocomputer & RAM Model
Microcomputer & RAM Model

Benefits of Micro Controller.pdf
Benefits of Micro Controller.pdfBenefits of Micro Controller.pdf
Benefits of Micro Controller.pdf

UNIT-III CASE STUDIES -FPGA & CPGA ARCHITECTURES APPLICATIONS
UNIT-III CASE STUDIES -FPGA & CPGA ARCHITECTURES APPLICATIONSUNIT-III CASE STUDIES -FPGA & CPGA ARCHITECTURES APPLICATIONS
UNIT-III CASE STUDIES -FPGA & CPGA ARCHITECTURES APPLICATIONS

11. Computer Systems Hardware 1
11. Computer Systems   Hardware 111. Computer Systems   Hardware 1
11. Computer Systems Hardware 1

Rom (read only memory)
Rom (read only memory)Rom (read only memory)
Rom (read only memory)

IRJET- Design And VLSI Verification of DDR SDRAM Controller Using VHDL
IRJET- Design And VLSI Verification of DDR SDRAM Controller Using VHDLIRJET- Design And VLSI Verification of DDR SDRAM Controller Using VHDL
IRJET- Design And VLSI Verification of DDR SDRAM Controller Using VHDL

computer Unit 5
computer Unit 5computer Unit 5
computer Unit 5

ARM architcture
ARM architcture ARM architcture
ARM architcture

8085 interfacing with memory chips
8085 interfacing with memory chips8085 interfacing with memory chips
8085 interfacing with memory chips

Project report on embedded system using 8051 microcontroller
Project  report on embedded system using 8051 microcontrollerProject  report on embedded system using 8051 microcontroller
Project report on embedded system using 8051 microcontroller

Embedded systems-unit-1
Embedded systems-unit-1Embedded systems-unit-1
Embedded systems-unit-1

Giao trinh he thong nhung vdk h8
Giao trinh he thong nhung   vdk h8Giao trinh he thong nhung   vdk h8
Giao trinh he thong nhung vdk h8

what is ROM? Rom(read only memory)
what is ROM? Rom(read only memory)what is ROM? Rom(read only memory)
what is ROM? Rom(read only memory)

Memory types
Memory typesMemory types
Memory types

2. the memory systems (module2)
2. the memory systems (module2)2. the memory systems (module2)
2. the memory systems (module2)

Random Access Memory ( RAM)
Random Access Memory ( RAM)Random Access Memory ( RAM)
Random Access Memory ( RAM)

Embedded system
Embedded systemEmbedded system
Embedded system

Embeddedsystem
EmbeddedsystemEmbeddedsystem
Embeddedsystem

L010236974
L010236974L010236974
L010236974


More from Moe Moe Myint

More from Moe Moe Myint (14)

Schematic and PCB Design Using Eagle
Schematic and PCB Design Using EagleSchematic and PCB Design Using Eagle
Schematic and PCB Design Using Eagle

Lect 06
Lect 06 Lect 06
Lect 06

Lect 03 - first portion
Lect 03 - first portionLect 03 - first portion
Lect 03 - first portion

Lect 02 second portion
Lect 02  second portionLect 02  second portion
Lect 02 second portion

Lect 02 first portion
Lect 02   first portionLect 02   first portion
Lect 02 first portion

Lect 02 first portion
Lect 02   first portionLect 02   first portion
Lect 02 first portion

Lecture 1 for Digital Image Processing (2nd Edition)
Lecture 1 for Digital Image Processing (2nd Edition)Lecture 1 for Digital Image Processing (2nd Edition)
Lecture 1 for Digital Image Processing (2nd Edition)

Digital Image Processing (Lab 09 and 10)
Digital Image Processing (Lab 09 and 10)Digital Image Processing (Lab 09 and 10)
Digital Image Processing (Lab 09 and 10)

Digital Image Processing (Lab 08)
Digital Image Processing (Lab 08)Digital Image Processing (Lab 08)
Digital Image Processing (Lab 08)

Digital Image Processing (Lab 07)
Digital Image Processing (Lab 07)Digital Image Processing (Lab 07)
Digital Image Processing (Lab 07)

Digital Image Processing (Lab 06)
Digital Image Processing (Lab 06)Digital Image Processing (Lab 06)
Digital Image Processing (Lab 06)

Digital Image Processing (Lab 05)
Digital Image Processing (Lab 05)Digital Image Processing (Lab 05)
Digital Image Processing (Lab 05)

Dital Image Processing (Lab 2+3+4)
Dital Image Processing (Lab 2+3+4)Dital Image Processing (Lab 2+3+4)
Dital Image Processing (Lab 2+3+4)

Digital image processing lab 1
Digital image processing lab 1Digital image processing lab 1
Digital image processing lab 1


Recently uploaded

Digital Signal Processing Lecture notes n.pdf
Digital Signal Processing Lecture notes n.pdfDigital Signal Processing Lecture notes n.pdf
Digital Signal Processing Lecture notes n.pdf
AbrahamGadissa

Online blood donation management system project.pdf
Online blood donation management system project.pdfOnline blood donation management system project.pdf
Online blood donation management system project.pdf
Kamal Acharya

ONLINE VEHICLE RENTAL SYSTEM PROJECT REPORT.pdf
ONLINE VEHICLE RENTAL SYSTEM PROJECT REPORT.pdfONLINE VEHICLE RENTAL SYSTEM PROJECT REPORT.pdf
ONLINE VEHICLE RENTAL SYSTEM PROJECT REPORT.pdf
Kamal Acharya

Laundry management system project report.pdf
Laundry management system project report.pdfLaundry management system project report.pdf
Laundry management system project report.pdf
Kamal Acharya


Recently uploaded (20)

Introduction to Machine Learning Unit-5 Notes for II-II Mechanical Engineering
Introduction to Machine Learning Unit-5 Notes for II-II Mechanical EngineeringIntroduction to Machine Learning Unit-5 Notes for II-II Mechanical Engineering
Introduction to Machine Learning Unit-5 Notes for II-II Mechanical Engineering

The Ultimate Guide to External Floating Roofs for Oil Storage Tanks.docx
The Ultimate Guide to External Floating Roofs for Oil Storage Tanks.docxThe Ultimate Guide to External Floating Roofs for Oil Storage Tanks.docx
The Ultimate Guide to External Floating Roofs for Oil Storage Tanks.docx

Democratizing Fuzzing at Scale by Abhishek Arya
Democratizing Fuzzing at Scale by Abhishek AryaDemocratizing Fuzzing at Scale by Abhishek Arya
Democratizing Fuzzing at Scale by Abhishek Arya

Digital Signal Processing Lecture notes n.pdf
Digital Signal Processing Lecture notes n.pdfDigital Signal Processing Lecture notes n.pdf
Digital Signal Processing Lecture notes n.pdf

Courier management system project report.pdf
Courier management system project report.pdfCourier management system project report.pdf
Courier management system project report.pdf

Halogenation process of chemical process industries
Halogenation process of chemical process industriesHalogenation process of chemical process industries
Halogenation process of chemical process industries

KIT-601 Lecture Notes-UNIT-5.pdf Frame Works and Visualization
KIT-601 Lecture Notes-UNIT-5.pdf Frame Works and VisualizationKIT-601 Lecture Notes-UNIT-5.pdf Frame Works and Visualization
KIT-601 Lecture Notes-UNIT-5.pdf Frame Works and Visualization

Introduction to Machine Learning Unit-4 Notes for II-II Mechanical Engineering
Introduction to Machine Learning Unit-4 Notes for II-II Mechanical EngineeringIntroduction to Machine Learning Unit-4 Notes for II-II Mechanical Engineering
Introduction to Machine Learning Unit-4 Notes for II-II Mechanical Engineering

Toll tax management system project report..pdf
Toll tax management system project report..pdfToll tax management system project report..pdf
Toll tax management system project report..pdf

2024 DevOps Pro Europe - Growing at the edge
2024 DevOps Pro Europe - Growing at the edge2024 DevOps Pro Europe - Growing at the edge
2024 DevOps Pro Europe - Growing at the edge

Cloud-Computing_CSE311_Computer-Networking CSE GUB BD - Shahidul.pptx
Cloud-Computing_CSE311_Computer-Networking CSE GUB BD - Shahidul.pptxCloud-Computing_CSE311_Computer-Networking CSE GUB BD - Shahidul.pptx
Cloud-Computing_CSE311_Computer-Networking CSE GUB BD - Shahidul.pptx

Natalia Rutkowska - BIM School Course in Kraków
Natalia Rutkowska - BIM School Course in KrakówNatalia Rutkowska - BIM School Course in Kraków
Natalia Rutkowska - BIM School Course in Kraków

Pharmacy management system project report..pdf
Pharmacy management system project report..pdfPharmacy management system project report..pdf
Pharmacy management system project report..pdf

Online blood donation management system project.pdf
Online blood donation management system project.pdfOnline blood donation management system project.pdf
Online blood donation management system project.pdf

Explosives Industry manufacturing process.pdf
Explosives Industry manufacturing process.pdfExplosives Industry manufacturing process.pdf
Explosives Industry manufacturing process.pdf

IT-601 Lecture Notes-UNIT-2.pdf Data Analysis
IT-601 Lecture Notes-UNIT-2.pdf Data AnalysisIT-601 Lecture Notes-UNIT-2.pdf Data Analysis
IT-601 Lecture Notes-UNIT-2.pdf Data Analysis

ONLINE VEHICLE RENTAL SYSTEM PROJECT REPORT.pdf
ONLINE VEHICLE RENTAL SYSTEM PROJECT REPORT.pdfONLINE VEHICLE RENTAL SYSTEM PROJECT REPORT.pdf
ONLINE VEHICLE RENTAL SYSTEM PROJECT REPORT.pdf

A CASE STUDY ON ONLINE TICKET BOOKING SYSTEM PROJECT.pdf
A CASE STUDY ON ONLINE TICKET BOOKING SYSTEM PROJECT.pdfA CASE STUDY ON ONLINE TICKET BOOKING SYSTEM PROJECT.pdf
A CASE STUDY ON ONLINE TICKET BOOKING SYSTEM PROJECT.pdf

Laundry management system project report.pdf
Laundry management system project report.pdfLaundry management system project report.pdf
Laundry management system project report.pdf

Furniture showroom management system project.pdf
Furniture showroom management system project.pdfFurniture showroom management system project.pdf
Furniture showroom management system project.pdf


Introduction to Embedded System I : Chapter 2 (2nd portion)

  • 1. Introduction to EMBEDDED SYSTEM (2nd Edition) SHIBU K V Dr Moe Moe Myint Department of Computer Engineering & Information Technology Mandalay Technological University www.slideshare.net/MoeMoeMyint moemoemyint@moemyanmar.ml moe2myint.mdy@gmail.com drmoemoemyint.blogspot.com
  • 2. Agenda 2.1 Core of the Embedded System 17 2.2 Memory 28 2.3 Sensors and Actuators 35 2.4 Communication Interface 45 2.5 Embedded Firmware 59 2.6 Other System Components 60 2.7 PCB and Passive Components 64 2 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 3. Learning Objectives  Learn the building blocks of a typical Embedded System  Learn about General Purpose Processors (GPPs), Application Specific Instruction Set Processors (ASIPs), Microprocessors, Microcontrollers, Digital Signal Processors, RISC & CISC processors, Harvad and Von-Neumann Processor Architecture, Big- endian v/s Little endian processors, Load Store operation and Instruction pipelining  Learn about different PLDs like Complex Programmable Logic Devices (CPLDs), Field Programmable Gate Arrays (FPGAs), etc. 3 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 4. Cont’d  Learn about the different memory technologies and memory types used in embedded system development  Learn about Masked ROM (MROM), PROM, OTP, EPROM, EEPROM, and FLASH memory for embedded firmware storage  Learn about Serial Access Memory (SAM), Static Random Access Memory (SRAM), Dynamic Random Access Memory (DRAM) and Nonvolatile SRAM (NVRAM)  Understand the different factors to be considered in the selection of memory for embedded systems  Understand the role of sensors, actuators and their interfacing with the I/O subsystems of an embedded system 4 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 5. Cont’d  Learn about the interfacing of LEDs, 7-segment LED Displays, Piezo Buzzer, Stepper Motor, Relays, Optocouplers, Matrix keyboard, Push button switches, Programmable Peripheral Interface Device (e.g. 8255 PPI), etc. with the I/O subsystem of the embedded system  Learn about the different communication interfaces of an embedded system  Understand the various chip level communication interfaces like I2C, SPI, UART, 1-wire, parallel bus, etc  Understand the different wired and wireless external communication interfaces like RS-232C, RS-485, Parallel Port, USB, IEEE1394, Infrared (IrDA), Bluetooth, Wifi, ZigBee, GPRS, etc.  Know what embedded firmware is and its role in embedded systems 5 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 6. Cont’d  Understand the different system components like Reset Circuit, Brown-out protection circuit, Oscillator Unit, Real-Time Clock (RTC) and Watchdog Timer unit  Understand the role of PCB in embedded systems 6 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 7. 2.2 Memory  Memory is an important part of a processor/controller based embedded systems.  Some of the processors/controllers contain built in memory and this memory is referred as on-chip memory.  Others do not contain any memory inside the chip and requires external memory to be connected with the controller/processor to store the control algorithm. It is called off-chip memory. 7 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 8. Cont’d  There are different types of memory used in embedded system applications: i. Program Storage Memory (ROM)  Masked ROM (MROM)  Programmable Read Only Memory (PROM)/ (OTP)  Erasable Programmable Read Only Memory (EPROM)  Electrically Erasable Programmable Read Only Memory (EEPROM)  FLASH ii. Read-Write Memory/Random Access Memory (RAM)  Static RAM (SRAM)  Dynamic RAM (DRAM)  NVRAM 8 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 9. Program Storage Memory (ROM)  The program memory or code storage memory of an embedded system stores the program instructions and it can be classified into different types as per the block diagram representation given in Figure.  The code memory retains its contents even after the power to it is turned off. It is generally known as non- volatile storage memory.  Depending on the fabrication, erasing and programming techniques they are classified into the following types. 9 Figure. Classification of Program Memory (ROM) Mandalay Technological University Department of Computer Engineering and Information Technology Non Volatile Memory FLASH
  • 10. Classification of ROM  Mask ROM : Masked ROM is a static ROM which comes programmed into an integrated circuit by its manufacturer. Masked ROM makes use of the hardwired technology for storing data. It is a good candidate for storing the embedded firmware for low cost embedded devices. The primary advantage of this is low cost for high volume production. The limitation with MROM based firmware storage is the inability to modify the device firmware against firmware upgrades. They are used in network operating systems, server operating systems, storing of fonts for laser printers, sound data in electronic musical instruments.  PROM/ OTP : Unlike MROM, One Time Programmable Memory (OTP) or PROM is not pre-programmed by the manufacturer. The end user is responsible for programming these devices. They have several different applications, including cell phones, video game consoles, RFID tags, medical devices, and other electronics. 10 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 11. Cont’d  EPROM : EPROM gives the flexibility to re-program the same chip. EPROM stores the bit information by charging the floating gate of an FET and contains a quartz crystal window for erasing the stored information. Even though the EPROM chip is flexible in terms of re- programmability, it needs to be taken out of the circuit board and put in a UV eraser device for 20 to 30 minutes. So it is a tedious and time-consuming process.  EEPROM : The information contained in the EEPROM memory can be altered by using electrical signal at the register/Byte level. They can be erased and reprogrammed in-circuit. These chips include a chip erase mode and in this mode they can be erased in a few milliseconds. It provides greater flexibility for system design. The only limitation is their capacity is limited when compared with the standard ROM (a few kilobytes). It is used for storing the computer system BIOS. 11 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 12. How MOS-FET Transistor works?12 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 13.  FLASH : It is an enhanced version of EEPROM. It combines the re-programmability of EEPROM and the high capacity of standard ROMs. FLASH memory is organized as sectors (blocks) or pages. FLASH memory stores information in an array of floating gate MOS-FET transistors. The erasing of memory can be done at sector level or page level without affecting the other sectors or pages. Each sector/ page should be erased before re-programming. The typical erasable capacity of FLASH is 1000 cycles. Many modern PCs have their BIOS stored on a flash memory chip, called as flash BIOS and they are also used in memory cards, USB flash drives, modems as well. 13 Mandalay Technological University Department of Computer Engineering and Information Technology Cont’d
  • 14. Read-Write Memory/Random Access Memory (RAM)  The Random Access Memory (RAM) is the data memory or working memory of the controller/processor.  Controller/processor can read from it and write to it.  RAM is volatile, meaning when the power is turned off, all the contents are destroyed.  RAM generally falls into three categories: Static RAM (SRAM), dynamic RAM (DRAM) and non- volatile RAM (NVRAM). 14 Figure. Classification of Working Memory (RAM) Mandalay Technological University Department of Computer Engineering and Information Technology
  • 15. Static RAM (SRAM)  SRAM : SRAM stores data in the form of voltage. They are made up of flip-flops. A flip-flop for a memory cell takes four or six transistors (or 6 MOSFETs) along with some wiring, four of the transistors are used for building the latch (flip-flop) part of the memory cell and two for controlling the access. SRAM is fast in operation due to its resistive networking and switching capabilities. In its simplest representation an SRAM cell can be visualized as shown in Figure. 15 Figure. SRAM Cell Implementation Mandalay Technological University Department of Computer Engineering and Information Technology
  • 16. Cont’d  This implementation in its simpler form can be visualized as two-cross coupled inverters with read/write control through transistors. The four transistors in the middle form the cross-coupled inverters. This can be visualized as shown in Figure.  The major limitations of SRAM are low capacity and high cost. 16 Mandalay Technological University Department of Computer Engineering and Information Technology Figure. Visualization of SRAM cell
  • 17. Dynamic RAM (DRAM)  DRAM : DRAM stores data in the form of charge. They are made up of MOS transistor gates.  The advantages of DRAM are its high density and low cost compared to SRAM.  The disadvantage is that since the information is stored as charge it gets leaked off with time and to prevent this they need to be refreshed periodically.  Special circuits called DRAM controllers are used for the refreshing operation.  The refresh operation is done periodically in milliseconds interval.  The MOSFET acts as the gate for the incoming and outgoing data whereas the capacitor acts as the bit storage unit. 17 Figure. DRAM Cell Implementation Mandalay Technological University Department of Computer Engineering and Information Technology
  • 18. Summary of the relative merits and demerits of SRAM and DRAM technology 18 SRAM Cell DRAM Cell Made up of 6 CMOS transistors (MOSFET) Made up of a MOSFET and a capacitor Doesn’t require refreshing Requires refreshing Low capacity (Less dense) High capacity (Highly dense) More expensive Less expensive Fast in operation. Typical access time is 10 ns. Slow in operation due to refresh requirements. Typical access time is 60 ns. Write operation is faster than read operation. Mandalay Technological University Department of Computer Engineering and Information Technology
  • 19. NVRAM  NVRAM: Non-volatile RAM is a random access memory with battery backup.  It contains static RAM based memory and a minute battery for providing supply to the memory in the absence of external power supply.  The memory and battery are packed together in a single package.  NVRAM is used for the non-volatile storage of results of operations.  The life span of NVRAM is expected to be around 10 years.  DS1744 from Maxim/Dallas is an example for 32 KB NVRAM. 19 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 20. Understanding Test Questions III 1. Which of the following is one-time programmable memory? (a) SRAM (b) PROM (c) FLASH (d) NVRAM 2. Which of the following memory type is best suited for development purpose? (a) EEPROM (b) FLASH (c) UVEPROM (d) OTP (e) (a) or (b) 3. EEPROM memory is alterable at byte level. State True or False (a) True (b) False 4. Non-volatile RAM is a Random Access Memory with battery backup. State True or False (a) True (b) False 5. Execution of program from ROM is faster than the execution from RAM. Sate True or False (a) True (b) False 6. Dynamic RAM stores data in the form of voltage. State True or False (a) True (b) False 20 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 21. Reviewed Questions III 1. What is the difference between RAM and ROM? 2. What are the different types of RAM used for Embedded System design? 3. What are the different types of memories used for Program storage in Embedded System Design? 4. What are the advantages of FLASH over other program storage in Embedded System Design? 5. Explain the operation of Static RAM (SRAM) cell. 6. Explain the merits and limitations of SRAM and DRAM as Random Access Memory. 21 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 22. Assignment III Write a “C” program to find the endianness of the processor in which the program is running. If the processor is big endian, print “The processor architecture is Big endian”, else print “The processor architecture is Little endian” on the console window. Remark: for all groups Deadline : 2. 1. 18 (Coming Tuesday) 22 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 23.  Only Original Owner has full rights reserved for copied images.  This PPT is only for fair academic use.  Coming soon for chapter 2 (2nd portion) 23 Mandalay Technological University Department of Computer Engineering and Information Technology
  • 24. 24

Editor's Notes

  1. Understand the different types of core i.e. processor Understand the difference between microprocessor & microcontroller Understand the classification of processors based on Bus Architecture, Instruction set Architecture, and Endiannes. Have an overview of processors from most simple and cheap to most expensive and complex, powerful Understand what are sensors and actuators, communication interfaces
  2. What are the different types of memories used for Program storage in Embedded System Design? What is the difference between RAM and ROM?
  3. Fabrication : manufacture/invent a product especially from prepared component The Read Only Memory (ROM) is a non-volatile memory for storing the firmware and embedded OS files. MROM, PROM (OTP), EPROM, EEPROM, FLASH and NVRAM are the commonly used firmware storage memory. The Random Access Memory (RAM) is a volatile memory for temporary data storage. RAM generally falls into three categories: SRAM, DRAM and NVRAM. Volatile memory, it means information written to it can be accessed as long as power is on. As soon as the power is off, it can not be accessed. Vice versa
  4. RFID : Radio Frequency Identification RFID tagging is an ID system that uses small radio frequency identification devices for identification and tracking purposes. An RFID tagging system Includes the tag itself, a read/write device, and a host system application for data collection, processing, and transmission. An RFID tag (sometimes called an RFID transponder) consists of a chip, some memory and an antenna. What is the difference between Masked ROM and OTP? OTPs are not useful and worth for development purpose. Not economical……
  5. EPROM stores the bit information by charging the floating gate of an FET transistors. (The floating-gate MOSFET (FEMOS) is a field-effect transistor, whose structure is similar to a conventional MOSFET. Bit information is stored by using an EPROM programmer, which applies high voltage to charge the floating gate. EPROM contains a quartz crystal window for erasing the stored information. If the window is exposed to ultraviolet rays for a fixed duration, the entire memory will be erased.
  6. A normal transistor has three connections (wires that control it) called the source, drain, and gate. Think of a transistor as a pipe through which electricity can flow as through it’s water. One end of the pipe (where the water flows in) is called the source- think of that as a tap or faucet. The other end of the pipe is called the drain-where the water drains out and flows away. In between the source and drain, blocking the pipe, there’s a gate. When the gate is closed, the pipe is shut off, no electricity can flow and the transistor is off. In this state, the transistor stores a zero. When the gate is opened, electricity flows, the transistor is on, and it stores a one. But when the power is turned off, the transistor switches off too. When you switch the power back on, the transistor is still off, and since you can’t know whether it was on or off before the power was removed, you can see why we say it “forgets” any information it stores.
  7. MOS (Metal Oxide Semiconductor) Field Effect transistor What are the advantages of FLASH over other program storage memory in Embedded System Design? Latest ROM technology ( Combines the re-programmability of EEPROM and the high capacity of standard ROMs) So, Flash ROM is much faster than EEPROM. How flash memory works – the simple explanation Flash works using an entirely different kind of transistor that stays switched on (or switched off) even when the power is turned off. A normal transistor has three connections (wires that control it) called the source, drain, and gate. Think of a transistor as a pipe through which electricity can flow as through it’s water. One end of the pipe (where the water flows in) is called the source- think of that as a tap or faucet. The other end of the pipe is called the drain-where the water drains out and flows away. In between the source and drain, blocking the pipe, there’s a gate. When the gate is closed, the pipe is shut off, no electricity can flow and the transistor is off. In this state, the transistor stores a zero. When the gate is opened, electricity flows, the transistor is on, and it stores a one. But when the power is turned off, the transistor switches off too. When you switch the power back on, the transistor is still off, and since you can’t know whether it was on or off before the power was removed, you can see why we say it “forgets” any information it stores.
  8. Volatile memory, it means information written to it can be accessed as long as power is on. As soon as the power is off, it can not be accessed. So this mean RAM computer memory essentially empty. RAM holds data and processing instructions temporarily until the CPU needs it.
  9. Explain the operation of Static RAM (SRAM) cell. A digital computer needs devices which can store information. A flip flop is a binary storage device. It can store binary bit either 0 or 1. It has two stable states HIGH and LOW i.e. 1 and 0. It can store binary bit either 0 or 1. It has two stable states HIGH and LOW i.e. 1 and 0. (Flip Flop NAND / NOR Gate) SRAM retains stored information only as long as the power supply is on. SRAMs are costlier and consume more power. They have higher speed than DRAM. A form of flip-flop holds each bit of memory.
  10. From the SRAM implementation diagram, it is clear that access to the memory cell is controlled by the line Word Line, which controls the access transistors (MOSFETs) Q5 and Q6. The access transistors control the connection to bit lines B & B\. In order to write a value to the memory cell, apply the desired value to the bit control lines (For writing 1, make B=1 and B\=0; For writing 0, make B=0 and B\=1) and assert the Word Line (Make Word line high). This operation latches the bit written in the flip-flop. For reading the content of the memory cell, assert both B and B\ bit lines to 1 and set the Word line to 1.
  11. Current is the rate of flow of charge. In other words a current is caused by the electrons moving around the conductor. A voltage is defined as the work done per unit charge. This means that voltage is the amount of energy used for each charge. Capaciftance is reisitance to change in voltage by sacrificing or absorbing current.
  12. Explain the merits and limitations of SRAM and DRAM as Random Access Memory.
  13. SRAM retains stored information only as long as the power supply is on. SRAMs are costlier and consume more power. They have higher speed than DRAM. A form of flip-flop holds each bit of memory.
