This document discusses methods for extending the service life of existing bridges, including:
1. Better calculation methods such as improved shear capacity formulas, probabilistic analysis, and non-linear finite element models.
2. Better inspection methods like non-destructive testing and proofloading to assess bridge condition.
3. Better rehabilitation techniques like using carbon fiber sheets, external prestressing, and jacketing to strengthen bridges in need of repair.
Applying Experimental Results to the Shear Assessment Method for Solid Slab B...Eva Lantsoght
The combination of increased live loads and a more conservative shear capacity in the recently implemented Eurocodes, resulted in a large number of existing solid slab bridges in the Netherlands being shear-critical upon assessment. However, an enhancement of the shear capacity can occur in slabs under concentrated wheel loads due to transverse load redistribution. To quantify this effect, a comprehensive series of experiments on slabs and slabs strips under a concentrated load near to the support and under a combination of a concentrated and a line load was carried out. The experiments show the difference in behaviour for slabs, carrying the load in a two-dimensional way, as compared to beams in shear. The results from the laboratory research are used to develop recommendations, that are easily used in combination with the codes. These recommendations are implemented in a spreadsheet-based first-level assessment tool, the Quick Scan method. The assessment with this tool of selected cases of existing solid slab bridges shows that applying the experimental results into the assessment practice leads to an improved selection ability of the Quick Scan method.
Practical Application of Transverse Load Redistribution in Reinforced Concret...Eva Lantsoght
For an initial design or assessment of a reinforced concrete solid slab bridge, spreadsheet-based or hand calculations are typically used. The shear stress is compared to the shear capacity as prescribed by the code. The distributed loads result in a uniform shear stress at the support. Concentrated loads are less straightforward to take into account. It is known that transverse load redistribution occurs in slabs. To explore the topic of transverse load redistribution, experiments on elements subjected to a concentrated load close to the support were carried out. These elements had an increasing width, starting at 0.5 m and increasing with steps of 0.5 m up to 2.5 m, so that the effect of transverse load redistribution could be studied. The threshold effective width resulting from the experiments was then compared to load spreading methods, in order to give recommendations for the practical use with concentrated loads. It was found that the load spreading method as used in French practice is to be preferred. As compared to load spreading methods that were used previously, the French load spreading method results in smaller shear stresses at the support. This result allows for more economic designs and provides a better assessment tool.
Effective Width in Shear of Reinforced Concrete Solid Slab Bridges under Whee...Eva Lantsoght
For the assessment of reinforced concrete slab bridges in the Netherlands, the shear stress resulting from the dead loads and live loads is determined in a spreadsheet or from a finite element model. In a spreadsheet-based approach, an assumption for the distribution of the loads from the wheel prints is necessary. When finite element methods are used, it is necessary to determine over which length (a multiple of the effective depth) the peak shear stress can be distributed for comparison to the design shear capacity.
To recommend a load-spreading method, experiments were executed on slab strips of increasing widths. The shear capacity did not increase with the increasing width upon passing a threshold. This threshold is compared to different load spreading methods, indicating that a distribution from the far side of the wheel print is to be preferred. This recommendation is also supported by the results of a statistical analysis and the stress distribution in nonlinear finite element models.
To find the distribution width in a finite element method, a numerical model is compared to an experiment on a slab subjected to a concentrated load in which the support consists of a line of 7 bearings equipped with load cells measuring the reaction forces. These measurements were compared to the stress profile at the support from the model, showing that the peak can be distributed over 4 times the effective depth.
These recommendations for the effective width and distribution width are research-based tools that replace the previously used rules of thumb resulting from engineering judgement.
Recommendations for the Shear Assessment of Reinforced Concrete Solid Slab Br...Eva Lantsoght
As a result of the heavier live load models and more conservative shear approaches prescribed by the recently implemented Eurocodes, a large number of existing reinforced concrete solid slab bridges in the Netherlands were found to be shear-critical. The beneficial effect of the transverse load redistribution in slabs under concentrated loads is not taken into account. To quantify this effect, a comprehensive number of experiments was carried out. These results are used to formulate recommendations for the assessment practice for the case of solid slab bridges. The recommendations focus on the effective width over which the axle load can be distributed and its lower bound, the beneficial effect of transverse load redistribution and the influence of the yield strength of the reinforcement on the lower bound of the shear capacity. These recommendations are implemented in the “Quick Scan” method, leading to a significant reduction of the shear stresses.
Application of Modified Bond Model to the capacity of Ruytenschildt BridgeEva Lantsoght
The Ruytenschildt bridge in Friesland is a continuously supported concrete slab bridge, and was tested in two spans to failure in August 2014. The results of this experiment are valuable for the analysis of existing slab bridges and for analyzing the moment and shear capacity of reinforced concrete slabs and slab bridges.
Earlier analyses found that a large number of existing slab bridges in The Netherlands rate as insufficient for shear. However, these analyses did not take into account the beneficial effect of transverse load redistribution. Therefore, the Modified Bond Model was developed. This model covers beam shear, punching shear and flexure for reinforced concrete slabs.
The test results are now to compare to the predictions with the Modified Bond Model. Since the Modified Bond Model is independent of the failure mode, the maximum load that is found can be directly correlated to the maximum tandem load in the experiment. Comparing the test results on the bridge with the predictions based on the Modified Bond Model shows good correspondence. The results are also compared to a new proposal for vmin, the minimum shear stress at which shear failure takes place. For smaller value, a moment failure takes place.
While the presented results only show a comparison between 2 tests on an existing bridge and the proposed Modified Bond Model, the results indicate that the Modified Bond Model can become a useful tool for design and analysis of reinforced concrete slabs based on the principles of the theory of plasticity.
Applying Experimental Results to the Shear Assessment Method for Solid Slab B...Eva Lantsoght
The combination of increased live loads and a more conservative shear capacity in the recently implemented Eurocodes, resulted in a large number of existing solid slab bridges in the Netherlands being shear-critical upon assessment. However, an enhancement of the shear capacity can occur in slabs under concentrated wheel loads due to transverse load redistribution. To quantify this effect, a comprehensive series of experiments on slabs and slabs strips under a concentrated load near to the support and under a combination of a concentrated and a line load was carried out. The experiments show the difference in behaviour for slabs, carrying the load in a two-dimensional way, as compared to beams in shear. The results from the laboratory research are used to develop recommendations, that are easily used in combination with the codes. These recommendations are implemented in a spreadsheet-based first-level assessment tool, the Quick Scan method. The assessment with this tool of selected cases of existing solid slab bridges shows that applying the experimental results into the assessment practice leads to an improved selection ability of the Quick Scan method.
Practical Application of Transverse Load Redistribution in Reinforced Concret...Eva Lantsoght
For an initial design or assessment of a reinforced concrete solid slab bridge, spreadsheet-based or hand calculations are typically used. The shear stress is compared to the shear capacity as prescribed by the code. The distributed loads result in a uniform shear stress at the support. Concentrated loads are less straightforward to take into account. It is known that transverse load redistribution occurs in slabs. To explore the topic of transverse load redistribution, experiments on elements subjected to a concentrated load close to the support were carried out. These elements had an increasing width, starting at 0.5 m and increasing with steps of 0.5 m up to 2.5 m, so that the effect of transverse load redistribution could be studied. The threshold effective width resulting from the experiments was then compared to load spreading methods, in order to give recommendations for the practical use with concentrated loads. It was found that the load spreading method as used in French practice is to be preferred. As compared to load spreading methods that were used previously, the French load spreading method results in smaller shear stresses at the support. This result allows for more economic designs and provides a better assessment tool.
Effective Width in Shear of Reinforced Concrete Solid Slab Bridges under Whee...Eva Lantsoght
For the assessment of reinforced concrete slab bridges in the Netherlands, the shear stress resulting from the dead loads and live loads is determined in a spreadsheet or from a finite element model. In a spreadsheet-based approach, an assumption for the distribution of the loads from the wheel prints is necessary. When finite element methods are used, it is necessary to determine over which length (a multiple of the effective depth) the peak shear stress can be distributed for comparison to the design shear capacity.
To recommend a load-spreading method, experiments were executed on slab strips of increasing widths. The shear capacity did not increase with the increasing width upon passing a threshold. This threshold is compared to different load spreading methods, indicating that a distribution from the far side of the wheel print is to be preferred. This recommendation is also supported by the results of a statistical analysis and the stress distribution in nonlinear finite element models.
To find the distribution width in a finite element method, a numerical model is compared to an experiment on a slab subjected to a concentrated load in which the support consists of a line of 7 bearings equipped with load cells measuring the reaction forces. These measurements were compared to the stress profile at the support from the model, showing that the peak can be distributed over 4 times the effective depth.
These recommendations for the effective width and distribution width are research-based tools that replace the previously used rules of thumb resulting from engineering judgement.
Recommendations for the Shear Assessment of Reinforced Concrete Solid Slab Br...Eva Lantsoght
As a result of the heavier live load models and more conservative shear approaches prescribed by the recently implemented Eurocodes, a large number of existing reinforced concrete solid slab bridges in the Netherlands were found to be shear-critical. The beneficial effect of the transverse load redistribution in slabs under concentrated loads is not taken into account. To quantify this effect, a comprehensive number of experiments was carried out. These results are used to formulate recommendations for the assessment practice for the case of solid slab bridges. The recommendations focus on the effective width over which the axle load can be distributed and its lower bound, the beneficial effect of transverse load redistribution and the influence of the yield strength of the reinforcement on the lower bound of the shear capacity. These recommendations are implemented in the “Quick Scan” method, leading to a significant reduction of the shear stresses.
Application of Modified Bond Model to the capacity of Ruytenschildt BridgeEva Lantsoght
The Ruytenschildt bridge in Friesland is a continuously supported concrete slab bridge, and was tested in two spans to failure in August 2014. The results of this experiment are valuable for the analysis of existing slab bridges and for analyzing the moment and shear capacity of reinforced concrete slabs and slab bridges.
Earlier analyses found that a large number of existing slab bridges in The Netherlands rate as insufficient for shear. However, these analyses did not take into account the beneficial effect of transverse load redistribution. Therefore, the Modified Bond Model was developed. This model covers beam shear, punching shear and flexure for reinforced concrete slabs.
The test results are now to compare to the predictions with the Modified Bond Model. Since the Modified Bond Model is independent of the failure mode, the maximum load that is found can be directly correlated to the maximum tandem load in the experiment. Comparing the test results on the bridge with the predictions based on the Modified Bond Model shows good correspondence. The results are also compared to a new proposal for vmin, the minimum shear stress at which shear failure takes place. For smaller value, a moment failure takes place.
While the presented results only show a comparison between 2 tests on an existing bridge and the proposed Modified Bond Model, the results indicate that the Modified Bond Model can become a useful tool for design and analysis of reinforced concrete slabs based on the principles of the theory of plasticity.
Predicting the Shear Capacity of Reinforced Concrete Slabs subjected to Conce...Eva Lantsoght
The shear problem is typically studied by testing small, heavily reinforced, slender beams subjected to concentrated loads, resulting in a beam shear failure, or by testing slab-column connections, resulting in a punching shear failure. Slabs subjected to concentrated loads close to supports, as occurring when truck loads are placed on slab bridges, are much less studied. For this purpose, the Bond Model for concentric punching shear was studied at first. Then, modifications were made, resulting in the Modified Bond Model. The Modified Bond Model takes into account the enhanced capacity resulting from the direct strut that forms between the load and the support. Moreover, the Modified Bond Model is able to deal with moment changes between the support and the span, as occurs near continuous supports, and can take into account the reduction in capacity when the load is placed near to the edge. The resulting Modified Bond Model is compared to the results of experiments that were carried out at the Stevin laboratory. As compared to the Eurocodes (NEN-EN 1992-1-1:2005) and the ACI code (ACI 318-11), the Modified Bond Model leads to a better prediction.
Shear capacity of the ruytenschildt bridge Eva Lantsoght
In August 2014, the Ruytenschildt Bridge, a reinforced concrete solid slab bridge (reinforced with plain bars) in the Friesland province in the Netherlands was tested until failure. One of the goals of proof loading and testing this bridge to failure, was to study the failure mode of existing slab bridges. The combination of smaller shear capacities as prescribed by the Eurocode in combination with the heavier live load models, has raised concerns with regard to a number of existing slab bridges in the Netherlands. As the shear capacity of existing bridges is under study, the results of testing an actual slab bridge until failure are used to compare to the results of testing half-scale slab specimens in the laboratory, and the conclusions resulting from those experiments. In this paper, the results of the predictions based on the first order of approximation rating procedure from the Netherlands for shear, the Quick Scan method, as well as based on predictions of the failure mode and the average predicted capacity are compared to the experimental results. The predictions show a possibility of shear failure in the second span of the bridge. The experiment showed that both spans of the bridge failed in flexure. The observed failure mode is important, as some of the results indicate that the solid slab bridges, currently under discussion with regard to their shear capacity, fail in flexure in reality. Flexural failure is considered a ductile failure compared to the brittle failure mode in case of a shear failure.
Shear and moment capacity of the Ruytenschildt BridgeEva Lantsoght
In August 2014, the Ruytenschildt Bridge, a reinforced concrete solid slab bridge, in Friesland, the Netherlands was tested until failure. One of the goals of the experiment is to analyze the failure mode of the slab bridge under a tandem of 4 wheel loads and to compare the capacity of the full bridge structure to the predicted results, to have an idea of the residual strength of existing bridges. The methods used are experi-mental (testing of the bridge to failure in two of its five spans) and analytical. The analytical work involved predicting the bending moment capacity, the shear capacity and the punching capacity of the bridge. In both spans, the bridge failed in flexure. The total capacity during the experiment was significantly higher than pre-dicted. The results indicate that the traditional rating procedures for shear are very conservative when applied to slab bridges that benefit from transverse load redistribution.
Defining loading criteria for proof loading Eva Lantsoght
As the bridge stock in The Netherlands and Europe is ageing, various methods to analyse existing bridges are being studied. Proof loading of bridges is an option to study the capacity when crucial information about the structure is lacking. This information could be related to the material (for example, the effect of alkali-silica reaction on the structural capacity) as well as to the structural system (for example, the effect of restraints at the supports or transverse redistribution capacity). When it is decided to proof load a bridge, the question arises which maximum load should be attained during the experiment to approve the capacity of the bridge, and which criteria, based on the measurements during the test, would indicate that the proof loading needs to be aborted before reaching the maximum desired load (the so-called stop criteria). To define the required loading criteria, a review of the literature has been made, finite element models of existing viaducts have been made, and on these viaducts, proof loading tests have been carried out. These bridges were heavily instrumented, with a goal of learning as much as possible about the structural behaviour during proof loading. As a result of the analysis and experiments, recommendations are given for proof loading of bridges with respect to the required maximum load and the stop criteria.
These recommendations are important, since they form the basis of a guideline for proof loading of existing concrete bridges that is under development in The Netherlands.
Extended Strip Model for slabs subjected to a combination of loadsEva Lantsoght
Reinforced concrete slab bridges are assessed for a combination of loads that include self-weight, superimposed loads, and distributed and concentrated live loads. The shear capacity of reinforced concrete slabs subjected to a combination of loads is thus an important topic for the assessment of existing bridges. Currently, a plastic model exists for the assessment of reinforced concrete solid slabs subjected to a concentrated load: the Extended Strip Model, based on the Strip Model for concentric punching shear. To apply this model to slabs subjected to a combination of loads, the model needs to be adapted based on theoretical principles. The results are then compared with the results from experiments on half-scale slab bridges subjected to a combination of a concentrated load close to the support and a line load. The result of this comparison is that the proposed method is suitable to find a safe estimate of the maximum concentrated load on the slab. The implication of this development is that an improved tool is available to estimate the maximum load of a truck that can be placed on a reinforced concrete bridge, thus improving the current assessment.
Modeling of symmetrically and asymmetrically loaded reinforced concrete slabsEva Lantsoght
For the assessment of existing structures and the design of new structures, it is important to have a good understanding of the flow of forces, here applied to reinforced concrete solid slabs. Two analyti-cal methods are used: finite element models with 3D solid elements and a plasticity-based model that is suita-ble for hand calculations, the Modified Bond Model. The slabs that are modeled are half-scale models of rein-forced concrete solid slab bridges. As the Eurocode live load model prescribes more heavily loaded trucks in the first lane, the load model is asymmetric. For the finite element models, limited use is made of the redistri-bution capacity of the slab. For the Modified Bond Model, the influence of torsion and the edge effect need to be taken into account. The results of these studies improve the current state-of-the-art for analysis and design of reinforced concrete slabs.
Reliability index after proof load testing: viaduct De BeekEva Lantsoght
Proof load tests can be used for a field assessment of the bridge under study. This paper addresses the determination of the reliability index of an existing bridge by means of proof loading through the case study viaduct De Beek. The information of this bridge is used to determine the updated reliability index after proof load testing. A sensitivity study is carried out to identify the effect of the assumptions with regard to the coefficient of variation on the resistance and load effects. In the current practice of proof load testing with vehicles, it can typically only be demonstrated that a certain vehicle type can cross the bridge safely. The results in this paper provide a new insight on the updating of the reliability index after proof load testing. Consensus on the coefficients of variation that need to be used on the resistance and load effects, is still missing.
Load testing of reinforced concrete bridges in the NetherlandsEva Lantsoght
As the bridge stock in The Netherlands and Europe is ageing, various methods to analyze existing bridges are being studied. Load testing of bridges is an option to study the capacity when crucial information about the structure is lacking. This information could be related to the material (for example, the effect of ASR on the capacity) as well as to the structural system (for example, the effect of restraints at the supports or transverse redistribution capacity).
When it is decided to load test a bridge, the question arises which maximum load should be attained during the experiment to approve the capacity of the bridge, and which criteria, based on the measurements during the test, would indicate that the test needs to be aborted before reaching the maximum desired load (the “stop criteria”).
A number of reinforced concrete slab bridges have been load tested over the course of the past few years. These load tests were pilot cases, in which the bridges were heavily equipped with sensors, to study the bridges’ behavior at critical positions for bending moment and shear. The test results were then extensively analyzed, and compared to the stop criteria available in the currently used codes and guidelines.
As a result of the analysis and experiments, recommendations are given for proof loading of bridges. These recommendations are important, since they will form the basis of a guideline for proof loading of existing concrete bridges that is under development in The Netherlands.
Recommendations for proof load testing of reinforced concrete slab bridges - ...Eva Lantsoght
Proof loading of existing bridges is an option to study the capacity when crucial information about
the structure is lacking. To define the loading criteria for proof load testing, a review of the
literature has been made, finite element models of existing viaducts have been made, and on
these viaducts, proof loading tests have been carried out. These bridges were heavily
instrumented, to learn as much as possible about the structural behaviour during proof loading.
Additional laboratory experiments have been used to develop controlled loading protocols, and to
identify which stop criteria can be used for which case. As a result of the analysis and experiments,
recommendations are given for proof loading of bridges with respect to the required maximum
load and the stop criteria. These recommendations have resulted in a guideline for proof loading
of existing reinforced concrete slab bridges for The Netherlands.
Proof load testing of the viaduct De BeekEva Lantsoght
Proof load testing can be a suitable method to show that a bridge can carry the required loads
from the code without distress. This paper addresses the preparation, execution, and analysis of a
proof load test on a four-span reinforced concrete solid slab bridge, viaduct de Beek. The bridge
has one lane in each direction, but was restricted to a single lane, since an assessment showed
that the capacity is not sufficient to allow both lanes. For this proof load test, the bridge was
heavily equipped with sensors, so that early signs of distress can be seen. The difficulty in this test
was that, for safety reasons, only the first span could be tested, but that the lowest ratings were
found in the second span. A direct approval of the viaduct by proof loading was thus not possible,
and an analysis was necessary after the field test. The result of this analysis is that only by allowing
6.7% of plastic redistribution in the second span, sufficient capacity can be demonstrated.
Predicting the Shear Capacity of Reinforced Concrete Slabs subjected to Conce...Eva Lantsoght
The shear problem is typically studied by testing small, heavily reinforced, slender beams subjected to concentrated loads, resulting in a beam shear failure, or by testing slab-column connections, resulting in a punching shear failure. Slabs subjected to concentrated loads close to supports, as occurring when truck loads are placed on slab bridges, are much less studied. For this purpose, the Bond Model for concentric punching shear was studied at first. Then, modifications were made, resulting in the Modified Bond Model. The Modified Bond Model takes into account the enhanced capacity resulting from the direct strut that forms between the load and the support. Moreover, the Modified Bond Model is able to deal with moment changes between the support and the span, as occurs near continuous supports, and can take into account the reduction in capacity when the load is placed near to the edge. The resulting Modified Bond Model is compared to the results of experiments that were carried out at the Stevin laboratory. As compared to the Eurocodes (NEN-EN 1992-1-1:2005) and the ACI code (ACI 318-11), the Modified Bond Model leads to a better prediction.
Shear capacity of the ruytenschildt bridge Eva Lantsoght
In August 2014, the Ruytenschildt Bridge, a reinforced concrete solid slab bridge (reinforced with plain bars) in the Friesland province in the Netherlands was tested until failure. One of the goals of proof loading and testing this bridge to failure, was to study the failure mode of existing slab bridges. The combination of smaller shear capacities as prescribed by the Eurocode in combination with the heavier live load models, has raised concerns with regard to a number of existing slab bridges in the Netherlands. As the shear capacity of existing bridges is under study, the results of testing an actual slab bridge until failure are used to compare to the results of testing half-scale slab specimens in the laboratory, and the conclusions resulting from those experiments. In this paper, the results of the predictions based on the first order of approximation rating procedure from the Netherlands for shear, the Quick Scan method, as well as based on predictions of the failure mode and the average predicted capacity are compared to the experimental results. The predictions show a possibility of shear failure in the second span of the bridge. The experiment showed that both spans of the bridge failed in flexure. The observed failure mode is important, as some of the results indicate that the solid slab bridges, currently under discussion with regard to their shear capacity, fail in flexure in reality. Flexural failure is considered a ductile failure compared to the brittle failure mode in case of a shear failure.
Shear and moment capacity of the Ruytenschildt BridgeEva Lantsoght
In August 2014, the Ruytenschildt Bridge, a reinforced concrete solid slab bridge, in Friesland, the Netherlands was tested until failure. One of the goals of the experiment is to analyze the failure mode of the slab bridge under a tandem of 4 wheel loads and to compare the capacity of the full bridge structure to the predicted results, to have an idea of the residual strength of existing bridges. The methods used are experi-mental (testing of the bridge to failure in two of its five spans) and analytical. The analytical work involved predicting the bending moment capacity, the shear capacity and the punching capacity of the bridge. In both spans, the bridge failed in flexure. The total capacity during the experiment was significantly higher than pre-dicted. The results indicate that the traditional rating procedures for shear are very conservative when applied to slab bridges that benefit from transverse load redistribution.
Defining loading criteria for proof loading Eva Lantsoght
As the bridge stock in The Netherlands and Europe is ageing, various methods to analyse existing bridges are being studied. Proof loading of bridges is an option to study the capacity when crucial information about the structure is lacking. This information could be related to the material (for example, the effect of alkali-silica reaction on the structural capacity) as well as to the structural system (for example, the effect of restraints at the supports or transverse redistribution capacity). When it is decided to proof load a bridge, the question arises which maximum load should be attained during the experiment to approve the capacity of the bridge, and which criteria, based on the measurements during the test, would indicate that the proof loading needs to be aborted before reaching the maximum desired load (the so-called stop criteria). To define the required loading criteria, a review of the literature has been made, finite element models of existing viaducts have been made, and on these viaducts, proof loading tests have been carried out. These bridges were heavily instrumented, with a goal of learning as much as possible about the structural behaviour during proof loading. As a result of the analysis and experiments, recommendations are given for proof loading of bridges with respect to the required maximum load and the stop criteria.
These recommendations are important, since they form the basis of a guideline for proof loading of existing concrete bridges that is under development in The Netherlands.
Extended Strip Model for slabs subjected to a combination of loadsEva Lantsoght
Reinforced concrete slab bridges are assessed for a combination of loads that include self-weight, superimposed loads, and distributed and concentrated live loads. The shear capacity of reinforced concrete slabs subjected to a combination of loads is thus an important topic for the assessment of existing bridges. Currently, a plastic model exists for the assessment of reinforced concrete solid slabs subjected to a concentrated load: the Extended Strip Model, based on the Strip Model for concentric punching shear. To apply this model to slabs subjected to a combination of loads, the model needs to be adapted based on theoretical principles. The results are then compared with the results from experiments on half-scale slab bridges subjected to a combination of a concentrated load close to the support and a line load. The result of this comparison is that the proposed method is suitable to find a safe estimate of the maximum concentrated load on the slab. The implication of this development is that an improved tool is available to estimate the maximum load of a truck that can be placed on a reinforced concrete bridge, thus improving the current assessment.
Modeling of symmetrically and asymmetrically loaded reinforced concrete slabsEva Lantsoght
For the assessment of existing structures and the design of new structures, it is important to have a good understanding of the flow of forces, here applied to reinforced concrete solid slabs. Two analyti-cal methods are used: finite element models with 3D solid elements and a plasticity-based model that is suita-ble for hand calculations, the Modified Bond Model. The slabs that are modeled are half-scale models of rein-forced concrete solid slab bridges. As the Eurocode live load model prescribes more heavily loaded trucks in the first lane, the load model is asymmetric. For the finite element models, limited use is made of the redistri-bution capacity of the slab. For the Modified Bond Model, the influence of torsion and the edge effect need to be taken into account. The results of these studies improve the current state-of-the-art for analysis and design of reinforced concrete slabs.
Reliability index after proof load testing: viaduct De BeekEva Lantsoght
Proof load tests can be used for a field assessment of the bridge under study. This paper addresses the determination of the reliability index of an existing bridge by means of proof loading through the case study viaduct De Beek. The information of this bridge is used to determine the updated reliability index after proof load testing. A sensitivity study is carried out to identify the effect of the assumptions with regard to the coefficient of variation on the resistance and load effects. In the current practice of proof load testing with vehicles, it can typically only be demonstrated that a certain vehicle type can cross the bridge safely. The results in this paper provide a new insight on the updating of the reliability index after proof load testing. Consensus on the coefficients of variation that need to be used on the resistance and load effects, is still missing.
Load testing of reinforced concrete bridges in the NetherlandsEva Lantsoght
As the bridge stock in The Netherlands and Europe is ageing, various methods to analyze existing bridges are being studied. Load testing of bridges is an option to study the capacity when crucial information about the structure is lacking. This information could be related to the material (for example, the effect of ASR on the capacity) as well as to the structural system (for example, the effect of restraints at the supports or transverse redistribution capacity).
When it is decided to load test a bridge, the question arises which maximum load should be attained during the experiment to approve the capacity of the bridge, and which criteria, based on the measurements during the test, would indicate that the test needs to be aborted before reaching the maximum desired load (the “stop criteria”).
A number of reinforced concrete slab bridges have been load tested over the course of the past few years. These load tests were pilot cases, in which the bridges were heavily equipped with sensors, to study the bridges’ behavior at critical positions for bending moment and shear. The test results were then extensively analyzed, and compared to the stop criteria available in the currently used codes and guidelines.
As a result of the analysis and experiments, recommendations are given for proof loading of bridges. These recommendations are important, since they will form the basis of a guideline for proof loading of existing concrete bridges that is under development in The Netherlands.
Recommendations for proof load testing of reinforced concrete slab bridges - ...Eva Lantsoght
Proof loading of existing bridges is an option to study the capacity when crucial information about
the structure is lacking. To define the loading criteria for proof load testing, a review of the
literature has been made, finite element models of existing viaducts have been made, and on
these viaducts, proof loading tests have been carried out. These bridges were heavily
instrumented, to learn as much as possible about the structural behaviour during proof loading.
Additional laboratory experiments have been used to develop controlled loading protocols, and to
identify which stop criteria can be used for which case. As a result of the analysis and experiments,
recommendations are given for proof loading of bridges with respect to the required maximum
load and the stop criteria. These recommendations have resulted in a guideline for proof loading
of existing reinforced concrete slab bridges for The Netherlands.
Proof load testing of the viaduct De BeekEva Lantsoght
Proof load testing can be a suitable method to show that a bridge can carry the required loads
from the code without distress. This paper addresses the preparation, execution, and analysis of a
proof load test on a four-span reinforced concrete solid slab bridge, viaduct de Beek. The bridge
has one lane in each direction, but was restricted to a single lane, since an assessment showed
that the capacity is not sufficient to allow both lanes. For this proof load test, the bridge was
heavily equipped with sensors, so that early signs of distress can be seen. The difficulty in this test
was that, for safety reasons, only the first span could be tested, but that the lowest ratings were
found in the second span. A direct approval of the viaduct by proof loading was thus not possible,
and an analysis was necessary after the field test. The result of this analysis is that only by allowing
6.7% of plastic redistribution in the second span, sufficient capacity can be demonstrated.
Reinforced arches have a wide range of applications. This paper discuss about use of fibre reinforced polymer (FRP) for strengthening of reinforced concrete arches. The experiment is conducted on shallow arches. Three arches are tested. One is used as a control arch while other two are strengthened using FRP strips in different patterns. Six non symmetric point loads are equally spaced along the arches. The arch is modelled as a polygon.
Concrete Repair: Bridges and Tunnels--Epoxies jbors
Examples of maintenance, rehabilitation and repair of transportation structures including bridges and tunnels using epoxy products for structural repair and protection. ASTM C881 catagories are explained. ChemCo Systems, Redwood City, CA manufactures epoxies for these applications (www.chemcosystems.com).
Bridging the gap between one way and two-way shear in slabsEva Lantsoght
The shear capacity of slabs under concentrated loads is particularly of interest for bridge decks under concentrated live loads. Often, one-way shear will be analyzed by considering the slab as a wide beam (without taking advantage of the transverse load redistribution capacity of the slab) and two-way shear by considering the punching area around the load. Since experiments showed that the failure mode of slabs under concentrated loads is a combination of one-way and two-way shear as well as two-way flexure, a method was sought that bridges the gap between traditional one-way and two-way shear approaches. The proposed method is a plasticity-based method. This method is based on the Strip Model for concentric punching shear and takes the effects of the geometry into account for describing the ultimate capacity of a slab under a concentrated load. The model consists of “strips” that work with arching action (one-way shear) and slab “quadrants” that work in two-way shear. As such, the resulting Extended Strip Model is suitable for the design and assessment of elements that are in the transition zone between one-way and two-way shear.
Growing of Precast construction system has given emphasis on improving work zone safety, reducing construction time and environmental impact, while maintaining the quality. The connections are the most important part of precast construction systems, being the general behavior of the precast structures related to their design, construction and performance. In this civil engineering project a trial to compare the strength of three types of portal frames viz. Monolithic Portal Frame, Portal Frame with corbel and Portal Frame without corbel and their deflections at various loads were observed and derived conclusion which one is efficient among all frames designed and cast.
Uses of Larsa 4 d and Lusas 4 D models for Implementation of Cable Stayed ...Rajesh Prasad
The paper deals with how an engineering challenge confronted in a busy yard due to presence of a distressed bridge(ROB) was replaced by a Cable Stayed Bridge by adopting safe practices with proper quality and within the time frame. The paper was presented today ie 18.08.17 in a lecture organised by IIBE at Institution of Engineers, Mumbai
There was a Bridge 2018 Conference on Innovative Technologies of Bridges organised by IIBE at Lucknow. During the conference held on 25.05.18 this paper was presented by Rajesh Prasad, ED Metro RVNL.
Shear and Moment Capacity of the Ruytenschildt BridgeEva Lantsoght
In August 2014, the Ruytenschildt Bridge, a reinforced concrete solid slab bridge, in Friesland, the Netherlands was tested until failure. One of the goals of the experiment is to analyze the failure mode of the slab bridge under a tandem of 4 wheel loads and to compare the capacity of the full bridge structure to the predicted results, to have an idea of the residual strength of existing bridges. The methods used are experi-mental (testing of the bridge to failure in two of its five spans) and analytical. The analytical work involved predicting the bending moment capacity, the shear capacity and the punching capacity of the bridge. In both spans, the bridge failed in flexure. The total capacity during the experiment was significantly higher than pre-dicted. The results indicate that the traditional rating procedures for shear are very conservative when applied to slab bridges that benefit from transverse load redistribution.
There was a Bridge 2018 Conference on Innovative Technologies of Bridges organised by IIBE at Lucknow. During the conference held on 25.05.18 this paper was presented by Rajesh Prasad, ED Metro RVNL.
Detailed Power point presentation on Implementation of 4 lane Cable Stayed Road over bridge at Bardhman- a future fast track model for construction over busy and longer Railway yards in India
Dr Boulent Imam presented a seminar titled "Risk-based bridge assessment under changing load-demand and environmental conditions" as part of the SMART Seminar Series on 17th July 2018.
More information: https://news.eis.uow.edu.au/event/risk-based-bridge-assessment-under-changing-load-demand-and-environmental-conditions/
Keep updated with future events: http://www.uoweis.co/events/category/smart-infrastructure-facility/
Stop criteria for proof load tests verified with field and laboratory testing...Eva Lantsoght
As the existing bridge stock is aging, improved assessment methods such as proof load testing become increasingly important. Proof load testing involves large loads, and as such the risk for the structure and personnel can be significant. To capture the structural response, extensive measurements are applied to proof load tests. Stop criteria, based on the measured quantities, are used to identify when further loading in a proof load test is not permitted. For proof load testing of buildings, stop criteria are available in existing codes. For bridges, recently stop criteria based on laboratory tests on beams reinforced with plain bars have been proposed. Subsequently, improved stop criteria were developed based on theoretical considerations for bending moment and shear. The stop criteria from the codes and the proposed stop criteria are compared to the results from field testing to collapse on the Ruytenschildt Bridge, and to the results from laboratory tests on beams sawn from the Ruytenschildt Bridge. This comparison shows that only a small change to the stop criteria derived from laboratory testing is necessary. The experimental evidence strengthens the recommendation for using the proposed stop criteria in proof load tests on bridges for bending moment, whereas further testing to confirm the stop criteria for shear is necessary.
Como evaluar la capacidad de puentes de hormigón existentes?Eva Lantsoght
Después de la expansión de la red vial del país, la comunidad de ingenieros civiles y el gobierno tienen un número mayor de puentes existentes a manejar. En el futuro, esos puentes necesitaran mantenimiento y adopciones a los cambios en términos de las cargas vivas. En ese artículo vamos a ver como en Europa y América del Norte se está evaluando la capacidad de puentes de hormigón existentes. Típicamente, la evaluación es primero analítico, y después, dependiendo de la necesidad, experimental. En caso de concluir que no hay capacidad suficiente, diseñamos un refuerzo estructural para el puente. Revisaremos diferentes métodos de cálculo, inspección, pruebas de carga, y reforzamiento para puentes de hormigón existentes.
Recommendations for proof load testing of reinforced concrete slab bridges - ...Eva Lantsoght
Proof loading of existing bridges is an option to study the capacity when crucial information about
the structure is lacking. To define the loading criteria for proof load testing, a review of the
literature has been made, finite element models of existing viaducts have been made, and on
these viaducts, proof loading tests have been carried out. These bridges were heavily
instrumented, to learn as much as possible about the structural behaviour during proof loading.
Additional laboratory experiments have been used to develop controlled loading protocols, and to
identify which stop criteria can be used for which case. As a result of the analysis and experiments,
recommendations are given for proof loading of bridges with respect to the required maximum
load and the stop criteria. These recommendations have resulted in a guideline for proof loading
of existing reinforced concrete slab bridges for The Netherlands.
Determination of loading protocol and stop criteria for proof loading with be...Eva Lantsoght
Proof loading of existing bridges is an interesting option when insufficient information about a bridge is available. To safely carry out a proof loading test, high loads are placed on the bridge. To avoid permanent damage to the structure, a controlled loading protocol needs to be described, and the measurements need to be closely monitored to identify the onset of distress. The criteria from existing codes and guidelines to evaluate the measurements, called stop criteria, are not universally applicable. To develop recommendations for proof loading of reinforced concrete solid slab bridges, beam experiments were analysed. The beams were heavily instrumented to evaluate the existing stop criteria, and possibly develop new stop criteria. The result of these experiments is the development of a standard loading protocol for the proof loading of reinforced concrete slab bridges. Recommendations for the use of the stop criteria are also formulated. These insights are used to develop a new guideline for the proof loading of reinforced concrete slab bridges in the Netherlands.
Observability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdfPaige Cruz
Monitoring and observability aren’t traditionally found in software curriculums and many of us cobble this knowledge together from whatever vendor or ecosystem we were first introduced to and whatever is a part of your current company’s observability stack.
While the dev and ops silo continues to crumble….many organizations still relegate monitoring & observability as the purview of ops, infra and SRE teams. This is a mistake - achieving a highly observable system requires collaboration up and down the stack.
I, a former op, would like to extend an invitation to all application developers to join the observability party will share these foundational concepts to build on:
Removing Uninteresting Bytes in Software FuzzingAftab Hussain
Imagine a world where software fuzzing, the process of mutating bytes in test seeds to uncover hidden and erroneous program behaviors, becomes faster and more effective. A lot depends on the initial seeds, which can significantly dictate the trajectory of a fuzzing campaign, particularly in terms of how long it takes to uncover interesting behaviour in your code. We introduce DIAR, a technique designed to speedup fuzzing campaigns by pinpointing and eliminating those uninteresting bytes in the seeds. Picture this: instead of wasting valuable resources on meaningless mutations in large, bloated seeds, DIAR removes the unnecessary bytes, streamlining the entire process.
In this work, we equipped AFL, a popular fuzzer, with DIAR and examined two critical Linux libraries -- Libxml's xmllint, a tool for parsing xml documents, and Binutil's readelf, an essential debugging and security analysis command-line tool used to display detailed information about ELF (Executable and Linkable Format). Our preliminary results show that AFL+DIAR does not only discover new paths more quickly but also achieves higher coverage overall. This work thus showcases how starting with lean and optimized seeds can lead to faster, more comprehensive fuzzing campaigns -- and DIAR helps you find such seeds.
- These are slides of the talk given at IEEE International Conference on Software Testing Verification and Validation Workshop, ICSTW 2022.
Alt. GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using ...James Anderson
Effective Application Security in Software Delivery lifecycle using Deployment Firewall and DBOM
The modern software delivery process (or the CI/CD process) includes many tools, distributed teams, open-source code, and cloud platforms. Constant focus on speed to release software to market, along with the traditional slow and manual security checks has caused gaps in continuous security as an important piece in the software supply chain. Today organizations feel more susceptible to external and internal cyber threats due to the vast attack surface in their applications supply chain and the lack of end-to-end governance and risk management.
The software team must secure its software delivery process to avoid vulnerability and security breaches. This needs to be achieved with existing tool chains and without extensive rework of the delivery processes. This talk will present strategies and techniques for providing visibility into the true risk of the existing vulnerabilities, preventing the introduction of security issues in the software, resolving vulnerabilities in production environments quickly, and capturing the deployment bill of materials (DBOM).
Speakers:
Bob Boule
Robert Boule is a technology enthusiast with PASSION for technology and making things work along with a knack for helping others understand how things work. He comes with around 20 years of solution engineering experience in application security, software continuous delivery, and SaaS platforms. He is known for his dynamic presentations in CI/CD and application security integrated in software delivery lifecycle.
Gopinath Rebala
Gopinath Rebala is the CTO of OpsMx, where he has overall responsibility for the machine learning and data processing architectures for Secure Software Delivery. Gopi also has a strong connection with our customers, leading design and architecture for strategic implementations. Gopi is a frequent speaker and well-known leader in continuous delivery and integrating security into software delivery.
Essentials of Automations: The Art of Triggers and Actions in FMESafe Software
In this second installment of our Essentials of Automations webinar series, we’ll explore the landscape of triggers and actions, guiding you through the nuances of authoring and adapting workspaces for seamless automations. Gain an understanding of the full spectrum of triggers and actions available in FME, empowering you to enhance your workspaces for efficient automation.
We’ll kick things off by showcasing the most commonly used event-based triggers, introducing you to various automation workflows like manual triggers, schedules, directory watchers, and more. Plus, see how these elements play out in real scenarios.
Whether you’re tweaking your current setup or building from the ground up, this session will arm you with the tools and insights needed to transform your FME usage into a powerhouse of productivity. Join us to discover effective strategies that simplify complex processes, enhancing your productivity and transforming your data management practices with FME. Let’s turn complexity into clarity and make your workspaces work wonders!
Securing your Kubernetes cluster_ a step-by-step guide to success !KatiaHIMEUR1
Today, after several years of existence, an extremely active community and an ultra-dynamic ecosystem, Kubernetes has established itself as the de facto standard in container orchestration. Thanks to a wide range of managed services, it has never been so easy to set up a ready-to-use Kubernetes cluster.
However, this ease of use means that the subject of security in Kubernetes is often left for later, or even neglected. This exposes companies to significant risks.
In this talk, I'll show you step-by-step how to secure your Kubernetes cluster for greater peace of mind and reliability.
UiPath Test Automation using UiPath Test Suite series, part 4DianaGray10
Welcome to UiPath Test Automation using UiPath Test Suite series part 4. In this session, we will cover Test Manager overview along with SAP heatmap.
The UiPath Test Manager overview with SAP heatmap webinar offers a concise yet comprehensive exploration of the role of a Test Manager within SAP environments, coupled with the utilization of heatmaps for effective testing strategies.
Participants will gain insights into the responsibilities, challenges, and best practices associated with test management in SAP projects. Additionally, the webinar delves into the significance of heatmaps as a visual aid for identifying testing priorities, areas of risk, and resource allocation within SAP landscapes. Through this session, attendees can expect to enhance their understanding of test management principles while learning practical approaches to optimize testing processes in SAP environments using heatmap visualization techniques
What will you get from this session?
1. Insights into SAP testing best practices
2. Heatmap utilization for testing
3. Optimization of testing processes
4. Demo
Topics covered:
Execution from the test manager
Orchestrator execution result
Defect reporting
SAP heatmap example with demo
Speaker:
Deepak Rai, Automation Practice Lead, Boundaryless Group and UiPath MVP
Dr. Sean Tan, Head of Data Science, Changi Airport Group
Discover how Changi Airport Group (CAG) leverages graph technologies and generative AI to revolutionize their search capabilities. This session delves into the unique search needs of CAG’s diverse passengers and customers, showcasing how graph data structures enhance the accuracy and relevance of AI-generated search results, mitigating the risk of “hallucinations” and improving the overall customer journey.
Communications Mining Series - Zero to Hero - Session 1DianaGray10
This session provides introduction to UiPath Communication Mining, importance and platform overview. You will acquire a good understand of the phases in Communication Mining as we go over the platform with you. Topics covered:
• Communication Mining Overview
• Why is it important?
• How can it help today’s business and the benefits
• Phases in Communication Mining
• Demo on Platform overview
• Q/A
Epistemic Interaction - tuning interfaces to provide information for AI supportAlan Dix
Paper presented at SYNERGY workshop at AVI 2024, Genoa, Italy. 3rd June 2024
https://alandix.com/academic/papers/synergy2024-epistemic/
As machine learning integrates deeper into human-computer interactions, the concept of epistemic interaction emerges, aiming to refine these interactions to enhance system adaptability. This approach encourages minor, intentional adjustments in user behaviour to enrich the data available for system learning. This paper introduces epistemic interaction within the context of human-system communication, illustrating how deliberate interaction design can improve system understanding and adaptation. Through concrete examples, we demonstrate the potential of epistemic interaction to significantly advance human-computer interaction by leveraging intuitive human communication strategies to inform system design and functionality, offering a novel pathway for enriching user-system engagements.
DevOps and Testing slides at DASA ConnectKari Kakkonen
My and Rik Marselis slides at 30.5.2024 DASA Connect conference. We discuss about what is testing, then what is agile testing and finally what is Testing in DevOps. Finally we had lovely workshop with the participants trying to find out different ways to think about quality and testing in different parts of the DevOps infinity loop.
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...Neo4j
Leonard Jayamohan, Partner & Generative AI Lead, Deloitte
This keynote will reveal how Deloitte leverages Neo4j’s graph power for groundbreaking digital twin solutions, achieving a staggering 100x performance boost. Discover the essential role knowledge graphs play in successful generative AI implementations. Plus, get an exclusive look at an innovative Neo4j + Generative AI solution Deloitte is developing in-house.
GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024Neo4j
Neha Bajwa, Vice President of Product Marketing, Neo4j
Join us as we explore breakthrough innovations enabled by interconnected data and AI. Discover firsthand how organizations use relationships in data to uncover contextual insights and solve our most pressing challenges – from optimizing supply chains, detecting fraud, and improving customer experiences to accelerating drug discoveries.
GraphRAG is All You need? LLM & Knowledge GraphGuy Korland
Guy Korland, CEO and Co-founder of FalkorDB, will review two articles on the integration of language models with knowledge graphs.
1. Unifying Large Language Models and Knowledge Graphs: A Roadmap.
https://arxiv.org/abs/2306.08302
2. Microsoft Research's GraphRAG paper and a review paper on various uses of knowledge graphs:
https://www.microsoft.com/en-us/research/blog/graphrag-unlocking-llm-discovery-on-narrative-private-data/
Climate Impact of Software Testing at Nordic Testing DaysKari Kakkonen
My slides at Nordic Testing Days 6.6.2024
Climate impact / sustainability of software testing discussed on the talk. ICT and testing must carry their part of global responsibility to help with the climat warming. We can minimize the carbon footprint but we can also have a carbon handprint, a positive impact on the climate. Quality characteristics can be added with sustainability, and then measured continuously. Test environments can be used less, and in smaller scale and on demand. Test techniques can be used in optimizing or minimizing number of tests. Test automation can be used to speed up testing.
Smart TV Buyer Insights Survey 2024 by 91mobiles.pdf91mobiles
91mobiles recently conducted a Smart TV Buyer Insights Survey in which we asked over 3,000 respondents about the TV they own, aspects they look at on a new TV, and their TV buying preferences.
2. 2Extending the service life of existing bridges
Overview
• Introduction
• Better calculation methods
• Better inspection methods
• Better rehabilitation methods
• Summary
3. 3Extending the service life of existing bridges
Introduction
Problem Statement
Bridges from 60s and 70s
The Hague in 1959
Increased live loads
heavy and long truck
(600 kN > perm. max = 50ton)
End of service life + larger loads
4. 4Extending the service life of existing bridges
Introduction
Highway network in the Netherlands
• NL: 60% of bridges built before 1976
• First checks since mid-2000s
• 3715 structures to be studied
• 600 slab bridges shear critical
• But: checks according to design
rules
• => Residual capacity???
• Hidden reserves of the bearing
capacity Highways in the Netherlands
5. 5Extending the service life of existing bridges
Introduction
Aging infrastructure in Europe
6. 6Extending the service life of existing bridges
Principle of Levels of Approximation
Model Code 2010
• Approach from fib Model
Code 2010
• Solution strategy = different
levels of approximation
• Eg: Shear capacity in Model
Code 2010
7. 7Extending the service life of existing bridges
Better calculation methods
• Shear capacity
• Testing elements
• Better understanding of
behavior
• Fatigue life of concrete in
compression
• Probabilistic analysis
• Improved live load factors
• Advanced analysis
• Non-linear finite element
models
8. 8Extending the service life of existing bridges
Shear capacity
Importance of shear behavior
Shear failure of the de la Concorde bridge, Laval
=> five people killed, six others seriously injured
9. 9Extending the service life of existing bridges
Shear capacity
Beam shear and punching shear
• Design: shear capacity of slabs
• Flexural failure before shear failure
• Punching shear formulas
• Beam shear formulas over effective width
Beam shear, one-way shear Punching shear, two-way shear
10. 10Extending the service life of existing bridges
Shear capacity
The riddle of shear failure
• Since 1899 (Ritter)
• 1955: collapse of
warehouse
• Most experiments:
• Beams
• Heavily reinforced
• Slender (a/d ≥ 2,5)
• Small size
• Basis for design codes
amount of shear experiments done
12. 12Extending the service life of existing bridges
Shear
Mechanisms of shear transfer
Concrete in compression
zone
Dowel action
Aggregate interlock
Stirrups
13. 13Extending the service life of existing bridges
Shear capacity
Distance between load and support
Shear span to depth ratio: Kani’s valley
Influence of the support
14. 14Extending the service life of existing bridges
Shear capacity
Influence of reinforcement ratio
17. 17Extending the service life of existing bridges
Background
Design codes for Shear
0
500
1000
1500
2000
2500
1 1,2 1,4 1,6 1,8 2 2,2 2,4 2,6 2,8 3a/d
Pu(kN)
Regan SS
NEN SS
ACI SS
EN
Different design codes – different approaches
19. 19Extending the service life of existing bridges
Testing elements – slabs in shear
Size: 5m x 2,5m (variable) x 0,3m = scale 1:2
Continuous support, Line supports
Concentrated load: vary a/d and position along width
20. 20Extending the service life of existing bridges
Testing elements
Slabs in shear
• 2nd
series experimental work:
• Slabs under combined loading
• Line load
• Preloading
• 50% of strength from slab strips
• Concentrated load
• loading until failure
• Conclusions from 1st
series valid
when combining loads?
• Total: 26 experiments, 8 slabs
22. 22Extending the service life of existing bridges
Testing elements – slabs in shear
BS = 0,5m wide BX = 2,0m wide
23. 23Extending the service life of existing bridges
Testing elements – slabs in shear
• Transverse load redistribution
• Geometry governing in slabs
• Location of load
• result of different load-carrying paths
• Mid support vs end support
• influence of transverse moment
• Wheel size
• more 3D action
24. 24Extending the service life of existing bridges
Testing elements – slabs in shear
5000 1000 1500 2000 2500
b (mm)
25. 25Extending the service life of existing bridges
Testing elements – slabs in shear
45° load spreading - Dutch practice 45° load spreading – French practice
Or: fixed value (eg. 1m)
26. 26Extending the service life of existing bridges
Testing elements – slabs in shear
Modified Bond Model (1)
• Based on Bond Model
(Alexander and
Simmonds, 1990)
• For slabs with
concentrated load in
middle
27. 27Extending the service life of existing bridges
Testing elements – slabs in shear
Modified Bond Model (2)
28. 28Extending the service life of existing bridges
Testing elements – slabs in shear
Modified Bond Model (3)
• Adapted for slabs with concentrated
load close to support
• Geometry is governing as in
experiments
• Determine factor that reduces capacity
of “radial” strip
• Maximum load: based on sum
capacity of 4 strips
29. 29Extending the service life of existing bridges
Testing elements
beams in shear
• Beams from existing
bridges
• Beams cast in the
laboratory
• Different combinations of
load
• Comparison with Eurocode
• Recommendations for
M/Vd
30. 30Extending the service life of existing bridges
Testing elements
Beams in shear
• Changing position of load
• Effect of moment distribution on shear
capacity
• Photogrammetry + LVDTs
31. 31Extending the service life of existing bridges
Testing elements
Time dependent effects
• Time dependent effects
• Speed of loading vs direct
tensile capacity
• Beams under sustained load
in shear
32. 32Extending the service life of existing bridges
Testing elements
Transversally prestressed decks
• Bridge decks cast in
between girders
• Compressive membrane
action => increased capacity
34. 34Extending the service life of existing bridges
Application of test results to analysis
Live load models
Truck load, AASHTO
Tandem loads, EC
35. 35Extending the service life of existing bridges
Application of test results to analysis
• Loading at edge
• Asymmetric effective width
36. 36Extending the service life of existing bridges
Application of test results to analysis
Effective width per axle instead of per wheel print
37. 37Extending the service life of existing bridges
Application of test results to analysis
• Larger effective width
• Smaller shear stress
• More economic design
• Sharper assessment
38. 38Extending the service life of existing bridges
Improved fatigue models
Reference fc,mean,max (MPa) Influence fc?
Petkovic et al., 1990 95 MPa No
Kim & Kim, 1996 103 MPa Yes
Hordijk et al., 1995 78,2 MPa No
Lohaus et al., 2011
Lohaus & Anders, 2006
170 MPa
(fibers)
MC 90 too
conservative
Tue & Mucha, 2006 65 MPa Yes
Effect of high strength concrete?
Conclusion fib task group 8.2: lower fatigue strength
for high strength concrete
Linear S-N curve starts at+- 100 cycles
Effect of few heavily loaded trucks?
41. 41Extending the service life of existing bridges
Existing codes for fatigue
Model Code 2010, fck in formules, γc = 1,5
EC 2-2: very conservative
EC 2-2 + NB: jump at Ni = 106
γc = 1,35
Kim & Kim: influence fc’ , γc = 1,5
42. 42Extending the service life of existing bridges
Database of test results fatigue
• 429 test results
• 234 no fibers
• ≤ 145 MPa
• 195 with fibers
• ≤ 226 MPa
43. 43Extending the service life of existing bridges
Improved fatigue model for analysis
• Proposed replacement
for Dutch National Annex
• k1 = 1
• γc,fat = γc = 1,5
• At 1 cycle: Smax = 1
• Iterative, but stable
• 1st iteration, try Smax = 1
• Converges at 3rd
iteration
( ) 66 1
log for 10
1
max
i i
max,EC
S
N N
S
−
= ≤
−
3
1 1 1 *
250 7
ck
max,EC i
f
S R
= − − − ÷ ÷
* min
i
max,EC
S
R
S
=
( ), 1 0 1
400
ck
cd fat cc cd
f
f k t fβ
= − ÷
44. 44Extending the service life of existing bridges
Improved fatigue model for analysis
• Comparison to test results forSmin = 0,05
45. 45Extending the service life of existing bridges
Probabilistic analysis
Full reliability analysis
• Full reliability calculation
• Variability of material
properties
• Variability of load effects
• Variability of dimensions
• Combination with finite
element models
• Spatial variability of material
properties
• Result: chance of failure
46. 46Extending the service life of existing bridges
Probabilistic analysis
Improved live load factors
• Data of real traffic
• WIM campaign
• Probabilistic analysis
• Different levels
• Analysis not same as
design
• Load factors for levels:
• Repair level
• Unfit for use level
• Code: NEN 8700
Steenbergen, R. D. J. M. et al., 2011
47. 47Extending the service life of existing bridges
Non-linear finite element models
• Advanced models
• Improved material models
• Tensile capacity of concrete
• Fracture mechanics
• Requires computational
power
• LoA IV method
• Better estimate for critical
infrastructure
48. 48Extending the service life of existing bridges
Non-linear finite element models
Link with experiments
(Doorgeest, 2012)
Models of 1,5m wide
a = center-to-center distance
between load and support
Effective width from shear stress
distribution over support
49. 49Extending the service life of existing bridges
Non-linear finite element models
Link with experiments
Models of 2,5m wide
a = center-to-center distance
between load and support
Effective width from shear
stress distribution over support
50. 50Extending the service life of existing bridges
Non-linear finite element models
Link with experiments
Models of 3,5m wide
a = center-to-center distance
between load and support
Effective width from shear
stress distribution over support
51. 51Extending the service life of existing bridges
Non-linear finite element models
Link with experiments
• French load spreading
method gives safe estimate
of beff
• NLFEA: beff depends slightly
on slab width
• NLFEA: influence of a/d less
than in French method
• French method
sufficient for LoA 1
52. 52Extending the service life of existing bridges
Better inspection methods
• Non-destructive test
methods
• Proofloading
• Bridge management
systems
53. 53Extending the service life of existing bridges
Non-destructive test methods
• Electrical resistivity
• Gives idea of corrosion rates in
concrete decks reinforced with
steel
54. 54Extending the service life of existing bridges
Non-destructive test methods
• Ground penetrating radar
• Objects inside depth of
concrete
• Reinforcement
• Wire meshes
55. 55Extending the service life of existing bridges
Non-destructive test methods
• Infrared thermography
• Detect concrete defects:
• cracks
• delaminations
• concrete disintegration
56. 56Extending the service life of existing bridges
Non-destructive test methods
• Combine methods to get
overview of condition of bridge
• More info: NDToolbox
• www.ndtoolbox.org
57. 57Extending the service life of existing bridges
Proofloading
Case Ruytenschildtbrug
• Proofloading to assess
capacity of existing bridge
• Study cracks and
deformations for applied
loads
• Crack formation: acoustic
emissions measurements
• Ruytenschildtbrug: testing to
failure
59. 59Extending the service life of existing bridges
Proofloading
Finding position of test loads
• Skewed viaduct
• Distance for shear av = 2,5dl
• Edge distance
• Tandem loads of Eurocode
• Result: center of axle at
2,5dl
60. 60Extending the service life of existing bridges
Proofloading
Failure mode
• Monte Carlo simulation
( )shear momentfp P= <
( )f shear momentp P uc uc= >
( )
( )
1/3,
1/3
,
, , ,
100
100
Rd c
l ck
Ed c
shear
Rd c
Rd c test l c mean
C
k f
v
uc
Testv C k f
Predicted
ρ
γ
ρ
= =
2
2
s y
Ed
moment
Rd
s u
M
a
A f d
M
uc
Test aM
A f d
Predicted
− ÷
= =
− ÷ ÷
61. 61Extending the service life of existing bridges
Probability of shear failure
Test/Predicted shear
From slab shear experiments TU Delft Test/Predicted wrt
Eurocode expression
62. 62Extending the service life of existing bridges
Probability of shear failure
Resulting limit state function
63. 63Extending the service life of existing bridges
Probability of shear failure
Results
• Span 1: 85,2% probability failure in bending before failure in
shear
• Span 2: 45,9% probability failure in bending before failure in
shear
• Span 2: 98,2% probability failure in bending before failure in
shear when using from slab shear experiments
V
Test
Predicted
÷
64. 64Extending the service life of existing bridges
Probability of shear failure
Uncertainties
• Effect skew on effective
width
• Material properties?
• Samples after proofloading
• Steel samples
• Concrete cores
65. 65Extending the service life of existing bridges
Analysis Ruytenschildtbrug
With Modified Bond Model
• Using measured average
material properties
• First span
• Ptot =2864kN
• Ptest=3049kN
• Second span
• Ptot = 3816kN
• Ptest= 3995 kN
• Failure in bending before shear
66. 66Extending the service life of existing bridges
Bridge management systems
• For bridge owners
• Better management of data
• Quick access to
• as-built plans
• Inspection reports
• Prioritize inspection and
repair efforts
67. 67Extending the service life of existing bridges
Better rehabilitation techniques
• Carbon fiber sheets
• External prestressing
• Jacketing of columns
• Overlays
• ECC
• UHPC
• Structural health monitoring
68. 68Extending the service life of existing bridges
Carbon fiber sheets
• External reinforcement
• Increases bending moment
capacity
• Problem: delamination of
sheets
69. 69Extending the service life of existing bridges
External prestressing
• Increase prestressing force
• For example, necessary
after loss of prestress from
time-dependent effects
• Creep
• Shrinkage
• Relaxation
70. 70Extending the service life of existing bridges
Jacketing of columns
• Steel jacketing
• Prestressed jacketing
• Place concrete under triaxial
compression
• Larger capacity
• Larger ductility
• In seismic regions
71. 71Extending the service life of existing bridges
Overlays
• UHP = ultra high
performance concrete
• High strength
• High ductility
• ECC = engineered cement
composites
• Higher capacity
72. 72Extending the service life of existing bridges
Structural health monitoring
• Information from sensors
• Real-time updating online
• Bridge warns when
problems arise
• Reality: lots of data,
interpretation sometimes
difficult
73. 73Extending the service life of existing bridges
End-of-life of bridges
• Repair and rehab before
replacing
• When need for replacing:
recover materials as much
as possible
• Recycled aggregates
• Can be reused for foundations
and pavements
75. 75Extending the service life of existing bridges
Summary & Conclusions
In order to extend the service life of
existing bridges, combine the
following:
1.Better calculation methods
(Research!)
2.Better inspection techniques
3.Better rehabilitation techniques
76. 76Extending the service life of existing bridges
Contact:
Eva Lantsoght
E.O.L.Lantsoght@tudelft.nl
elantsoght@usfq.edu.ec
