1. The document discusses various techniques for evaluating cement behind casing, including radioactive tracer surveys, hydraulic testing, temperature surveys, acoustic logging, and ultrasonic tools.
2. Acoustic logging techniques like cement bond logs (CBL) and variable density logs (VDL) provide qualitative information on cement-casing and cement-formation bonding but have limitations.
3. Ultrasonic imager tools (USI) provide higher resolution images that allow easier interpretation compared to acoustic logs, with the ability to detect narrow channels and distinguish between solid, liquid, and gas materials behind the casing.
The document provides an overview of bond log theory, interpretation, and applications including how acoustic bond logs work, what different measurements indicate, examples of good and poor cement bonds, considerations for scenarios like channeled cement or microannuli, and examples of bond log use for integrity evaluation in steam injection wells. Key topics covered include the purposes of cement, when bond logs are run, traditional acoustic bond tool components and measurements, factors that affect bond logs, and media coverage of oil industry environmental issues.
This document summarizes a Halliburton workshop on cementing evaluation in Algeria. It discusses challenges with cementing work in the region, including permeable zones and overpressurized areas. It also reviews cement testing methods, engineered cement systems like expansive and resin cements, and industry best practices for cementing. A key challenge discussed is evaluating cement bonding in wells cemented with light-weight "tuned light" cement slurries using conventional cement bond logs. The document suggests acoustic tools may be better for evaluating this type of cement.
This document provides an overview of cement bond logging (CBL), which is a well logging technique used to evaluate the integrity of cement bonding between casing and borehole walls. It works by transmitting acoustic waves through the casing into the cement and detecting reflected signals to analyze bonding. Good cement bonding is indicated by low amplitude signals and strong formation reflections on the logs. CBL is important for assessing cement fill quality, casing integrity, and identifying potential fluid migration paths. It provides a cost-effective way to evaluate cementing operations and design remediation if needed.
This document provides an introduction to well control from Kingdom Drilling Services. It discusses primary and secondary well control, including maintaining pressure and monitoring flows. Loss of primary control can occur through pressure changes or lost circulation. Secondary control indicators include increased flow rates or mud pit volume changes. Methods for controlling kicks include circulating or bullheading. The document also covers well control terms, blowout prevention, shallow well hazards, and lost circulation detection and remedies.
The document discusses various drilling problems that can occur such as pipe sticking, loss of circulation, hole deviation, and more. It describes the causes and solutions for different types of pipe sticking problems including differential pressure sticking and mechanical sticking due to cuttings accumulation, borehole instability, or key seating. The document also covers loss of circulation issues and explains common lost circulation zones and causes. Planning and understanding potential problems is key to successfully reaching the target zone.
This document provides information on gas lift valve mechanics, including the three basic types of gas lift valves, how they operate, and the forces involved in opening and closing them. It discusses unloading valves, orifice valves, and how gas lift valves close in sequence from the bottom of the well upward. Diagrams show the components of different gas lift valve designs and the formulas used to calculate valve opening and closing pressures.
The document outlines the steps for well drilling and site preparation. It describes leveling the site, digging a cellar and mud pits, hammering a conductor pipe, drilling a rathole, and transporting equipment to the site. It then details rig setup including raising the mast and substructure, connecting the conductor pipe, rig acceptance checks, and making up drill pipes. Preparing the spud mud by mixing and pumping it is covered. The process of spudding in the hole and cleaning mud returns is also outlined. Subsequent steps reviewed are picking up drill pipes, running and cementing the surface casing, waiting for the cement to cure, and completing the cement job.
A drill stem test (DST) is used to test characteristics of a newly drilled well while the drilling rig is still on site. It can provide estimates of permeability, reservoir pressure, fluid types, wellbore damage, barriers and fluid contacts. There are three main methods to analyze DST data: Horner's plot method, type curve matching method, and computer matching. Type curve matching involves matching pressure change over time data from the DST to standard type curves to determine properties like permeability and skin factor. Gringarten type curves are commonly used and account for variations in pressure over time based on reservoir-well configurations.
The document provides an overview of bond log theory, interpretation, and applications including how acoustic bond logs work, what different measurements indicate, examples of good and poor cement bonds, considerations for scenarios like channeled cement or microannuli, and examples of bond log use for integrity evaluation in steam injection wells. Key topics covered include the purposes of cement, when bond logs are run, traditional acoustic bond tool components and measurements, factors that affect bond logs, and media coverage of oil industry environmental issues.
This document summarizes a Halliburton workshop on cementing evaluation in Algeria. It discusses challenges with cementing work in the region, including permeable zones and overpressurized areas. It also reviews cement testing methods, engineered cement systems like expansive and resin cements, and industry best practices for cementing. A key challenge discussed is evaluating cement bonding in wells cemented with light-weight "tuned light" cement slurries using conventional cement bond logs. The document suggests acoustic tools may be better for evaluating this type of cement.
This document provides an overview of cement bond logging (CBL), which is a well logging technique used to evaluate the integrity of cement bonding between casing and borehole walls. It works by transmitting acoustic waves through the casing into the cement and detecting reflected signals to analyze bonding. Good cement bonding is indicated by low amplitude signals and strong formation reflections on the logs. CBL is important for assessing cement fill quality, casing integrity, and identifying potential fluid migration paths. It provides a cost-effective way to evaluate cementing operations and design remediation if needed.
This document provides an introduction to well control from Kingdom Drilling Services. It discusses primary and secondary well control, including maintaining pressure and monitoring flows. Loss of primary control can occur through pressure changes or lost circulation. Secondary control indicators include increased flow rates or mud pit volume changes. Methods for controlling kicks include circulating or bullheading. The document also covers well control terms, blowout prevention, shallow well hazards, and lost circulation detection and remedies.
The document discusses various drilling problems that can occur such as pipe sticking, loss of circulation, hole deviation, and more. It describes the causes and solutions for different types of pipe sticking problems including differential pressure sticking and mechanical sticking due to cuttings accumulation, borehole instability, or key seating. The document also covers loss of circulation issues and explains common lost circulation zones and causes. Planning and understanding potential problems is key to successfully reaching the target zone.
This document provides information on gas lift valve mechanics, including the three basic types of gas lift valves, how they operate, and the forces involved in opening and closing them. It discusses unloading valves, orifice valves, and how gas lift valves close in sequence from the bottom of the well upward. Diagrams show the components of different gas lift valve designs and the formulas used to calculate valve opening and closing pressures.
The document outlines the steps for well drilling and site preparation. It describes leveling the site, digging a cellar and mud pits, hammering a conductor pipe, drilling a rathole, and transporting equipment to the site. It then details rig setup including raising the mast and substructure, connecting the conductor pipe, rig acceptance checks, and making up drill pipes. Preparing the spud mud by mixing and pumping it is covered. The process of spudding in the hole and cleaning mud returns is also outlined. Subsequent steps reviewed are picking up drill pipes, running and cementing the surface casing, waiting for the cement to cure, and completing the cement job.
A drill stem test (DST) is used to test characteristics of a newly drilled well while the drilling rig is still on site. It can provide estimates of permeability, reservoir pressure, fluid types, wellbore damage, barriers and fluid contacts. There are three main methods to analyze DST data: Horner's plot method, type curve matching method, and computer matching. Type curve matching involves matching pressure change over time data from the DST to standard type curves to determine properties like permeability and skin factor. Gringarten type curves are commonly used and account for variations in pressure over time based on reservoir-well configurations.
Cement Bond (CBL) & variabile desnity (VDL) Logs.pdfAhmedAlfadaly2
1. Cement bond logs (CBL) and variable density logs (VDL) evaluate cement integrity and bonding. CBL uses sonic tools to examine cement bonding to casing while VDL provides a detailed waveform display of acoustic signals.
2. VDL logs provide more information than CBL by showing the full acoustic waveform recorded by the downhole receiver. This allows differentiation of signals from the casing, cement, and formation to evaluate cement-formation bonding.
3. A good CBL/VDL log shows low acoustic signal amplitude on the CBL indicating good cement bonding. The VDL clearly shows formation signals with no casing arrivals, indicating good zonal isolation. A bad CBL has high signal amplitude and the VDL shows parallel
Drilling fluids are absolutely essential during the drilling process and considered the primary well control.
Know more now about such a very important component of the drilling process.
wireline sampling or testing tools and bore hole televiewer are a formation testing tools.they help in understanding and evaluating the formation fluid ,composition ,rock type(hard or soft),mud cake thickness etc better .FT,FIT,RFT help in bringing out the formation fluid to the surface and test in the laboratory to conduct a detailed study on fluid type.
Petroleum Production Engineering - PerforationJames Craig
This document provides an overview of perforation for oil and gas wells. It discusses key objectives and components of perforation including shaped charges, explosives, perforating guns, and efficiency factors. It also covers well and reservoir characteristics relevant to perforation and provides equations for calculating perforation skin effects on well performance. The high-level goal of perforation is to establish communication between the wellbore and formation while maintaining reservoir inflow capacity.
Complete Casing Design with types of casing, casing properties, casing functions, design criteria and properties used for designing and one numerical problem
This document discusses squeeze cementing techniques and considerations. Squeeze cementing involves pumping cement slurry under pressure against a permeable formation to create a cement seal. Key aspects covered include reasons for squeeze cementing, slurry design factors like viscosity and fluid loss control, laboratory testing methods, and primary concerns like establishing an injection rate and avoiding formation fracture. Detailed explanations are provided for methods like running squeezes through packers or cement retainers and different injection techniques.
This document provides information about fluids and cementing for third year bachelor's degree students. It introduces cementing operations for wells, including primary and remedial cementing. It discusses why cementing is important for zonal isolation and casing support. The document outlines the steps for well preparation before cementing, including cleaning the hole, running and centering the casing column. It describes the various equipment used in cementing like float shoes, float collars, scratchers, wiper plugs, and cement heads. The document also covers laboratory tests on cement slurries and the process for primary cementing of conductor pipes and surface casing.
This document discusses well testing and well test analysis software programs. It provides information on:
- The objectives of well testing including identifying fluid types and reservoir parameters
- Types of well tests including productivity tests for development wells and descriptive tests for exploration wells
- Popular well test software programs for analytical and numerical analysis including Saphir, PanSystem, Interpret 2000, and Weltest 200
- An overview of the Weltest 200 program which links analytical and numerical well test analysis through different modules
- Using an example of liquid productivity or IPR testing to demonstrate how well test data is incorporated and analyzed in the software
WELL COMPLETION, WELL INTERVENTION/ STIMULATION, AND WORKOVERAndi Anriansyah
This document discusses various well completion, intervention, and workover topics including:
- Well completion involves preparing the well for production by installing equipment like casing and tubing.
- Open hole and cased hole completions are described, along with advantages and disadvantages of each.
- Well intervention operations like scale removal, acidizing, and sand cleaning are performed during production.
- Formation damage from fluids introduced into the well is also discussed.
- Stimulation techniques like acidizing and hydraulic fracturing aim to increase well productivity. The document outlines the processes, equipment, and evaluation of these operations.
- Other topics covered include intelligent well completions, perforating, sand control, squeeze cement
Drilling operations can encounter various problems related to geological uncertainties, wellbore stability issues, and depletion effects. Some key risks include uncertainties in pore pressure-fracture gradient measurements, mud volcanoes causing landslides or weak formations, fault zones providing pathways for fluid flow, and maintaining wellbore integrity in low-pressure depleted zones. Operators address these challenges through careful planning, identifying potential hazard areas using seismic data, selecting appropriate drilling fluid properties, and employing wellbore strengthening techniques and lost circulation materials when needed to prevent fluid losses and wellbore collapse.
Well testing provides essential information for characterizing oil and gas reservoirs and evaluating their economic potential. It involves short-term production of reservoir fluids to estimate deliverability and analyze pressure transients caused by changes in flow rates. Integrated analysis of multiple well tests helps optimize development by assessing near-wellbore conditions, estimating reservoir boundaries and drive mechanisms, and characterizing permeability. Modern testing combines downhole measurements and computer analysis to maximize information about the reservoir.
This document discusses well intervention techniques using coiled tubing. It describes coiled tubing as continuously-milled tubular product that is straightened before insertion into the wellbore. The main types of well intervention discussed are pumping, slickline, snubbing, workover, and coiled tubing. It provides details on the components and functions of a coiled tubing unit, including the reel, injector head, control cabin, power pack, blowout preventer, stripper, and bottom hole assembly.
The document discusses the functions and types of casing strings used in oil and gas wells. It describes the different casing strings like conductor casing, surface casing, intermediate casing, and production casing. It also covers casing design criteria like classifications based on outside diameter, length, connections, weight, and grade. The mechanical properties of casing are discussed in relation to withstanding tensile, burst, and collapse loads during drilling and production operations.
The document discusses the use of RFT (Repeat Formation Tester) and MDT (Modular Formation Dynamics Tester) tools for reservoir evaluation and fluid sampling. These wireline tools are used to measure formation pressure, permeability and obtain fluid samples. The document outlines how the tools work, providing examples of pressure measurement and fluid analysis. It also presents a case study and discusses applications of the tools in reservoir development and contact analysis.
Production tubing is installed in oil and gas wells to allow hydrocarbons to flow from the reservoir to the surface while protecting the casing from reservoir fluids. Tubing is specified based on its size, length, grade, and connection type. Common tubing sizes range from 2-3/8" to 4-1/2" in diameter. Tubing joints are typically 20-48 feet in length. Tubing grade depends on the application and is chosen based on strength, corrosion resistance, and availability. Connections can be either upset or non-upset threaded types.
This document provides an overview of well control procedures. It discusses causes of kicks such as swabbing or pumping light mud that can lead to underbalance. Primary well control relies on mud hydrostatic pressure, while secondary control uses a blowout preventer. Tertiary control involves pumping substances to stop downhole flow. Methods for killing a well are also presented, including the driller's method, wait and weight, volumetric, and bullheading. Kick detection equipment like the pit volume totalizer and flow indicator are also outlined.
This presentation is a course a bout wellheads which includes the basic components of the well head and the advanced techniques.
helping students who are cared about petroleum industry to increase their knowledge about this tool that is important for both drilling and production.
For Further information, use the following LinkedIn account:
https://www.linkedin.com/in/mohamed-abdelshafy-abozeima-9b7589119/
This document discusses challenges and solutions related to deep water drilling. It describes different types of rigs used for deep water drilling at various water depths. Key challenges discussed include gas hydrates, reactive formations, low fracture gradients, large mud volumes, low flow line temperatures, and high rig costs. Solutions provided relate to additive selection, temperature and pressure management, casing design, logistics planning, and optimization to reduce costs and time.
The document provides an overview of testing conducted at the NTPC Gadarwada power plant project site. It summarizes various material testing methods used, including testing of concrete (compressive strength, slump, and core cutter tests), cement (Vicat test), soil (liquid limit, proctor, and core cutter tests), steel (bend-rebend test), bricks (water absorption, compression, warpage, and efflorescence tests), and reinforcement. It also summarizes quality control methods used in various construction activities like fabrication, erection, site leveling, roads, foundations, and pre-engineered structures.
Assessing Flow-Accelerated Corrosion in Hard-to-Reach PlacesEddyfi
A major petrochemical company challenged Eddyfi to develop an inspection solution to detect flow-accelerated corrosion (FAC) and erosion in insulated carbon steel pipes with diameters of 318.5 mm and wall thicknesses of 9.5 mm. Eddyfi's pulsed eddy current (PEC) Lyft solution was able to detect FAC on the inner pipe surface through 50 mm of insulation and an aluminum cladding without removing them. Testing a straight pipe section and elbow found unexpected wall loss in the elbow concentrated at the bend transition, demonstrating the solution's effectiveness in hard-to-reach places.
Cement Bond (CBL) & variabile desnity (VDL) Logs.pdfAhmedAlfadaly2
1. Cement bond logs (CBL) and variable density logs (VDL) evaluate cement integrity and bonding. CBL uses sonic tools to examine cement bonding to casing while VDL provides a detailed waveform display of acoustic signals.
2. VDL logs provide more information than CBL by showing the full acoustic waveform recorded by the downhole receiver. This allows differentiation of signals from the casing, cement, and formation to evaluate cement-formation bonding.
3. A good CBL/VDL log shows low acoustic signal amplitude on the CBL indicating good cement bonding. The VDL clearly shows formation signals with no casing arrivals, indicating good zonal isolation. A bad CBL has high signal amplitude and the VDL shows parallel
Drilling fluids are absolutely essential during the drilling process and considered the primary well control.
Know more now about such a very important component of the drilling process.
wireline sampling or testing tools and bore hole televiewer are a formation testing tools.they help in understanding and evaluating the formation fluid ,composition ,rock type(hard or soft),mud cake thickness etc better .FT,FIT,RFT help in bringing out the formation fluid to the surface and test in the laboratory to conduct a detailed study on fluid type.
Petroleum Production Engineering - PerforationJames Craig
This document provides an overview of perforation for oil and gas wells. It discusses key objectives and components of perforation including shaped charges, explosives, perforating guns, and efficiency factors. It also covers well and reservoir characteristics relevant to perforation and provides equations for calculating perforation skin effects on well performance. The high-level goal of perforation is to establish communication between the wellbore and formation while maintaining reservoir inflow capacity.
Complete Casing Design with types of casing, casing properties, casing functions, design criteria and properties used for designing and one numerical problem
This document discusses squeeze cementing techniques and considerations. Squeeze cementing involves pumping cement slurry under pressure against a permeable formation to create a cement seal. Key aspects covered include reasons for squeeze cementing, slurry design factors like viscosity and fluid loss control, laboratory testing methods, and primary concerns like establishing an injection rate and avoiding formation fracture. Detailed explanations are provided for methods like running squeezes through packers or cement retainers and different injection techniques.
This document provides information about fluids and cementing for third year bachelor's degree students. It introduces cementing operations for wells, including primary and remedial cementing. It discusses why cementing is important for zonal isolation and casing support. The document outlines the steps for well preparation before cementing, including cleaning the hole, running and centering the casing column. It describes the various equipment used in cementing like float shoes, float collars, scratchers, wiper plugs, and cement heads. The document also covers laboratory tests on cement slurries and the process for primary cementing of conductor pipes and surface casing.
This document discusses well testing and well test analysis software programs. It provides information on:
- The objectives of well testing including identifying fluid types and reservoir parameters
- Types of well tests including productivity tests for development wells and descriptive tests for exploration wells
- Popular well test software programs for analytical and numerical analysis including Saphir, PanSystem, Interpret 2000, and Weltest 200
- An overview of the Weltest 200 program which links analytical and numerical well test analysis through different modules
- Using an example of liquid productivity or IPR testing to demonstrate how well test data is incorporated and analyzed in the software
WELL COMPLETION, WELL INTERVENTION/ STIMULATION, AND WORKOVERAndi Anriansyah
This document discusses various well completion, intervention, and workover topics including:
- Well completion involves preparing the well for production by installing equipment like casing and tubing.
- Open hole and cased hole completions are described, along with advantages and disadvantages of each.
- Well intervention operations like scale removal, acidizing, and sand cleaning are performed during production.
- Formation damage from fluids introduced into the well is also discussed.
- Stimulation techniques like acidizing and hydraulic fracturing aim to increase well productivity. The document outlines the processes, equipment, and evaluation of these operations.
- Other topics covered include intelligent well completions, perforating, sand control, squeeze cement
Drilling operations can encounter various problems related to geological uncertainties, wellbore stability issues, and depletion effects. Some key risks include uncertainties in pore pressure-fracture gradient measurements, mud volcanoes causing landslides or weak formations, fault zones providing pathways for fluid flow, and maintaining wellbore integrity in low-pressure depleted zones. Operators address these challenges through careful planning, identifying potential hazard areas using seismic data, selecting appropriate drilling fluid properties, and employing wellbore strengthening techniques and lost circulation materials when needed to prevent fluid losses and wellbore collapse.
Well testing provides essential information for characterizing oil and gas reservoirs and evaluating their economic potential. It involves short-term production of reservoir fluids to estimate deliverability and analyze pressure transients caused by changes in flow rates. Integrated analysis of multiple well tests helps optimize development by assessing near-wellbore conditions, estimating reservoir boundaries and drive mechanisms, and characterizing permeability. Modern testing combines downhole measurements and computer analysis to maximize information about the reservoir.
This document discusses well intervention techniques using coiled tubing. It describes coiled tubing as continuously-milled tubular product that is straightened before insertion into the wellbore. The main types of well intervention discussed are pumping, slickline, snubbing, workover, and coiled tubing. It provides details on the components and functions of a coiled tubing unit, including the reel, injector head, control cabin, power pack, blowout preventer, stripper, and bottom hole assembly.
The document discusses the functions and types of casing strings used in oil and gas wells. It describes the different casing strings like conductor casing, surface casing, intermediate casing, and production casing. It also covers casing design criteria like classifications based on outside diameter, length, connections, weight, and grade. The mechanical properties of casing are discussed in relation to withstanding tensile, burst, and collapse loads during drilling and production operations.
The document discusses the use of RFT (Repeat Formation Tester) and MDT (Modular Formation Dynamics Tester) tools for reservoir evaluation and fluid sampling. These wireline tools are used to measure formation pressure, permeability and obtain fluid samples. The document outlines how the tools work, providing examples of pressure measurement and fluid analysis. It also presents a case study and discusses applications of the tools in reservoir development and contact analysis.
Production tubing is installed in oil and gas wells to allow hydrocarbons to flow from the reservoir to the surface while protecting the casing from reservoir fluids. Tubing is specified based on its size, length, grade, and connection type. Common tubing sizes range from 2-3/8" to 4-1/2" in diameter. Tubing joints are typically 20-48 feet in length. Tubing grade depends on the application and is chosen based on strength, corrosion resistance, and availability. Connections can be either upset or non-upset threaded types.
This document provides an overview of well control procedures. It discusses causes of kicks such as swabbing or pumping light mud that can lead to underbalance. Primary well control relies on mud hydrostatic pressure, while secondary control uses a blowout preventer. Tertiary control involves pumping substances to stop downhole flow. Methods for killing a well are also presented, including the driller's method, wait and weight, volumetric, and bullheading. Kick detection equipment like the pit volume totalizer and flow indicator are also outlined.
This presentation is a course a bout wellheads which includes the basic components of the well head and the advanced techniques.
helping students who are cared about petroleum industry to increase their knowledge about this tool that is important for both drilling and production.
For Further information, use the following LinkedIn account:
https://www.linkedin.com/in/mohamed-abdelshafy-abozeima-9b7589119/
This document discusses challenges and solutions related to deep water drilling. It describes different types of rigs used for deep water drilling at various water depths. Key challenges discussed include gas hydrates, reactive formations, low fracture gradients, large mud volumes, low flow line temperatures, and high rig costs. Solutions provided relate to additive selection, temperature and pressure management, casing design, logistics planning, and optimization to reduce costs and time.
The document provides an overview of testing conducted at the NTPC Gadarwada power plant project site. It summarizes various material testing methods used, including testing of concrete (compressive strength, slump, and core cutter tests), cement (Vicat test), soil (liquid limit, proctor, and core cutter tests), steel (bend-rebend test), bricks (water absorption, compression, warpage, and efflorescence tests), and reinforcement. It also summarizes quality control methods used in various construction activities like fabrication, erection, site leveling, roads, foundations, and pre-engineered structures.
Assessing Flow-Accelerated Corrosion in Hard-to-Reach PlacesEddyfi
A major petrochemical company challenged Eddyfi to develop an inspection solution to detect flow-accelerated corrosion (FAC) and erosion in insulated carbon steel pipes with diameters of 318.5 mm and wall thicknesses of 9.5 mm. Eddyfi's pulsed eddy current (PEC) Lyft solution was able to detect FAC on the inner pipe surface through 50 mm of insulation and an aluminum cladding without removing them. Testing a straight pipe section and elbow found unexpected wall loss in the elbow concentrated at the bend transition, demonstrating the solution's effectiveness in hard-to-reach places.
Alumni; Dave Cousins, gave this presentation on Thursday 26th October. Have a look at this to find out how to enhance your CPD as an engineer and detect faults in bridges!
Reformer Tube design principles
- Larsen Miller Plot
- Larsen Miller & Tube Design
- Design Margins - Stress Data Used
- Max Allowable & Design Temperature
- Tube Life
- Effect of Temperature on Life
- Material Types
HK40: 25 Cr / 20 Ni
HP Modified: 25 Cr / 35 Ni + Nb
Microalloy: 25 Cr / 35 Ni + Nb + Ti
- Alloy Developments
- Comparison of Alloys
Manufacturing Technology
- Welds
Failure mechanisms
- Failure Mechanisms - Creep
- Creep Propagation
- Common Failure Modes
- Uncommon Failure Modes
- Failure by Creep
- Creep Rupture - Cross Section
- Failure at Weld
Actions to Take if Tube Fails
- Pigtail Nipping
Inspection techniques
Classification of Problems
- Visual Examination
- Girth Measurement
- Ultrasonic Attenuation
- Radiography
Eddy Current Measurement
LOTIS Tube Inspection
LOTIS Compared to External Inspection
This document summarizes the description and condition of a bridge located at Chemin Côte-des-Neiges and Chemin Remembrance in Montreal. The bridge is made of concrete and steel and is owned by the city. It shows signs of deterioration from corrosion, cracking, and efflorescence. Testing and evaluations indicate repairs are needed for corrosion, alkali-silica reaction, and cracks. Recommendations include repairs to the concrete and application of protective coatings or overlays. The bridge is rated as deficient but repairs are not urgent unless the planned elimination is delayed.
The document discusses corrosion monitoring techniques, providing details on manual monitoring methods like corrosion probes and coupons, semi-automatic online monitoring systems, and factors to consider for corrosion monitoring locations and safety procedures. It also covers corrosion causes and forms, cost impacts, and the importance of corrosion monitoring programs for assessing infrastructure integrity and costs.
Weld probe presentation- Given at COTEQ, Porto Galinhas, Brazil, June 2013John Hansen
This document discusses the advantages of using eddy current technology and specialized weld probes for weld inspection. It provides background on the development of weld probes and how they work. Weld probes allow inspection of welds through coatings with minimal lift-off sensitivity. They are well-suited for difficult-access inspections and have various applications in industries like offshore, nuclear, and rail. The document also covers standardization, equipment used, and concludes that weld probes provide a good alternative to other NDT methods for weld inspection.
D1 (B2) Jan Suchorzewski - Combined carbonation-frost resistance of sustainab...Svenska Betongföreningen
The document summarizes research on developing sustainable high-performance concrete with very high slag content for use in wave energy converter hulls. Testing showed that concrete mixes with cement contents as low as 100 kg/m3 and slag replacements over 50% achieved compressive strengths over 100 MPa and frost resistance classified as "very good" even after carbonation. However, one mix (HPC200) showed increased frost scaling after carbonation, requiring further testing. Microscopy revealed microcracking in the carbonated layer for this mix. Overall, the research demonstrates that high-slag concrete can perform well in Nordic climates if evaluated using combined carbonation and frost testing.
This document discusses copper tubes for air conditioning and refrigeration (ACR) applications. It outlines the key challenges for the ACR industry, such as cost reduction and energy savings. It then describes the key features of Mandev's ACR-grade copper tubes, including compliance with RoHS regulations, testing procedures, dimensional tolerances, and packaging and labeling. The document provides information on Mandev's manufacturing standards and product range.
The document provides definitions and test procedures for determining properties of concrete materials. It discusses tests to determine SSD bulk specific gravity and water absorption of coarse and fine aggregates, fineness modulus of fine aggregate, and rodded bulk density of coarse aggregate. It also outlines the steps to calculate a design mix for M25 grade concrete using test data for materials' properties and strengths. The design mix calculation involves selecting water-cement ratio, determining cement and aggregate contents, and quantities of materials for 1 cubic meter of concrete.
This document provides information on concrete technology and the ingredients and manufacturing process of cement. It discusses the key components of cement including tricalcium silicate, dicalcium silicate, tricalcium aluminate, and tetracalcium aluminoferrite. It also describes the testing methods for cement such as consistency, setting time, soundness, and compressive/tensile strength tests. Different types of cement are mentioned like rapid hardening, low heat, sulphate resisting, and Portland slag cement.
Cellular Light Weight Concrete Blocks Machine- Manufacturers & Suppliers
Our proficient and dedicated professionals make the utmost use of these facilities and work round the clock with a client centric approach to meet the industrial requirements. These professionals are well versed and have updated knowledge on the latest technology which ensures hassle free and efficient procurement and storage. We have been highly benefited by our facilities, this being one of the reasons for establishing ourselves as a prominent organization.
www.clcblockmachine.in, www.clcplant.com
The document discusses efficient operation and maintenance of boilers at NTPC Simhadri. It provides an overview of NTPC's journey and capacity, describes the types of boilers used, and outlines best practices adopted to reduce boiler tube leakages. These include improved startup procedures, monitoring of chemical parameters, thorough inspections and testing, and implementation of new technologies like acoustic leak detectors and process instrumentation systems. The presentation aims to share experiences in achieving zero boiler tube failures through preventative maintenance practices.
Your Score 1420Not bad. Your score means youre slightly bette.docxodiliagilby
Your Score: 14/20
Not bad. Your score means you're slightly better than the average at reading expressions. And research suggests that people can improve their emotion recognition skills with practice. So keep an eye out for our forthcoming empathy training tool, designed to boost your emotional intelligence. Sign upfor our e-newsletter for updates on it.
Drilling Engineering
Class 8
1
Casing
• What is casing?
• Pipe that is API certified for its specific application
• Why is casing set?
• Zonal Isolation when cemented in place
• Casing point selection
• Regulations
• Area Geology
• Formation Pressures
• As the operator, who decides on casing points?
2
Casing
• API casing is available in standard sizes from 4-1/2” to 20” OD
• Usually steel but can be aluminum, fiberglass, stainless steel,
plastic, titanium etc.
• One piece of casing pipe is referred to as a “joint” of casing
• Casing length is dependent on the “range” of pipe
• Range-1: 18-22ft
• Range-2: 27-30ft
• Range-3: 38-45ft
• Casing Threads are defined by the coupling type
• API Threads
• LTC: Long thread coupling
• STC: Short thread coupling
• BTC: Buttress thread coupling
• Semi & Premium Threads
• See VAM Presentation
3
Casing
• Casing Components
• Casing
• Size, Weight, Grade, Threads
• 9-5/8" 53.5# P-110 LTC Rg 3
• See Casing Data Chart
• What is Drift Diameter?
• Pup Joints
• Float Collars
• Float Shoe
• Guide Shoe
• Centralizers
• Baskets
• Scratchers/Scrapers
4
Casing
• Running Casing
• Bales/Elevators
• Power Tongs
• Torque Turn
• Calculate weight and Hookload HL
• Calculate collapse, how often should you fill the pipe?
• Is the pipe taking the proper amount of fluid to fill? CSGcap
• Is the proper amount of fluid coming back to the pits as the
casing is run in the hole? CSGcap & CSGdisp
• Once casing is landed, circulated mud. Calculate B/U
5
Casing
• Centralization
• Vertical Wells
• Never truly vertical, usually spiral
• Typically use bow spring type centralizers
• There are state regulations on centralizer placement
• The shoe is very important to be centralized
• Horizontal Wells
• Balance between too many and not enough centralizers
• Many types: rigid, floating, bow spring, bladed, spiral bladed, etc.
• Centralizer design software can model the well as drilled and suggest
centralizer placement
• High dogleg areas need more frequent centralizers to obtain
sufficient standoff
6
Casing
• Stand-off
• Pipe Stand-off is a major contributor to hole cleaning, mud
removal, and cement quality.
• % 𝑆𝑡𝑎𝑛𝑑𝑜𝑓𝑓 = ൗ𝑊𝑛 𝑅2−𝑅1 ∗ 100%
7
Casing
• Stand-off
• The Stand-off formula results a percentage, where 0% represents
the pipe in contact with the wellbore wall. 100% represents the
pipe is perfectly centered in the well.
• When the pipe is not centered, the wider portions will promote
flow due to less resistance. There can be pockets of cuttings or
mud in the tighter areas causing
A cement bond log (CBL) measures the loss of acoustic energy as it passes through casing to evaluate the integrity of cement bonding between the casing and formation. A sonic tool detects the bond by transmitting acoustic waves and measuring the amplitude of reflected waves, with lower amplitudes indicating better cement bonding. CBLs are used to detect cement bonding, which is important for supporting the casing, preventing fluid leaks, and isolating zones. Interpreters look for intervals of continuous cement bonding indicated by amplitudes below thresholds like 10 mV over a minimum distance.
ACEP Magazine edition 4th launched on 05.06.2024Rahul
This document provides information about the third edition of the magazine "Sthapatya" published by the Association of Civil Engineers (Practicing) Aurangabad. It includes messages from current and past presidents of ACEP, memories and photos from past ACEP events, information on life time achievement awards given by ACEP, and a technical article on concrete maintenance, repairs and strengthening. The document highlights activities of ACEP and provides a technical educational article for members.
Understanding Inductive Bias in Machine LearningSUTEJAS
This presentation explores the concept of inductive bias in machine learning. It explains how algorithms come with built-in assumptions and preferences that guide the learning process. You'll learn about the different types of inductive bias and how they can impact the performance and generalizability of machine learning models.
The presentation also covers the positive and negative aspects of inductive bias, along with strategies for mitigating potential drawbacks. We'll explore examples of how bias manifests in algorithms like neural networks and decision trees.
By understanding inductive bias, you can gain valuable insights into how machine learning models work and make informed decisions when building and deploying them.
TIME DIVISION MULTIPLEXING TECHNIQUE FOR COMMUNICATION SYSTEMHODECEDSIET
Time Division Multiplexing (TDM) is a method of transmitting multiple signals over a single communication channel by dividing the signal into many segments, each having a very short duration of time. These time slots are then allocated to different data streams, allowing multiple signals to share the same transmission medium efficiently. TDM is widely used in telecommunications and data communication systems.
### How TDM Works
1. **Time Slots Allocation**: The core principle of TDM is to assign distinct time slots to each signal. During each time slot, the respective signal is transmitted, and then the process repeats cyclically. For example, if there are four signals to be transmitted, the TDM cycle will divide time into four slots, each assigned to one signal.
2. **Synchronization**: Synchronization is crucial in TDM systems to ensure that the signals are correctly aligned with their respective time slots. Both the transmitter and receiver must be synchronized to avoid any overlap or loss of data. This synchronization is typically maintained by a clock signal that ensures time slots are accurately aligned.
3. **Frame Structure**: TDM data is organized into frames, where each frame consists of a set of time slots. Each frame is repeated at regular intervals, ensuring continuous transmission of data streams. The frame structure helps in managing the data streams and maintaining the synchronization between the transmitter and receiver.
4. **Multiplexer and Demultiplexer**: At the transmitting end, a multiplexer combines multiple input signals into a single composite signal by assigning each signal to a specific time slot. At the receiving end, a demultiplexer separates the composite signal back into individual signals based on their respective time slots.
### Types of TDM
1. **Synchronous TDM**: In synchronous TDM, time slots are pre-assigned to each signal, regardless of whether the signal has data to transmit or not. This can lead to inefficiencies if some time slots remain empty due to the absence of data.
2. **Asynchronous TDM (or Statistical TDM)**: Asynchronous TDM addresses the inefficiencies of synchronous TDM by allocating time slots dynamically based on the presence of data. Time slots are assigned only when there is data to transmit, which optimizes the use of the communication channel.
### Applications of TDM
- **Telecommunications**: TDM is extensively used in telecommunication systems, such as in T1 and E1 lines, where multiple telephone calls are transmitted over a single line by assigning each call to a specific time slot.
- **Digital Audio and Video Broadcasting**: TDM is used in broadcasting systems to transmit multiple audio or video streams over a single channel, ensuring efficient use of bandwidth.
- **Computer Networks**: TDM is used in network protocols and systems to manage the transmission of data from multiple sources over a single network medium.
### Advantages of TDM
- **Efficient Use of Bandwidth**: TDM all
Embedded machine learning-based road conditions and driving behavior monitoringIJECEIAES
Car accident rates have increased in recent years, resulting in losses in human lives, properties, and other financial costs. An embedded machine learning-based system is developed to address this critical issue. The system can monitor road conditions, detect driving patterns, and identify aggressive driving behaviors. The system is based on neural networks trained on a comprehensive dataset of driving events, driving styles, and road conditions. The system effectively detects potential risks and helps mitigate the frequency and impact of accidents. The primary goal is to ensure the safety of drivers and vehicles. Collecting data involved gathering information on three key road events: normal street and normal drive, speed bumps, circular yellow speed bumps, and three aggressive driving actions: sudden start, sudden stop, and sudden entry. The gathered data is processed and analyzed using a machine learning system designed for limited power and memory devices. The developed system resulted in 91.9% accuracy, 93.6% precision, and 92% recall. The achieved inference time on an Arduino Nano 33 BLE Sense with a 32-bit CPU running at 64 MHz is 34 ms and requires 2.6 kB peak RAM and 139.9 kB program flash memory, making it suitable for resource-constrained embedded systems.
Using recycled concrete aggregates (RCA) for pavements is crucial to achieving sustainability. Implementing RCA for new pavement can minimize carbon footprint, conserve natural resources, reduce harmful emissions, and lower life cycle costs. Compared to natural aggregate (NA), RCA pavement has fewer comprehensive studies and sustainability assessments.
Literature Review Basics and Understanding Reference Management.pptxDr Ramhari Poudyal
Three-day training on academic research focuses on analytical tools at United Technical College, supported by the University Grant Commission, Nepal. 24-26 May 2024
CHINA’S GEO-ECONOMIC OUTREACH IN CENTRAL ASIAN COUNTRIES AND FUTURE PROSPECTjpsjournal1
The rivalry between prominent international actors for dominance over Central Asia's hydrocarbon
reserves and the ancient silk trade route, along with China's diplomatic endeavours in the area, has been
referred to as the "New Great Game." This research centres on the power struggle, considering
geopolitical, geostrategic, and geoeconomic variables. Topics including trade, political hegemony, oil
politics, and conventional and nontraditional security are all explored and explained by the researcher.
Using Mackinder's Heartland, Spykman Rimland, and Hegemonic Stability theories, examines China's role
in Central Asia. This study adheres to the empirical epistemological method and has taken care of
objectivity. This study analyze primary and secondary research documents critically to elaborate role of
china’s geo economic outreach in central Asian countries and its future prospect. China is thriving in trade,
pipeline politics, and winning states, according to this study, thanks to important instruments like the
Shanghai Cooperation Organisation and the Belt and Road Economic Initiative. According to this study,
China is seeing significant success in commerce, pipeline politics, and gaining influence on other
governments. This success may be attributed to the effective utilisation of key tools such as the Shanghai
Cooperation Organisation and the Belt and Road Economic Initiative.
Comparative analysis between traditional aquaponics and reconstructed aquapon...bijceesjournal
The aquaponic system of planting is a method that does not require soil usage. It is a method that only needs water, fish, lava rocks (a substitute for soil), and plants. Aquaponic systems are sustainable and environmentally friendly. Its use not only helps to plant in small spaces but also helps reduce artificial chemical use and minimizes excess water use, as aquaponics consumes 90% less water than soil-based gardening. The study applied a descriptive and experimental design to assess and compare conventional and reconstructed aquaponic methods for reproducing tomatoes. The researchers created an observation checklist to determine the significant factors of the study. The study aims to determine the significant difference between traditional aquaponics and reconstructed aquaponics systems propagating tomatoes in terms of height, weight, girth, and number of fruits. The reconstructed aquaponics system’s higher growth yield results in a much more nourished crop than the traditional aquaponics system. It is superior in its number of fruits, height, weight, and girth measurement. Moreover, the reconstructed aquaponics system is proven to eliminate all the hindrances present in the traditional aquaponics system, which are overcrowding of fish, algae growth, pest problems, contaminated water, and dead fish.
4. RADIOACTIVE TRACERS
• Radioactive tracer work is very rare in
cementing evaluation and requires specialty
equipment and personnel
• Generally used only in very special
applications
5. PRESSURE EVALUATION
• The most common method of cement
evaluation is to perform some type of
pressure evaluation to determine if
isolation has been achieved
6. TEMPERATURE LOGS
Temperature surveys (logs) are very effective
but must be run within a specific time window
to be valid
Very cost effective
Limited application
7. TEMPERATURE SURVEY
The Heat of hydraiton
causes a temperature
rise
Compare results with
caliper
8. Class A
With 100 o
F 120 o
F 140 o
F 160 o
F
0 % Gel 8-12 8-12 6-9 4-8
4 % Gel 8-12 8-12 6-9 4-8
8 % Gel 9-12 9-12 6-9 6-9
12 % Gel 9-12 9-12 9-12 9-12
Time (h)
Example table for determining the time after
cementing to run a temperature log
TEMPERATURE SURVEY
9. ACOUSTIC LOGGING
Noise Logging
Detects noise from moving fluids
Not continuous
Sonic Tools
Conventional bond logs
Ultrasonic tools
USIT, CAST V
13. What is needed?
– Expected cement impedance --> amplitude for
100% bond: E100%
– Free pipe amplitude: EFree
– Measured amplitude: EMeas
Bond index:
BI = log10(Emeas/Efree)
log10 (E100%/Efree)
Conventionally:
– 80% < BI < 100%: Good cement
– 80% > BI: ?
CBL
14. Strengths
Most well fluids, tolerates corrosion
Responds to solidity (shear coupling)
Qualitative cement-formation bond from VDL
Inexpensive
CBL
15. Weaknesses
High CBL amplitude is ambiguous
liquid microannulus (shear coupling lost)
channel
contaminated cement
light cement mixed with neat
Fast formation arrivals
reflections from double string or hard formation
Low amplitude doesn’t ensure 100% bond
CBL
16. The USI evaluates
cement with an
ultrasonic
transducer (0.2 -
0.7 MHz)
Ultrasonic Tools
Solids
behind
pipe
Free Pipe
17. 1. Measure fluid properties
using reference plate while
running into well:
- velocity FVEL
- acoustic impedance ZMUD
2. Enter ZMUD and FVEL
parameters. Flip transducer to
face casing and log up.
USI logging procedure
19. Casing OD 4.5 - 13.375 in.
Casing thickness 0.17 - 0.59 in. (4.5-15 mm)
Acoustic Impedance 0-10 MRayl
Max. deviation No limit
Logging speed 400 to 3200 ft/hr
Sampling
- Azimuthal 5-10 deg.
- Vertical 0.6-6 in.
Max mud weight
-Water-base mud ~16 lbm/gal
-Oil-base mud ~11.6 lbm/gal*
* Depends on composition, temp. and pressure. Good logs can be
obtained up to 13 lb/gal and in rare cases to 16 lb/gal
Measurement Specifications
20. Tolerate liquid (wet) microannulus
(vibrations normal to surface)
Full coverage, 30 mm resolution image
– Detailed picture of material distribution:
solid, liquid, gas, debonded cement
– Detects narrow channels
Easier interpretation and less uncertainty
than sonics (CBL/CBT)
Casing inspection in same pass
Ultrasonic Tools
21. Acoustic logs are sensitive to the acoustic
properties (especially impedance) of the material
in contact with the casing.
The USI is the primary evaluation tool: the image
is easier to interpret and much less ambiguous
than the CBL log.
USI and CBL are sensitive to the cement/casing
bond but in different ways- complementary
evaluation.
Summary
23. SUMMARY
• Type of evaluation depends on the
need
• For top of cement
• use temperature if less than 24
hours
• use CBL if more than 24 hours
24. SUMMARY
• Conventional CBL vs. Focused Tools
• CBL is an average but improved data
from focused tools
• Can identify areas of no cement and
identify channel, but is must be large.
• Both tools have same limitations
25. SUMMARY
• Sonic vs. Ultrasonic
• Cost of ultrasonic is higher (+ 50 %)
• Quality of data is significantly better
• Do not depend on the computer to do the
interpretation with Ultrasonic Logs
26. • Acoustic methods are limited in very
light cements (low acoustic contrast
from mud).
• For optimum evaluation, cement job
data must be included in the
evaluation because cement does not
disappear.
Summary
27. Conclusion
In the absence of cement job data, the slurries
pumped, and formations involved, cement
evaluation is very difficult and subject to
extreme interpretation errors.
28. COMMON QUESTIONS
I have a well that is making water and I need
to run a cement evaluation log to determine
where the water is coming from. What is the
best log ?
I need to be sure I have isolation, but I can
not spend the money on a decent log. What
can I do ?
33. LIGHTWEIGHT CEMENTS
• Generally speaking they are more difficult to
evaluate
– Lower acoustic impedance
– Slower setting (longer waiting time)
• For a given density all lightweight cementsare not alike
– Dowell LiteCRETE systems exhibit:
• Low porosity (low water content)and hence a
relatively high ultimate acoustic impedance
• Fast strength development and hence a fast acoustic
impedance development (can be logged earlier)
• For a given density they are easier to log than any
other lightweight cement
34. SONIC (CBL/VDL) PRINCIPLE
20 kHz
Transmitter
3 ft Receiver
5 ft Receiver
Casing
Formation
t
t
Bonded cement
Mud
Cement
VDL
CBL amplitude
0 100
CBL amp
35. CBL AMPLITUDE INTERPRETATION
• What is needed?
➢ Expected cement impedance --> amplitude for 100%
bond: E100%
➢ Free pipe amplitude: EFree
➢ Measured amplitude: EMeas
• Bond index:
BI = log10(Emeas/Efree)
log10 (E100%/Efree)
• Conventionally:
➢ 80% < BI < 100%: Good cement
➢ 80% > BI: ?
36. SONIC (CBL/CBT)
Strengths
• Most well fluids, tolerates corrosion
• Responds to solidity (shear coupling)
• Qualitative cement-formation bond from VDL
Weaknesses
• High CBL amplitude is ambiguous
– liquid microannulus (shear coupling lost)
– channel
– contaminated cement
– light cement mixed with neat
– Fast formation arrivals
– reflections from double string or hard formation
• Low amplitude doesn’t ensure 100% bond
37. OUTLINE CBL-VDL
Introduction to Cementing
Role of cementing
Mechanics
Sonic as a Cement Evaluation
tool
Hardware
Operations
Parameters & Setup
LQC & Hints
Normalization
Safety
Factors effecting tool response
Log Example
39. ROLE OF PRIMARY CEMENTING
Conductor Casing (spudded)
Isolate loose surface sediments
Avoid surface corrosion
Surface Casing
Isolate sweet water zones
Mounting rig BOP and
later CSG strings
Oil string (Casing/Liner)
Isolate production zones
Avoid hydrocarbon loss to thief zones
Reduce water production
Intermediate Casing
Isolate loose or high pressure formation
Typical casing string
40. b
Environment
Fluid filled casing
Cement top.
Poor cement to formation bond.
(example: due to mud-cake)
Formation
Micro-Annulus due to expansion of
casing during cement job.
Less than perfect cement job.
Two stage cement job.
Double Casing
41. ROLE OF SECONDARY CEMENTING
Repair defects in primary cementing job
L Unsuccessful primary cementing
L Casing corrosion, leaking, split
L Isolate water production in old well
42. CAUSES OF BAD CEMENTING
Mechanical problems
L Poor pipe centralisation
L Hole conditions: Poor removal of mud from around pipe
Channels or missing cement
Pressure problems
L Influx of formation fluid
L Loss of cement into permeable zone: Permeable, weakened or missing cement
Micro-and cement annulus (Casing flexing contraction)
L Changes in pressure inside casing before setting
L Over pressuring the casing after cement setting
ã May not isolate over gas zones
44. WHY RUN CBL-VDL
• Primary application is to evaluate the quality of
the casing cement job
• Secondary but equally important application is
to depth match the open hole GR to the cased
hole CCL
• The CBL-VDL-GR-CCL becomes the cased hole
base log to which all subsequent work is depth
referenced.
45. SONIC PATH IN CASED HOLE
• CBL measures casing to cement bond
• VDL indicates cement to formation bond if casing to
cement bond is good
46. Cement to Casing Bond
If the casing is well bonded, the
sound will be attenuatedas it travels
through the casing
The received amplitude will be low
We measure E1 amplitude and call it
CBL
CBL: Poor Bond
CBL: Good Bond
Transit Time (TT)
2
4
3
1
47. Free Pipe Amplitude
If there is no cement bonded to the
casing, then the amplitude will not
be attenuated.
This is called the free pipe
amplitude.
CBL: Free Pipe
2
4
3
1
48. Less Than Perfect Bond
The more “free” pipe or
“contaminated” cement in an interval
, the poorer the bond.
If the cement job is not perfect, the
amplitude will not decrease as
much.
CBL: Poor Bond
2
4
3
1
50. SOUND TRANSMISSION
Water
Steel
Cement
Sound
The amount of sound transmitted depends on the acoustic
impedance (Z) difference between the two materials
•If Z1/Z2 is high, low transmittance
•If Z1/Z2 is low, high transmittance
Z1
Z2
54. FACTOR EFFECTING TOOL RESPONSE
Eccentering
Cycle skipping
Fast Formation
(if good cement)
Fluid Type
Stretch
Casing Size
Cement quality!
55. Eccentering
As in open hole, the amplitude is
dramatically decreased when the
tool is eccentered.
This will give show an incorrectly
good bond.
Since the travel distance is
decreased, the transit time will also
decrease.
Transit Time (TT)
A bad log which
cannot be played back.
2
4
3
1
59. Micro Annulus
A micro annulus is caused by the
expansion of the casing under
pressure during cementing.
E1 amplitude is larger than it should
be (poorer bond than actual)
A pressure pass can be used to
eliminate the micro annulus.
CBL: Poor Bond
2
4
3
1
60. INTERPRETATION HINTS
VDL
TYPE OF BOND CBL CASING FORMATION
AMPLITUDE ARRIVALS ARRIVAL
Free Pipe High Large Very Weak or none
Good Casing -
to - Cement - Low Weak Strong
to - Formation
Good Casing Bond
- Poor Formation Bond Low Moderate to Weak Weak or none
Microannulus, Channeling,
Thin Cement Sheath High Moderate Moderate
Fast Formation Arrivals High Absent Strong
63. CONCLUSION
CBL – VDL Measurement Provides
L Casing to Cement Bond
L Cement to Formation Bond
L Zonal Isolation
L Channels / Patchy Cement Identification
L Microannulus
66. ULTRASONIC (USI) ADVANTAGES OVER SONIC
(CBL)
• Tolerates liquid microannulus (vibrations normal to
surface)
• Full coverage, 30 mm resolution image
– Detailed picture of material distribution: solid, liquid,
gas, debonded cement
– Detects narrow channels
• Easier interpretation and less uncertainty than
sonics (CBL/CBT)
• Casing inspection in same pass
68. ACOUSTIC EVALUATION SUMMARY
• Acousticlogs are sensitive to the acoustic properties
(especially impedance) of the material in contactwith the
casing.
• The USI is the primary evaluation tool: the image is easier to
interpret and much less ambiguous than the CBL log.
• USI and CBL are sensitive to the cement/casing bond but in
different ways- complementaryevaluation.
• Acousticmethods are limited in very light cements (low
acoustic contrast from mud).
• For optimum evaluation, cement job data must be included
in the evaluation because cement does not disappear.
69. CEMENT EVALUATION WITH THE
ULTRASONIC IMAGER
• Introduction
• Acoustics basics
• USI tool basics
– Measurements and processing
– Tool and specifications
– Logging procedure
– Images
• USI QC
• USI and CBL/VDL interpretation
• Integrating logs and cementing data
70. ULTRASONIC IMAGER
• Ultrasonic tool operating between 200 and 700 kHz.
• Full casing coverage at 1.2 in. (30 mm) resolution
using rotating transducer
• Measurements
• Cement evaluation
• Casing corrosion and wear
73. USI SIGNAL PROCESSING
Fluid properties measurement (FPM)
Zmud mud
V
T3 processing:
Echo amplitude
Travel time
Resonant frequency:
Fractional bandwith:
f 0
f 0
D f
Internal
rugosity
Casing
thickness
Internal
radius
Waveform
Cement
impedance
Fit plane wave
model
Correct for cylindrical casing
geometry
Casing
thickness
Cement
impedance
77. FEATURES AND BENEFITS
Improved processing ( eliminates the need for free pipe ).
Can Differentiate fluids behind the casing.
Gives internal casing radius and image.
Strong centralization system.
100% azimuth coverage improves resolution
78. USIT FAMILY
Service Application
Measurement
USI Cement evaluation Transit time
Baseline corrosion log Amplitude
Casing wear & damage Casing thickness via
casing resonance
Cement
Impedance -T3
UBI High resolution Transit time
Measurements of inner Amplitude
surface of casing &
borehole Borehole geometry &
deformation
Thinbed & fracture analysis
UCI High resolution Transit time
Measurements of casing Amplitude
Inner & outer surface Casing thickness via
Inspection (with thickness) multiple echoes
79. USI SONDE Length (sonde and cartridge only)
248 in. [6.3 m]
Diameter 3.6 to 11.2
in.
Weight
Sonde 188 to 210
lb
Cartridge 153 lb
Maximum temperature rating 350oF
[175oC]
Maximum operating pressure 20,000 psi
Maximum mud weight
Water-base mud 16 lbm/gal
Oil-base mud 11.6
lbm/gal
Recommended logging speed (ft/hr)
400 to 3200
Acoustic impedance
Range 0 to 10
MRayl
Resolution 0.2 Mrayl
Casing inside diameter
Range 4.5 to 14 in.
Radius resolution 0.002 in.
Casing thickness
Range 0.18 - 0.59
in
Resolution 0.002 in.
80. Principle and Measurement
Transducer
Mud Casing Cement
• Acoustic Impedance
• Thickness
• Transit time
• Amplitude of main
echo
• Cement images
• Thickness and
External metal loss
images
• I.D. and Internal
metal loss images
• Images of casing
internal condition
Principle
Measurement
81. Acoustic Properties of
Materials
Material Density Velocity Acoustic
(Kg/m3) (m/sec) Impedance
(MRay1 106•m-2•sec-1)
Air (1-100 bar) 1.3-130 330 0.004-0.04
Water 1000 1500 1.5
Drilling Fluids 1000-2000 1300-1800 1.5-3.0
Cement Slurries 1000-2000 1800-1500 1.8-3.0
Cement (litefil) 1400 2200-2600 3.1-3.6
Cement (classG) 1900 2700-3700 5.0-7.0
Limestone 2500 5000 12
82. PLANE-WAVE REFLECTION AND TRANSMISSION
COEFFICIENTS
ACOUSTIC IMPEDANCE Z = Density X Acoustic Velocity
(For a homogeneous medium)
REFLECTION COEFFICIENT
R = (Z2 -Z1)/(Z2+Z1)
TRANSMISSION COEFFICIENT
T = 1 + R =(2Z2)/Z2+Z1)
Z1 Z2
1
T
R
90. USI Signal Processing
T-3 : TRAITMENT TRES TOT
➔ Four Basic Outputs
➔ Amplitude
➔ Internal Radii
➔ Thickness
➔ Acoustic Impedance
➔ Internal Radii & Amplitude
➔ From the TIME DOMAIN
➔ Thickness + Acoustic Impedance
➔ From GROUP DELAY in FREQUENCY DOMAIN
99. USI GENERAL SPECIFICATIONS
Length (sonde and cartridge only) 248 in. [6.3 m]
Diameter 3.6 to 11.2 in.
Weight
-Sonde 188 to 210 lb
-Cartridge 153 lb
Maximum temperature rating 350o
F[175o
C]
Maximum operating pressure 20,000 psi
Recommended logging speed 400 to 3200 ft/hr
Combinable with CBL-VDL, CBT, GPIT,
GammaRay. CCL
100. USI MEASUREMENT SPECIFICATIONS
Casing OD 4.5 - 13.375 in.
Casing thickness 0.17 - 0.59 in. (4.5-15 mm)
Acoustic Impedance 0-10 MRayl
Max. deviation No limit
Logging speed 400 to 3200 ft/hr
Sampling
- Azimuthal 5-10 deg.
- Vertical 0.6-6 in.
Maximum mud weight
-Water-base mud ~16 lbm/gal
-Oil-base mud ~11.6 lbm/gal*
* Depends on composition, temperature and pressure.
Good logs are usually obtained up to 13 lb/gal and sometimes up to 16
102. USI LOGGING PROCEDURE
1. Measure fluid
properties using
reference plate while
running into well:
- velocity FVEL
- acoustic impedance
ZMUD
2. Enter ZMUD and FVEL
parameters. Flip
transducer to face casing
and log up.
103. USI CEMENT IMAGE SETTINGS
Raw
Interpreted Image
Cement
Liquid
Gas or dry micro-annulus
Standar
d
Light
0
2
4
6
8
Z MRayl
Solid/liquid
threshold ZTCM
Maximum
impedance
Gas/liquid
threshold
+/- 0.5
The USI discriminates between solid, liquid and
gas/dry microannulus using acoustic impedance
thresholds.
104. USI PARAMETERS
Mud impedance inside casing Zmud
• From FPM (after Q-check versus theoretical value). 0.1
MRayl change in Zmud changes Zcem by ~ 0.5 MRayl.
Cement impedance scale
• Adapt upper limit to cement impedance
C e m e n t t y p e D e n s i t y ( p p g ) U p p e r Z v a l u e
( M R a y l )
N e a t > 1 3 8
L i g h t b e n t o n i t i c 1 4 < d e n s i t y < 1 1 . 5 5
V e r y l i g h t b e n t o n i t i c < 1 1 . 5 4
L i t e C R E T E 1 4 < d e n s i t y < 1 1 . 5 6
L i t e C R E T E < 1 1 . 5 5
Liquid/solid threshold ZTCM
• About 0.5 MRayl above impedance of mud in annulus.
Typical values:
S l u r r y d e n s i t y
( p p g )
Z T C M ( M R a y l )
< 1 2 . 5 *
1 2 . 5 2 . 1
1 6 2 . 6
1 9 3 . 1
105. USI COMBINED CASING + CEMENT PRESENTATION
Casing Cement
QC
Process flags, Eccentering, CCL, gamma
Processing flags
Amplitude
Casing cross-section
Internal radius
Thickness
Thickness
Cement raw
Cement
interpreted
Bond index
Channel
106. USI + CBL/VDL
CEMENT PRESENTATION
USI VDL
QC
Acoustic impedance
Cement image interpreted
VDL
Bond index
CBL, gamma
Process flags, eccentering
CBL
CBL
107. IMAGE ORIENTATION
• In deviated wells, interpretation of channels etc. is
aided by orienting images upper/lower side of
casing
• Orientation tools such as GPIT can be run in
combination with the USI and CBL.
• If no orientation tool is run the USI eccentering
azimuth curve AZEC is usually a good indication of
higher side except in near-vertical wells and S-
bends. It is not sufficiently reliable for automatic
image orientation.
109. USI PRESENTATION WITH DOWELL CEMENT
DATA
USI
Calipers
Casing standoff Average USI
impedance
110. USI/CBL PRESENTATION WITH DOWELL
CEMENTING DATA
Casing
standoff
Calipers
Average USI
impedance
USI
CBL
Predicted
CBL for 80%
and 100%
bond
VDL
111. USI/CBL PRESENTATION WITH DOWELL
CEMENTING DATA
Casing
standoff
G ray USI cement CBL
Predicted CBL for
80% and 100% bond
VDL
USI
amp
USI
ecc
112. STANDARD USI PRESENTATION
Client Log
Dowell CementHeader (if
cementing by Dowell)
Standard API Header
SLB Composite/LQC log
Repeatsection(Client log)
ZMUD and FVELplots
Standard API Tail
113. CEMENT EVALUATION WITH THE
ULTRASONIC IMAGER
• Introduction
• Acoustics basics
• USI tool basics
• USI QC
– FPM check
– QC presentations
– Factors affecting USI response
• USI and CBL/VDL interpretation
• Integrating logs and cementing data
114. USI QC PROCEDURE
• Check fluid properties log (FPM)
• Check QC log for correct echo acquisition
• Check no processing flags
• Eccentering inside spec
• Casing radius and thickness close to nominal in
uncorroded areas
• Casing must be in good condition and radius and
thickness accurate for a good cement log
115. FLUID PROPERTIES MEASUREMENT QC
Fluid velocity curve
is smooth and
consistent withfluid
type
Mud impedance is
inside theoretical
limits with small
dispersion
116. ZMUD CALCULATION
Clear Fluids
Z_FLUID (MRayl) = Rho (g/cm3) * 304.8/Velocity (US/ft)
Rho=downhole density
Check measured Impedance = theory ± 10%
Weighted Muds
Z_FLUID (MRayl) =
K * Rho (G/C3) * 304.8 / Velocity (US/ft )
K - Factor is in the range of 0.85 -1.0. An empirical formula exists for K.
Check measured impedance= theory ± 10%
or +10% - 25% if K not known.
Excel spreadsheet available to check Zmud.
117. USI QC LOG
Travel Time
histogram
Time
Echoes centred
in window
Eccentering inside
tolerance.
Gain below max
Casing ID close
to nominal
Detection
window
118. QC OF COMBINED CASING + CEMENT
IMAGES
Casing Cement
QC
Mean casing diameter and thickness agree
with nominal, curves don’t straight-line
Processing flags
clean
Eccentering
inside tolerance
Casing must be in good conditon for
good cement log
Amplitude image clean (no
rugosity or eccentering)
119. NEW QC+CASING+CEMENT PRESENTATION
Casing Cement
QC
Processing flags
clean
Eccentering
inside tolerance
Casing must be in good conditon for
good cement log
Amplitude image clean
(no rugosity or
eccentering)
QC
Echoes
centred in
window
TT histogram
Mean casing diameter and thickness
agree with nominal, no straight-lining
120. USI PROCESSING FLAGS
0
1
2
3
4-6
7-10
No problem.
Casing thickness error (thickness and
cement impedance invalid).
Error fitting model (cement impedance invalid).
Telemetry.
Echo not detected (all data invalid).
Signal too short for processing (thickness
and cement impedance invalid).
Flags indicate problems during processing of echo
waveforms that may invalidate the data
121. FACTORS AFFECTING USI RESPONSE
• Casing shape and rugosity
– Normal manufacturing patterns affect cement image
slightly
– Wear and corrosion and extreme manufacturing
patterns create artefacts that can be diagnosed by
correlations with casing images
• Tool eccentering
– < 2 to 4% of casing diameter (depending on
thickness) for < 0.5 MRayl error
• Third interface reflections (outer casing or hard
formation)
122. CASING SHAPE EFFECTS
Internal manufacturing patterns often affect
cement image slightly but do not usually affect
interpretation
Amp Int rad. Cement
Formation
reflections
123. POOR CASING CONDITION AFFECTS CEMENT
EVALUATION
Red “Gas”
indications
Processing
flags
Echo amplitude
shows rugosity
Processing flags and amplitude image show that
gas indications are an artifact of internal rugosity
QC Casing Cement
125. DEFORMED CASING
QC Casing Cement
Deformed casing can cause lost echoes and tool
eccentering. Even the eccentering curve becomes false. The
log must be repeated with a wider acquisition window.
Max/min TT TT histogram
Echoes outside
acquisition window
Window
Lost echoes
Eccentering
126. THIRD INTERFACE REFLECTIONS
Int.
radius
Thickness Cement
Typical “galaxy” patterns created by interference between
casing resonance and reflections from outer casing (here) or
hard formation. The patterns indicate good cement except
when the casing touches the formation in free pipe.
Narrow side of
annulus
Galaxy pattern
Channel
127. THIRD INTERFACE REFLECTIONS
Casing Cement
No centralizers, 4.5 in. liner inside 7 in. casing
Galaxy patterns
on narrow side of
annulus
3 centralizers/joint, 7 in. casing in open hole
Tigerskin
pattern all
round
Collar
Collar
Centralizers
128. CEMENT EVALUATION WITH THE
ULTRASONIC IMAGER
• Introduction
• Acoustics basics
• USI tool basics
• USI QC
• USI and USI/CBL Interpretation
– USI response
– USI and CBL/VDL
– Typical images and logs
– Interpretation summary
– Limitations of ultrasonics
• Integrating logs and cementing data
129. USI RESPONSE TO MATERIALS IN
ANNULUS
G o o d c e m e n t + / - 1 5 % i m p e d a n c e
( + 2 5 % i f s h e a r b o n d )
L iq u id s / g a s + / - 0 .5 M R a y l
G a s m ic r o a n n u lu s / d r y
d e b o n d
R e a d s g a s
L iq u id la y e r
- < 0 .2 m m m ic r o a n n u lu s
- M u d la y e r > 0 .5 m m
T o l e r a t e s 0 .1 t o 0 .2 m m
( 5 0 % r e a d i n g w i t h 6 t o
1 2 m m c a s i n g
t h i c k n e s s )
R e a d s m u d
T h in c e m e n t R e f l e c t i o n s f r o m
s e c o n d c a s i n g o r h a r d
f o r m a t i o n c r e a t e
i n t e r f e r e n c e p a t t e r n s
131. BP TEST WELL (1)
Channel and contaminated cement
Contaminated
cement
Good
cement
Channel
Heavily
contam.
cement
132. BP TEST WELL (2)
Mud cake
Good
cement
Mud
cake
Outer casing
reflections
133. USI AND CBL/VDL
In simple cases (good well-bonded cement,
free pipe, mud channel) the tools agree.
In more complicated real-life situations the
tools have different responses which can
aid interpretation:
Contaminated cement
Wet microannulus
Dry microannulus
134. USI AND CBL/VDL GUIDE
U S I C B L / V D L
R e s o lu t io n 1 . 2 i n . 3 6 0 d e g . x 3 f t
W e l l b o n d e d
c e m e n t
C e m e n t C e m e n t
V e r y l ig h t
c e m e n t
L o w c o n t r a s t
[ s p e c i a l p r o c e s s in g
i f d e b o n d e d ]
L o w c o n t r a s t f r o m
m u d
D r y m i c r o a n n .
D e b o n d e d
c e m e n t
D r y m i c r o a n n . / g a s
( s p e c i a l p r o c e s s in g )
G o o d / f a i r b o n d
W e t m ic r o a n n . S l i g h t l y a f f e c t e d A m b i g u o u s
M u d la y e r C h a n n e l A m b i g u o u s
C o n t a m i n a t e d
c e m e n t
L o w - Z c e m e n t A m b i g u o u s
M i x e d l e a d / t a il
c e m e n t
M i x e d l e a d / t a il A m b i g u o u s
M u d c h a n n e l C h a n n e l A m b i g u o u s
G a s c h a n n e l G a s c h a n n e l C e m e n t / a m b i g u o u s
F o r m a t i o n b o n d N o t s e e n V D L q u a l it a t i v e
O u t e r c a s in g /
h a r d f o r m a t i o n
S l i g h t l y a f f e c t e d S t r o n g l y a f f e c t e d
C a s i n g c o n d i t i o n V e r y s e n s i t i v e S l i g h t l y s e n s i t i v e
M u d a t t e n u a t i o n < 1 2 d B / c m / M H Z N o l i m it
135. GOOD CEMENT
USI VDL
QC CBL
CBL flat, low
Strong formation
arrival
Weak casing arrival
Mean Z 8
MRayl
142. MICROANNULUS/ DEBOND
A small gap (< 0.2 mm) between casing and
cement formed by pressure and
temperature changes, or a mud film left on
the casing
USI and CBL respond in different ways
M ic r o a n n u lu s U S I C B L
W e t W e a k l y
a f f e c t e d f o r
g a p s < 0 . 1 t o
0 .2 m m
S t r o n g l y
a f f e c t e d
D r y R e a d s g a s .
S p e c i a l
m i c r o -
d e b o n d i n g
p r o c e s s i n g
W e a k l y
a f f e c t e d f o r
v e r y s m a l l g a p s
( m i c r o n s )
V D L "b i t t y "
143. WET MICROANNULUS
USI BI VDL
High CBL
Uniform
medium-Z USI
Strong, regular
casing arrival
• USI is weakly affected
• CBL reads near free pipe
144. DRY MICROANNULUS/ DEBOND
Dry microannulus
Gas microannulus
Dry debond
Micro debond
Mean the same thing
Indicate solid cement
Often occur without gas entry even in double casing strings due
to pressure or temperature changes
Act as a barrier to ultrasound
Gas entry should only be suspected if in known gas zone, gas
injector well near, or gas at surface
145. GAS CHANNEL AND MICROANNULUS
Gas coming to surface of old storage well
Old CBL showed almost 100% bond
New USI showed narrow gas channel plus areas of debond
(gas microannulus)
Narrow gas channel
Gas microannulus
Good cement
Raw BI Interp
147. EXTENDED DRY MICROANNULUS
(DEBONDED CEMENT)
Debonding can be extensive
with low impedance
variability and not
associated with gas entry
Raw BI Interp
148. MICRO-DEBONDING: USI AND CBL ARE
COMPLEMENTARY
CBL less affected than USI without pressure
USI and CBL improve with pressure
USI BI VDL USI BI VDL
With pressure Without pressure
USI
CBL
150. MICRO-DEBONDED CEMENT PROCESSING
H o r i z o n t a l
D e v i a t i o n
D i a g o n a l 1
D i a g o n a l 2
V e r t i c a l
D e v i a t i o n
T r a n s d u c e r
“ s p o t ” s i z e
If all 4 standard deviations are higher than set thresholds, the
current data point is considered to be locally debonded.
156. ACOUSTIC EVALUATION AT A GLANCE
Good interpretation
Ambiguous
Very ambiguous or not detectable
C e m e n t U S I C B L
H e a v y , m e d i u m , g o o d b o n d
V e r y l i g h t , g o o d b o n d
D e b o n d e d , d r y
m i c r o a n n u l u s
L i q u i d m i c r o a n n u l u s
M u d l a y e r
M u d c h a n n e l
C o n t a m i n a t e d
G a s c h a n n e l
157. CEMENT EVALUATION WITH THE
ULTRASONIC IMAGER
• Introduction
• Acoustic methods basics
• USI tool basics
• USI QC
• USI Interpretation
• Integrating logs and cementing data
– Well and cementing data needed
– Is cement present?
– Are the logs consistent with the data?
– Schlumberger integrated evaluation
158. INTEGRATED ANALYSIS
Acoustic logs have limitations. To make the best
evaluation the logs must be analyzed together
with the well data and cement job data.
159. WELL AND CEMENT JOB DATA NEEDED
• Well data:
– Caliper, GR, sonic, directional survey, temperature,
frac pressures
– Casings and centralization
• Cement job data:
– Density, rheology, pump rates, well head pressure,
mud rheology
– Volumes and returns
– >> Predictions of cement placement
• Expected cement acoustic impedance
– Measured in lab (e.g. UCA)
160. Q1: IS CEMENT LIKELY TO BE PRESENT?
• Where is the expected top of cement?
– Is the cement log depth far away from this depth?
• What could have gone wrong?
– Were caliper data used to determine top of cement?
– Was the cement volume pumped as designed?
– Did the top plug bump?
– Were losses encountered during the job?
– How does the measured wellhead pressure compare
with the predicted one (Job Signature)?
161. Q2: IS THE LOG CONSISTENT WITH THE
WELL AND CEMENTING DATA? (1)
• Channel
– Poor pipe centralization?
– Poor mud conditionbefore cement job?
• Yieldpoint or gel strength too high?
– Flow rate too low?
• Mini. circulationrate to mobilisemud on narrow side not achieved?
– Washout (caliper)?
• Thick mud film
– Good pipe centralization?
– Poor mud conditionbefore the cement job?
• Yieldpoint or gel strength too high?
– Flow rate too low?
162. Q2: IS THE LOG CONSISTENT WITH THE WELL AND
CEMENTING DATA? (2)
• Contaminated cement / Poorly set cement:
1. Not enough bottom plugs?
– Did formation fluid enter during/after the job? (OH logs)
– Cement/permeable formation interactions? (OH logs)
– Temperatures overestimated?
163. Q2: IS THE LOG CONSISTENT WITH THE WELL AND CEMENTING
DATA? (3)
• Microannulus / Debonding:
– Did log improve with pressure?
– Is it due to a post job event ?
• Pressure testing of the pipe
• Change of fluid density
• Drilling of next section
– Thin layer of mud/spacer left at the pipe wall (mud
condition and flow rate incorrect)?
• Gas entry or gas channel
– Is there a known gas zone (OH logs)?
– Is there a gas injection well near?
164. SCHLUMBERGER INTEGRATED CEMENTING
AND EVALUATION
Integrating Dowell cementing and cement job
analysis with USI and CBL/VDL wireline logs
provides the optimum evaluation.
In the past cement job analysis was
separate from wireline logs.
Now key well and cementing data can be
integrated in the USI/CBL log for a complete
evaluation.
165. CBL ADVISER
Accounts for all well parameters and slurry properties
Computes expected cement properties and flags
misleading situations
Light lead slurry
1200 kg/m3
Tail 1 1900 kg/m3
Tail 2 2000 kg/m3
Fill Impedance CBL
amplitude
Attenuation
166. SCHLUMBERGER INTEGRATED EVALUATION
New USI wellsite software allows:
Automatic inclusion of detailed Dowell cement
header
Inclusion of Dowell well and cementing data:
Cement density histogram
Caliper logs
Calculated pipe standoffs
Expected cement impedances
Predicted CBL reading for 100% and 80% bond
168. CONCLUSION
The USI provides the most detailed view of the
distribution of cement in the annulus available
today.
The combination with the CBL/VDL is
recommended for added confidence, especially
when microannulus is present.
Acoustic logs have limitations.
Cement evaluation must combine cement job
analysis and acoustic logs
Schlumberger integrated cementing and evaluation
is the optimum solution.
