Automated Traffic Control Paradigms: Thinking Beyond Signals

This document summarizes the key points made in a presentation about modeling transportation systems for an automated vehicle world. It discusses how autonomous vehicles could impact traffic flow by allowing closer vehicle spacing, potentially increasing road capacity. It also explores how autonomous vehicles may affect traveler choices and demand for different modes like transit or personal vehicles. New opportunities for real-time traffic control are presented. The document emphasizes that transportation models need to account for interactions between the supply of infrastructure and demand from travelers to adequately capture impacts of autonomous vehicles.

Technology

Modeling for an Automated Vehicle World
Stephen Boyles
Assistant Professor
Civil, Architectural & Environmental Engineering
The University of Texas at Austin
March 2, 2015
D-STOP Symposium
Austin, TX

What do we mean by “automated”?
This talk is about future possibilities of fully-autonomous
vehicles which do not require human interaction at all.

Why is everybody talking about AVs?
Enormous opportunities for improving mobility, reducing
congestion, improving safety, etc.

The technology for AVs is imminent...
...policymaking is the likely bottleneck, not technology.

So, there’s no time like the present to plan.
While AVs present great opportunities, it is not clear that these
opportunities will be realized.
?

Talk outline:
1. How can we model impacts of AVs on congestion?
2. How can we model impacts of AVs on traveler choices?
3. What are the new opportunities for traffic control?
4. Implications for transportation modeling in the future

Transportation models can roughly be
grouped into “supply” and “demand”
“Supply” side
Traffic jams
Signalized control
Contraflow lanes
“Demand” side
Route choice
Traveler information
Mode choice
Autonomous vehicles interact very heavily with both of these.

“Supply” side
Traffic jams
Signalized control
Contraflow lanes
“Demand” side
Route choice
Traveler information
Mode choice
These two “sides” interact with each other heavily, and an
equilibrium concept is often used to reconcile them.
Travel choices determine congestion, but congestion affects
travel choices.

On a highway, AVs can increase capacity because they require
less following distance.

In traffic flow theory, this will change the shape of the
“fundamental diagram” relating vehicle density to flow.
0
1000
2000
3000
4000
5000
6000
7000
8000
0 50 100 150 200 250 300
Flow(veh/hr)
Density (veh/mi)
0.25 0.5
1 1.5
Levin & Boyles (2015, under review)

At intersections, we can do even better.
Dresner & Stone (2010)

Levin & Boyles (2014)
These high-detail simulation models can also be approximated
for use in models with hundreds of intersections.
Reservation-based intersections in DTA Model

Will AVs induce new demand?
How will they affect choice of destination? Parking? Transit?
vs.

Trip generation
Productions and attractions
Trip distribution
Person-trips per origin-destination
Mode choice
Origin-destination trips per mode
Traffic assignment
Routes and flows at user equilibrium
feedback

Transit
Park at destination
• Parking fee
Return to origin
• Fuel costs
logit
model
minimum
cost
Personal vehicle
Person trips

Downtown Austin network
– 88 zones
– 634 nodes
– 1574 links
– 62836 trips
– 84 bus routes
10 value of time classes
Levin & Boyles (2015)

Levin & Boyles (2015)
20
21
22
23
24
25
26
27
28
29
0 2 4 6 8 10
Avg.linktraveltime(sec)
Number of classes with autonomous vehicles
Effects on traffic

Levin & Boyles (2015)
Effects on transit
14000
15000
16000
17000
18000
19000
20000
21000
0 2 4 6 8 10
Transitdemand(persontrips)
Number of classes with autonomous vehicles

In the future, we may see the distinction between “operations”
and “planning” start to blur.
Planning: Long-term time horizon; future
forecasts or scenarios; alternatives
analysis and project rankings
Operations: Present-day modeling; real-
time observation and control; travel
information provision
The future: Future planning and
policy analysis accounting for
real-time control technologies

Conclusions
• AVs present tremendous opportunity, but must be carefully
planned for.

Conclusions
• AVs present tremendous opportunity, but must be carefully
planned for.
• Emerging modeling techniques can help guide policy.

Conclusions
• AVs present tremendous opportunity, but must be carefully
planned for.
• Emerging modeling techniques can help guide policy.
• The future is now!
