This work presents a fast response and stable computer based a brushed DC motor speed controller. The controller configured of gate drive circuits for H-Bridge accompanied with data acquisition unit DAQ-6211. These gate drive circuits include, phase comparator, current booster and wave forms cleaning circuits. An optical encoder is used for motor speed to frequency conversion. The CD4046 PLL chip compares phases of the encoder output frequency (motor speed) with a reference frequency (desired speed). The obtained phase difference (error) is used to allocate the suitable PWM duty cycles. An H-Bridge BJT switches driven by PWM is interfaced with the motor. The system hardware is provided with a simple and accurate data acquisition unit DAQ-6211 to be interfaced with the LabVIEW software Package. This allows monitoring and storing the different measured data of this platform. The system relative stability is determined and examined based on the Bode plot analysis and design. Then the relative stability criterion (Phase Margin) is measured the closed-loop stability of the system. This system considers the fast feedback response with indication of its stability state as well as the stable wide dynamic range. It compensates the changes in system parameters due to the environmental effects and other disturbances.
This paper introduces experimental comparison study between six and four switch inverter fed three phase induction motor drive system. The control strategy of the drive is based on speed sensoreless vector control using model reference adaptive system as a speed estimator. The adaptive mechanism of speed control loop depends on fuzzy logic control. Four switch inverter conFigureurations reduces the cost of the inverter, the switching losses, the complexity of the control algorithms, interface circuits, the computation of real-time implementation, volume-compactness and reliability of the drive system. The robustness of the proposed model reference adaptive system based on four switch three-phase inverter (FSTPI) fed induction motor drive is verified experimentally at different operating conditions. Experimental work is carried using digital signal processor (DSP1103) for a 1.1 kW motor. A performance comparison of the proposed FSTP inverter fed IM drive with a conventional six switch three-phase inverter (SSTP) inverter system is also made in terms of speed response. The results show that the proposed drive system provides a fast speed response and good disturbance rejection capability. The proposed FSTP inverter fed IM drive is found quite acceptable considering its performance, cost reduction and other advantages features.
Analysis of Induction Motor Speed Control Using SCADA Based Drive Operated Sy...IJSRD
This Paper represents the analysis of induction motor speed control using VFD (Variable Frequency Drive) system operated by PLC-SCADA system. The main aim of the paper is to dealt with the concept of speed control of a three-phase induction motor with energy saving. To do so, a VFD (Variable Frequency Drive) is used for controlling the speed of a three-phase induction motor with variable load attached to the motor. It certainly leads to the best performance and high efficiency of the induction motor. Programmable Logic Controller (PLC) and Supervisory Control And Data Acquisition (SCADA) are two new systems to control a Variable Frequency Drive (VFD) whose output is given to a three-phase induction motor and driving a conveyor belt. The conveyor belt has three sensors are inputs which senses a passing object and carries out the necessary instructions programmed in ladder logic programming of the PLC through the computer (PC). The SCADA software installed in the PC in turn enables the human operator to control the entire operation away from the plant and just by using the virtual inputs designated on his computer screen.
Nowadays, A lot of industry requires Multi Motor System (MMS) applications such as propulsion and traction power, HEV, conveyer and air-conditioner. The Conventional arrangement for MMS usually done by cascading the motors drives which each drives has individual inverter. Part of MMS, Dual-Motor drives fed by a single inverter is being paid attention by the researchers. Dual-motor drives using a single three-leg inverter has its limitation in the case of different operating conditions and independent speed control requirement. Therefore, dual-Motor drives using a single Five-leg Inverter (FLI) was proposed for independent control for both motors. In PMSM drives, the information of the feedback speed and rotor angular position is compulsory for variable speed drives. Conventional solution is by using speed sensor which will increase size, cost, extra hardwire and feedback devices, especially for the case of dual-PMSM drives. The best solution to overcome this problem is by eliminating the usage of speed and position sensors for Dual-motor drives. This paper presents a new sensorless strategy using speed and position estimator for Independent Dual- Permanent Magnet Synchronous Machine (PMSM) drives which utilize Five-Leg Inverter (FLI). The proposed strategy is simulated using MATLAB/Simulink to evaluate the overall motor drive performance. Meanwhile the experimental set-up is connected to dSPACE 1103 Board. The experimental results demonstrate that the proposed estimator is successfully managed to control the Dual-PMSM drives for variation of speed and for different direction applications.
The batteries used in electric and hybrid vehicles
consists of several cells with voltages between 3.6V battery and
4.2 V in series or parallel combinations of configurations for
obtaining the necessary available voltages in the operation of a
hybrid electric vehicle. How malfunction of a single cell affects
the behavior of the entire battery pack, BMS main function is to
protect individual cells against over-discharge, overload or
overheating. This is done by correct balancing of the cells. In
addition BMS estimates the battery charge status
