In electric vehicles (EVs) and hybrid EVs, energy efficiency is essential where the energy storage is limited. Adding to its high stability and low cost, the induction motor efficiency improves with loss minimisation. Also, it can consume more power than the actual need to perform its working when it is operating in less than full load condition. This study proposes a control strategy based on the fuzzy logic control (FLC) for EV applications. FLC controller can improve the starting current amplitude and saves more power. Through the MATLAB/SIMULINK software package, the performance of this control was verified through simulation. As compared with the conventional proportional integral derivative controller, the simulation schemes show good, high-performance results in time-domain response and rapid rejection of system-affected disturbance. Therefore, the core losses of the induction motor are greatly reduced, and in this way improves the efficiency of the driving system. Finally, the suggested control system is validated by the experimental results obtained in the authors’ laboratory, which are in good agreement with the simulation results.
For Induction motor is a system that works at their speed, nevertheless there are applications at which the speed operations are needed. The control of range of speed of induction motor techniques is available. The robust control is used with induction motor and the performance of the system with the controller will be improved. The mathematical model to the controller, which were coded in MATLAB. The modeling and controller will be shown by the conditions of robustness of be less than one.
Dynamic Simulation of Induction Motor Drive using Neuro Controlleridescitation
Induction Motors are widely used in Industries, because of the low maintenance
and robustness. Speed Control of Induction motor can be obtained by maximum torque and
efficiency. Apart from other techniques Artificial Intelligence (AI) techniques, particularly
the neural networks, improves the performance & operation of induction motor drives. This
paper presents dynamic simulation of induction motor drive using neuro controller. The
integrated environment allows users to compare simulation results between conventional,
Fuzzy and Neural Network controller (NNW).The performance of fuzzy logic and artificial
neural network based controller's are compared with that of the conventional proportional
integral controller. The dynamic Modeling and Simulation of Induction motor is done using
MATLAB/SIMULINK and the dynamic performance of induction motor drive has been
analyzed for artificial intelligent controller.
