This study investigates experimentally the performance of two-dimensional solar tracking systems with reflector using commercial silicon based photovoltaic module, with open and closed loop control systems. Different reflector materials were also investigated. The experiments were performed at the Hashemite University campus in Zarqa at a latitude of 32⁰, in February and March. Photovoltaic output power and performance were analyzed. It was found that the modified photovoltaic module with mirror reflector generated the highest value of power, while the temperature reached a maximum value of 53 ̊ C. The modified module suggested in this study produced 5% more PV power than the two-dimensional solar tracking systems without reflector and produced 12.5% more PV power than the fixed PV module with 26⁰ tilt angle.
Harvesting energy from the sun makes the photovoltaic (PV) power generation a promising technology. To obtain a consistent state of charge (SOC), consistent energy must be harvested and efficiently directed to the battery. Overcharging or undercharging phenomena decreases the lifetime of the battery. Besides, the effect of irradiance toward solar in term of sunlight intensity effects the efficiency and hence, sluggish the SOC. The main problem of the solar panel revealed when the temperature has increased, the efficiency of solar panel will also be decreased. This manuscript reports the finding of developing an automatic active cooling system for a solar panel with a real time energy monitoring system with internet-of-things (IoT) facility. The IoT technology assists user to measure the efficiency of the solar panel and SOC of the battery in real time from any locations. The automatic active cooling system is designed to improve the efficiency of the solar panel. The effectiveness of the proposed system is proven via the analysis of the effect of active cooling toward efficiency and SOC of photovoltaic system. The results also tabulate the comparative studies of active-to-passive cooling system, as well as the effect of cooling towards SOC and efficiency of the solar panel.
When the irradiance distribution over the photovoltaic panels is uniform, the pursuit of the maximum power point is not reached, which has allowed several researchers to use traditional MPPT techniques to solve this problem Among these techniques a PSO algorithm is used to have the maximum global power point (GMPPT) under partial shading. On the other hand, this one is not reliable vis-à-vis the pursuit of the MPPT. Therefore, in this paper we have treated another technique based on a new modified PSO algorithm so that the power can reach its maximum point. The PSO algorithm is based on the heuristic method which guarantees not only the obtaining of MPPT but also the simplicity of control and less expensive of the system. The results are obtained using MATLAB show that the proposed modified PSO algorithm performs better than conventional PSO and is robust to different partial shading models.
A hybrid DC/DC/AC converter connected to the grid without a three-phase transformer is controlled. The decentralized control method is applied to the hybrid DC-DC converter such that the maximum power of PV flows to the grid side. This controller must charge and discharge the battery at the proper time. It must also regulate DC-link voltage. An additional advantage of the proposed control is that the three-phase inverter does not need a separate controller such as PWM and SPWM. A simple technique is used for creating the desired phase shift in the three-phase inverter, which makes the active and reactive power of the inverter controllable. A new configuration is also proposed to transmit and manage the generation power of PV. In this scheme, the battery and fuel cell are employed as an auxiliary source to manage the generation power of PV. Finally, a real-time simulation is performed to verify the effectiveness of the proposed controller and system by considering the real characteristics of PV and FC.
This paper presents simulation and experimental results of anti-windup PI controller to improve induction machine speed control based on direct torque control (DTC) strategy. Problems like rollover can arise in conventional PI controller due to saturation effect. In order to avoid such problems anti-windup PI controller is presented. This controller is simple for implementation in practice. The proposed anti-windup PI controller demonstrates better dynamic step changes response in speed in terms of overshoots. All simulation work was done using Simulink in the MATLAB software. The experimental results were obtained by practical implementation on a dSPACE 1104 board for a 1.5 KW induction machine. Simulation and experimental results have proven a good performance and verified the validity of the presented control strategy.
This paper presents an online efficiency optimization method for the interior permanent magnet synchronous motor (IPMSM) drive system in an electric vehicle (EV). The proposed method considers accurately the total system losses including fundamental copper and iron losses, harmonic copper and iron losses, magnet loss, and inverter losses. Therefore, it has the capability to always guarantee maximum efficiency control. A highly trusted machine model is built using finite element analysis (FEA). This model considers accurately the magnetic saturation, spatial harmonics, and iron loss effect. The overall system efficiency is estimated online based on the accurate determination of system loss, and then the optimum current angle is defined online for the maximum efficiency per ampere (MEPA) control. A series of results is conducted to show the effectiveness and fidelity of proposed method. The results show the superior performance of proposed method over the conventional offline efficiency optimization methods.
This paper deals with an advanced design for a pump powered by solar energyto supply agricultural lands with water and also the maximum power point is used to extract the maximum value of the energy available inside the solar panels and comparing between techniques MPPT such as Incremental conductance, perturb & observe, fractional short current circuit, and fractional open voltage circuit to find the best technique among these. The solar system is designed with main parts: photovoltaic (PV) panel, direct current/direct current (DC/DC) converter, inverter, filter, and in addition, the battery is used to save energy in the event that there is an increased demand for energy and not to provide solar radiation, as well as saving energy in the case of generation more than demand. This work was done using the matrix laboratory (MATLAB) simulink program.
The power generation using solar photovoltaic (PV) system in microgrid requires energy storage system due to their dilute and intermittent nature. The system requires efficient control techniques to ensure the reliable operation of the microgrid. This work presents dynamic power management using a decentralized approach. The control techniques in microgrid including droop controllers in cascade with proportional-integral (PI) controllers for voltage stability and power balance have few limitations. PI controllers alone will not ensure microgrid’s stability. Their parameters cannot be optimized for varying demand and have a slow transient response which increases the settling time. The droop controllers have lower efficiency. The load power variation and steady-state voltage error make the droop control ineffective. This paper presents a control scheme for dynamic power management by incorporating the combined PI and hysteresis controller (CPIHC) technique. The system becomes robust, performs well under varying demand conditions, and shows a faster dynamic response. The proposed DC microgrid has solar PV as an energy source, a lead-acid battery as the energy storage system, constant and dynamic loads. The simulation results show the proposed CPIHC technique efficiently manages the dynamic power, regulates DC link voltage and battery’s state of charge (SoC) compared to conventional combined PI and droop controller (CPIDC).
The emerging of inductive wireless power transfer (IWPT) technology provides more opportunities for the electric vehicle (EV) battery to have a better recharging process. With the development of IWPT technology, various way of wireless charging of the EV battery is proposed in order to find the best solution. To further understand the fundamentals of the IWPT system itself, an ample review is done. There are different ways of EV charging which are static charging (wired), static wireless charging (SWC) and dynamic wireless charging (DWC). The review starts with a brief comparison of static charging, SWC and DWC. Then, in detailed discussion on the fundamental concepts, related laws and equations that govern the IWPT principle are also included. In this review, the focus is more on the DWC with a little discussion on static charging and SWC to ensure in-depth understanding before one can do further research about the EV charging process. The in-depth perception regarding the development of DWC is elaborated together with the system architecture of the IWPT and DWC system and the different track versions of DWC, which is installable to the road lane.
Harvesting energy from the sun makes the photovoltaic (PV) power generation a promising technology. To obtain a consistent state of charge (SOC), consistent energy must be harvested and efficiently directed to the battery. Overcharging or undercharging phenomena decreases the lifetime of the battery. Besides, the effect of irradiance toward solar in term of sunlight intensity effects the efficiency and hence, sluggish the SOC. The main problem of the solar panel revealed when the temperature has increased, the efficiency of solar panel will also be decreased. This manuscript reports the finding of developing an automatic active cooling system for a solar panel with a real time energy monitoring system with internet-of-things (IoT) facility. The IoT technology assists user to measure the efficiency of the solar panel and SOC of the battery in real time from any locations. The automatic active cooling system is designed to improve the efficiency of the solar panel. The effectiveness of the proposed system is proven via the analysis of the effect of active cooling toward efficiency and SOC of photovoltaic system. The results also tabulate the comparative studies of active-to-passive cooling system, as well as the effect of cooling towards SOC and efficiency of the solar panel.
When the irradiance distribution over the photovoltaic panels is uniform, the pursuit of the maximum power point is not reached, which has allowed several researchers to use traditional MPPT techniques to solve this problem Among these techniques a PSO algorithm is used to have the maximum global power point (GMPPT) under partial shading. On the other hand, this one is not reliable vis-à-vis the pursuit of the MPPT. Therefore, in this paper we have treated another technique based on a new modified PSO algorithm so that the power can reach its maximum point. The PSO algorithm is based on the heuristic method which guarantees not only the obtaining of MPPT but also the simplicity of control and less expensive of the system. The results are obtained using MATLAB show that the proposed modified PSO algorithm performs better than conventional PSO and is robust to different partial shading models.
A hybrid DC/DC/AC converter connected to the grid without a three-phase transformer is controlled. The decentralized control method is applied to the hybrid DC-DC converter such that the maximum power of PV flows to the grid side. This controller must charge and discharge the battery at the proper time. It must also regulate DC-link voltage. An additional advantage of the proposed control is that the three-phase inverter does not need a separate controller such as PWM and SPWM. A simple technique is used for creating the desired phase shift in the three-phase inverter, which makes the active and reactive power of the inverter controllable. A new configuration is also proposed to transmit and manage the generation power of PV. In this scheme, the battery and fuel cell are employed as an auxiliary source to manage the generation power of PV. Finally, a real-time simulation is performed to verify the effectiveness of the proposed controller and system by considering the real characteristics of PV and FC.
This paper presents simulation and experimental results of anti-windup PI controller to improve induction machine speed control based on direct torque control (DTC) strategy. Problems like rollover can arise in conventional PI controller due to saturation effect. In order to avoid such problems anti-windup PI controller is presented. This controller is simple for implementation in practice. The proposed anti-windup PI controller demonstrates better dynamic step changes response in speed in terms of overshoots. All simulation work was done using Simulink in the MATLAB software. The experimental results were obtained by practical implementation on a dSPACE 1104 board for a 1.5 KW induction machine. Simulation and experimental results have proven a good performance and verified the validity of the presented control strategy.
This paper presents an online efficiency optimization method for the interior permanent magnet synchronous motor (IPMSM) drive system in an electric vehicle (EV). The proposed method considers accurately the total system losses including fundamental copper and iron losses, harmonic copper and iron losses, magnet loss, and inverter losses. Therefore, it has the capability to always guarantee maximum efficiency control. A highly trusted machine model is built using finite element analysis (FEA). This model considers accurately the magnetic saturation, spatial harmonics, and iron loss effect. The overall system efficiency is estimated online based on the accurate determination of system loss, and then the optimum current angle is defined online for the maximum efficiency per ampere (MEPA) control. A series of results is conducted to show the effectiveness and fidelity of proposed method. The results show the superior performance of proposed method over the conventional offline efficiency optimization methods.
This paper deals with an advanced design for a pump powered by solar energyto supply agricultural lands with water and also the maximum power point is used to extract the maximum value of the energy available inside the solar panels and comparing between techniques MPPT such as Incremental conductance, perturb & observe, fractional short current circuit, and fractional open voltage circuit to find the best technique among these. The solar system is designed with main parts: photovoltaic (PV) panel, direct current/direct current (DC/DC) converter, inverter, filter, and in addition, the battery is used to save energy in the event that there is an increased demand for energy and not to provide solar radiation, as well as saving energy in the case of generation more than demand. This work was done using the matrix laboratory (MATLAB) simulink program.
The power generation using solar photovoltaic (PV) system in microgrid requires energy storage system due to their dilute and intermittent nature. The system requires efficient control techniques to ensure the reliable operation of the microgrid. This work presents dynamic power management using a decentralized approach. The control techniques in microgrid including droop controllers in cascade with proportional-integral (PI) controllers for voltage stability and power balance have few limitations. PI controllers alone will not ensure microgrid’s stability. Their parameters cannot be optimized for varying demand and have a slow transient response which increases the settling time. The droop controllers have lower efficiency. The load power variation and steady-state voltage error make the droop control ineffective. This paper presents a control scheme for dynamic power management by incorporating the combined PI and hysteresis controller (CPIHC) technique. The system becomes robust, performs well under varying demand conditions, and shows a faster dynamic response. The proposed DC microgrid has solar PV as an energy source, a lead-acid battery as the energy storage system, constant and dynamic loads. The simulation results show the proposed CPIHC technique efficiently manages the dynamic power, regulates DC link voltage and battery’s state of charge (SoC) compared to conventional combined PI and droop controller (CPIDC).
The emerging of inductive wireless power transfer (IWPT) technology provides more opportunities for the electric vehicle (EV) battery to have a better recharging process. With the development of IWPT technology, various way of wireless charging of the EV battery is proposed in order to find the best solution. To further understand the fundamentals of the IWPT system itself, an ample review is done. There are different ways of EV charging which are static charging (wired), static wireless charging (SWC) and dynamic wireless charging (DWC). The review starts with a brief comparison of static charging, SWC and DWC. Then, in detailed discussion on the fundamental concepts, related laws and equations that govern the IWPT principle are also included. In this review, the focus is more on the DWC with a little discussion on static charging and SWC to ensure in-depth understanding before one can do further research about the EV charging process. The in-depth perception regarding the development of DWC is elaborated together with the system architecture of the IWPT and DWC system and the different track versions of DWC, which is installable to the road lane.
Electricity is a major source of energy for fast growing population and the use of nonrenewable source is harmful for our environment. This reason belongs to devastating of environment, so it is required to take immediate action to solve these problems which result the solar energy development. Production of a solar energy can be maximizing if we use solar follower. The major part of solar panels is microcontroller with arrangement of LDR sensor is used to follow the sun, where the sensors is less efficient to track the sun because of the low sensitivity of LDR. We are proposing a method to track sun more effetely with the help of both LDR sensors and image processing. This type of mechanism can track sun with the help of image processing software which combines both result of sensors and processed sun image to control the solar panel. The combination of both software and hardware can control thousands of solar panels in solar power plants.
In industrial electric drive systems, it is common to find objects that need to solve the problem of angular position control, moving the object from one position to another asymptotically with no over-correction and guarantee. calculation of maximum fast impact. This is a multi-target optimization problem with many different solutions. This paper presents a method of constructing a PMSM motor position controller with a variable structure using dSPACE 1104 card. The system consists of a position control loop with a variable structure that is an outer loop and a speed control loop degree is the inner loop. In which, the speed adjustment loop uses adaptive law to compensate for uncertain functions and build a sliding mode observation to estimate load torque, friction and noise. The results of the simulation study were verified on Matlab-Simulink environment and experimented on dSPACE 1104 card to check the correctness of the built controller algorithm. The research results in the paper are the basis for the evaluation and setting up of control algorithms, design of electric drive systems in industry and the military.
This paper provides a new approach to reducing high-order harmonics in 400 Hz inverter using a three-level neutral-point clamped (NPC) converter. A voltage control loop using the harmonic compensation combined with NPC clamping diode control technology. The capacitor voltage imbalance also causes harmonics in the output voltage. For 400 Hz inverter, maintain a balanced voltage between the two input (direct current) (DC) capacitors is difficult because the pulse width modulation (PWM) modulation frequency ratio is low compared to the frequency of the output voltage. A method of determining the current flowing into the capacitor to control the voltage on the two balanced capacitors to ensure fast response reversal is also given in this paper. The combination of a high-harmonic resonator controller and a neutral-point voltage controller working together on the 400 Hz NPC inverter structure is given in this paper.
Alternating current (AC) electrical drives mainly require smaller current (or torque) ripples and lower total harmonic distortion (THD) of voltage for excellent drive performances. Normally, in practice, to achieve these requirements, the inverter needs to be operated at high switching frequency. By operating at high switching frequency, the size of filter can be reduced. However, the inverter which oftenly employs insulated gate bipolar transistor (IGBT) for high power applications cannot be operated at high switching frequency. This is because, the IGBT switching frequency cannot be operated above 50 kHz due to its thermal restrictions. This paper proposes an alternate switching strategy to enable the use of IGBT for operating the inverter at high switching frequency to improve THD performances. In this strategy, each IGBT in a group of switches in the modified inverter circuit will operate the switching frequency at one-fourth of the inverter switching frequency. The alternate switching is implemented using simple analog and digital integrated circuits.
The inverter is the principal part of the photovoltaic (PV) systems that assures the direct current/alternating current (DC/AC) conversion (PV array is connected directly to an inverter that converts the DC energy produced by the PV array into AC energy that is directly connected to the electric utility). In this paper, we present a simple method for detecting faults that occurred during the operation of the inverter. These types of faults or faults affect the efficiency and cost-effectiveness of the photovoltaic system, especially the inverter, which is the main component responsible for the conversion. Hence, we have shown first the faults obtained in the case of the short circuit. Second, the open circuit failure is studied. The results demonstrate the efficacy of the proposed method. Good monitoring and detection of faults in the inverter can increase the system's reliability and decrease the undesirable faults that appeared in the PV system. The system behavior is tested under variable parameters and conditions using MATLAB/Simulink.
Direct current (DC) electronic load is a useful equipment for testing the electrical system. It can emulate various load at a high rating. The electronic load requires a power converter to operate and a linear regulator is a common option. Nonetheless, it is hard to control due to the temperature variation. This paper proposed a DC electronic load using the boost converter. The proposed electronic load operates in the continuous current mode and control using the integral controller. The electronic load using the boost converter is compared with the electronic load using the linear regulator. The results show that the boost converter able to operate as an electronic load with an error lower than 0.5% and response time lower than 13 ms.
Mainly the DC motors are employed in most of the application. The main objective is to Regulate the DC motor system. A motor which displays the appearances of a DC motor but there is no commutator and brushes is called as brushless DC motor. These motors are widespread to their compensations than other motors in relationships of dependability, sound, efficiency, preliminary torque and longevity. To achieve the operation more reliable and less noisy, brushless dc motors are employed. In the proposed work, dissimilar methods of speed control are analysed. In real time submission of speed control of BLDC motor, numerous strategies are executed for the speed control singularity. The modified approaches are the employment of PI controller, use of PID controller and proposed current controller.
The development of modeling wind speed plays a very important in helping to obtain the actual wind speed data for the benefit of the power plant planning in the future. The wind speed in this paper is obtained from a PCE-FWS 20 type measuring instrument with a duration of 30 minutes which is accumulated into monthly data for one year (2019). Despite the many wind speed modeling that has been done by researchers. Modeling wind speeds proposed in this study were obtained from the modified Rayleigh distribution. In this study, the Rayleigh scale factor (Cr) and modified Rayleigh scale factor (Cm) were calculated. The observed wind speed is compared with the predicted wind characteristics. The data fit test used correlation coefficient (R2), root means square error (RMSE), and mean absolute percentage error (MAPE). The results of the proposed modified Rayleigh model provide very good results for users.
The electrical and environmental parameters of polymer solar cells (PSC) provide important information on their performance. In the present article we study the influence of temperature on the voltage-current (I-V) characteristic at different temperatures from 10 °C to 90 °C, and important parameters like bandgap energy Eg, and the energy conversion efficiency η. The one-diode electrical model, normally used for semiconductor cells, has been tested and validated for the polemeral junction. The PSC used in our study are formed by the poly(3-hexylthiophene) (P3HT) and [6,6]-phenyl C61-butyric acid methyl ester (PCBM). Our technique is based on the combination of two steps; the first use the Least Mean Squares (LMS) method while the second use the Newton-Raphson algorithm. The found results are compared to other recently published works, they show that the developed approach is very accurate. This precision is proved by the minimal values of statistical errors (RMSE) and the good agreement between both the experimental data and the I-V simulated curves. The obtained results show a clear and a monotonic dependence of the cell efficiency on the studied parameters.
With the dominating utility of the internet, it becomes critical to manage the efficiency and reliability of telecom and datacenter, as the power consumption of the involved equipment also increases. Much power being wasted through the power conversion stages by converting AC voltage to DC voltage and then stepping down to lower voltages to connect to information and communication technology (ICT) equipment. 48/12 VDC is the standard DC bus architecture to serve the end utility equipment. This voltage level is further processed to multiple lower voltages to power up the internal auxiliary circuits. Power losses are involved when it is converted from higher voltage to lower voltages. Therefore, the efficiency of power conversion is lower. There is a need to increase the efficiency by minimizing the power losses which occur due to the conversion stages. Different methods are available to increase the efficiency of a system by optimizing the converter topologies, semiconductor materials and control methods. There is another possibility of increasing the efficiency by changing the architecture of a system by increasing the DC bus voltage to higher voltages to optimize the losses. This paper presents a review of available high voltage options for telecom power distribution and developments, implementations and challenges across the world.
Recently, LCL has become amongst the most attractive filter used for grid-connected flyback inverters. Nonetheless, the switching of power devices in the inverter configuration creates harmonics that affect the end application behavior and might shorten its lifetime. Furthermore, the resonance frequencies produced by the LCL network contribute to the system instability. This paper proposes a step-by-step guide to designing an LCL filter by considering several key aspects such as the resonance frequency and maximum current ripple. A single-phase grid-connected flyback microinverter with an LCL filter was designed then constructed in the MATLAB/Simulink environment. Several different parameter variations and damping solutions were used to analyze the performance of the circuit. The simulation result shows a promising total harmonic distortion (THD) value below 5% and harmonic suppression up to 14%.
The electrical distribution network is undergoing tremendous modifications with the introduction of distributed generation technologies which have led to an increase in fault current levels in the distribution network. Fault current limiters have been developed as a promising technology to limit fault current levels in power systems. Though, quite a number of fault current limiters have been developed; the most common are the superconducting fault current limiters, solid-state fault current limiters, and saturated core fault current limiters. These fault current limiters present potential fault current limiting solutions in power systems. Nevertheless, they encounter various challenges hindering their deployment and commercialization. This research aimed at designing a bridge-type nonsuperconducting fault current limiter with a novel topology for distribution network applications. The proposed bridge-type nonsuperconducting fault current limiter was designed and simulated using PSCAD/EMTDC. Simulation results showed the effectiveness of the proposed design in fault current limiting, voltage sag compensation during fault conditions, and its ability not to affect the load voltage and current during normal conditions as well as in suppressing the source powers during fault conditions. Simulation results also showed very minimal power loss by the fault current limiter during normal conditions.
Optimizing of the installed capacity of hybrid renewable energy with a modifi...IJECEIAES
The lack of wind speed capacity and the emission of photons from sunlight are the problem in a hybrid system of photovoltaic (PV) panels and wind turbines. To overcome this shortcoming, the incremental conductance (IC) algorithm is applied that could control the converter work cycle and the switching of the buck boost therefore maximum efficiency of maximum power point tracking (MPPT) is reached. The operation of the PV-wind hybrid system, consisting of a 100 W PV array device and a 400 W wind subsystem, 12 V/100 Ah battery energy storage and LED, the PV-wind system requires a hybrid controller for battery charging and usage and load lamp and it’s conducted in experimental setup. The experimental has shown that an average increase in power generated was 38.8% compared to a single system of PV panels or a single wind turbine sub-system. Therefore, the potential opportunities for increasing power production in the tropics wheather could be carried out and applied with this model.
An improved luo converter for high power applicationseSAT Journals
Abstract
Power conversion is one of the major requirements in various industries and in daily life. Among various types of power
conversion, DC-DC conversion has greater importance. DC-DC conversion can be reliably performed using luo converter. It
employs voltage lift technique so that output voltage is increased stage by stage, in arithmetic progression. Luo converter can be
incorporated with the Z network or impedance network so as to ensure simple start up and smooth power conversion. An
impedance network consist of two identical inductors and two identical capacitors connected in ‘X’ shape. Besides power
conversion it also offers filtering operation. The luo converter in this scheme is of switched capacitor type. It helps to provide
regulated output voltage from an unregulated source of power supply. The major benefits of this proposed scheme is that it
combines the advantages of the switched capacitor, voltage lift technique and the impedance network. Hence the proposed scheme
has various advantages such as high power density, larger range of output DC voltage, lower or no inrush current, lower
harmonic injection, simple circuit, high voltage transfer gain, can process upto several tens of watts of power. The simulation
analysis and the hardware implementation shows that the output voltage obtained is higher than the expected theoretical value.
i.e, it is the highly boosted voltage output.
Keywords: Z-network, boost voltage, voltage lift technique
This paper presents a novel shunt active power filter (SAPF). The power converter that is used in this SAPF is constructed from a four-leg asymmetric multi-level cascaded H-bridge (CHB) inverter that is fed from a photovoltaic source. A three-dimensional space vector modulation (3D-SVPWM) technique is adopted in this work. The multi-level inverter can generate 27-level output with harmonic content is almost zero. In addition to the capability to inject reactive power and mitigating the harmonics, the proposed SAPF has also, the ability to inject real power as it is fed from a PV source. Moreover, it has a fault-tolerant capability that makes the SAPF maintaining its operation under a loss of one leg of the multi-level inverter due to an open-circuit fault without any degradation in the performance. The proposed SAPF is designed and simulated in MATLAB SIMULINK using a single nonlinear load and the results have shown a significant reduction in total harmonics distortion (THD) of the source current under the normal operating condition and post a failure in one phase of the SAPF. Also, similar results are obtained when IEEE 15 bus network is used.
Design and fabrication of rotor lateral shifting in the axial-flux permanent-...IJECEIAES
The development of axial-flux permanent-magnet (AFPM) machines has become a mature technology. The single-stator double-rotor (SSDR) AFPM structure has advantages on the compactness and the low up to medium power applications so the microscale size and low-cost applications are reachable to be designed. The research main objectives are designing and manufacturing the lateral shifting from the north poles of the first rotor face the north poles of the second rotor (NN) to the north poles of the first rotor face the south poles of the second rotor (NS) categories as well as finding the best performance of the proposed method and implementing in a low cost and micro-scale AFPMG. The novel lateral shifting on the one of the rotors shows performance at 19.2 0 has the highest efficiency at 88.39% during lateral shifting from N–N (0 0 ) to N–S (36 0 ) on rotor 2.
This paper presents the analysis, modeling and control of a grid connected photovoltaic generation system. The model contains a detailed representation of the solar array, grid side multilevel neutral point clamped voltage source inverter. Fuzzy logic controller for the maximum power point tracking of a photovoltaic system under variable temperature and insulation conditions is discussed. The PQ control approach has been presented for the multilevel inverter. One of the most common control strategies structures applied to decentralized power generator is based on power direct control employing a controller for the dc link voltage and a controller to regulate the injected current to the utility network. The proposed models were implemented in Matlab/Simulink.
Load frequency control of a two area hybrid system consisting of a grid conne...eSAT Publishing House
IJRET : International Journal of Research in Engineering and Technology is an international peer reviewed, online journal published by eSAT Publishing House for the enhancement of research in various disciplines of Engineering and Technology. The aim and scope of the journal is to provide an academic medium and an important reference for the advancement and dissemination of research results that support high-level learning, teaching and research in the fields of Engineering and Technology. We bring together Scientists, Academician, Field Engineers, Scholars and Students of related fields of Engineering and Technology.
Electricity is a major source of energy for fast growing population and the use of nonrenewable source is harmful for our environment. This reason belongs to devastating of environment, so it is required to take immediate action to solve these problems which result the solar energy development. Production of a solar energy can be maximizing if we use solar follower. The major part of solar panels is microcontroller with arrangement of LDR sensor is used to follow the sun, where the sensors is less efficient to track the sun because of the low sensitivity of LDR. We are proposing a method to track sun more effetely with the help of both LDR sensors and image processing. This type of mechanism can track sun with the help of image processing software which combines both result of sensors and processed sun image to control the solar panel. The combination of both software and hardware can control thousands of solar panels in solar power plants.
In industrial electric drive systems, it is common to find objects that need to solve the problem of angular position control, moving the object from one position to another asymptotically with no over-correction and guarantee. calculation of maximum fast impact. This is a multi-target optimization problem with many different solutions. This paper presents a method of constructing a PMSM motor position controller with a variable structure using dSPACE 1104 card. The system consists of a position control loop with a variable structure that is an outer loop and a speed control loop degree is the inner loop. In which, the speed adjustment loop uses adaptive law to compensate for uncertain functions and build a sliding mode observation to estimate load torque, friction and noise. The results of the simulation study were verified on Matlab-Simulink environment and experimented on dSPACE 1104 card to check the correctness of the built controller algorithm. The research results in the paper are the basis for the evaluation and setting up of control algorithms, design of electric drive systems in industry and the military.
This paper provides a new approach to reducing high-order harmonics in 400 Hz inverter using a three-level neutral-point clamped (NPC) converter. A voltage control loop using the harmonic compensation combined with NPC clamping diode control technology. The capacitor voltage imbalance also causes harmonics in the output voltage. For 400 Hz inverter, maintain a balanced voltage between the two input (direct current) (DC) capacitors is difficult because the pulse width modulation (PWM) modulation frequency ratio is low compared to the frequency of the output voltage. A method of determining the current flowing into the capacitor to control the voltage on the two balanced capacitors to ensure fast response reversal is also given in this paper. The combination of a high-harmonic resonator controller and a neutral-point voltage controller working together on the 400 Hz NPC inverter structure is given in this paper.
Alternating current (AC) electrical drives mainly require smaller current (or torque) ripples and lower total harmonic distortion (THD) of voltage for excellent drive performances. Normally, in practice, to achieve these requirements, the inverter needs to be operated at high switching frequency. By operating at high switching frequency, the size of filter can be reduced. However, the inverter which oftenly employs insulated gate bipolar transistor (IGBT) for high power applications cannot be operated at high switching frequency. This is because, the IGBT switching frequency cannot be operated above 50 kHz due to its thermal restrictions. This paper proposes an alternate switching strategy to enable the use of IGBT for operating the inverter at high switching frequency to improve THD performances. In this strategy, each IGBT in a group of switches in the modified inverter circuit will operate the switching frequency at one-fourth of the inverter switching frequency. The alternate switching is implemented using simple analog and digital integrated circuits.
The inverter is the principal part of the photovoltaic (PV) systems that assures the direct current/alternating current (DC/AC) conversion (PV array is connected directly to an inverter that converts the DC energy produced by the PV array into AC energy that is directly connected to the electric utility). In this paper, we present a simple method for detecting faults that occurred during the operation of the inverter. These types of faults or faults affect the efficiency and cost-effectiveness of the photovoltaic system, especially the inverter, which is the main component responsible for the conversion. Hence, we have shown first the faults obtained in the case of the short circuit. Second, the open circuit failure is studied. The results demonstrate the efficacy of the proposed method. Good monitoring and detection of faults in the inverter can increase the system's reliability and decrease the undesirable faults that appeared in the PV system. The system behavior is tested under variable parameters and conditions using MATLAB/Simulink.
Direct current (DC) electronic load is a useful equipment for testing the electrical system. It can emulate various load at a high rating. The electronic load requires a power converter to operate and a linear regulator is a common option. Nonetheless, it is hard to control due to the temperature variation. This paper proposed a DC electronic load using the boost converter. The proposed electronic load operates in the continuous current mode and control using the integral controller. The electronic load using the boost converter is compared with the electronic load using the linear regulator. The results show that the boost converter able to operate as an electronic load with an error lower than 0.5% and response time lower than 13 ms.
Mainly the DC motors are employed in most of the application. The main objective is to Regulate the DC motor system. A motor which displays the appearances of a DC motor but there is no commutator and brushes is called as brushless DC motor. These motors are widespread to their compensations than other motors in relationships of dependability, sound, efficiency, preliminary torque and longevity. To achieve the operation more reliable and less noisy, brushless dc motors are employed. In the proposed work, dissimilar methods of speed control are analysed. In real time submission of speed control of BLDC motor, numerous strategies are executed for the speed control singularity. The modified approaches are the employment of PI controller, use of PID controller and proposed current controller.
The development of modeling wind speed plays a very important in helping to obtain the actual wind speed data for the benefit of the power plant planning in the future. The wind speed in this paper is obtained from a PCE-FWS 20 type measuring instrument with a duration of 30 minutes which is accumulated into monthly data for one year (2019). Despite the many wind speed modeling that has been done by researchers. Modeling wind speeds proposed in this study were obtained from the modified Rayleigh distribution. In this study, the Rayleigh scale factor (Cr) and modified Rayleigh scale factor (Cm) were calculated. The observed wind speed is compared with the predicted wind characteristics. The data fit test used correlation coefficient (R2), root means square error (RMSE), and mean absolute percentage error (MAPE). The results of the proposed modified Rayleigh model provide very good results for users.
The electrical and environmental parameters of polymer solar cells (PSC) provide important information on their performance. In the present article we study the influence of temperature on the voltage-current (I-V) characteristic at different temperatures from 10 °C to 90 °C, and important parameters like bandgap energy Eg, and the energy conversion efficiency η. The one-diode electrical model, normally used for semiconductor cells, has been tested and validated for the polemeral junction. The PSC used in our study are formed by the poly(3-hexylthiophene) (P3HT) and [6,6]-phenyl C61-butyric acid methyl ester (PCBM). Our technique is based on the combination of two steps; the first use the Least Mean Squares (LMS) method while the second use the Newton-Raphson algorithm. The found results are compared to other recently published works, they show that the developed approach is very accurate. This precision is proved by the minimal values of statistical errors (RMSE) and the good agreement between both the experimental data and the I-V simulated curves. The obtained results show a clear and a monotonic dependence of the cell efficiency on the studied parameters.
With the dominating utility of the internet, it becomes critical to manage the efficiency and reliability of telecom and datacenter, as the power consumption of the involved equipment also increases. Much power being wasted through the power conversion stages by converting AC voltage to DC voltage and then stepping down to lower voltages to connect to information and communication technology (ICT) equipment. 48/12 VDC is the standard DC bus architecture to serve the end utility equipment. This voltage level is further processed to multiple lower voltages to power up the internal auxiliary circuits. Power losses are involved when it is converted from higher voltage to lower voltages. Therefore, the efficiency of power conversion is lower. There is a need to increase the efficiency by minimizing the power losses which occur due to the conversion stages. Different methods are available to increase the efficiency of a system by optimizing the converter topologies, semiconductor materials and control methods. There is another possibility of increasing the efficiency by changing the architecture of a system by increasing the DC bus voltage to higher voltages to optimize the losses. This paper presents a review of available high voltage options for telecom power distribution and developments, implementations and challenges across the world.
Recently, LCL has become amongst the most attractive filter used for grid-connected flyback inverters. Nonetheless, the switching of power devices in the inverter configuration creates harmonics that affect the end application behavior and might shorten its lifetime. Furthermore, the resonance frequencies produced by the LCL network contribute to the system instability. This paper proposes a step-by-step guide to designing an LCL filter by considering several key aspects such as the resonance frequency and maximum current ripple. A single-phase grid-connected flyback microinverter with an LCL filter was designed then constructed in the MATLAB/Simulink environment. Several different parameter variations and damping solutions were used to analyze the performance of the circuit. The simulation result shows a promising total harmonic distortion (THD) value below 5% and harmonic suppression up to 14%.
The electrical distribution network is undergoing tremendous modifications with the introduction of distributed generation technologies which have led to an increase in fault current levels in the distribution network. Fault current limiters have been developed as a promising technology to limit fault current levels in power systems. Though, quite a number of fault current limiters have been developed; the most common are the superconducting fault current limiters, solid-state fault current limiters, and saturated core fault current limiters. These fault current limiters present potential fault current limiting solutions in power systems. Nevertheless, they encounter various challenges hindering their deployment and commercialization. This research aimed at designing a bridge-type nonsuperconducting fault current limiter with a novel topology for distribution network applications. The proposed bridge-type nonsuperconducting fault current limiter was designed and simulated using PSCAD/EMTDC. Simulation results showed the effectiveness of the proposed design in fault current limiting, voltage sag compensation during fault conditions, and its ability not to affect the load voltage and current during normal conditions as well as in suppressing the source powers during fault conditions. Simulation results also showed very minimal power loss by the fault current limiter during normal conditions.
Optimizing of the installed capacity of hybrid renewable energy with a modifi...IJECEIAES
The lack of wind speed capacity and the emission of photons from sunlight are the problem in a hybrid system of photovoltaic (PV) panels and wind turbines. To overcome this shortcoming, the incremental conductance (IC) algorithm is applied that could control the converter work cycle and the switching of the buck boost therefore maximum efficiency of maximum power point tracking (MPPT) is reached. The operation of the PV-wind hybrid system, consisting of a 100 W PV array device and a 400 W wind subsystem, 12 V/100 Ah battery energy storage and LED, the PV-wind system requires a hybrid controller for battery charging and usage and load lamp and it’s conducted in experimental setup. The experimental has shown that an average increase in power generated was 38.8% compared to a single system of PV panels or a single wind turbine sub-system. Therefore, the potential opportunities for increasing power production in the tropics wheather could be carried out and applied with this model.
An improved luo converter for high power applicationseSAT Journals
Abstract
Power conversion is one of the major requirements in various industries and in daily life. Among various types of power
conversion, DC-DC conversion has greater importance. DC-DC conversion can be reliably performed using luo converter. It
employs voltage lift technique so that output voltage is increased stage by stage, in arithmetic progression. Luo converter can be
incorporated with the Z network or impedance network so as to ensure simple start up and smooth power conversion. An
impedance network consist of two identical inductors and two identical capacitors connected in ‘X’ shape. Besides power
conversion it also offers filtering operation. The luo converter in this scheme is of switched capacitor type. It helps to provide
regulated output voltage from an unregulated source of power supply. The major benefits of this proposed scheme is that it
combines the advantages of the switched capacitor, voltage lift technique and the impedance network. Hence the proposed scheme
has various advantages such as high power density, larger range of output DC voltage, lower or no inrush current, lower
harmonic injection, simple circuit, high voltage transfer gain, can process upto several tens of watts of power. The simulation
analysis and the hardware implementation shows that the output voltage obtained is higher than the expected theoretical value.
i.e, it is the highly boosted voltage output.
Keywords: Z-network, boost voltage, voltage lift technique
This paper presents a novel shunt active power filter (SAPF). The power converter that is used in this SAPF is constructed from a four-leg asymmetric multi-level cascaded H-bridge (CHB) inverter that is fed from a photovoltaic source. A three-dimensional space vector modulation (3D-SVPWM) technique is adopted in this work. The multi-level inverter can generate 27-level output with harmonic content is almost zero. In addition to the capability to inject reactive power and mitigating the harmonics, the proposed SAPF has also, the ability to inject real power as it is fed from a PV source. Moreover, it has a fault-tolerant capability that makes the SAPF maintaining its operation under a loss of one leg of the multi-level inverter due to an open-circuit fault without any degradation in the performance. The proposed SAPF is designed and simulated in MATLAB SIMULINK using a single nonlinear load and the results have shown a significant reduction in total harmonics distortion (THD) of the source current under the normal operating condition and post a failure in one phase of the SAPF. Also, similar results are obtained when IEEE 15 bus network is used.
Design and fabrication of rotor lateral shifting in the axial-flux permanent-...IJECEIAES
The development of axial-flux permanent-magnet (AFPM) machines has become a mature technology. The single-stator double-rotor (SSDR) AFPM structure has advantages on the compactness and the low up to medium power applications so the microscale size and low-cost applications are reachable to be designed. The research main objectives are designing and manufacturing the lateral shifting from the north poles of the first rotor face the north poles of the second rotor (NN) to the north poles of the first rotor face the south poles of the second rotor (NS) categories as well as finding the best performance of the proposed method and implementing in a low cost and micro-scale AFPMG. The novel lateral shifting on the one of the rotors shows performance at 19.2 0 has the highest efficiency at 88.39% during lateral shifting from N–N (0 0 ) to N–S (36 0 ) on rotor 2.
This paper presents the analysis, modeling and control of a grid connected photovoltaic generation system. The model contains a detailed representation of the solar array, grid side multilevel neutral point clamped voltage source inverter. Fuzzy logic controller for the maximum power point tracking of a photovoltaic system under variable temperature and insulation conditions is discussed. The PQ control approach has been presented for the multilevel inverter. One of the most common control strategies structures applied to decentralized power generator is based on power direct control employing a controller for the dc link voltage and a controller to regulate the injected current to the utility network. The proposed models were implemented in Matlab/Simulink.
Load frequency control of a two area hybrid system consisting of a grid conne...eSAT Publishing House
IJRET : International Journal of Research in Engineering and Technology is an international peer reviewed, online journal published by eSAT Publishing House for the enhancement of research in various disciplines of Engineering and Technology. The aim and scope of the journal is to provide an academic medium and an important reference for the advancement and dissemination of research results that support high-level learning, teaching and research in the fields of Engineering and Technology. We bring together Scientists, Academician, Field Engineers, Scholars and Students of related fields of Engineering and Technology.
Harvesting solar energy as a renewable energy source has received significant attention through serious studies that could be applied massively. However, the nonlinear nature of photovoltaic (PV) concerning the surrounding environment, especially irradiation and temperature, affects the resulting output. Therefore, the correlation between environmental parameters and PV's energy needs to be studied. This paper presents a design for measuring solar PV parameters monitored on a laboratory scale. The monitoring is based on internet of things (IoT) technology analyzed in realtime. The system was tested in various weather conditions for 18 hours. The results obtained indicate that the output voltage was influenced by the lighting factor of the PV and the surrounding temperature.
An efficient optical inspection of photovoltaic modules deploying edge detec...IJECEIAES
With the enhanced industrial and domestic energy needs, there is a great urge for renewable energy sources because of their eco-friendly nature. Solar energy is crucial among renewable energy sources and there is a great need to optimize and enhance the performance of solar energy usage that is mainly dependent on the system components. The current work has been aimed to discuss the fault detection of photovoltaic (PV) modules by evaluating an efficient, facile inspection algorithm electrical analysis for real-time applications. The paper presents a real-time experimental model for infrared thermography using a thermal imager mounted on a tripod at a suitable distance from the PV modules to capture the images in the best possible way. A novel hybrid algorithm has been proposed and the fault detection along with the electrical parameter analysis has been accurately performed on the PV modules to analyze and process various externally induced faults in the PV systems.
Fabrication and Performance Analysis of Solar Tracking System by Using By-Pas...IJMREMJournal
Energy is a burning issue that almost every person experience now a days. Energy demand increases exponentially
since a decade. Due to the global warming and it’s threatening impacts on human life. Therefore, to overcome
such disastrous impacts on the planet, renewable energy resources play vital role now a days. Solar energy is one
of the vastest available renewable energy resources around the globe, but the main issue is its poor efficiency.
Pakistan is facing energy shortage that can be compensated through solar power and the need is to design a project
that maximizes its efficiency. So, the research is mainly focused on improving efficiency of solar panels against
shading loss by using different techniques. In this research, different results will be obtained and compared with
different techniques which are LDR based solar tracking system, by-pass diodes technology and super capacitors.
Fabrication of solar tracker is based on Microcontroller that drives L298N driver to operate stepper motor.
This article presents the system design and prediction performance of a 1kW capacity grid-tied photovoltaic inverter applicable for low or medium-voltage electrical distri-bution networks. System parameters, for instance, the longitude and latitude of the solar plant location, panel orientation, tilt and azimuth angle calculation, feasibility testing, optimal sizing of installment are analyzed in the model and the utility is sim-ulated precisely to construct an efficient solar power plant for residential applications. In this paper, meteorological data are computed to discuss the impact of environmen-tal variables. As regards ensuring reliability and sustenance, a simulation model of the system of interest is tested in the PVsyst software package. Simulation results yield that the optimum energy injected to the national grid from the solar plant, specific pro-duction, and performance ratio are 1676kWh/year, 1552kWh/kWp/year, and 79.29% respectively. Moreover, the predicted carbon footprint reduction is 23.467 tons during the 30 years lifetime of the system. Therefore, the performance assessments affirm the effectiveness of the proposed research.
This paper discusses the construction and implementation of a system for the measurement of
electrical power parameters; amperage and voltage of the hybrid system photovoltaic solar-wind, to evaluate
the system parameters and performance. The basis of the development of the measuring apparatus is the use of
an Arduino Mega 2560 to provide the interface between the electrical circuits of the sensors and the dynamics
of the voltage-amperage as well as collect data in an analog format as well as development of functional
dependence relationships. The collected data is converted into digital format and stored it in an Excel format
through the "PLX-DAQ Spreadsheet" that connects the Arduino and the PC for display and analysis of the
system parameters. The proposed technique for power measurements of AC and DC proved to be reliable and
can predict the power amperage and voltage within relative error of 1.63 % for AC and 4.16% for DC,
respectively.
Performance of low-cost solar radiation loggerIJECEIAES
In solar power systems, irradiance value data are among the most important parameters. Such data can be used in installing photovoltaic (PV) modules, such as determining the exact location, tilt angle, and required area, for optimal power efficiency. In this study, the comprehensive simulation and implementation of a solar radiation meter with a PV cell and temperature sensor are presented. The irradiance measurement value is based on the power reading generated by the small capacity of the PV cell at a specific load converted into a digital value in the microcontroller using the implicit Newton polynomial interpolation (NPI) equation as a low-cost alternative method. The effect of temperature is included in the conversion to obtain precise measurement results. Firstly, the structure and characteristics of the PV cell are discussed. Secondly, the parameters, measuring method, and conversion of the measurement reading data using the NPI equation are presented to assess the results. Finally, the simulation of the solar radiation meter using the PSIM and implementation of the hardware are conducted to validate the concepts and compare their results. The proposed hardware has an average error of 2.72% in the implementation of the measurement test.
Fuzzy Sliding Mode Control for Photovoltaic SystemIJPEDS-IAES
In this study, a fuzzy sliding mode control (FSMC) based maximum power point tracking strategy has been applied for photovoltaic (PV) system. The key idea of the proposed technique is to combine the performances of the fuzzy logic and the sliding mode control in order to improve the generated power for a given set of climatic conditions. Different from traditional sliding mode control, the developed FSMC integrates two parts. The first part uses a fuzzy logic controller with two inputs and 25 rules as an equivalent controller while the second part is designed for an online adjusting of the switching controller’s gain using a fuzzy tuner with one input and one output. Simulation results showed the effectiveness of the proposed approach achieving maximum power point. The fuzzy sliding mode (FSM) controller takes less time to track the maximum power point, reduced the oscillation around the operating point and also removed the chattering phenomena that could lead to decrease the efficiency of the photovoltaic system.
International Journal of Engineering Research and Applications (IJERA) is an open access online peer reviewed international journal that publishes research and review articles in the fields of Computer Science, Neural Networks, Electrical Engineering, Software Engineering, Information Technology, Mechanical Engineering, Chemical Engineering, Plastic Engineering, Food Technology, Textile Engineering, Nano Technology & science, Power Electronics, Electronics & Communication Engineering, Computational mathematics, Image processing, Civil Engineering, Structural Engineering, Environmental Engineering, VLSI Testing & Low Power VLSI Design etc.
THERMAL FAULT DETECTION SYSTEM FOR PV SOLAR MODULESelelijjournal
Photovoltaic (PV) modules used to convert sunlight into electricity. PV researches and industries are
rapidly becoming popular in the energy field since PV technologies do not harm to environment and use
sun which is unlimited energy source. Nowadays, many applications are realized with photovoltaic (PV)
modules in different areas such as buildings, aviation, solar power plants, land and sea transportations,
etc. Construction, operation and maintenance of solar PV system are not easy and complex. There are
many methods for PV plants inspection such as visual inspection, using current sensors, comparing the
input and output power units of PV modules, and thermal monitoring with infrared cameras. Monitoring
the differences on the PV module output voltage by means of sensors is the most appropriate methods but it
is very expensive solution since there are thousand PV modules in some plants. Thermal monitoring system
is more suitable method for large PV plants’ inspection. Because, it reduces the fault detection costs and
provide shorten maintenance time. The main aim of this paper is to investigate thermal monitoring of the
PV solar modules and realize image processing by thermal radiation on PV modules. For this purpose, it is
created a wireless directable robotic vehicle which has RF and thermal camera, two brushless hub motor
and X-Bee modules to send direction commands. In this way, the robot moves between the panels and sent
data for user whether there is fault on the panels or not. The test results indicate that PV module faults are
detected effectively by using thermal cameras.
The aim of this research is the speed tracking of the permanent magnet synchronous motor (PMSM) using an intelligent Neural-Network based adapative backstepping control. First, the model of PMSM in the Park synchronous frame is derived. Then, the PMSM speed regulation is investigated using the classical method utilizing the field oriented control theory. Thereafter, a robust nonlinear controller employing an adaptive backstepping strategy is investigated in order to achieve a good performance tracking objective under motor parameters changing and external load torque application. In the final step, a neural network estimator is integrated with the adaptive controller to estimate the motor parameters values and the load disturbance value for enhancing the effectiveness of the adaptive backstepping controller. The robsutness of the presented control algorithm is demonstrated using simulation tests. The obtained results clearly demonstrate that the presented NN-adaptive control algorithm can provide good trackingperformances for the speed trackingin the presence of motor parameter variation and load application.
This paper presents a fast and accurate fault detection, classification and direction discrimination algorithm of transmission lines using one-dimensional convolutional neural networks (1D-CNNs) that have ingrained adaptive model to avoid the feature extraction difficulties and fault classification into one learning algorithm. A proposed algorithm is directly usable with raw data and this deletes the need of a discrete feature extraction method resulting in more effective protective system. The proposed approach based on the three-phase voltages and currents signals of one end at the relay location in the transmission line system are taken as input to the proposed 1D-CNN algorithm. A 132kV power transmission line is simulated by Matlab simulink to prepare the training and testing data for the proposed 1D- CNN algorithm. The testing accuracy of the proposed algorithm is compared with other two conventional methods which are neural network and fuzzy neural network. The results of test explain that the new proposed detection system is efficient and fast for classifying and direction discrimination of fault in transmission line with high accuracy as compared with other conventional methods under various conditions of faults.
Among the most widespread renewable energy sources is solar energy; Solar panels offer a green, clean, and environmentally friendly source of energy. In the presence of several advantages of the use of photovoltaic systems, the random operation of the photovoltaic generator presents a great challenge, in the presence of a critical load. Among the most used solutions to overcome this problem is the combination of solar panels with generators or with the public grid or both. In this paper, an energy management strategy is proposed with a safety aspect by using artificial neural networks (ANNs), in order to ensure a continuous supply of electricity to consumers with a maximum solicitation of renewable energy.
In this paper, the artificial neural network (ANN) has been utilized for rotating machinery faults detection and classification. First, experiments were performed to measure the lateral vibration signals of laboratory test rigs for rotor-disk-blade when the blades are defective. A rotor-disk-blade system with 6 regular blades and 5 blades with various defects was constructed. Second, the ANN was applied to classify the different x- and y-axis lateral vibrations due to different blade faults. The results based on training and testing with different data samples of the fault types indicate that the ANN is robust and can effectively identify and distinguish different blade faults caused by lateral vibrations in a rotor. As compared to the literature, the present paper presents a novel work of identifying and classifying various rotating blade faults commonly encountered in rotating machines using ANN. Experimental data of lateral vibrations of the rotor-disk-blade system in both x- and y-directions are used for the training and testing of the network.
This paper focuses on the artificial bee colony (ABC) algorithm, which is a nonlinear optimization problem. is proposed to find the optimal power flow (OPF). To solve this problem, we will apply the ABC algorithm to a power system incorporating wind power. The proposed approach is applied on a standard IEEE-30 system with wind farms located on different buses and with different penetration levels to show the impact of wind farms on the system in order to obtain the optimal settings of control variables of the OPF problem. Based on technical results obtained, the ABC algorithm is shown to achieve a lower cost and losses than the other methods applied, while incorporating wind power into the system, high performance would be gained.
The significance of the solar energy is to intensify the effectiveness of the Solar Panel with the use of a primordial solar tracking system. Here we propounded a solar positioning system with the use of the global positioning system (GPS) , artificial neural network (ANN) and image processing (IP) . The azimuth angle of the sun is evaluated using GPS which provide latitude, date, longitude and time. The image processing used to find sun image through which centroid of sun is calculated and finally by comparing the centroid of sun with GPS quadrate to achieve optimum tracking point. Weather conditions and situation observed through AI decision making with the help of IP algorithms. The presented advance adaptation is analyzed and established via experimental effects which might be made available on the memory of the cloud carrier for systematization. The proposed system improve power gain by 59.21% and 10.32% compare to stable system (SS) and two-axis solar following system (TASF) respectively. The reduced tracking error of IoT based Two-axis solar following system (IoT-TASF) reduces their azimuth angle error by 0.20 degree.
Kosovo has limited renewable energy resources and its power generation sector is based on fossil fuels. Such a situation emphasizes the importance of active research and efficient use of renewable energy potential. According to the analysis of meteorological data for Kosovo, it can be concluded that among the most attractive potential wind power sites are the locations known as Kitka (42° 29' 41" N and 21° 36' 45" E) and Koznica (42° 39′ 32″ N, 21° 22′30″E). The two terrains in which the analysis was carried out are mountain areas, with altitudes of 1142 m (Kitka) and 1230 m (Koznica). the same measuring height, about 84 m above the ground, is obtained for these average wind speeds: Kitka 6,667 m/s and Koznica 6,16 m/s. Since the difference in wind speed is quite large versus a difference in altitude that is not being very large, analyses are made regarding the terrain characteristics including the terrain relief features. In this paper it will be studied how much the roughness of the terrain influences the output energy. Also, that the assumption to be taken the same as to how much they will affect the annual energy produced.
Large-scale grid-tied photovoltaic (PV) station are increasing rapidly. However, this large penetration of PV system creates frequency fluctuation in the grid due to the intermittency of solar irradiance. Therefore, in this paper, a robust droop control mechanism of the battery energy storage system (BESS) is developed in order to damp the frequency fluctuation of the multi-machine grid system due to variable active power injected from the PV panel. The proposed droop control strategy incorporates frequency error signal and dead-band for effective minimization of frequency fluctuation. The BESS system is used to consume/inject an effective amount of active power based upon the frequency oscillation of the grid system. The simulation analysis is carried out using PSCAD/EMTDC software to prove the effectiveness of the proposed droop control-based BESS system. The simulation result implies that the proposed scheme can efficiently curtail the frequency oscillation.
This paper focuses on the modeling and control of a wind energy conversion chain using a permanent magnet synchronous machine. This system behaves a turbine, a generator, DC/DC and DC/AC power converters. These are connected on both sides to the DC bus, where the inverter is followed by a filter which is connected to the grid. In this paper, we have been used two types of controllers. For the stator side converter, we consider the Takagi-Sugeno approach where the parameters of controller have been computed by the theory of linear matrix inequalities. The stability synthesis has been checked using the Lyapunov theory. According to the grid side converter, the proportional integral controller is exploited to keep a constant voltage on the DC bus and control both types of powers. The simulation results demonstrate the robustness of the approach used.
The objective of this paper is to provide an overview of the current state of renewable energy resources in Bangladesh, as well as to examine various forms of renewable energies in order to gain a comprehensive understanding of how to address Bangladesh's power crisis issues in a sustainable manner. Electricity is currently the most useful kind of energy in Bangladesh. It has a substantial influence on a country's socioeconomic standing and living standards. Maintaining a stable source of energy at a cost that is affordable to everyone has been a constant battle for decades. Bangladesh is blessed with a wealth of natural resources. Bangladesh has a huge opportunity to accelerate its economic development while increasing energy access, livelihoods, and health for millions of people in a sustainable way due to the renewable energy system.
A stable operation of wind turbines connected to the grid is an essential requirement to ensure the reliability and stability of the power system. To achieve such operational objective, installing static synchronous compensator static synchronous compensator (STATCOM) as a main compensation device guarantees the voltage stability enhancement of the wind farm connected to distribution network at different operating scenarios. STATCOM either supplies or absorbs reactive power in order to ensure the voltage profile within the standard-margins and to avoid turbine tripping, accordingly. This paper present new study that investigates the most suitable-location to install STATCOM in a distribution system connected wind farm to maintain the voltage-levels within the stability margins. For a large-scale squirrel cage induction generator squirrel-cage induction generator (SCIG-based) wind turbine system, the impact of STATCOM installation was tested in different places and voltage-levels in the distribution system. The proposed method effectiveness in enhancing the voltage profile and balancing the reactive power is validated, the results were repeated for different scenarios of expected contingencies. The voltage profile, power flow, and reactive power balance of the distribution system are observed using MATLAB/Simulink software.
This paper presents a new simplified cascade multiphase DC-DC buck power converter suitable for low voltage and large current applications. Cascade connection enables very low voltage ratio without using very small duty cycles nor transformers. Large current with very low ripple content is achieved by using the multiphase technique. The proposed converter needs smaller number of components compared to conventional cascade multiphase DC-DC buck power converters. This paper also presents useful analysis of the proposed DC-DC buck power converter with a method to optimize the phase and cascade number. Simulation and experimental results are included to verify the basic performance of the proposed DC-DC buck power converter.
A new bidirectional multilevel inverter topology with a high number of voltage levels with a very reduced number of power components is proposed in this paper. Only TEN power switches and four asymmetric DC voltage sources are used to generate 25 voltage levels in this new topology. The proposed multilevel converter is more suitable for e-mobility and photovoltaic applications where the overall energy source can be composed of a few units/associations of several basic source modules. Several benefits are provided by this new topology: Highly sinusoidal current and voltage waveforms, low Total Harmonic Distortion, very low switching losses, and minimum cost and size of the device. For optimum control of this 25-level voltage inverter, a special Modified Hybrid Modulation technique is performed. The proposed 25-level inverter is compared to various topologies published recently in terms of cost, the number of active power switches, clamped diodes, flying capacitors, DC floating capacitors, and the number of DC voltage sources. This comparison clearly shows that the proposed topology is cost-effective, compact, and very efficient. The effectiveness and the good performance of the proposed multilevel power converter (with and without PWM control) are verified and checked by computational simulations.
Transmission lines react to an unexpected increase in power, and if these power changes are not controlled, some lines will become overloaded on certain routes. Flexible alternating current transmission system (FACTS) devices can change the voltage range and phase angle and thus control the power flow. This paper presents suitable mathematical modeling of FACTS
devices including static var compensator (SVC) as a parallel compensator and high voltage direct current (HVDC) bonding. A comprehensive modeling of SVC and HVDC bonding in the form of simultaneous applications for power flow is also performed, and the effects of compensations are compared. The comprehensive model obtained was implemented on the 5-bus test system in MATLAB software using the Newton-Raphson method, revealed that generators have to produce more power. Also, the addition of these devices stabilizes the voltage and controls active and reactive power in the network.
Environmental factors such as air pollution and increase in global warming by using polluting fuels are the most important reasons of using renewable and clean energy that runs in global community. Wind energy is one of the most suitable and widely used kind of renewable energy which had been in consideration so well. This paper introduces an electric power generation
system of wind based on Y-source and improved Y-source inverter to deliver optimal electrical power to the network. This new converter is from impedance source converters family. This presented converter has more degrees of freedom to adjust voltage gain and modulation. Also, by limiting the range of simultaneous control (shooting through) while it maintains the
highest power of maximizer, it can operate in higher modulation range. This causes the reduce of stress in switching and thus it will improve the quality of output. Recommended system had been simulated in MATLAB/Simulink and shown results indicate accurate functionality.
This paper presents an analytical comparison between two-level inverter and three-level neutral point diode clamped inverters for electric vehicle traction purposes. The main objective of the research is to declare the main differences in the performance of the two inverter schemes in terms of the switching and conduction losses over an entire domain of the modulation index and the phase angle distribution, steady-state operation, transient operation at a wide range of speed variation, and the total harmonic distortion THD% of the line voltage output waveform. It also declares the analysis of the three-level neutral point diode clamped inverter (NPCI) obstacle and the unbalance of the DC-link capacitor voltages. The introduced scheme presents an Induction Motor (IM) drive for electric vehicle (EV) applications. Considering the dynamic operation of the EV, the speed of the three-phase induction motor is controlled using a scalar V/Hz control for the full range of the IM power factor (PF). A comprehensive MATLAB/Simulink model for the proposed scheme is established.
The study made in this paper concerns the use of the voltage-oriented control (VOC) of three-phase pulse width modulation (PWM) rectifier with constant switching frequency. This control method, called voltage-oriented controlwith space vector modulation (VOC-SVM). The proposed control scheme has been founded on the transformation between stationary (α-β) and and synchronously rotating (d-q) coordinate system, it is based on two cascaded control loops so that a fast inner loop controls the grid current and an external loop DC-link voltage, while the DC-bus voltage is maintained at the desired level and ansured the unity power factor operation. So, the stable state performance and robustness against the load’s disturbance of PWM rectifiers are boths improved. The proposed scheme has been implemented and simulated in MATLAB/Simulink environment. The control system of the VOC-SVM strategy has been built based on dSPACE system with DS1104 controller board. The results obtained show the validity of the model and its control method. Compared with the conventional SPWM method, the VOC-SVM ensures high performance and fast transient response.
The traction inverter is a crucial power device in the electric vehicle’s powertrain, and its failure is intolerable as it would considerably compromise the system’s safety. For more reliable driving, installing a traction inverter that is sufficiently resistant to electrical failure is inherent. Due to its compact size and the small number of switches incorporated in three-phase four-switch inverter, this modular topology was used to compensate for the open switch’s failure. However, it is known to have manifold weaknesses mainly distinguished in the low-frequency region. This paper introduces a new fault-tolerant indirect control that handles the IGBT’s failure constituting the traction inverter. The fault compensator is designed first based on the Proportional Integral regulator combined with the notch filter to mitigate the current imbalance and restore the DC voltage equilibrium.Furthermore, to conceive a comprehensive fault-tolerant control, there must therefore contain an accurate fault detector. In this regard, an uncomplicated fault diagnosis method based on the current spectral analysis has been performed. The effectiveness of the submitted controller was validated by simulation using Matlab.
More from International Journal of Power Electronics and Drive Systems (18)
Welcome to WIPAC Monthly the magazine brought to you by the LinkedIn Group Water Industry Process Automation & Control.
In this month's edition, along with this month's industry news to celebrate the 13 years since the group was created we have articles including
A case study of the used of Advanced Process Control at the Wastewater Treatment works at Lleida in Spain
A look back on an article on smart wastewater networks in order to see how the industry has measured up in the interim around the adoption of Digital Transformation in the Water Industry.
TECHNICAL TRAINING MANUAL GENERAL FAMILIARIZATION COURSEDuvanRamosGarzon1
AIRCRAFT GENERAL
The Single Aisle is the most advanced family aircraft in service today, with fly-by-wire flight controls.
The A318, A319, A320 and A321 are twin-engine subsonic medium range aircraft.
The family offers a choice of engines
Water scarcity is the lack of fresh water resources to meet the standard water demand. There are two type of water scarcity. One is physical. The other is economic water scarcity.
Democratizing Fuzzing at Scale by Abhishek Aryaabh.arya
Presented at NUS: Fuzzing and Software Security Summer School 2024
This keynote talks about the democratization of fuzzing at scale, highlighting the collaboration between open source communities, academia, and industry to advance the field of fuzzing. It delves into the history of fuzzing, the development of scalable fuzzing platforms, and the empowerment of community-driven research. The talk will further discuss recent advancements leveraging AI/ML and offer insights into the future evolution of the fuzzing landscape.
About
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
• Remote control: Parallel or serial interface.
• Compatible with MAFI CCR system.
• Compatible with IDM8000 CCR.
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
• Easy in configuration using DIP switches.
Technical Specifications
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
Key Features
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
• Remote control: Parallel or serial interface
• Compatible with MAFI CCR system
• Copatiable with IDM8000 CCR
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
Application
• Remote control: Parallel or serial interface.
• Compatible with MAFI CCR system.
• Compatible with IDM8000 CCR.
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
• Easy in configuration using DIP switches.
COLLEGE BUS MANAGEMENT SYSTEM PROJECT REPORT.pdfKamal Acharya
The College Bus Management system is completely developed by Visual Basic .NET Version. The application is connect with most secured database language MS SQL Server. The application is develop by using best combination of front-end and back-end languages. The application is totally design like flat user interface. This flat user interface is more attractive user interface in 2017. The application is gives more important to the system functionality. The application is to manage the student’s details, driver’s details, bus details, bus route details, bus fees details and more. The application has only one unit for admin. The admin can manage the entire application. The admin can login into the application by using username and password of the admin. The application is develop for big and small colleges. It is more user friendly for non-computer person. Even they can easily learn how to manage the application within hours. The application is more secure by the admin. The system will give an effective output for the VB.Net and SQL Server given as input to the system. The compiled java program given as input to the system, after scanning the program will generate different reports. The application generates the report for users. The admin can view and download the report of the data. The application deliver the excel format reports. Because, excel formatted reports is very easy to understand the income and expense of the college bus. This application is mainly develop for windows operating system users. In 2017, 73% of people enterprises are using windows operating system. So the application will easily install for all the windows operating system users. The application-developed size is very low. The application consumes very low space in disk. Therefore, the user can allocate very minimum local disk space for this application.
Automobile Management System Project Report.pdfKamal Acharya
The proposed project is developed to manage the automobile in the automobile dealer company. The main module in this project is login, automobile management, customer management, sales, complaints and reports. The first module is the login. The automobile showroom owner should login to the project for usage. The username and password are verified and if it is correct, next form opens. If the username and password are not correct, it shows the error message.
When a customer search for a automobile, if the automobile is available, they will be taken to a page that shows the details of the automobile including automobile name, automobile ID, quantity, price etc. “Automobile Management System” is useful for maintaining automobiles, customers effectively and hence helps for establishing good relation between customer and automobile organization. It contains various customized modules for effectively maintaining automobiles and stock information accurately and safely.
When the automobile is sold to the customer, stock will be reduced automatically. When a new purchase is made, stock will be increased automatically. While selecting automobiles for sale, the proposed software will automatically check for total number of available stock of that particular item, if the total stock of that particular item is less than 5, software will notify the user to purchase the particular item.
Also when the user tries to sale items which are not in stock, the system will prompt the user that the stock is not enough. Customers of this system can search for a automobile; can purchase a automobile easily by selecting fast. On the other hand the stock of automobiles can be maintained perfectly by the automobile shop manager overcoming the drawbacks of existing system.
Sachpazis:Terzaghi Bearing Capacity Estimation in simple terms with Calculati...Dr.Costas Sachpazis
Terzaghi's soil bearing capacity theory, developed by Karl Terzaghi, is a fundamental principle in geotechnical engineering used to determine the bearing capacity of shallow foundations. This theory provides a method to calculate the ultimate bearing capacity of soil, which is the maximum load per unit area that the soil can support without undergoing shear failure. The Calculation HTML Code included.
Saudi Arabia stands as a titan in the global energy landscape, renowned for its abundant oil and gas resources. It's the largest exporter of petroleum and holds some of the world's most significant reserves. Let's delve into the top 10 oil and gas projects shaping Saudi Arabia's energy future in 2024.
Student information management system project report ii.pdfKamal Acharya
Our project explains about the student management. This project mainly explains the various actions related to student details. This project shows some ease in adding, editing and deleting the student details. It also provides a less time consuming process for viewing, adding, editing and deleting the marks of the students.
AKS UNIVERSITY Satna Final Year Project By OM Hardaha.pdf
Performance of solar modules integrated with reflector
1. International Journal of Power Electronics and Drive Systems (IJPEDS)
Vol. 12, No. 3, September 2021, pp. 1845~1852
ISSN: 2088-8694, DOI: 10.11591/ijpeds.v12.i3.pp1845-1852 1845
Journal homepage: http://ijpeds.iaescore.com
Performance of solar modules integrated with reflector
Jamil Al Asfar1
, Ahmad Sakhrieh2
, Waleed Al-Nayfeh3
, Ahmad Ghandoor4
1,2
Department of Mechanical Engineering, The University of Jordan, Jordan
2
Department of Mechanical and Industrial Engineering, American University of Ras Al Khaimah, UAE
3,4
Mechanical Engineering Department, Hashemite University, Jordan
Article Info ABSTRACT
Article history:
Received Apr 19, 2021
Revised Jul 7, 2021
Accepted Jul 19, 2021
This study investigates experimentally the performance of two-dimensional
solar tracking systems with reflector using commercial silicon based
photovoltaic module, with open and closed loop control systems. Different
reflector materials were also investigated. The experiments were performed
at the Hashemite University campus in Zarqa at a latitude of 32⁰, in February
and March. Photovoltaic output power and performance were analyzed. It
was found that the modified photovoltaic module with mirror reflector
generated the highest value of power, while the temperature reached a
maximum value of 53 ⁰C. The modified module suggested in this study
produced 5% more PV power than the two-dimensional solar tracking
systems without reflector and produced 12.5% more PV power than the fixed
PV module with 26⁰ tilt angle.
Keywords:
Closed loop
Control system
PV module
PV with reflectors
Solar tracking This is an open access article under the CC BY-SA license.
Corresponding Author:
Jamil Al Asfar
Department of Mechanical Engineering
The University of Jordan
Queen Rania St., 11942 Amman, Jordan
Email: jasfar@ju.edu.jo
1. INTRODUCTION
Jordan confronts critical challenges in the energy sector due to increased demands on energy. The
major challenge is to provide and produce more energy at reasonable cost to meet the growing demands of
the consumers. Jordan imports more than 95% of its energy needs [1]-[3]. Thus, the energy sector in Jordan
depends mainly on oil products, and natural gas. Energy bill has put a heavy burden on Jordan’s economy.
Furthermore, extra burden is caused by the interruption of the natural gas coming through the pipeline from
Egypt. This forced the energy sector to convert to oil to produce electricity, which causes extra expenses on
Jordan’s economy. Moreover, oil shale development utilization is still facing serious problems.
In this regard, renewable energy sources present important alternative to generate electric power.
Thus, new projects have been constructed to get benefit of the available renewable energy sources such as
wind and solar energy. Solar energy is considered a clean, non-polluting and an inexhaustible energy source
[4]. Several systems have been developed to use the solar energy, such as flat-plate solar panels [5] or
concentrated solar power (CSP) systems [6]. In order to encourage others to switch from using fossil fuel
energy sources to renewable energy sources, the PV panel performance should be improved. The potential
lies in the method and the techniques used for the maximum efficiency possible. The power generated by the
PV panel depends on the sun radiation and angle of incidence on the PV panel surface. If a reflector is
incorporated in the PV system, the collective area will be increased. On the other hand, using solar tracker,
will reduce the angle of incidence to minimum value. Hopefully, this will increase the power output of the
two-axis photovoltaic tracking PV-system with reflector (modified solar tracking system). Eventually, this
2. ISSN: 2088-8694
Int J Pow Elec & Dri Syst, Vol. 12, No. 3, September 2021 : 1845 – 1852
1846
will decrease the number of PV panels needed to maintain certain amount of energy, which means reducing
the initial cost.
PV is one of the fastest growing solar energy technologies in the world. Therefore, there is a good
potential for PV application in Jordan due to available high rates of solar radiation. Furthermore, increasing
the contribution of renewable energy sources in Jordan energy sector will reduce energy bill and improve
current economic status. There are many methods used to enhance the performance of solar panel system.
The most common one is to track sun motion [7]-[12]. Air-cooling, liquid-cooling and immersion are
examples of methods to increase the efficiency of solar cell [13]-[16]. In spite of the improved energy
extraction from solar tracking system, these systems are less preferred due to their higher installation and
maintenance costs and their additional power requirement for the moving parts [17]-[20]. PV augmented
mirroring affects positively the performance of PV systems [21]-[25]. In this work, a fixed PV panel mounted
towards south, a two-axis photovoltaic tracker panel without reflector and a two-axis photovoltaic tracking
system with reflector were built, studied and investigated. The performance and generated power were
experimentally analyzed for the three systems. This research aims to provide a PV tracking system, which
can reduce the power generation cost and to get the maximum output power from a PV solar system using a
simple reflector on the PV module. Previous studies either used a two-axis photovoltaic tracking system or a
reflector to enhance the performance of a PV system. This work combines both techniques to study the
potential of enhancing the power output of the PV system under Jordanian climate conditions.
2. EXPERIMENTAL WORK
The experimental setup used in the study is installed at Hashemite University campus in Zarqa at a
latitude of 32⁰. The experimental setup consists of three Mono-crystalline silicon PV panels of 310 W
maximum output power. The first PV panel was fixed towards south and mounted at 26⁰ tilt angle, which is
the optimum tilt angle for a fixed PV panel. For the second PV panel, a two-axis photovoltaic tracker was
installed. A two-axis photovoltaic tracking system and mirror reflector were installed to the third panel. The
technical specifications of the PV panels used are given in Table 1.
Table 1. PV panel specifications
Specification Detail
Maximum output power, Pmax (W) 310
Open circuit voltage, Voc (V) 45.79
Short circuit current, Isc (A) 8.99
Nominal operating cell temp. C 45
Cell type Mono-crystalline
Dimension (mm) 1956x992x40
Two flat reflectors were fitted at the shortest side of the PV panel in order to increase the sun
intensity on the panel surface by reflecting the sun radiation that has missed the panel surface. In other words,
they increase the surface area of the panels. The reflector has an optimum angle to gain the greatest exposure
to sun radiation that can be reflected to the PV panel surface. The reflector tilt angle Ө is defined as the
angle between the reflector surface and the PV panel surface. The dimension of the reflector is (1000x500)
mm. The reflector size is identical during all experiments. The optimum tilt angle and the material of the
reflector will be determined in this study. There are two reflectors for the PV panel: The north reflector and
the south one. The optimum tilt angle for each one will be estimated separately. The tracking system used in
these experiments is the two-axis type tracking with both open and close loop systems. The micro-controller
circuit diagram and board of the tracking system are shown in Figures 1 and 2.
The micro controller consists of software and hardware components. The software may be
programmed by using micro basic language that decodes the input signals and sends it to control the motors
status. The hardware executes these signals or commands. Every tracking system have two DC motors. One
motor is used for E-W motion, while the second one is used for S-N motion. DC motors can be controlled
with the polarity of their inputs. For polarity alternation, we have used a simple SPDT relay (5 V)
arrangement. The motor terminals are connected to the two common poles of the relay in the circuit. For
various ranges of input voltage, the IC 7805 controls the output voltage to be 5V. During a circuit's operation,
it serves as an excellent component against voltage fluctuations, adding an additional layer of safety. The
LM358 IC is used as a transducer standard amplifier. It can handle voltages from 3V to 32V DC supply and
currents up to 20mA per channel. Signals from sensors are usually small, so this amplifier was used.
3. Int J Pow Elec & Dri Syst ISSN: 2088-8694
Performance of solar modules integrated with reflector (Jamil Al Asfar)
1847
Figure 1. Micro-controller circuit diagram
Figure 2. Micro-controller board
To ensure accurate and reasonable comparison between the three solar systems, those three systems
have same PV specifications. They are located near each other oriented towards south with an adequate
distance between them; to avoid any shadow effect on the PV panels. A weather station was mounted near
the three systems. The two PV panels with their tracking systems are moving simultaneously having same
controller, but each one has its own control board. The data collected from the three systems was analyzed.
The experimental work was conducted daily for 2 months (February and March); from 9:30 AM to
2:30 PM. The total rotation angle that the PV system will cover solar azimuth angle will be around 70⁰ each
day. The controller sends a signal to the DC motor each time period (30 minutes) ordering it to operate for a
certain angle. This angle is calculated by dividing the total angle of rotation on the number of time periods. A
potentiometer is mounted on the main joint to acquire the required rotation angle. The panel motion reference
was the solar noon time. At solar noon time, the three solar PV panels should be oriented towards the sun.
This was verified by placing a small piece of wood vertical to the PV panel surface to ensure that no shadow
exist for the moving panels. This method can be used any time of the day to make sure that the calculated
angles are correct. The PV tilt angle may be stored in the controller software all over the year. To achieve an
exact tilt angle, a sensor was used. A potentiometer was mounted on a joint to acquire the required tilt angle
during experimental work. This is an open loop control system that operates on time basis, that needs sensors
to achieve the required time basis motion. Two micro-controller boards were built, one for each PV tracking
system. Each PV tracking system needs two DC motors: One motor for the E-W motion, and the second for
the S-N motion. As mentioned earlier, a simple weather station consisting of an anemometer, two
pyranometers, and four thermocouples of K-type was used in this study. Three temperature sensors were used
for the three PV panel’s surfaces, while the fourth temperature sensor was used to determine the ambient
temperature. A micro inverter is connected to each one of the PV panels. Three micro inverters were used to
convert the DC current into AC current and compute the output energy for each PV panel.
3. RESULTS AND DISCUSSION
All the readings in these experiments were taken simultaneously to get accurate comparison. The
experimental results are summarized in Table 2. Figure 3 shows the output power with daytime. In this
experiment, the reflector material is aluminum. The figure reveals that PV system with reflectors produces
more power than the other 2 systems. Another experiment was done to specify the optimum tilt angle. Figure
Motor terminal
IC 7805
Micro -controller
LM 358 Op Amp
Switch
Relay
Motor
Relay
Potentiometer to
simulate sensor output
Switch
Micro -controller
5. Int J Pow Elec & Dri Syst ISSN: 2088-8694
Performance of solar modules integrated with reflector (Jamil Al Asfar)
1849
Figure 3. Output power vs. daytime
Figure 4. Output power vs. reflector tilt angle
When Aluminum material was used for reflector material, with a reflector tilt angle of 125⁰, the
output power for both solar tracking systems with daytime is presented in Figure 5. The power output
difference between the two systems is about 12W. The same experiment was repeated with replacing the
Aluminum reflector with stainless steel reflector. The tilt angle of 125⁰ was kept as before. The obtained
results are presented in Figure 6. The power output difference between the two systems was around 12W.
When a mirror was used as a reflected material, the power output difference between the two systems in
average is about 14.3W as shown in Figure 7. The experiments were done at the same tilt angle of 125⁰
Figure 5. Output power using aluminum as a reflector material
Thus, the modified solar tracker with mirror as a reflector material achieved the highest power
output. The optimum reflector tilt angle is 125⁰. Comparing the solar tracker with reflector, the solar tracker
6. ISSN: 2088-8694
Int J Pow Elec & Dri Syst, Vol. 12, No. 3, September 2021 : 1845 – 1852
1850
without reflector and the fixed solar panel with the optimum tilt angle 26⁰ power output shows an increase in
output power of 14W when a reflector is used and 18.6W when the the solar system with reflector is
compared with the fixed solar panel. The results show that solar cells can produce more power by about
12.5% with a reflector. According to our estimates, the reflectors will add 10 US dollars to a 310 Wp PV
module. This additional cost needs to be added to the sale price. At the same time, by adding reflectors, 38.75
Wp of additional power can be generated. In other words, the new module is capable of producing 348.75
Wp. Using the USD 0.5/Wp market price of flat plate PV modules, the gain thus represents 19.375 US
dollars which exceeds the added 10 US dollars due to the reflectors.
Figure 6. Output power vs. daytime with stainless steel as a reflector material
Figure 7. Output powers using mirror as a reflector material
4. CONCLUSION
There are many methods used to enhance the performance of PV solar panel systems. Tracking the
sun is the most common method but requires high cost. This work proved that using other techniques to
increase the power output, with lower the cost compared with installing tracking system, is possible. In this
research, the optimal condition for reflector material and reflector integration angle is studied experimentally.
The improvement in the system power output shows that the proposed system is effective. It can be
concluded from the experimental outcome that the system with reflector is capable in producing 5% power
output from the solar tracker without reflector. The only limitation observed in the system with reflector is
the increase in temperature which increases the degradation of the panel. More research work needs to be
carried out to study power mismatch of PV panels and degradation factors for the integrated reflectors with
the help of I–V curves.
REFERENCES
[1] R. Al-Rbaihat et al., “Performance assessment and theoretical simulation of adsorption refrigeration system driven
by flat plate solar collector,” Jordan Journal of Mechanical and Industrial Engineering, vol. 11, no. 1, pp. 1-11,
2017.
7. Int J Pow Elec & Dri Syst ISSN: 2088-8694
Performance of solar modules integrated with reflector (Jamil Al Asfar)
1851
[2] M. A Hamdan, E. M. Alqallab and A. H. Sakhrieh, “Potential of solar cells performance enhancement using liquid
absorption filters, Iranian Journal of Science and Technology,” Iranian Journal of Science and Technology,
Transactions of Mechanical Engineering, vol. 43, pp. 383–398, 2019, doi: 10.1007/s40997-018-0165-x.
[3] A. Sakhrieh, Y. Abdullat, and M. A. Hamdan, “Enhancement of thermal energy storage using phase-change
material under Jordanian climate,” Journal of Infrastructure Systems, vol. 22, no. 4, pp. 1-5, 2016, doi:
10.1061/(asce)is.1943-555x.0000187.
[4] I. Aschilean, G. Rasoi, M. S. Raboaca, C. Filote, and M. Culcer, “Design and concept of an energy system based on
renewable sources for greenhouse sustainable agriculture,” Energies, pp. 1, no. 5, pp. 1-12, 2018, doi:
10.3390/en11051201.
[5] E. Arıkan, S. Abbasoğlu, and M. Gazi, “Experimental performance analysis of flat plate solar collectors using
different nanofluids,” Sustainability, vol. 10, no. 6, pp. 1-11, 2018, doi: 10.3390/su10061794.
[6] S. Qiu, L. Solomon, and G. Rinker, “Development of an integrated thermal energy storage and free-piston stirling
generator for a concentrating solar power system,” Energies, vol. 10, no. 9, pp. 1-17, 2017, doi:
10.3390/en10091361.
[7] R. P. Semma and M. S. Imamura, “Sun Tracking Controller for Multi Kw Photovoltaic Concentrator System,”
Photovoltaic Solar Energy Conference, Cannes, 1981, pp. 27-31, doi: 10.1007/978-94-009-8423-3_54.
[8] J. Gadewadikar, “Microprocessor Based Solar Tracking System Using Stepper Motor,” B.S. thesis, Depart, of.
Electron. Instrum. Eng., S.G.S. Inst. of Tech. Sci., Indore, 1997.
[9] G. M. Masters, “Renewable and Efficient Electrical Power Systems,” 1st ed. New York: John Wiley, 2004.
[10] J. K. Kiet, “Miniature solar tracker,” thesis dissertation, Universiti Tun Hussein Onn Malaysia, Johor, 2006.
[11] S. A. Kalogirou, “Design and construction of one axis sun tracking system,” Solar Energy, vol. 57, no. 60, pp: 465-
469, 1996, doi: 10.1016/S0038-092X(96)00135-1.
[12] A. Abu Sneineh and W. Salah, “Design and implementation of an automatically aligned solar tracking
system”, International Journal of Power Electronics and Drive Systems (IJPEDS), vol. 10, no. 4, pp. 2055- 2064,
2019, doi: 10.11591/ijpeds.v10.i4.pp2055-2064.
[13] P. G. Nikhil, and M. Premalatha, “Performance enhancement of solar module by cooling: An experimental
investigation,” International Journal of Energy and Environment, vol. 3, no. 1, pp. 73-82, 2012.
[14] K. A. Moharram, M. S. Abd-Elhady , H. A. Kandil, and H. El-Sherif, “Enhancing the performance of photovoltaic
panels by water cooling,” Ain Shams Engineering Journal, vol. 4, no. 4, pp. 869–877, 2013, doi:
10.1016/j.asej.2013.03.005.
[15] A. Aldihani, A. Aldossary, S. Mahmoud, and R. K. AL-Dadah, “The effect of cooling on the performance of
photovoltaic cells under dusty environmental conditions,” Energy Procedia, vol. 61, pp. 2383-2386, 2014, doi:
10.1016/j.egypro.2014.12.010.
[16] M. Layth, S. Ahmad, A. Ahmad, H. Amer, A. Eman, and H. Mohammed, “Optimized cleaning and cooling for
photovoltaic modules based on the output performance,” Thermal Science, vol. 22, no. 1 Part A, pp. 237-246, 2018,
doi: 10.2298/TSCI151004145M.
[17] W. Nsengiyumv, S. G. Chen, L. Hu, and X. Chen, “Recent advancements and challenges in solar tracking systems
(STS): A review,” Renew. Sust. Energy Rev., vol. 81, pp. 250-279, 2018, doi: 10.1016/j.rser.2017.06.085.
[18] H. Z. Al Garni, A. Awasthi, and M. A. M. Ramli, “Optimal design and analysis of grid-connected photovoltaic
under different tracking systems using HOMER’,” Energy Convers. Manage., vol. 155, pp. 42-57, 2018, doi:
10.1016/j.enconman.2017.10.090.
[19] H. M. Fahad, A. Islam, M. Islam, M. F. Hasan, W. F. Brishty and M. M. Rahman, “Comparative analysis of dual
and single axis solar tracking system considering cloud cover,” 2019 International Conference on Energy and
Power Engineering (ICEPE), 2019, pp. 1-5, doi: 10.1109/CEPE.2019.8726646.
[20] S. A. Jumaat, M. N. A. M. Said and C. R. A. Jawa, “Dual axis solar tracker with IoT monitoring system using
arduino,” International Journal of Power Electronics and Drive Systems (IJPEDS), vol. 11, no. 1, pp. 451-458,
2020, doi: 10.11591/ijpeds.v11.i1.pp451-458.
[21] Y. Siahaan and H. Siswono, “Analysis the effect of reflector (flat mirror, convex mirror, and concave mirror) on
solar panel,” International Journal of Power Electronics and Drive Systems (IJPEDS), vol. 10, no. 2, pp. 943-952,
2019, doi: 10.11591/ijpeds.v10.i2.pp943-952.
[22] R. ur Rahman, D. I. Ahmed, M. A. Fahmi, T. Tasnuva, and M. F. Khan, “Performance enhancement of PV solar
system by diffused reflection,” 2009 1st International Conference on the Developements in Renewable Energy
Technology (ICDRET), 2009, pp. 1-4, doi: 10.1109/ICDRET.2009.5454204.
[23] J. Rizk and M. H. Nagrial, “Impact of reflrctors on solar energy systems,” World Academy of Science Engineering
and technology, vol 41, pp. 131-135, 2018.
[24] R. Baccoli, A. Kumar, A. Frattolillo, C. Mastino, E. Ghianib, and G. Gatto, “Enhancing energy production in a PV
collector – Reflector system supervised by an optimization model: Experimental analysis and validation,” Energy
Conversion and Management, vol. 229, 113774, 2021, doi: 10.1016/j.enconman.2020.113774.
[25] M. Mansoor, S. P. Simon, K. A. Kumar, K. Sundareswaran, P. S. R. Nayak, and N. P. Padhy, “Impact and
economic assessment on solar PV mirroring system - A feasibility report,” Energy Conversion and Management,
vol. 203, 2020, doi: 10.1016/j.enconman.2019.112222.
8. ISSN: 2088-8694
Int J Pow Elec & Dri Syst, Vol. 12, No. 3, September 2021 : 1845 – 1852
1852
BIOGRAPHIES OF AUTHORS
Jamil Al Asfar received his Ph. D in Mechanical Engineering from the University of Jordan
in 2007, from which he also obtained his M. Sc. in 1996. He received his B.Sc. in Mechanical
Engineering in 1985 from Yarmouk University in Jordan. He worked as Head of engineering
department at the National College (intermediate university college) for engineering and
management careers in Amman till 1995. Then, he joined the Jordanian Ministry of Trade and
Industry (Jordan Investment Board) as Head of planning and studies department, and director
of a UNDP project for capacity building, from 1995 to 2007. Currently, he works as Professor
at the University of Jordan-School of Engineering/ Mechanical Engineering Department. His
current research interests include CFD, Energy, Combustion, Hybrid renewable energy
systems, Alternative Fuel. He also worked as visiting professor in Tabuk University/KSA,
Philadelphia and Al Zaytooneh University. Prof. Al Asfar has published more than 40
articles in many ISI/Scopus journals.
Prof. Sakhrieh joined the department of Mechanical and Industrial Engineering at the
American University of Ras Al Khaimah, UAE in fall 2015. Prior to that he was the chairman
of the mechanical engineering department at the University of Jordan. Prof. Sakhrieh is the
author and coauthor of more than 60 papers in international journals and conferences. Prof.
Sakhrieh served as a co-president of the Arab German Academy for Science and Humanities
(AGYA) in 2016. He is a reviewer several for International Journals such as Applied Thermal
Engineering, Energy Conversion & Management, Sustainable Cities and Society and Journal
of Energy. He chaired the organizing committee of several conferences and workshop such as
the International Conference on Energy, Water & Environmental Sciences (ICEWES)
conference in 2018; boosting opportunities awareness for women in STEM education and
career pathway: Boosting Opportunities and Awareness workshop; Energy and Water in the
Gulf Cooperation Council Countries (EWGCC) workshop; Entrepreneurship and innovation
challenges in the 21st-century students Forum.
Waleed Al-Nayfeh experienced mechanical and industrial engineering laboratory teaching
and conducting experiments with a demonstrated history of working in the work shops as a
training and production engineer and as a renewable energy center supervisor for research
purpose. Skilled in operating and programming the lathe and milling CNC machines. Strong
research professional with a Master’s Degree focused on Energy management from the
University of Jordan.
Ahmed Ghandour is a Jordanian scientist, solar energy expert and a professor of industrial
engineering at the Hashemite University. The Association of Energy Engineers has rated it as
the Energy Manager of the Year for the Middle East. Dr. Ghandour was honored by King
Abdullah II Bin Al Hussein among the Jordanian Stars of Science for his contributions to his
field of specialization during the World Science Forum 2017.
