This document summarizes several research papers on low-density parity-check (LDPC) coding for wireless data transmission using Raspberry Pi modules. Specifically:
(1) It discusses implementations of LDPC encoding and decoding of text data using Raspberry Pi modules connected over Wi-Fi, with decoding using sum-product algorithms.
(2) It mentions other research on minimizing bit error rate using specific LDPC parity matrix structures and efficient encoding/decoding techniques.
(3) The document reviews various approaches to LDPC coding implementation including using FPGAs, ZigBee modules, and novel decoding algorithms.
