8. Infrared(IR) Diode
Light Emitting Diode
Peak Wavelength λp=940nm
Photo Diode
Sense the Reflected light
Fingertip Sensors are Connected
with PORT 3 of Microcontroller
9.
10. Connected with PORT 0 of
Microcontroller through ADC
Range = -55℃ to150℃
Operated from 3V to 30V
11. Two low Pass Filters
Cut off Frequency = 2.5HZ
Gain of each Filter = 101
Resistor R1 = 680kΩ ,R2 = 6.8kΩ
Capacitor 100nF
12. Lm358
Amplify weak Signals
Operating Voltage=5V DC
Operating Current=50 mA
13.
14. 8051(AT89S52)
4V to 5.5V Operating Range
40 Pins on 8051
4 I/O PORTS each PORT has 8 Pins
32 Programmable I/O Lines
Three 16 Bit Timer/Counters
Full Duplex Serial Channel
15. PORT 2 is used for LCD
◦ 20 Characters by 4 Lines Display
◦ 4 Bit Mode is use to save 4 Pins
on Microcontroller
5V DC Power Supply
16 pins on 20x4 LCD
DB0 to DB7 are Data Pins
Enable and Register select are for
LCD Control
3 Pins for Power Supply
16. Keypad Interface with PORT 1 of Microcontroller
16 Button Keypad
Keypad 4x4
Keypad is used for setting the Range of Upper
and Lower Limit of Heart Beat and Temperature
Buzzer Interface with PORT 3 of Microcontroller
Alarm on when Temperature and Heart Beat
are out of Range
17. GSM (Global System for Mobile Communication)
Interface with PORT 3
GSM Modem for Transmission of Data
Maximum Transmission Speed of
9.6 Kbps
Provides Continuous Monitoring.
We can also observe the Blood Pressure
of a Patient on the Cell Phone with the help
of GSM.
18.
19.
20. Calculate Heart Rate.
Calculate Temperature.
Useful for Telemedicine.
Send Alert in the form of SMS to Emergency Ambulance.
Work any where in the Country (with GSM Availability).
21. We Summarized the Progress with Respect to our
Project
In Implementation of Wireless Systems for Patient
Monitoring System, the Heart Beat and Body
Temperature are Successfully Sensed.
Hence both Parameters are Displayed on the LCD.
Both the Parameters are Transmitted and Displayed in a
Distant location on Cell Phone using GSM Modem.
22. This Device Can be Enhanced to Measure Blood
Pressure and ECG
Audio Communications
This System Can be Control from Mobile
This Device Can be Communicate Through Bluetooth
and GPRS
23. Range of Heart Rates per Minute and Average Heart
Rate for Various Ages”.
Available: http://www.smm.org/heart/lessons.htm
Heart rate measurement from the finger using a low cost
microcontroller by Dogan Ibrahim and Kadri Buruncuk.
http://www.brianmac.co.uk/maxhr.htm
www.atmel.com
