1. Introduction
Euler’s Method
Engineering Computations
Numerical Ordinary Differential Equations
Dr.Wisam Haitham
Computer Engineering Department
College of Engineering
Al-Mustansiriyah University
July/2020
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 1 / 11

2. Introduction
Euler’s Method
Agenda
1 Introduction
2 Euler’s Method
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 2 / 11

3. Introduction
Euler’s Method
Introduction
Many problems in science and engineering when formulated mathe-
matically are readily expressed in terms of ordinary differential equa-
tions (ODE) with initial and boundary condition.
Consider the problem of solving the first-order differential equation
dy
dt
= f(t, y)
such that we know the rate of change of a quantity as a function
of time and the quantity itself. The problem is to obtain a solution
for y(t), possibly in a general form, but in practical problems usually
where an initial condition y(t0) = y0 is known. In many problems
this can be solved analytically. In general such an integration is not
possible, for example, the differential equation dy/dt = −y2 − t,
and we have to solve the equation numerically, which usually means
obtaining a sequence of numerical values y1, y2, ... corresponding to
specified values t1, t2, ....
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 3 / 11

4. Introduction
Euler’s Method
The figure below shows the nature of the numerical solution of a
differential equation
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 4 / 11

5. Introduction
Euler’s Method
Agenda
1 Introduction
2 Euler’s Method
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 5 / 11

6. Introduction
Euler’s Method
Euler’s Method
Euler method is one of the oldest numerical methods used for inte-
grating the ordinary differential equations. Though this method is
not used in practice, its understanding will help us to gain insight
into nature of predictor-corrector method.
To find the solution of the given Differential Equation in the form
of a recurrence relation
ym+1 = ym + hf(tm, ym) Is called Euler Method
FORMULA DERIVATION
Consider the differential Equation of the first order
dy
dx = f(t, y) and y(t0) = y0
Let (t0, y0) and (t1, y1) be two points of approximation curve. Then
y1 − y0 = m(x1 − x0) ....... (i)(point Slope form)
Given That dy
dx = f(t, y)
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 6 / 11

7. Introduction
Euler’s Method
y1 − y0 = f(t0, y0)(x1 − x0)
So y1 = y0 + f(t0, y0)(x1 − x0)
Similarly
y2 = y1 + f(t1, y1)(x2 − x1)
y3 = y2 + f(t2, y2)(x3 − x2)
. . .
. . .
. . .
ym+1 = ym + f(tm, ym)(xm+1 − xm)
ym+1 = ym + hf(tm, ym) (m = 0, 1, ..)
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 7 / 11

8. Introduction
Euler’s Method
Example 1 :
Use Euler’s method with h = 0.1 to solve the initial value problem
dy
dx = x2 + y2 with y(0)=0 in the range 0 6 x 6 0.5.
Solution:
Here
f(x, y) = x2 + y2, x0 = 0, y0 = 0, h = 0.1
Hence
x1 = x0 + h = (0 + 0.1) = 0.1, x2 = x1 + h = (0.1 + 0.1) = 0.2,
x3 = x2 + h = 0.3, x4 = x3 + h = 0.4, x5 = x4 + h = 0.5
ym+1 = ym + hf(tm, ym)
y1 = y0 + 0.1(x2
0 + y2
0) = 0 + 0.1(0 + 0) = 0
y2 = y1 + 0.1(x2
1 + y2
1) = 0 + 0.1((0.1)2 + 0) = 0.001
y3 = y2 + 0.1(x2
2 + y2
2) = 0.001 + 0.1((0.2)2 + (0.001)2) = 0.005
y4 = y3 + 0.1(x2
3 + y2
3) = 0.005 + 0.1((0.3)2 + (0.005)2) = 0.014
y5 = y4 +0.1(x2
4 +y2
4) = 0.014+0.1((0.4)2 +(0.014)2) = 0.0300196
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 8 / 11

9. Introduction
Euler’s Method
Hence
y(0)=0 y(0.1)=0 y(0.2)=0.001 y(0.3)=0.005
y(0.4)=0.014 y(0.5)=0.0300196
Example 2 :
Using Euler method solve the equation dy
dx = 2xy + 1 with y(0)=0,
h = 0.02, for x=0.1
Solution:
Here
f(x, y) = 2xy + 1, x0 = 0, y0 = 0, h = 0.02
Hence
x1 = x0 + h = (0 + 0.02) = 0.02,
x2 = x1 + h = (0.02 + 0.02) = 0.04, x3 = x2 + h = 0.06,
x4 = x3 + h = 0.08, x5 = x4 + h = 0.1
ym+1 = ym + hf(tm, ym)
y1 = y0 + 0.02(2x0y0 + 1) = 0 + 0.02(0 + 1) = 0.02
y2 = y1 + 0.02(2x1y1 + 1) = 0.02 + 0.02(2 ∗ 0.02 ∗ 0.02 + 1) = 0.04
y3 = y2 + 0.02(2x2y2 + 1) = 0.04 + 0.02(2 ∗ 0.04 ∗ 0.04 + 1) = 0.06
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 9 / 11

10. Introduction
Euler’s Method
y4 = y3 +0.02(2x3y3 +1) = 0.005+0.02(2∗0.06∗0.06+1) = 0.08
y5 = y4 + 0.02(2x4y4 + 1) = 0.014 + 0.02(2 ∗ 0.08 ∗ 0.08 + 1) = 0.1
Hence
y(0)=0 y(0.02)=0.02 y(0.04)=0.04 y(0.06)=0.06
y(0.08)=0.08 y(0.1)=0.1
That is the approximate value of y(0.1) is 0.1
Example 3 :
Using Euler’s method, compute y in the range 0 6 x 6 0.5, if y
satisfies dy
dx = 3x + y2 with y(0)=1, h=0.1
Solution:
Here
f(x, y) = 3x + y2, x0 = 0, y0 = 1, h = 0.1
Hence
x1 = x0 + h = 0.1, x2 = x1 + h = 0.2, x3 = x2 + h = 0.3,
x4 = x3 + h = 0.4, x5 = x4 + h = 0.5
ym+1 = ym + hf(tm, ym)
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 10 / 11

11. Introduction
Euler’s Method
y1 = y0 + 0.1(3x0 + y2
0) = 1.1
y2 = y1 + 0.1(3x1 + y2
1) = 1.251
y3 = y2 + 0.1(3x2 + y2
2) = 1.4675
y4 = y3 + 0.1(3x3 + y2
3) = 1.7728
y5 = y4 + 0.1(3x4 + y2
4) = 2.2071
Hence
y(0)=1 y(0.1)=1.1 y(0.2)=1.251 y(0.3)=1.4675
y(0.4)=1.7728 y(0.5)=2.2071
Example 4 :
Given dy
dx = y−x
y+x , with y=1 for x=0 . Find y approximately for
x=0.1 by Euler’s method in five steps, choosing h=0.002.
Solution:
Here
f(x, y) = y−x
y+x , x0 = 0, y0 = 1, h = 0.002
Al-Mustansiriyah University, College of Engineering NUMERICAL ORDINARY DIFFERENTIAL EQUATIONS 11 / 11

12. Introduction
Euler’s Method
y1 = y0 + 0.002(y0−x0
y0+x0
) = 1.02
y2 = y1 + 0.002(y1−x1
y1+x1
) = 1.0392
y3 = y2 + 0.002(y2−x2
y2+x2
) = 1.0577
y4 = y3 + 0.002(y3−x3
y3+x3
) = 1.0756
y5 = y4 + 0.002(y4−x4
y4+x4
) = 1.0928
Hence
y=1.0928 and x=0.1
