BIOLOGY
TEACHER
*cough*
DNA is the hereditary
The deoxyribonucleic acid,
                                material in humans and
DNA, is a long chain of         almost all other organisms.
nucleotides which consist of:   Most DNA is located in the
• Deoxyribose (a pentose        cell nucleus , but a small
   = sugar with 5 carbons)      amount of DNA can also be
• Phosphoric Acid               found in the mitochondria
• Organic (nitrogenous)         (where it is called
   bases (Purines - Adenine     mitochondrial DNA or
   and Guanine, or              mtDNA).
   Pyrimidines -Cytosine        The information in DNA is stored
   and Thymine)                 as a code made up of four
                                chemical bases
• Rosalind Franklin used
  X-ray diffraction to
  understand the
  physical structure of
  the DNA molecule.
• The structure of
  double helix was first
  described by James
  Watson and Francis
  Crick in 1953.
Purines       Pyrimidines
                              A             T
                              G             C


• four chemical bases:
  adenine (A), guanine (G),
  cytosine (C), and
  thymine (T).
• DNA bases pair up with
  each other, A with T and
  C with G, to form units
          called base
              pairs.

                                        The pyrimidine bases have a 6-
                                        membered ring with two nitrogens
                                        and four carbons.
                                        The purine bases have a 9-membere
                                        double-ring system with four
                                        nitrogens and five carbons.
• Together, a base, sugar, and phosphate are
  called a nucleotide.
• Nucleotides are arranged in two long
  strands that form a spiral called a double
  helix.
• The structure of the double helix is
  somewhat like a ladder, with the
  base pairs forming the ladder’s
  rungs and the sugar and phosphate
  molecules forming the vertical
  sidepieces of the ladder.
• DNA stores an organism's genetic
  information and controls the
  production of proteins.
                                              DNA's function is to provide
                                              the code on which all life is
                                              based.
 DNA is found primarily in the nucleus of a
 cell in strands of genetic material called
 Chromosomes.

                                              Each chromosome is a single piece
                                              of double stranded DNA.
• http://ghr.nlm.nih.gov/handbook/basics/dna
• http://www.nature.com/scitable/topicpage/disco
  very-of-dna-structure-and-function-watson-397
• http://bridget-coila.suite101.com/structure-and-
  function-of-dna-a168784
• http://bcs.deakin.edu.au/bcs_courses/forensic/C
  hemical%20Detective/dna_function.htm
• http://www.accessexcellence.org/RC/VL/GG/stru
  cture.php
