Dewatering System
•Download as PPT, PDF•
6 likes•6,174 views
The document discusses two methods for controlling water levels around excavation sites: deep well systems and wellpoint systems. Deep well systems use individual wells with submersible pumps that can lower water levels over 100 feet in depth, making them suitable for deep excavations. Wellpoint systems consist of multiple wellpoints connected to a common header and pump, allowing them to dewater sites where water needs to be lowered up to 20 feet. The deep well system is best for deep, homogeneous aquifers, while the wellpoint system works well in shallow aquifers requiring less lowering of the water table.
