3. STABILIZATION
Soil stabilization means the improvement of
the stability of the soil by Compaction or
Addition of suitable admixtures(stabilizers).
It increases binding property between soil
particles.
It improves a bearing capacity( power) of the
soil.
7. COMPACTION
Compaction is a densification of soil by mechanical
energy.
It decreases volume of soil by expelling air from
partially saturated or dry soil.
Rapid process
Artificial process
8. To increase the strength of soil
To improve the stability of soil
To reduce soil permeability
To reduce erosion damage
To reduce settlement of soil
9. EFFECT OF COMPACTION ON SOIL PROPERTIES
Bearing capacity increase
Void ratio decrease
Permeability decreases
Strength increases
Settlement reduces
15. SHEEP-FOOT ROLLER
Principal Pressure
Specialization Steel wheels with cylindrical feet ( area 30-80 sq.cm)
Ballast Water / dump sand
Speed 4 to 6 mph
No. of passes 6 to 10 passes for 8-in clay
Pressure Exerted Light – 4 to 7 Kg/cm2 Heavy – 25 to 70 Kg/cm2
• It also aerates soil while compacting, since can be used for soils having
moisture contents more than required.
• Does not compact top layers, therefore finishing should be done with
other type of rollers.
16. FACTORS GOVERNING THE COMPACTION
Gross weight of the roller
Area of each feet
No. of feet
Total no. of feet per drum
Maximum pressure exerted on soil when foot is
vertical
17. ROLLER COMPACTION ESTIMATING
W : Compacted width per roller pass in feet
S : Average roller speed in mph
L : Compacted list thickness in inches
n : No. of roller passes required
20. Principal Pressure & Kneading
Specialization Heavy wagon with several rows of closely spaced tyres
Ballast Steel sections
Speed 6 to 24 mph
No. of passes 8 passes for max density
Pressure Exerted 7 Kg/cm2
PNEUMATIC ROLLERS
• The flexible tyre surface permits efficiency over slightly irregular surfaces
which helps in maintaining uniform density & bearing capacity.
• They are efficient when used to finish off the embankment compacted by
sheep-foot roller.
21. Tyre pressure
Area of contact/tyre size
Inflation pressure ( Pressure variance)
Tyre ply
FACTORS GOVERNING THE COMPACTION
24. VIBRATING ROLLERS
Principal Impact & Vibration
Specialization Vibrating drum converts P.E. to K.E. to pack particles closely
Ballast Provision of eccentric shaft to produce required vibrations
Speed 2 to 4 mph
No. of passes Depends on the working speed
Pressure Exerted Weight of the equipment – 4 to 6 tonnes
• Vibrations normally vary from 1,000 to 5,000 rpm.
• It has two components :
Amplitude – measurement of movement
Frequency – measurement of vibrations per minute
• Amplitude controls the effective area/depth of compaction, while frequency
controls the vibration transmitted in a period of time.
25. Frequency of the blows
Time period
No. of drums provided
Vibratory rollers basically have two types of drums
Single drum roller
Two drum roller
FACTORS GOVERNING THE COMPACTION
28. Principal Pressure
Specialization A large steel drum in front & one/two drums at rear
Ballast Water/wet sand
Speed 3 to 6 km/hr
No. of passes 8 passes for 20 cm layer
Pressure Exerted 10 to 17 Kg/cm2
SMOOTH WHEELED ROLLERS
•When the moisture content is slightly more optimum, it will compact
more easily.
•Steam roller can withstand high wear & tear & it is more easy to
operate but once it started it cannot be cut off for a small break.
29. Load per cm width
Diameter of the roll
FACTORS GOVERNING THE COMPACTION
31. Principal Impact
Specialization A 4-stroke engine, diesel/gasoline operated
Speed 200 cm/s
Pressure exerted 10.5 KN
VIBRATORY PLATES
• These compactors gives efficiency where heavy & large compactors
cannot be operated or cannot be accessed.
• Remote controlled compactors can be operated from a certain distance to
protect worker from unfavorable conditions.
32. Centrifugal force
Exciter revolutions per minute
Depth of vibration penetration
Foot per minute travel
Area of coverage per hour
FACTORS GOVERNING THE COMPACTION
34. Heavy tamping, impact densification.
Suitable on coarse grained soils
Compaction depth : 35 ft
Weight : 6-35 tons
Drop heights : for cranes – 100 ft
DYNAMIC COMPACTION
35. QUESTIONS:
1) List types of Compactors and principal methods of
compaction. Also state suitability of each method with type of
soil. (Winter 2016)- 8 marks
2) What is meant by Soil stabilization ? Explain various soil
properties affecting the selection of compacting equipment.
(Winter 2015)- 6 marks
3) Explain with neat sketch working of Sheep-Footed roller.
Discuss the suitability of sheep footed roller as compacting
equipment. (Winter2015)- 6 marks
4) Explain Vibratory compactor. (Winter 2010)-
5) Discuss the salient features and suitability of
Sheep footed roller
Pneumatic roller (Winter 2010)
