Every computer stores numbers, letters and other specially characters In coded form. There are two types of number system-
Non-Positional Number system
Positional Number System
Introduction to Computing lecture presentation to analyze the number systems handled by digital computing devices to process data, convert decimal to binary, solve Binary Arithmetic, and extend understanding of other number systems (Octal and Hexadecimal).
CONTENTS
INTRODUCTION,
TYPES OF NUMBER SYSTEM,
DECIMAL NUMBER SYSTEM,
BINARY NUMBER SYSTEM,
OCTAL NUMBER SYSTEM,
HEXADECIMAL NUMBER SYSTEM,
CONVERSION METHOD,
• INTRODUCTION:
A set of values used to represent different quantities is known as NUMBER SYSTEM.
For example-
A number can be used to represent the number of student in a class or number of viewers watching a certain TV program etc.
• TYPES OF NUMBER SYSTEM:
Number systems are four types,
1. DECIMAL NUMBER SYSTEM,
2. BINARY NUMBER SYSTEM,
3. OCTAL NUMBER SYSTEM,
4. HEXADECIMAL NUMBER SYSTEM,
DECIMAL NUMBER SYSTEM:
The number system that we used in our day to day life is the decimal number system.
Decimal number system has base 10 as it uses ten digits from 0 to 9.
EXAMPLE-(234)10
BINARY NUMBER SYSTEM:
Binary number system uses two digits 0&1.
Its base is 2.
A combination of binary numbers may be used to represent different quantities like 1001.
Example –
(1001)2,
(100)2,
OCTAL NUMBER SYSTEM:
Octal number system consists of eight digits from 0 to 7.
The base of octal system is 8.
Any digit in this system is always less than 8.
It is shortcut method to represent long binary number.
Example –
(34)8,
(235)8,
• HEXADECIMAL NUMBER SYSTEM:
Hexadecimal number system consist of 16 digits from 0 to 9 and a to f.
Its base is 16.
Each digit of this number system represents a power of 8.
Example-
(6D) 16,
(A3)16,
CONVERSION METHOD:
There are two methods used most frequently to convert a number in a particular base to another base.
Remainder method,
Expansion method,
REMAINDER METHOD:
This method is used to convert a decimal number to its equivalent value in any other base.
The following steps are to be followed by this method:
Divide the number by the base and note the remainder.
Divide the quotient by the base and note the remainder.
Repeat step 2 until the quotient cannot be divided further. That is, the quotient become to smaller than divisor.
The sequence of remainder starting from last generated 1 prefix by undivided quotient is the converted number.
EXPANSION METHOD:
This method can be applied to convert any number in any base to its equivalent in base 10.
During expansion, the base of the number is sequentially raised to start with 0 and is incremented by one for every digit that occurs in the binary number.
THANK YOU!!!!!
