Advanced Networking on GloMoSim

Dr.A.Kathirvel
Professor
Kalasalingam University
Krishnankoil

FDP on Advanced Networking and Cloud
Computing
Simulation of Advanced Networking using
GloMoSim Simulator
Dr.A.Kathirvel
Professor & HOD
Department of Information Technology
09.12.2014 and 10.12.2014

Ad Hoc Networks
(Session – I)

4
Outline
 Introduction
 Ad Hoc Wireless Networks
 Research Issues in MANET
 Ad Hoc Wireless Internet
 Conclusion

Advent of Ad hoc Wireless Networks
 The principle behind ad hoc networking is multi-hop relaying in
which messages are sent from the source to the destination by
relaying through the intermediate hops (nodes).
 In multi-hop wireless networks, communication between two end
nodes is carried out through a number of intermediate nodes whose
function is to relay information from one point to another. A static
string topology is an example of such network:
0 1 2 3 4 5 6 7
 In the last few years, efforts have been
focused on multi-hop "ad hoc" networks, in
which relaying nodes are in general mobile,
and communication needs are primarily
between nodes within the same network.

6
Ad hoc Wireless Networks
 An examples of such developments is the Bluetooth standard that
is one of the first commercial realizations of ad hoc wireless
networking developed by Bluetooth Special Interest Group (SIG):
 A piconet formed by a group of nodes establishes a single-hop
(master node) point-to-point wireless link.
 A scatternet formed by multiple piconets (master nodes) can
establish a multi-hop wireless network.
 Though the IEEE 802.11 protocols have developed for the wireless
networks, they don’t function well in multi-hop networks.
 Realizing the necessity of open standards in this emerging area of
computer communication, the mobile ad hoc networks (MANET)
standards are being developed by the Internet Working Tasking
Force (IETF) MANET working group.

7
Ad hoc Wireless Networks
 Even though ad hoc wireless networks are expected to work in the
absence of any fixed infrastructure, recent advances in wireless
network architectures enable the mobile ad hoc nodes to function
in the presence of infrastructure
 Multi-hop cellular networks (MCNs), self-organizing packet radio
ad hoc networks with overlay (SOPRANO), and mesh networks
are examples of such types of networks.
 Mesh networks serve as access networks that employ multi-hop
wireless forwarding by non-mobile nodes to relay traffic to and
from the wired Internet. In such an environment, hybrid
technologies and/or hierarchical network organization can be used
for ad hoc and infrastructure wireless links.

8
Cellular and Ad Hoc Wireless Networks
 The following figure represents different wireless networks.
 Infrastructure: cellular wireless networks
 Ad hoc: wireless sensor networks
 Hybrid: mesh networks
Cellular Wireless
Networks
Hybrid Wireless
Networks
Wireless Mesh
Networks
Wireless Sensor
Networks

Cellular Vs Ad Hoc Networks
Cellular Networks Ad Hoc Wireless Networks
Fixed infrastructure-based Infrastructureless
Guaranteed bandwidth (designed for
voice traffic)
Shared radio channel (more suitable for
best-effort data traffic)
Centralized routing Distributed routing
Circuit-switched (evolving toward
packet switching)
Packet-switched (evolving toward
emulation of circuit switching)
Seamless connectivity (low call drops
during handoffs)
Frequent path breaks due to mobility
High cost and time of deployment Quick and cost-effective deployment
Reuse of frequency spectrum through
geographical channel reuse
Dynamic frequency reuse based on
carrier sense mechanism
Easier to employ bandwidth reservation Bandwidth reservation requires complex
medium access control protocols

10
Cellular Vs Ad Hoc Networks
Cellular Networks Ad Hoc Wireless Networks
Application domains include mainly
civilian and commercial sectors
Application domains include battlefields,
emergency search and rescue operations,
and collaborative computing
High cost of network maintenance
(backup power source, staffing, etc.)
Self-organization and maintenance
properties are built into the network
Mobile hosts are of relatively low
complexity
Mobile hosts require more intelligence
(should have a transceiver as well as
routing/switching capability)
Major goals of routing and call
admission are to maximize the call
acceptance ratio and minimize the
call drop ratio
Main aim of routing is to find paths with
minimum overhead and also quick
reconfiguration of broken paths
Widely deployed and currently in the
third generation of evolution
Several issues are to be addressed for
successful commercial deployment even
though widespread use exists in defense

11
Applications of Ad hoc Wireless
Networks
 Military applications
 Ad hoc wireless networks is useful in establishing
communication in a battle field.
 Collaborative and Distributed Computing
 A group of people in a conference can share data in ad hoc
networks.
 Streaming of multimedia objects among the participating nodes.
 Emergency Operations
 Ad hoc wireless networks are useful in emergency operations
such as search and rescue, and crowd control.
 A Wireless Mesh Network is a mesh network that is built upon
wireless communications and allows for continuous connections
and reconfiguration around blocked paths by "hopping" from node
to node until a connection can be established.

12
Wireless Mesh Networks
 In a wireless mesh network, multiple nodes cooperate to relay a message to its
destination. The mesh topology enhances the overall reliability of the network,
which is particularly important when operating in harsh industrial environments.

13
 The investment required in wireless mesh networks is much less
than in the cellular network counterparts.
 Such networks are formed by placing wireless replaying equipment
spread across the area to be covered by the network.
 The possible deployment scenarios include:
 Residential zones (where broadband Internet
connectivity is required)
 Highways (where a communication facility for
moving automobiles is required)
 Business zones (where an alternate communication system to
cellular networks is required)
 Important civilian regions (where a high degree of service
availability is required)
 University campuses (where inexpensive campus-wide network
coverage can be provided)

14
 Wireless mesh networks should be capable of self-organization
and maintenance.
 Advantages
 High data rate
 Quick and low cost of deployment
 Enhanced services
 High scalability
 Easy extendability
 High availability
 Low cost per bit
 High availability
 Low cost per bit
 It operates at 2.4 GHz or 5 GHz
 Data rates of 2 Mbps to 60 Mbps can be supported.

15
Wireless Sensor Networks
 Wireless Sensor Networks are a special category of ad hoc
networks that are used to provide a wireless communication
infrastructure among the sensors deployed in a specific application
domain.
 A sensor network is a collection of a large number of sensor nodes
that are deployed in a particular region.
 Distinct properties of wireless sensor networks:
 Mobility of nodes are not needed in all cases in wireless sensor
networks.
 The size of the network is much larger than that in a typical ad
hoc wireless network.
 The density of nodes in a sensor network varies with the domain
of application.
 The power constraints in sensor networks are much more
stringent than those in ad hoc wireless networks.

Wireless Sensor Networks
 Distinct properties of wireless sensor networks:
 The power source can be classified into three categories:
 Replenishable power resource
 Non- Replenishable power source
 Regenerative power source
 Data/information fusion aims at processing the sensed data at
the intermediate nodes and relaying the outcome to the monitor
node.
 The communication traffic pattern varies with the domain of
applications.

17
Hybrid Wireless Networks
 Hybrid Wireless Networks
 Multi-hop cellular networks (MCNs) allows the transmission
through the base stations or multi-hop of mobile nodes.
 Integrated cellular ad hoc relay (iCAR) is a system that
combines conventional cellular technology with Ad hoc Relay
Station (ARS) technology. In this system cellular stations will
relay or reroute calls from the congested cell to an adjacent one
that is not congested.
 Advantages
 Higher capacity than cellular networks
 Increased flexibility and reliability in routing
 Better coverage and connectivity

18
Issues in Ad hoc Wireless Networks
 Medium access scheme
 Distributed operation is required.
 Throughput needs to be maximized.
 Access delay should be minimized.
 Synchronization is required in TDMA-based systems.
 Hidden terminals are nodes hidden from a sender.
 Exposed terminals are exposed nodes preventing a sender from
sending.
 Fairness refers to provide an equal share to all competing nodes.
 Real-time traffic support is required for voice, video, and real-
time data.
 Resource reservation is required for QoS.
 Ability to measure resource availability handles the resources.
 Capability for power control reduces the energy consumption.
 Adaptive rate control refers to the variation in the data bit rate.
 Use of directional antennas has advantages including increased
spectrum reuse, reduced interference, and reduced power
consumption.

 Routing
 Mobility
 Bandwidth constraint
 Minimum route acquisition delay
 Quick route reconfiguration
 Loop-free routing
 Error-prone and shared channel: wireless channel (10-5 to 10-3),
wired channel (10-12 to 10-9)
 Location-dependent contention depends on the number of nodes.
 Other resource constraints such as computing power, battery power
 Distributed routing approach
 Minimum control overhead
 Scalability
 Provisioning of QoS
 Support for time-sensitive traffic: hard real-time and soft real-time
traffic
 Security and privacy

20
 Provisioning of multiple links among the nodes in an ad hoc network
results in a mesh-shaped structure. The mesh-shaped multicast routing
structure work well in a high-mobility environment.
 The issues in multicast routing protocols are:
 Robustness: It must be able to recover and reconfigure quickly.
 Efficiency: It should make a minimum number of transmissions to
deliver a packet.
 Control overhead: It demands minimal control overhead.
 Quality of service: QoS support is essential.
 Efficient group management needs to be performed with minimal
exchange of control messages.
 Scalability: It should be able to scale for a large network.
 Security is important.

21
 The objectives of the transport layer protocols include:
 Setting up and maintaining end-to-end connections
 Reliable end-to-end delivery of data packets
 Flow control
 Congestion control
 Connectionless transport layer protocol (UDP), unaware of high
contention, increases the load in the network.
 Pricing Schemes need to incorporate service compensation.
 Quality of Service Provisioning
 QoS parameters based on different applications
 QoS-aware routing uses QoS parameters to find a path.
 QoS framework is a complete system that aims at providing the
promised services to each users.

22
 Self-Organization is required in ad hoc wireless networks:
 Neighbor discovery
 Topology organization
 Topology reorganization
 Security
 Denial of service
 Resource consumption
 Energy depletion: deplete the battery power of critical nodes
 Buffer overflow: flooding the routing table or consuming the
data packet buffer space
 Host impersonation: A compromised node can act as another
node.
 Information disclosure: a compromised node can act as an
informer.
 Interference: jam wireless communication by creating a wide-
spectrum noise.

23
 Addressing and Service Discovery is essential because of absence
of a centralized coordinator.
 Energy Management
 Transmission power management: The radio frequency (RF)
hardware design should ensure minimum power consumption.
 Battery energy management is aimed at extending the battery
life.
 Processor power management: The CPU can be put into
different power saving modes.
 Devices power management: Intelligent device management
can reduce power consumption of a mobile node.
 Scalability is expected in ad hoc wireless networks.

24
 Deployment considerations
 Low cost of deployment
 Incremental deployment
 Short deployment time
 Reconfigurability
 Scenario of deployment
 Military deployment
 Emergency operations deployment
 Commercial wide-area deployment
 Home network deployment
 Required longevity of network
 Area of coverage
 Service availability
 Operational integration with other infrastructure
 Choice of protocols at different layers should be taken into
consideration.

25
Issues of Ad hoc Wireless Internet
 Gateways
 Gateway nodes are the entry points to the wired Internet and
generally owned and operated by a service provider.
 Perform the following tasks: keeping track of the end users,
band-width fairness, address, and location discovery.
 Address mobility
 Solutions such as Mobile IP can be used.
 Routing
 Specific routing protocols for ad hoc networks are required.
 Transport layer protocol
 Split approaches that use traditional wired TCP for the wired part
and a specialized transport layer protocol for the ad hoc wireless
network part.
 Load balancing
 Load balancing techniques are essential to distribute the load so
as to avoid the situation where the gateway nodes become
bottleneck nodes.

26
Issues of Ad hoc Wireless Internet
 Pricing/billing
 It is important to introduce pricing/billing strategies for the ad hoc
wireless internet.
 Provisioning of security
 It is essential to include security mechanisms
 QoS support
 Voice over IP (VoIP) and multimedia applications require the QoS
support.
 Service, address, and location discovery
 Service discovery refers to the activity of discovering or
identifying the party which provides a particular service or resource.
 Address discovery refers to the services such as address
resolution protocol (ARP) or domain name service (DNS).
 Location discovery refers to different activities such as detecting
the location of a particular mobile node.

Outline
 Introduction to Simulation
 Discrete Event Simulation
 Simulator
 NS - 2
 GloMoSim
 QualNet 5.0
 Conclusion

Introduction to Simulation
 What is simulation?
 A simulation is the imitation of the operation of
a real-world process or system over time.

 System and System Environment
 To model a system, it is necessary to understand the
concept of a system and the system boundary.
 A system is defined as a group of objects that are joined
together in some regular interaction or interdependence
toward the accomplishment of some purpose.
 A system is often affected by changes occurring outside the
system. Such changes are said to occur in the system
environment.
 In modeling a system, it is necessary to decide on the
boundary between the system and its environment.

 Components of a System
 An entity is an object of interest in the system.
 An attribute is a property of an entity.
 An activity represents a time period of specified length.
 The state of a system is defined to be that collection of
variables necessary to describe the system at any time.
 An event is defined as an instantaneous occurrence that
may change the state of the system.
 Discrete System
 A discrete system is one in which the state variables
change only at a discrete set of points in time.

 Model of a System
 A model is a representation of a system for the
purpose of studying the system.
 For most studies, it is enough to consider only those
aspects of the system that affects the problem under
investigation.
 Therefore, in most cases, a model is a simplification
of the system.
 On the other hand, the model should be sufficiently
detailed to permit valid conclusions to be drawn about
the real system.

 Types of Models
 Static/Dynamic
 A static simulation model, sometimes called a Monte Carlo
simulation, represent a system at a particular point in time.
 A dynamic simulation model represents a system as it changes
over time.
 Deterministic/Stochastic
 Simulation models that contain no random variables are
classified as deterministic
 Deterministic models have a known set of inputs that will result
in a unique set of outputs.
 On the other hand, a stochastic simulation model has one or
more random variables as inputs. (e.g., random backoff timers)

 Discrete/Continuous
 Like the definitions for discrete and continuous systems,
discrete and continuous models are defined similarly.
 However, a discrete simulation model is not always used to
model a discrete system, nor is a continuous model always
used to model a continuous system.
 Discrete-Event System Simulation
 Discrete-event system simulation is widely used and is the
focus of this course.
 Discrete-event system simulation is the modeling of the
systems in which the state variables change only at a discrete
set of points in time.

Discrete Event Simulation
 Strategies of discrete event simulation
 Activity-oriented simulation
 Event-oriented simulation
 Process-oriented simulation

 Activity-oriented simulation
 The programmer defines activities which are started when certain
conditions are satisfied.
 In many cases, this type of simulation uses a simulated clock which
advance in constant increments of time.
 With each advance, a list of activities is scanned, and those which
have become eligible are started.
 This type of model is used more often with simulating physical
devices.
 Simulate Network System
 Going to be very slow to execute
 Most time increments will produce no change to the system at all

Event-oriented simulation
 The simulation programmer defines events and
then writes routines which are invoked as each
kind of event occurs
 Simulated time may pass between the events
 Usually, a priority queue will be used

 Process-oriented simulation
 The programmer defines the processes (entities,
transactions, etc.) and the model in terms of interacting
processes.
 A process is an independent program or procedure which
can execute in parallel with other processes.
 The notion of in parallel is used with some liberty
 The processes will use the resources of the system.
 Resource-oriented
 Transaction-oriented
 Time Advance
 Hold
 Send a message to itself in the future

Simulator
 UCLA Parallel Computing Laboratory http://pcl.cs.ucla.edu/
 GloMoSim (Global Mobile system Simulator) is a library-
based simulator for wireless networks.
 It is designed as a set of library modules, each of which
simulates a specific wireless communication protocol in the
protocol stack.
 The communication protocol stack for wireless networks is
divided into a set of layers, each with its own API.
 The library has been developed using PARSEC, a C-based
parallel simulation language
 New protocols and modules can be programmed and
added to the library using PARSEC.

Simulators
 An object-oriented, discrete event network simulator
developed at UC Berkely ( NS-2)
 Mainly used for simulating local and wide area
networks
 It is written in C++ and OTcl (Object-oriented Tcl) and
primarily uses OTcl as command and configuration
language.
 OTcl: Network Topology
 C++: Network Component

Simulators
 Rapid prototyping of protocols
 Comparative performance evaluation of alternative
protocols at each layer
 Built-in measurements on each layer
 Modular, layered stack design
 Standard API for composition of protocols across
 different layers
 Scalability via support for parallel execution
 GUI Tools for system/protocol modeling

GloMoSim – 2.03
(Session – III)

Outline
 Introduction to GloMoSim
 Layers in GloMoSim
 GloMoSim Library
 Installation
 Creating Scenario in GloMoSim-2.03

Introduction to GloMoSim
 Global Mobile Information System Simulator (GloMoSim)
 Scalable simulation environment for large wireless and
wired communication networks
 Parallel discrete-event simulation capability provided by
Parsec
 Design and development of GloMoSim framework with
rich protocol stack
 Demonstrated scalability of GloMoSim using very high
fidelity models

Introduction to GloMoSim
 Demonstated feasibility of real-time simulation of networks
 Direct comparison of alternative unicast and multicast
wireless protocols for GloMosim scenarios
 GloMoSim simulates networks with up to thousand nodes
linked by a heterogeneous communications capability that
includes multicast, asymmetric communications using
direct satellite broadcasts, multi-hop wireless
communications using ad-hoc networking, and traditional
Internet protocols.

Layers in GloMoSim
The layers in GloMoSim are
 Radio (Physical)
 MAC (Data Link Layer)
 Network
 Transport
 Application

GloMoSim Library
 Modular, extensible library for network models
 Model each layer using abstract or detailed model
 Built-in statistics collection at each layer
 Large and growing model library
 Customizable GUI
 Open source

GloMoSim Library
Layers Protocols
Mobility
Random waypoint, Random drunken, Trace
based
Radio Propagation
(Physical)‫‏‬
Two ray and Free space
Radio Model Noise Accumulating
Packet Reception
Models
SNR bounded, BER based with
BPSK/QPSK modulation
Data Link (MAC)‫‏‬ CSMA, IEEE 802.11, TSMA and MACA
Network (Routing)‫‏‬
IP with AODV, Bellman-Ford, DSR,
Fisheye, LAR scheme 1, ODMRP
Transport TCP and UDP
Application CBR, FTP, HTTP and Telnet

Installations
 It support heterogeneous environment
 Software works on different OS such as AIX,
FreeBSD, IRIS, Redhat, Federo Linux, Sun
Solaris, Windows 2000, Windows XP, Windows
95, latest version ..

Installation in Windows
 Step 1 : Pre-requisition for GloMoSim
Java 2 (later version)
Visual C++ ( Visual Studio 6 )
 Step 2 : Setting up Environment variables
 Step 3 : Extracting GloMoSim software in c directory
 Step 4 : Run makent.exe file

Setting Environment Variables
 My Computer  Properties  Advanced 
Environment Variables
 Environment variables
 path , lib , include , PCC_DIRECTORY
 Path =C:glomosim-2.03parsecinclude;
C:glomosim-2.03parsecbin;
C:glomosim-2.03glomosimbin;

Setting Environment Variables
 Lib = c:glomosim-2.03parseclib
 INCLUDE = c:glomosim-2.03parsecinclude
C:glomosim-2.03glomosiminclude
 PCC_DIRECTORY = C:glomosim-2.03parsec

Installation in Unix
 Step 1 : Pre-requisition for GloMoSim
Linux version of Java 2 (later version)
GCC version 4.1.2 or later
 Step 2 : Customise the Environment variables
 Step 3 : Extracting GloMoSim software in root
directory
 Step 4 : Run make file

User Specific Environment
 SU mode
 .bash_profile
 path , PCC_DIRECTORY
 PATH=PATH:HOME/bin:/glomosim-
2.03/glomosim/main:/glomosim-
2.03/glomosim/include:/glomosim-
2.03/glomosim/bin:/glomosim-
2.03/parsec/bin:/glomosim-2.03/parsec/include

User Specific Environment
 PCC_DIRECTORY=/glomosim-2.03/parsec
 export PATH PCC_DIRECTORY

Extracting the software
To ucompress the GloMoSim software archive
# tar xvfz glomosim-2.03.tar.gz

Installation
 If you are run this tool in fedora Linux, copy all
files inside the redhat-7.2 directory, paste it in
/parsec directory.
 # cd /glomosim-2.03/glomosim/main
 Make clean
 Make

Creating Scenario in GloMoSim-2.03
(Session – IV)

Outline
 Introduction
 Input/Output files
 Understanding Files/Directories
 Design a wired Network
 Design a wireless Network
 Understanding Transmission range
 Discussion

Introduction to scenarios
 In GloMoSim, a specific network topology is
referred to as a scenario.
 scenario allows the user to specify all the
network components and conditions under
which the network will operate.
 Terrain details, channel propagation effects
including path loss, wired and wireless subnets,
network devices, the entire protocol stack of a
variety of standard, and applications running on
the network.

Input Files
 3 input files
 Scenario Configuration file
 This is the primary input file for GloMoSim and
specifies the network scenario andparameters for the
simulation. This file usually the extension “.in”.
 Node placement file
 This file is referenced by the scenario configuration file
and specifies the initial position of nodes in the
scenario. This file usually has the extension “.input”.
 Application configuration file
 This file is referenced by the scenario configuration file
and specifies the applications running on the nodes in
the scenario. This file usually has the extension “.conf”.

Output File
 GloMoSim Statistics file
 The primary output file generated by a GloMo
simulation run is a statistics file, which has the
extension “.stat”. This file contains the statistics
collected during the simulation run. Other output files
that may be generated by GloMoSim include the trace
file (which has the extension “.trace”) which records
packet traces.
 Configuration files located in bin/ directory :
-IN : app.conf : Application execution options
-IN : config.in : Simulation configuration options
-OUT : glomo.stat : Simulation results

GloMoSim Sub-Directories
 Main, Include, Bin, Doc, TCPLib, Java_gui
 Application
 Transport
 Network
 Mac
 Radio
 Scenarios

GloMoSim Files
 File Extensions:
 .pc – C source code
 .h - C header files
 .pi – Message file created and maintained
internally by Parsec (don’t edit)

Design a Network using GloMoSim

Wired Networks
 In this exercise, you will build and configure a simple
wired network of four nodes connected with point-to-
point links shown in the following figure.
 By reducing the transmission rate of a link to create a
"bottleneck", you will find how applications overwhelm
the link and cause significant packet loss.

Normal situation
( PDR = 100 % )

Solution
 Step 1: Node placement
 Step 2: Wired link definition
 Step 3: Creation of routing table
 Step 4: Application selection
 Step 5: Configuration
 Step 6: Execution & Analysis the Results

Scenario Topology
 The topology of a network is defined by the number
and location of network devices and the physical and
logical connections between them.
 NODE-PLACEMENT-FILE
 Format:
 nodeAddr 0 (x, y, z)
 The second parameter is for the consistency with the
mobility trace format.
 0 0 (250, 250, 0)
 1 0 (500, 250, 0)
 2 0 (375, 500, 0)
 3 0 (375, 750, 0)

wired link definition
 Each link is bidirectional, and the bandwidth is
specified in bits per second.
 Format:
 nodeAddr1 nodeAddr2 bandwidth1 propDelay1
0-----|
|______
|2 3
1-----|
0 2 10000000 1MS
1 2 10000000 1MS
2 3 10000000 1MS

Routing Table (static)
 Format: sourceAddr destAddr nextHop
0-----|
|______
|2 3
1-----|
 0 1 2 0 2 2 0 3 2
 1 0 2 1 2 2 1 3 2
 2 0 0 2 1 1 2 2 0
 2 3 3 3 0 2 3 1 2
 3 2 2

Application Layer
 The traffic generators currently available are FTP,
FTP/GENERIC, TELNET, CBR, and HTTP.
 FTP <src> <dest> <items to send> <start time>
 FTP/GENERIC <src> <dest> <items to send> <item size>
<start time> <end time>
 TELNET <src> dest> <session duration> <start time>
 CBR <src> <dest> <items to send> <item size> <interval>
<start time> <end time>
 Client: HTTP <address> <num_of_server> <server_1> ...
<server_n> <start> <thresh>
 Server: HTTPD <address>
 CBR 0 3 75 512 1MS 0S 30S
 CBR 1 3 75 512 1MS 0S 30S

Configure the wired Network
 SIMULATION-TIME 100S
 SEED 2
 TERRAIN-DIMENSIONS (1000, 1000)
 NUMBER-OF-NODES 4
 NODE-PLACEMENT FILE
 NODE-PLACEMENT-FILE ./wired_nodes.input
 MOBILITY NONE
 PROPAGATION-LIMIT -111.0
 PROPAGATION-PATHLOSS FREE-SPACE
 RADIO-TYPE RADIO-NONOISE
 RADIO-BANDWIDTH 2000000
 MAC-PROTOCOL WIRED
 WIRED-LINK-FILE wired.conf

Configure the wired Network
 NETWORK-PROTOCOL IP
 NETWORK-OUTPUT-QUEUE-SIZE-PER-PRIORITY 100
 ROUTING-PROTOCOL STATIC
 STATIC-ROUTE-FILE wired_route.in
 APP-CONFIG-FILE ./wired_app.conf
 APPLICATION-STATISTICS YES
 TCP-STATISTICS NO
 UDP-STATISTICS NO
 ROUTING-STATISTICS NO
 NETWORK-LAYER-STATISTICS NO
 MAC-LAYER-STATISTICS NO
 RADIO-LAYER-STATISTICS NO
 CHANNEL-LAYER-STATISTICS NO
 MOBILITY-STATISTICS NO

Output
Node: 0, Layer: AppCbrClient, (0) Server address: 3
Node: 0, Layer: AppCbrClient, (0) Session status: Closed
Node: 0, Layer: AppCbrClient, (0) Total number of packets sent: 75
Node: 3, Layer: AppCbrServer, (0) Client address: 1
Node: 3, Layer: AppCbrServer, (0) Average end-to-end delay [s]: 0.003365200
Node: 3, Layer: AppCbrServer, (0) Session status: Closed
Node: 3, Layer: AppCbrServer, (0) Total number of packets received: 75
Node: 3, Layer: AppCbrServer, (0) Session status: Closed

Data Packet Dropping Situations

wired link definition
 Each link is bidirectional, and the bandwidth is
specified in bits per second.
 Format:
 nodeAddr1 nodeAddr2 bandwidth1 propDelay1
0-----|
|______
|2 3
1-----|
0 2 10000000 1MS
1 2 10000000 1MS
2 3 1000000 1MS

Output
Node: 3, Layer: AppCbrServer, (0) Session status: Not closed
Node: 3, Layer: AppCbrServer, (0) Session status: Not closed

Solution
 Step 1: Node placement
 Step 2: Application selection
 Step 3: Configuration
 Step 4: Execution & Analysis the Results

Application Layer
 CBR 0 3 75 512 1NS 10S 30S
 CBR 1 3 75 512 1NS 40S 60S

Configure the wireless Network
 SIMULATION-TIME 100S
 SEED 1
 TERRAIN-DIMENSIONS (1000, 1000)
 NUMBER-OF-NODES 4
 NODE-PLACEMENT FILE
 NODE-PLACEMENT-FILE ./wireless_nodes.input
 MOBILITY NONE
 PROPAGATION-LIMIT -111.0
 PROPAGATION-PATHLOSS TWO-RAY
 NOISE-FIGURE 10.0
 TEMPARATURE 290.0

 RADIO-TYPE RADIO-ACCNOISE
 RADIO-FREQUENCY 2.4e9
 RADIO-BANDWIDTH 2000000
 RADIO-TX-POWER 15.0
 RADIO-ANTENNA-GAIN 0.0
 RADIO-RX-SENSITIVITY -91.0
 RADIO-RX-THRESHOLD -81.0
 MAC-PROTOCOL 802.11
 ROUTING-PROTOCOL BELLMANFORD

 NETWORK-PROTOCOL IP
 NETWORK-OUTPUT-QUEUE-SIZE-PER-PRIORITY 100
 APP-CONFIG-FILE ./wireless_app.conf
 APPLICATION-STATISTICS YES
 TCP-STATISTICS NO
 UDP-STATISTICS NO
 ROUTING-STATISTICS NO
 NETWORK-LAYER-STATISTICS NO
 MAC-LAYER-STATISTICS NO
 RADIO-LAYER-STATISTICS NO
 CHANNEL-LAYER-STATISTICS NO
 MOBILITY-STATISTICS NO

Output

Application Layer
CBR 0 3 75 512 1MS 0S 0S
CBR 1 3 75 512 1MS 0S 0S

Output

Advanced Network Simulation using
GloMoSim-2.03
(Session – V)

Outline
 Manet routing protocols
 Multicast routing protocols
 Experimental setup for MANET
 Discussion

Dynamic Source Routing
 This protocol uses the route cache that stores all possible info. Extracted
from source route contained in data packet
 if an intermediate node receiving a RREQ has a route to the destination
in its route cache it sends RREP with a complete route from S to D
Optimizations:
1. Route Cache
This cache information is used by intermediate nodes to reply to the S
node when they receive a RREQ and if they have a route to the
corresponding D
2. Promiscuous mode
By operating in this mode, an intermediate node learns abt the path
breaks. Info. Gained is used to update the route cache so that the active
routes maintained in route cache don’t use such links
3. During networks partition
The affected nodes initiate RREQ packets an exponential backoff algo. Is
used to avoid frequent RREQ flooding in the network when the D is in
another dispoint set.

DSR
Route maintenance
when an intermediate node moves away causing a wireless link to
break. For ex. If the link between node 5 & 7 fails, a route error msg is
generated by a node adjacent to path break to inform the source node.
The source node reinitiates the route establishment procedure. The
cached entries at the intermediate node and S node are removed when
the route error packet is received.
Advantages
 it eliminates periodical table update msg
 intermediate nodes utilize the route cache info efficiently to reduce the
ctrl overhead
Disadvantages
 route setup delay is more
 route maintenance mech doesn’t efficiently repair the path break
efficiently
 the performance of this protocol degrades rapidly with increasing
mobility

Adhoc Ondemand Distance Vector RP
 AODV uses ondemand approach, ie a route is established only when it is required
by a S node for transmitting data packet
 it differs from DSR from the fact that DSR uses source routing in which a data
packet carries complete path to the D
 in AODV, the S node and intermediate nodes stores the next hop info
corresponding to each flow for packet txn
 uses dest. Seqno to determine an up-to-date path to the D
 a node updates its path info only if the destseqno of the current packet received is
greater than the last destseqnum stored at the node
 a RREQ carries SID,DID,S-seqno,D-seqno,BcastID and TTL
 source 1 initiates the RREQ to be flooded in the nxw for D 15
Assuming that the Dseqno as 3 and Sseqno as 1. When the nodes 2,5 & 6 receive
the RREQ, they check their route to the D. In case a route to the D is not avail they
fwd it to their neighbors. Here nodes 3, 4 and 10 are neighbors of nodes 2,5 and 6.
This is with the assumption that the nodes 3 & 10 have routes to the D node 15
that is thro paths 10-14-15 & 3-7-9-13-15 resp.

AODV
If the Dseqno at node 10 is 4 and is 1 at intermediate node 3 then only
node 10 is allowed to reply along the cached route to S. when a path
breaks for ex bet nodes 4 and 5, both nodes initiates RERR msg to
inform their end nodes abt the link breaks
the end nodes deletes the corresponding entries from their tables. The
source node reinitiates the path finding process with the new BcastID
and the previous Dseqno
Advantages
 routes are estab. On demand and Dseqno are used to identify the latest
path
 route set up delay is less
disadvantages
 Multiple RREP in response to a RREQ packet can lead to a heavy ctrl
overhead
 periodic beaconing leads to unnecessary BW consumption

Zone Routing Protocol
 Hybird rp which effectively combines the adv of both proactive and reactive
 proactive - Intra zone RP(IARP)- for nodes within a particular zone
 Reactive - Inter zone RP(IERP) - for nodes beyond this zone
 the routing zone of a given node is a subset of the n/w within which all nodes
are reachable within less than or equal to zone radius hops
 within routing zone each node maintains the info abt the routes to all nodes by
exchanging periodic route update packets
 IERP is responsible for finding paths to nodes which are not within the routing
zone
when a node S(8) has packet to be sent to node D(16) it
checks whether D is within its zone. If the dest. Belongs its
own zone then it delivers the pack directly. Otherwise node
S bordercast(uses unicast routing to deliver pack directly to
the border nodes) the RREQ to its peripheral
nodes(2,3,5,19,14,15). If any peripheral finds a path to
node D then it sends RREP otherwise it rebordercast the
RREQ. This process continues until D is located. Nodes 10
and 14 find the info abt 16 therefore they send RREP pack
back to node 8. When an intermediate node in an active
path detects a broken link in the path it performs a local
path reconfig. In which broken link is bypassed by means
of a shorter alternate path

ZRP
 Advantages
 reduces ctrl overhead compared to the RREQ
flooding mechanism employed in on-demand
approaches and the periodic flooding of routing
info in table driven approaches
 disadvantages
 the decisions on the zone radius has a significant
impact on the performance of the protocol

On-Demand Multicast RP (ODMRP)
 In ODMRP a mesh is format by a set of nodes called forwarding nodes which are
responsible for forwarding data packets between a some-receiver pair. These
forwarding nodes maintain the message cache which is used to detect duplicate
data packets and duplicate join Req control packets
 Mesh initialization phase
 To create a mesh each same in the multicast group floods the joinReq control
packets periodically. Upon reception of the joinReq control packet from a source
potential receivers can send joinReply through the reverse shortest path. The route
between a source and receiver is established after the source receives the
joinReply packet. The join Reply packet contains the same ID and the
corresponding next node ID.
 Mesh maintenance phase
 In this phase attempts are made to maintain the multicast mesh topology formed
with sources forwarding nodes and receivers. For example due to movement of the
receiver R3 (from A to B) when the route S2-I9-I10-R3 breaks R3 can still receive
data packets through route S2-I6-I4-I7-I8-R3. When receiver R3 receives new
joinReq control packet from node I11, it sends a join Reply on this new shortest
path R3-I11-I10-I9-S2 there by maintaining the much structure.
 Advantages : Robust
 Disadvantages: 1. High control overhead
 2. Multicast efficiency is reduced

Wireless Mobile Ad Hoc Networks

Advanced Networking on GloMoSim

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Viewers also liked

Viewers also liked (14)

Similar to Advanced Networking on GloMoSim

Similar to Advanced Networking on GloMoSim (20)

More from Kathirvel Ayyaswamy

More from Kathirvel Ayyaswamy (20)

Recently uploaded

Recently uploaded (20)

Advanced Networking on GloMoSim
