This document outlines guidelines for subsurface exploration for earth and rockfill dams. It recommends conducting exploration in multiple stages - reconnaissance, preliminary, and detailed pre-construction investigations. The preliminary stage involves initial testing to evaluate feasibility, while the detailed stage involves intensive exploration to define subsurface conditions for design. Exploration methods include test pits, trenches, drilling, geophysics, and hydrological and material testing. The extent of exploration depends on dam size and complexity, with greater coverage for taller dams. Exploration should characterize foundation soils and rock to sufficient depth for design.
