Here are the key changes to the noise analysis of the common source amplifier example if:
1) Transistor is in triode region:
- gm would be a function of VGS and VDS instead of a constant
- inMOS would depend on gm as a function of voltages
2) Include flicker noise:
- Add a flicker noise current source inMOS,f
- PSD of inMOS,f is Kf/f instead of constant
- Integrate PSD from fmin to fmax
3) Replace RL with PMOS load:
- Replace RL with the output resistance ro of the PMOS load transistor
- Add thermal noise current source of the PMOS load transistor
