Traffic Forecasting (Transportation Engineering)
- 2. CEE320 Winter2006 Outline 1. Need for Traffic Forecasting 2. Traveler Decisions 3. Trip Generation 4. Mode Choice a. Survey
- 3. CEE320 Winter2006 Need for Traffic Forecasting • Impacts of facilities or modes of travel – Lines on existing roads – Roads – Light rail – Bus service • Geometric design • Pavement design
- 4. CEE320 Winter2006 Traveler Decisions • Types of decisions – Time (when do you go?) – Destination (where do you go?) – Mode (how do you get there?) – Route choice (what route do you choose?) • Influences – Economic – Social
- 5. CEE320 Winter2006 Predicting Travel Decisions • Collect data on travel behavior – Observation (number of buses, cars, bikes, etc.) – Surveys • Collect data on what travelers have done • Collect data on their values and choices (utility) • Inexact nature of prediction – Incomplete data – Reporting problems
- 6. CEE320 Winter2006 Trip Generation & Mode Choice
- 7. CEE320 Winter2006 Trip Generation • Purpose – Predict how many trips will be made – Predict exactly when a trip will be made • Approach – Aggregate decision-making units – Categorized trip types – Aggregate trip times (e.g., AM, PM, rush hour) – Generate Model
- 8. CEE320 Winter2006 Motivations for Making Trips • Lifestyle – Residential choice – Work choice – Recreational choice – Kids, marriage – Money • Life stage • Technology
- 9. CEE320 Winter2006 Reporting of Trips - Issues • Under-reporting trivial trips • Trip chaining • Other reasons (passenger in a car for example)
- 10. CEE320 Winter2006 Trip Generation Models • Linear (simple) • Poisson (a bit better) nn xxxT ββββ ...22110 +++= nni xxx ββββλ ...ln 22110 +++= ( ) ( ) = − ! tripsofnumber x x exP λλ
- 11. CEE320 Winter2006 Example kidsmarriedinternetagegender autosbus bicyclesedanvansportssuv incomeeducationi * 8 * 7 * 6 *5*4 *#37*36 *35*34*33*32*31 *2*10ln βββββ ββ βββββ βββλ +++++ ++ +++++ ++= Recreational or pleasure trips measured by λi (Poisson model):
- 12. Variable Coefficient Value Product Constant 0 1 0 Education (undergraduate degree or higher) 0.15 1 0.15 Income 0.00002 45,000 0.9 Whether or not individual owns an SUV 0.1 1 0.1 Whether or not individual owns a sports car 0.05 0 0 Whether or not individual owns a van 0.1 1 0.1 Whether or not individual owns a sedan 0.08 0 0 Whether or not individual uses a bicycle to work 0.02 0 0 Whether or not individual uses the bus to work all the time -0.12 0 0 Number of autos owned in the last ten years 0.06 6 0.36 Gender (female) -0.15 0 0 Age -0.025 40 -1 Internet connection at home -0.06 1 -0.06 Married -0.12 1 -0.12 Number of kids 0.03 2 0.06 Sum = 0.49 λi = 1.632 trips/day
- 13. CEE320 Winter2006 Example • Probability of exactly “n” trips using the Poisson model: • Cumulative probability – Probability of one trip or less: P(0) + P(1) = 0.52 – Probability of at least two trips: 1 – (P(0) + P(1)) = 0.48 • Confidence level – We are 52% confident that no more than one recreational or pleasure trip will be made by the average individual in a day ( ) ( ) 20.0 !0 0632.1 0 632.1 = = − eP ( ) ( ) 32.0 !1 1632.1 1 632.1 = = − eP
- 14. CEE320 Winter2006 Mode Choice • Purpose – Predict the mode of travel for each trip • Approach – Categorized modes (SOV, HOV, bus, bike, etc.) – Generate Model
- 15. CEE320 Winter2006 A Mode Choice Model • Logit Model • Final form mk n kmnmnmk zV εβ += ∑ ∑ = s U U mk sk mk e e P Specifiable part Unspecifiable part ∑= n kmnmnmk zU β s = all available alternatives m = alternative being considered n = traveler characteristic k = traveler
- 16. CEE320 Winter2006 Discrete Choice Example Regarding the TV sitcom Gilligan’s Island, whom do you prefer?
- 17. CEE320 Winter2006 Ginger Model UGinger = 0.0699728 – 0.82331(carg) + 0.90671(mang) + 0.64341(pierceg) – 1.08095(genxg) carg = Number of working vehicles in household mang = Male indicator (1 if male, 0 if female) pierceg = Pierce Brosnan indicator for question #11 (1 if Brosnan chosen, 0 if not) genxg = generation X indicator (1 if respondent is part of generation X, 0 if not)
- 18. CEE320 Winter2006 Mary Anne Model UMary Anne = 1.83275 – 0.11039(privatem) – 0.0483453(agem) – 0.85400(sinm) – 0.16781(housem) + 0.67812(seanm) + 0.64508(collegem) – 0.71374(llm) + 0.65457(boomm) privatem = number of years spent in a private school (K – 12) agem = age in years sinm = single marital status indicator (1 if single, 0 if not) housem = number of people in household seanm = Sean Connery indicator for question #11 (1 if Connery chosen, 0 if not) collegem = college education indicator (1 if college degree, 0 if not) llm = long & luxurious hair indicator for question #7 (1 if long, 0 if not) boomm = baby boom indicator (1 if respondent is a baby boomer, 0 if not)
- 19. CEE320 Winter2006 No Preference Model Uno preference = – 9.02430x10-6(incn) – 0.53362(gunsn) + 1.13655(nojames) + 0.66619(cafn) + 0.96145(ohairn) incn = household income gunsn = gun ownership indicator (1 if any guns owned, 0 if no guns owned) nojames = No preference indicator for question #11 (1 if no preference, 0 if preference for a particular Bond) cafn = Caffeinated drink indicator for question #5 (1 if tea/coffee/soft drink, 0 if any other) ohairn = Other hair style indicator for question #7 (1 if other style indicated, 0 if any style indicated)
- 20. CEE320 Winter2006 Results 10. Regarding the TV sitcom “Gilligan’s Island” whom do your prefer? 29 90 85 30 88 89 7 112 87 0 20 40 60 80 100 120 Ginger Mary Ann No Preference #ofRespondants Survey average Model Average probabilities of selection for each choice are shown in yellow. These average percentages were converted to a hypothetical number of respondents out of a total of 207.
- 21. CEE320 Winter2006 My Results ∑ = s U U mk sk mk e e P 8201.13265.02636.01075.1 =++= −−− ∑ eeee s Usk 1815.0 8201.1 1075.1 === − ∑ e e e P s U U ginger sk mk 4221.0 8201.1 2636.0 === − ∑ e e e P s U U annemary sk mk 3964.0 8201.1 3265.0 === − ∑ e e e P s U U preferenceno sk mk Uginger = – 1.1075 Umary anne = – 0.2636 Uno preference = – 0.3265
- 22. CEE320 Winter2006 Primary References • Mannering, F.L.; Kilareski, W.P. and Washburn, S.S. (2005). Principles of Highway Engineering and Traffic Analysis, Third Edition. Chapter 8 • Transportation Research Board. (2000). Highway Capacity Manual 2000. National Research Council, Washington, D.C.
Editor's Notes
- Saigon
- Poisson gives the average number of daily trips but can also calculate the probability of making X number of trips in a day.
- ln(λ) = 0.49
- Betas are estimated using maximum likelihood
